eBusiness Suite on Linux RAC Platform Transition through Upgrade

1
e-Business Suite on Linux RAC (Platform
Transition through Upgrade)
Chakri Reddy Director of Delivery Zensar
Technologies San Jose, CA.
Ram Laxmanan Director, PMO Office Zensar
Technologies San Jose, CA.
March 2005
2
Agenda

• Who we are
• Description of project Goals
• Hardware Architecture Scaling Plan
• 11i Linux / RAC Architecture
• Upgrade Process Overview
• Upgrade Takeaways
• Infrastructure Issues
• Global Team Tactics
• Questions Answers

3
Who we are

• Zensar Technologies (www.zensar.com)
• Global information technology organization
• Decade of experience of providing IT and IT
  enabled service
• Gained over 7500 person years of experience and
  executed over 1250 engagements
• Leading software exporter in India, over 2000
  skilled resources across six delivery centers
• 23 offices worldwide
• Zensars established Oracle Applications Practice
• Enterprise Applications Group (EAG) is a focus
  area in packaged solutions
• Dedicated Oracle competency center, with over 600
  skilled resources
• Engagements include implementations, upgrades,
  customizations, 3rd party integration and
  on-going support
• Customers include Cisco, Logitech, Fujitsu,
  Fluke, PO Ned Lloyd and Sprint

4
About Electronic Arts, our customer

• The 1 video game publisher in the US
• Over a hundred popular titles such as NBA Street,
  Madden NFL 2004, SimCity 4, Need for Speed, and
  Medal of Honor.
• Has also published extremely successful games
  based on Hollywood franchises, including The Lord
  of the Rings, Harry Potter and James Bond
• Total revenue for year 2003-04 3 billion
• Has offices throughout the Asia-pacific, Europe
  and North America EU territories contributed to
  over 1 billion of revenue last year

5
Project Goals (Business)

• Move all business applications from RISC platform
  to Linux
• Plan for future growth and scalability
• Cost savings in terms of licensing and hardware
• Rapid deployment
• Save s
• OM BPR
• Review and update customisations

6
Project Goals (Technical)

• Standardize the installation of Oracle
  Applications 11.5.9 across 4 global installations
  in Electronic Arts
• Upgrade to Oracle 11.5.9 e-business suite of
  products
• Transition to e-business suite running on Linux
  RAC
• Along with the upgrade
• Produce a common and extensible hardware
  environment
• That meets EAs user and performance criteria,
  currently and into the future
• Introduce a hardware and software architecture
  that would permit both scaling of capacity and
  continuous operations
• The upgrade and platform transition, including
  user testing must be accomplished inside of 130
  hours

7
Fact sheet

• Organizations, 1 in US, 21 in EU
• Languages, 1 in US, 4 in EU
• Database size, 200Gb in US, 350 in EU
• Users, 175 in US, 350 in EU
• Transaction volumes
• 9000 order lines booked per day
• 30000 picking line details per day
• 10000 concurrent requests per day
• Boundary systems, 15 in US, 25 in EU
• Customizations, 1000 each in US and EU
• Dual on-shore / off-shore delivery model

8
Hardware Architecture Scaling Plan

• Dell was selected as the vendor of choice at EA
  for world wide deployment of Oracle 11.5.9
• RedHat 2.1 was the operating system at all tiers
  of the architecture
• Multi-node Multi-tier
• Combination of both local storage and SAN storage

• Intelligently deployed to get the highest
  performance and greatest economy from Oracle
  Applications
• Hardware load balanced Oracle Applications
  servers
• Easily configured and robustly implemented.
• Dual concurrent process servers
• Assuring rapid process completion
• Confident continuous operations, deployed with
  PCP (parallel concurrent processing)
• Dual RAC nodes

9
11i Linux / RAC Architecture
10
11i Linux / RAC Architecture
Load Balancer
RAC
Database Datafiles
11
Upgrade Process - Overview

• Source
• Oracle Applications Release 11.03 with 8i DB
  running on HPUX
• Single Node Configuration
• 8 Processors at 575 MHz Speed
• Target
• Oracle e-Business Suite Release 11.5.9
• 2 Application Servers (H/W Load Balance)
• 2 Concurrent Manager Servers with PCP
  Configuration
• 2 RAC Load Balanced DB Nodes
• Upgrade Starts With
• Single Node RISC Server Running 11.03
• One Intel Linux Application Server
• One Linux CM Server
• One Linux DB Server

