Comfort II

1
Comfort II

• Product Training

Revised February 2009
2
Objectives

• Learn Comfort, benefits/features
• Learn to design Comfort system to suit customers
  requirements
• Learn how to install, connect Comfort and
  peripherals
• Learn how to program, test and commission Comfort

3
Equipment

• Training Rig with
• Comfort CP9000 Controller
• KP04 LCD keypad
• DP03 Door Station Ringer
• UCM05
• LEM01-M2
• SEM01 Slave Expansion Module
• RC01
• Optional (Trainer Kit)
• SCS
• UCM/GSM
• UCM/Cbus
• CWM

4
Handouts

• Comfort Resources (Transfer via USB Drive)
• Cytech Movie 2008 on DVD

5
Agenda

• Part I - Product Training
• Comfort Demo Movie
• Introduction to Cytech
• Product Introduction and Demo
• Key Features
• Configuration and Modules
• Part II Technical Training
• Connections and Layout
• Programming
• Hands-on Programming Exercise
• Testing and Commissioning
• Questions

6
About Cytech

• Established in 1995
• Comfort I without keypad produced in 1996,
  telephone operated system
• Keypad KP01 in 1999
• Sold in more than 20 countries
• Cytech supplies through distributors and system
  integrators, does not install or sell to end
  users.
• Cytech Europe UK Master distributor
• Staff of 10 (2008) mainly in RD and support.
  Manufacturing is subcontracted to contract
  manufacturers

7
Introduction
8
What is Comfort?

• An Intelligent Home System with
• Intruder Alarm System
• burglary and fire
• Digital answering machine
• Home automation system
• Controls lighting, HVAC and other home appliances
• Telephone Voice Menu
• Intercom Door Station and Keypads
• Reminder messages
• Time Programs/ Scheduling

9
Comfort Demonstration

• Demonstration of Comfort using Training Rig (with
  GSM),
• Security arming, disarming, alarm dialout to
  phone/GSM
• Home control Lighting and air conditioner
• Door station intercom with keypad
• RC01 remote control operation
• SCS06 operation
• SMS Control

10
Key Features

• Security System
• Home Automation
• Voicemail
• Intercom
• Time Programs
• Integration
• Logic Engine
• NOT a plug and play system requires integration

11
Security System
EN50131/PD6662 compliant (self declaration) Not
necessary unless police response is required
12
Security Modes

• 5 Modes
• Security Off, Away, Night, Day, Vacation.
• Security Off
• System disarmed, 24hrs zones still active
• Away
• Occupants are away
• Night
• Protects certain allocated zones when occupants
  are asleep
• Day
• Doors/windows protected by PIRs are inactive
• Vacation
• Same as Away but appliances can be switched
  on/off in a semi-random manner to create the
  impression of occupancy

13
Security Zones

• Up to 64 Zones of Security
• Each zone is assigned a Zone Type to describe its
  properties, words to announce, and Response

14
Security Types gtZone Types

• 31 Preconfigured Zone Types can be assigned to
  each zone
• Eg Door/Window, Entry Door, Fire, Panic
• Determines behaviour in each mode, Alarm type

15
Alarm Types

• 31 programmable alarm types
• Intruder, fire, smoke, gas, etc
• Dial-out to combination of 8 phones
• 20 siren types
• Dedicated strobe output
• Alarm response to trigger lights or announce
  message

16
Comfort Dialer

• Dials to 8 phone numbers
• Combination of Voice phones, pager, CMS, SMS
  (with UCM/GSM)
• Support 2 CMS numbers, standard formats
• Each Alarm type can dial to any combination of 8
  numbers
• Alarm message
• Voice message announces recorded alarm message
  and alarm type.
• Allows access to Comfort
• Listen to Alarm History or to disarm
• Listen to sounds at home through keypads

17
Security/Automation Linkage

• Programmable Alarm Response
• Eg Turn on all Lights on Intruder Alarm
• Lighting up fire exit route and switching off
  air-conditioners during fire alarm
• Lighting up areas in house when intruder alarm
  triggered in away mode to scare intruders

18
Security/Automation Linkage

• Each Zone has On and Off Response
• Arming to Away, Night, Day has Response
• Responses can have conditions, eg based on Time,
  If/Then, zone state, alarm state etc

19
Security/Automation Linkage

• Other possibilities
• Switching on the lights near the main door when
  opening the door at night
• Switching off of lights and appliances upon
  arming to away mode
• Triggering pre-recorded messages upon activation
  of perimeter motion detectors

20
User Codes

• 16 user codes
• Answer machine mailboxes for first 8
• Programmable authorisation for each user
• Sign-in tamper
• 6 incorrect entries cause Sign-in Tamper
• Duress alarm
• When forced to disarm by intruder. User code /-
  2. Need two entries to confirm duress to avoid
  unintentional activation

21
Engineer Menu

• Engineer Sign In Option
• Default code 6789 to enter Engineer Menu
• F0 on keypad must be enabled by user to allow
  engineer code access
• Allows programming via keypad or remote by
  telephone
• Disabled after midnight to prevent unauthorized
  login
• User may also disable it upon completion of
  programming

22
Security Safeguards

• Duress Code
• Provides impression system is disarmed if forced
  to disarm
• Sign In Tamper
• Maximum of 6 unsuccessful attempts
• Engineer Access Restriction
• F0 required on Keypad to allow Engineer
  Programming
• Cancels authorization when system is armed or
  after midnight each day

23
Industrial Monitoring

• Monitoring of Facilities (eg water, power,
  temperature, Equipment failure)
• Call or SMS to maintenance when alarm triggered
  alarms can call to any combinations of numbers
• English Industrial wordlist available

24
Home Automation
25
Home Control Menu

• Voice prompts on phone or keypad
• Human Voice announcement, many languages
  available
• No need to memorise activation codes
• Announces status in menu

26
Home Control Menu

• Programmable into control groups (max 6)
• Press 0 for Lights, 1 for Heating, 2 for Home
  Entertainment
• Status feedback possible

27
Home Control Menu

• Quick Reference Card supplied with all Comfort
  systems

28
Lighting Control

• Control On/Off (not dimming) using TWS modules
  (lighting relay and current sensor)
• Able to control X10 and PLCBus Modules
• No specific Dimming module available. Comfort is
  not a lighting system
• For dimming, use external lighting system eg EIB,
  C-Bus, Ulti, Dynalite, Lutron, X10, Zwave.
  Comfort does not tie installers or users to a
  specific lighting system
• Comfort is sold by Schneider (some countries) as
  Minder Pro

29
X10 Power Line Carrier

• X10 two-way capability is built-in
• Requires two-way X10 interface module (XM10E or
  equivalent)
• Able to send and receive X10 commands to any X10
  Address
• X10 commands limited by responses
• Received X10 codes can be used to trigger
  responses
• Preset dim function supported
• PLC Bus alternative to X10

30
Clipsal C-Bus Lighting

• Requires UCM/C-Bus
• Able to use C-Touch to simulate Comfort keypad
• Monitoring of zones, Comfort outputs
• Control of C-Bus devices
• ULTI RF switches can be controlled by UCM/ULTI

31
KNX/European Installation Bus

• Requires UCM/EIB
• Able to control Comfort outputs via EIB switches
• Control EIB/KNX devices

32
Dynalite

• Requires UCM/485 with RS485 interface
• Control of Dynalite lights, scenes (one way, no
  status)
• New Isolated RS485 interface available soon

33
Ulti RF Switches

• UCM/Ulti with antenna is required to control Ulti
  RF switches
• 1 way only, no status feedback