12
Upgrade Process - Overview
13
Upgrade Process - Overview
Cat 1-3
Auto Upgrade
Auto Patch
11.5.9 CM2
Cat 4-6
Export Import
Index Build
RAC (DB2) App2 CM2
Oracle Apps 11i Linux Apps/CM, HP DB
Export Import
HP Server Single-node
Linux 11.5.9
Linux 11.5.9
14
Upgrade Process - Overview

• Customized Oracle Upgrade Approach
• Heterogeneous upgrade approach
• Admin node running on Linux and DB node running
  on RISC server
• Pre upgrade steps
• Rapid install (Linux application server CM
  server)
• 9i DB Installation (Linux DB server)
• Category 1, 2 and 3 steps
• Perform all relevant category steps on RISC
  server running 11.03
• Gather schema statistics (30)
• Backup applications
• Auto Upgrade
• Admin node running on Linux and DB node running
  on RISC server
• Batch size of 10000 max workers of 20
• Backup applications
• Auto Patch
• Gather schema statistics (30)
• Backup applications

15
Upgrade Process - Overview

• Customized Oracle Upgrade Approach
• Patch the applications
• Apply consolidated update patch 2
• Apply one off patches
• Category 4, 5 and 6 steps
• Perform all relevant category steps
• Apply customizations (if any)
• Apply conversions (if any)
• e-Business suite functioning with
• Linux application server
• Linux CM server
• RISC DB server

16
Upgrade Process - Overview

• Customized Oracle Upgrade Approach
• Export source DB
• Apply applications consolidated export import
  patch (2981815 ) for 9i on SOURCE admin node.
• Direct path full DB export
• Import DB
• Apply patch 2873456
• Point your APPL_TOP to the 9i DB
• Full system import or
• Two phased import process where structure is
  imported first and data is subsequently imported.
• Index builds are always last with either of the
  import choice
• Post import activities
• Gather schema statistics
• Modify TNS names on Admin and CM nodes to point
  to 9i DB

17
Upgrade Process - Overview

• Customized Oracle Upgrade Approach
• Converting to RAC DB
• Modify ORACM configuration file
• Follow Metalink documentation
• Adding Second Application Server
• Change the application server name to load
  balancer
• Review H/W load balancer setup
• TAR and UNTAR the APPL_TOP onto second node
• Adding Second CM Server
• Create second CM node by cloning from first CM
• Setup Internal Monitor (ICM)
• Define Primary Secondary nodes for all
  Concurrent Managers
• Define the transaction managers for all the
  instances in RAC cluster

18
Upgrade Takeaways

• Total Production downtime of 98 hours
• Perform as many iterations as possible
• 12 practice iterations were performed
• Impact of hardware
• Import process needs lot of attention
• Impact of Orgs and Languages
• Be generous with your instance planning you
  will need them!
• Refine backup methodology, to provide total
  database backups as rapidly as technically
  achievable
• Perform Validate APPS Schema script on production
  regularly and fix the issues
• Make time for high quality testing of both
  standard and custom Oracle Applications code
• 20 One off patches applied on consolidated patch
  2
• Perform load test and regression testing

The Upgrade Category 0
The Upgrade Category 0
19
Infrastructure Issues

• Instance Planning
• Differences from Traditional Unix to Linux
  platforms
• Impact of server numbers
• Dont forget the disk space!
• Important considerations
• Data Archiving
• Getting it all to work! e.g. load balancing, DNS
  etc.
• Log/out files, UTL, FTP
• Individual server memory footprint

20
Global Team Tactics

• Global Project technical, functional and support
  teams
• Managing communication
• Coping with time zones
• Make it work to your advantage
• Sharing of knowledge
• Client/Vendor sharing
• Examples of success

21
Agenda Revisited

• Who we are
• Description of the Goals
• Hardware Architecture Scaling Plan
• 11i Linux / RAC Architecture
• Upgrade Process Overview
• Upgrade Takeaways
• Infrastructure Issues
• Global Team Tactics
• Questions Answers

22
QA

• Questions?
• Zensar Technologies
• Chakri Reddy
• chakri_at_usa.zensar.com
• Ram Laxmanan
• r.laxmanan_at_usa.zensar.com