34
ZWave RF System

• Eg from Merten and ACT

35
E-Home HDL Bus

• RS485-bus based Dimmers, Switches, relays

36
Other Lighting Options

• Rako (RF Lighting)
• Lutron
• Others being developed

37
Time Programs

• 32 Time programs (Ultra System)
• Activation on combination of days of
  week/holidays and a programmed time of day
• User has option to enable/disable the time
  program
• Trigger responses
• Lighting control to switch off all lights,
  heaters, Air-cons
• Arm or Disarm Security
• Open or close curtains

38
Responses/Scenes/Events

• Comfort Ultra has 1024 Responses or programs that
  can be used for Scene Control, Time Programs,
  Zone Responses, Alarm Responses, Cbus/KNX
  responses, Scene Control Switch Responses etc
• Events -gt Responses is the key to Comforts power

39
Sunrise/Sunset Responses

• Sunrise and Sunset Times defined by City or
  Longitude/ Latitude
• Automatic Daylight saving time change
• Sunrise and Sunset Responses
• Night Flag at night can be tested by Responses

40
Reminders

• 16 reminders (Ultra II)
• scheduled to play at selected time
• Combination of day of weeks and holidays
• Enabled/disabled by users
• Reminder Message is recorded by User
• Reminders can also be played on door stations or
  keypads as warning messages triggered by events
  eg Motion Detector

41
Voicemail
42
Digital Storage

• Comfort answers calls after programmed number of
  rings
• User Greeting message is recorded to enable
  voicemail
• Flash memory
• Up to 10 minutes of messages can be stored
• Messages stored in non-volatile memory,
  maintained even during power failure

43
Mailboxes

• 8 personal user mailboxes
• Users 9-16 do not have mailboxes
• Name can be recorded
• Callers can leave messages in the selected
  mailbox
• Instead of individual mailboxes, common mailbox
  can be set up
• Messages can be by callers or from other users
• Can also forward to users mobile phone.

44
Intercom
45
Keypad

• Able to intercom to any other keypads or
  doorstation
• Keypads can be Baby Monitors

46
KP04-SS

• Stainless Steel Faceplate by BS

47
Door Station

• Pressing Doorbell rings phones (RGR04 required)
• Talk to visitor at door station using the
  internal phones
• Dials to user in away mode allowing user to talk
  to the visitor
• User able to control a gate or door to let
  visitor in

DS01
DS02
48
Configuration/Modules
49
Control Panel CP9000

• 8 inputs and 8 outputs
• Programmable zones (31 Zone types)
• Outputs can be used to send pulse, IR signals,
  set On/Off
• All I/O protected against voltage surges and
  overcurrent (resettable fuses)
• Battery charger for 12V/7AH monitors battery
  voltage

50
I/O Expansion

• Local Expansion attached to Comfort or Slaves
• Slave Expansion Connected on Comfort RS485 bus
• Remote Input/Output (RIO) connected on Comfort
  RS485 bus

51
Local Expansion Module (LEM)

• LEM01 8 inputs and 8 outputs
• LEM02 8 inputs only
• LEM03 16 inputs, 0 Outputs. Not to be used if
  SEMs are installed.
• 1 LEM connected to Main Comfort or SEM

52
Slave Expansion Module (SEM)

• Allows expansion for more than 16 I/O
• 8 inputs and 8 outputs
• 1 LEM01/02 can be connected to give 8 I/O.
  Maximum 16 Inputs and Outputs per SEM/LEM
• Has power supply/battery charger to distribute
  current load in the system
• Monitors its own battery

53
Slave Expansion Modules

• Maximum of 3 SEMs for 1 Main Panel, hence max 64
  Inputs and Outputs per system for Comfort and
  SEMs)
• SEM01-M2 Requires Transformer and standby
  battery. Able to supply 1A to devices
• SEM02-M2 No built-in power supply and battery
  charger (1/2 Comfort PCB). 12V DC Supply from
  Comfort Controller, if within 1 A limit of Comfort

54
Remote Input/Output (RIO01)

• 8 digital inputs, 8 open-collector outputs per
  RIOI
• IR receiver (IRR01) or IR dome (IRD01) can be
  connected to inputs to receive Comfort IR codes,
  unlike other Comfort inputs
• Input not programmable as alarm zones.
• Max 15 RIO per Ultra II system giving 120
  non-alarm inputs and open-collector outputs

55
Outputs

• Comfort main board has 8 outputs
• SEM01 Slave Expansion Module has 8 Outputs
• LEM01-M2 has 8 outputs
• OP1 plug in board supplies 8 outputs on Comfort,
  Slave and LEM01-M2.
• OP01 can be unplugged and replaced if damaged
  without affecting the security system
• RIO supplies 8 outputs, up to 15 RIOs in Ultra
  (120 outputs)
• Up to 184 Outputs can
• Send learned IR for air-conditioners and AV
  equipment
• Pulsed
• Switch On/Off
• Outputs are open-collector with 12V common
• Relays RLY02/RLY01 can be connected to provide
  dry contacts
• IR can be learned using UCM05 and saved in
  Comfigurator IR Library

56
Keypads / Touchscreens

• KP03 without LCD
• KP04 with LCD
• KT01 touchscreen keypad

57
Keypads

• 16 programmable keys with backlight
• LEDs for status
• Acts as intercom
• Baby monitor feature
• Up to 8 keypads in the system NOT including KT01,
  all with IR Receivers
• KP03 no LCD
• KP04 LCD

58
KeyTouch Touchscreen Keypad (KT01)

• Monochrome LCD touchscreen Keypad
• Speaker and microphone built in
• IR Receiver built-in
• Keypad Emulation Page
• KT01 has a UCM ID, not keypad ID

59
Remote Control (RC01)

• Sends IR codes to
• IRR IR receiver (with RIO)
• IRD Dome (with RIO)
• SCS04/IR
• KT01/KP03/KP04
• 16 Scene buttons
• Room buttons to control lights/appliances in
  rooms
• Keypad simulation (to KP only)
• Panic keys
• Idea free gift to customers

60
Remote Controls

• Any Learning Remote Control can be used with
  Comfort
• Send 128 Comfort IR codes to trigger Responses

Harmony
Pronto
61
Door Station (DP03)

• Up to 3 supported
• Requires ringer module RGR04 to ring internal
  phones
• Speaker/microphone in-built
• Dial to mobile phone in Away mode, Ring internal
  phones/keypads in Off/night mode

62
DS01 Door Station

• Aluminium Door Station
• Option no camera, monochrome camera, colour
  camera
• Requires DM02 Door station Module and RGR04 to
  ring phones

63
DS02 Door Station

• Stainless Steel
• Anti-Vandal
• Options BW, Colour camera
• Requires DM02 Door station Module and RGR04 to
  ring phones

64
DP03X Door Station

• Door station with Mic and speaker only, no
  Communications bus
• Connects to DM02 inside house
• Less susceptible to damage to Comfort in lighting
  prone areas

65
Door Station Interface Module (DM02)

• Interface to link to other door entry systems
  (e.g. Fermax, DS01)
• Works like a normal door station
• Able to
• Ring local phones (need RGR04)
• Dial to Mobile phones
• Provide 2 relays contacts for opening gate or door

66
Ringer Module (RGR04)

• Creates ring tone for phones when doorbell is
  pressed, or for Reminder messages
• Require 1 RGR04 for each Comfort for up to 3 Door
  Stations
• RGR04 is mounted and plugged on to Main Board

67
Door Station Connections
68
Scene Control Switch (SCS)

• Designer switch from Gira (Germany)
• SCS04, SCS06, SCS08 depending on the number of
  switches
• Built-in Temperature sensor
• New Esprit frames in Glass, Aluminium, Brass,
  Chrome, Wood, Terracota

69
SCS Esprit Frames
70
UCM Interfaces

• UCMs are for Interface to external or 3rd Party
  systems
• Up to 8 UCMs in a system, including KT01 which
  are considered UCMs

• UCM05
• UCM/Ethernet
• UCM/Audio
• CWM02
• UCM/CBUS
• UCM/ZWave

• UCM/EIB
• UCM/Ulti
• UCM/Smartfit
• UCM/GSM
• UCM/485 Dynalite
• KT01
• UCM/HDL

71
UCM05 Universal Communications Module

• RS232 Interface
• Allows upload/download from PC to Comfort and
  vice versa
• Communicates with other products with Rs232
  Interfaces. Serial Protocol is available for 3rd
  party development
• Enables copying of configuration files
• IR Learning Tool
• Allows firmware upgrade for Comfort, Slave, other
  UCMs

72
UCM/Audio

• Speaker and microphone jacks connect to PC and
  speaker
• AUD01 can be plugged on UCM05 to become UCM/Audio
• Can also plug on Eth01 Ethernet module
• Allows WizComfort to simulate a Comfort keypad on
  the PC

73
UCM/Ethernet

• Allows Comfigurator to upload and download via
  LAN
• Can be used to interface between Comfort and PC
• ETH01 can be plugged on a UCM05 to become
  UCM/Ethernet

74
UCM/USB

• New UCM with USB interface
• Supported by Comfigurator 3

75
UCM/CBus

• Allows communication between Comfort and C-Bus
• Comfort able to control C-Bus devices and C-Bus
  switches able to control Comfort

76
C-Bus Schematic
77
UCM/EIB

• Interfaces between Comfort and EIB
• Allows Comfort to control EIB devices
• EIB switches can activate Comfort responses

78
KNX/EIB Schematic
79
UCM/GSM

• Backup dialer in case of telephone line cut.
• Provides dial in via GSM
• Sends SMS when Alarm is activated
• SMS to control Comfort
• Requires SIM card
• New Low cost UCM/GSM2 (185 retail)

80
CWM02

• New Webserver module
• Allows users to view current status and control
  devices via the internet or a local network using
  a browser
• Retail lt500

81
UCM/ULTI

• UCM/Ulti RF Interface sends scene commands to
  Ulti Switches
• Scene commands are learned into Ulti switches
• 433 Mhz and 315 Mhz available

82
FPR01 Fingerprint Reader

• Fingerprint Reader recognises stored fingerprints
  of 16 users
• Each user can submit several fingerprints for
  easier recognition
• Comfort activates Responses based on recognised
  user
• Tamper alarm if UCM/FPR01 loses communications
• Can be used to arm and disarm
• Not rated for outdoors

83
UCM/Smartfit (UK Only)

• Provides an interface between Smartfit and
  Comfort
• Allows Comfort to fix setpoints, query
  temperature of Smartfit

84
New Interfaces

• UCM/Z-wave
• for Z-Wave Wireless Mesh network
• Merten Connect Radio System
• ACT HomePro Radio system

85
New Interfaces

• UCM/HDL
• Interface to e-Home HDL Bus

86
Comfort Network
Architecture
87
Comfort Wiring

• CAT 5 cables can be run to all RS485 modules
• Security wires 4 or 6 core can be used for alarm
  wiring from sensors to Zone inputs (multistranded
  untwisted 7 x 0.2 mm). Allow spare cables for
  each alarm point to cater for future wire
  degradation
• Keypads and Door stations should have CAT 5 wires
  (preferrably shielded) run individually back to
  Comfort

88
Infrared Transmitter Module (IRM01/IRW01)

• IRM01
• Resettable fuse onboard for protection
• Distance up to 8 meters
• Allows beaming of IR signals to devices
• May be housed near the appliance itself or in
  blank switch plate
• IR01W for use at short range, mounted within
  Aircon FCU

89
Current Sensor Module (CSM03)

• Provides feedback to Comfort Input whether
  appliance is on/off.
• 2 parts CSM03-CT and CSM03-PCB
• CSM03-PCB mounted separately from CSM03-CT

90
Control of Airconditioners by IR

• IR01W to transmit IR signals connected to Comfort
  Output
• CSM03-CT around the FCU supply wire to monitor
  On/Off AC current. Connected to CSM03 at Comfort
  Input
• 1 Input and 1 output required for each FCU. CAT 5
  cable for each. Require Twisted pairs to prevent
  interference

91
Control of Airconditioners by IR
92
Infrared Receiver (IRR01)

• IRR01 allows IR signals to be received which
  activates IR Received Responses
• Must be connected to a RIO input

93
Infrared Dome (IRD01)

• 8 IR LEDs for transmitting IR 360 degrees
• Allows beaming of IR signals to devices
• 1 IR receiver for receiving Comfort IR codes to
  activate responses
• IR Receiver must be connected to the input of a
  RIO

94
Reed Relay Module

• RLY02/8 Provides 8 N/O relays/dry contacts. RLY02
  has 4 relays
• RLY01 has 4 relays with changeover contacts
  (NO/NC)
• NOT Meant for switching mains
• Connected to any Comfort output
• RLY02 has LEDs to indicate output status
• Suitable for control of Garage doors, auto-gates,
  electric locks, curtains

95
Two Way Switching of Lights

• TWS01/02 enables two way control of lights
• Control both by Comfort and mechanical switch
• Able to control lights using (two-way) wall
  switch even when Comfort is not functioning

96
Lighting Control Switch (TWS01/02)

• Relay and current sensor located together.
• Designed for controlling light switches. Two Way
  Lighting switch must be used
• Allows lighting control even if Comfort is down.
• TWS01 allows for control of 1 set of light, while
  TWS02 allows for 2.
• 1 Input and 1 output required for each lighting
  switch

97
TWS Connection Diagram
98
Software
99
Comfigurator Programming Software

• Requires a UCM05, UCM/Ethernet or UCM/USB
• Used to program Comfort

100
Infrared Learner

• UCM05 required
• Bundled with Comfigurator programming software.

101
Voice Customisation Software

• VoiceProc Software allows creation of vocabulary
  in a new language or Customisation of vocabulary
  sets

102
VoicePlay

• VoicePlay is a complementary tool to VoiceProc to
  allow sentences created by VoiceProc to be played
  back in compressed or uncompressed format

103
WizComfort

• Requires UCM05 or UCM/Ethernet
• Computer user interface
• Simulates keypad control. UCM/Audio allows voice
  to be heard and messages to be recorded
• Reads Comfigurator file for self configuration
• Activate Control Menu responses

104
Superna with Comfort Plug-in
www.supernasystems.com
105
Approvals
106
Approvals/ Test Reports

• ETSI EN 301 489-1 72002 for Europe safety
• ETSI TS103 021-1,2,3 (2003) Europe Telephony
• EN/IEC60950-1 Safety of Information Technology
  Equipment
• AS/NZ CISPR222002 for Australia/NZ EMC
• AS/ACIF 2002 - Australia Telephony
• IDA TS PSTN 1(Singapore) Singapore Telephony
• SIRIM (Malaysia) Malaysia Telephony
• TIA-968-A, FCC 47 CFR Part 68 US Telephony
• FCC Part 15C2004 (Class B) US EMC

107
Summing Up

• Products like lighting switches using RF, IR,
  powerline and various bus systems not
  competitors! Comforts role is to integrate the
  various systems in a home or office unit into an
  intelligent system.
• Security system is the basic component of an
  intelligent home. Security sensors are important
  even if the alarm is not required in the home.
• Comfort is not a one-stop or Plug and Play
  product. It requires design and system
  integration with the necessary modules and
  external components to fit the customers
  requirements. Skilled system integrators are
  needed.
• Key advantage is the ability to program scenarios
  to suit individual requirement

108
End of Product Training

• This concludes the Product Training section.
• Technical Training will cover Programming.
• Testing and Commissioning
• Further Reading
• Comfort Wiring Diagram
• How to Configure a Comfort System
