Title: EDK Introduction


1
EDK Introduction
2
Objectives
  • After completing this module, you will be able
    to
  • Describe the embedded systems development flow
  • Understand the components in the hardware design
  • Specify ways to create a hardware design
  • Identify the tools included in EDK
  • Locate the EDK documentation

3
Outline
  • Introduction
  • EDK
  • Overview of EDK
  • Embedded Development Design Flow
  • XPS Platform Management
  • Supported Platforms
  • Appendix Project Files and Structures

4
Embedded Systems
  • An embedded system is nearly any computing system
    (other than a general-purpose computer) with the
    following characteristics
  • Single-functioned
  • Typically, is designed to perform predefined
    function
  • Tightly constrained
  • Tuned for low cost
  • Single-to-fewer components based
  • Performs functions fast enough
  • Consumes minimum power
  • Reactive and real-time
  • Must continually monitor the desired environment
    and react to changes
  • Hardware and software co-existence

5
Embedded Systems
  • Examples
  • Mobile phone systems
  • Customer handsets and base stations
  • Communication devices
  • Wired and wireless routers and switches
  • Automotive applications
  • Braking systems, traction control, airbag release
    systems, and cruise-control applications
  • Aerospace applications
  • Flight-control systems, engine controllers,
    auto-pilots and passenger in-flight entertainment
    systems
  • Defense systems
  • Radar systems, fighter aircraft flight-control
    systems, radio systems, and missile guidance
    systems

6
Current Technologies
  • Microcontroller-based systems
  • DSP processor-based systems
  • ASIC technology
  • FPGA technology

7
Integration in System Design
Integration of Functions
Time
8
Embedded Design in an FPGA
  • Embedded design in an FPGA consists of the
    following
  • FPGA hardware design
  • C drivers for hardware
  • Software design
  • Software routines
  • Interrupt service routines (optional)
  • Real Time Operating System (RTOS) (optional)

9
PowerPC-based Embedded Design
Full system customization to meet performance,
functionality, and cost goals
10
MicroBlaze Processor-Based Embedded Design
I-Cache BRAM
Local Memory Bus
Flexible Soft IP
BRAM
Configurable Sizes
D-Cache BRAM
Fast Simplex Link
0,1.7
CacheLink
Off-Chip Memory
FLASH/SRAM
SRAM
11
Outline
  • Introduction
  • EDK
  • Overview of EDK
  • Embedded Development Design Flow
  • XPS Platform Management Hardware Design
  • Supported Platforms
  • Appendix Project Files and Structures

12
Embedded Development Kit
  • What is Embedded Development Kit (EDK)?
  • The Embedded Development Kit is the Xilinx
    software suite for designing complete embedded
    programmable systems
  • The kit includes all the tools, documentation,
    and IP that you require for designing systems
    with embedded IBM PowerPC hard processor cores,
    and/or Xilinx MicroBlaze soft processor cores
  • It enables the integration of both hardware and
    software components of an embedded system

13
Embedded DevelopmentTool Flow Overview
Instantiate the System Netlist and Implement
the FPGA
Include the BSP and Compile the Software Image
1
2
3
RTOS, Board Support Package
14
Embedded System Tools
  • GNU software development tools
  • C/C compiler for the MicroBlaze and PowerPC
    processors (gcc)
  • Debugger for the MicroBlaze and PowerPC
    processors (gdb)
  • Hardware and software development tools
  • Base System Builder Wizard
  • Hardware netlist generation tool PlatGen
  • Software Library generation tool LibGen
  • Simulation model generation tool SimGen
  • Create/Import Peripherals Wizard
  • Xilinx Microprocessor Debug (XMD)
  • Hardware debugging using ChipScope Pro Analyzer
    cores
  • Eclipse IDE-based Software Development Kit (SDK)
  • Application code profiling tools
  • Virtual Platform generator VPGen
  • Flash Writer utility

15
Embedded System Tools
  • Board Support Packages (BSPs)
  • Standalone BSP
  • Wind River VxWorks
  • MontaVista Linux
  • Xilinx MicroKernel (XMK)
  • Xilinx Platform Studio
  • Xilinx Platform Studio (XPS) is a graphical
    Integrated Design Environment (IDE) that
    incorporates all the Embedded System Tools for
    seamless creation of hardware and software
    components and, optionally, a verification
    component

16
Xilinx Platform Studio (XPS)
See notes section for detailed explanation
17
XPS Functions
  • Project management
  • MHS or MSS file
  • XMP file
  • Software application management
  • Platform management
  • Tool flow settings
  • Software platform settings
  • Tool invocation
  • Debug and simulation

XPS
HW/SW Simulation
Hardware Design
HW/SW Debug
Software Design
18
Outline
  • Introduction
  • EDK
  • Overview of EDK
  • Embedded Development Design Flow
  • XPS Platform Management
  • Supported Platforms
  • Appendix Project Files and Structures

19
Project Management
  • Create a new project
  • Using File ? New Project or toolbar button
  • Select Base System Builder option
  • The Base System Builder (BSB) wizard is a
    software tool that helps you quickly build a
    working system targeted at a specific development
    board
  • Select Blank XPS Project option
  • Open an existing project
  • Using File ? Open Project or toolbar button
  • Browse to a pre-created project directory and
    selecting an xmp file
  • Using File ? New Project or toolbar button
  • Select Open a Recent Project option and selecting
    a project
  • Project information is saved in the Xilinx
    Microprocessor Project (XMP) file

20
Project Creation Using Base System Builder (BSB)
Option
  • Select a target board
  • Select a processor
  • Configure the processor
  • Select and configure I/O interfaces
  • Add internal peripherals
  • Generate the system software and the linker
    script
  • Generate the design
  • Generated files
  • system.mhs system.mss
  • System.xmp data/system.ucf
  • etc/fast_runtime.opt etc/download.cmd
  • pcore directory (empty) system.bsb (optional, if
    selected)
  • TestApp_Memory/src directory containing
    (optional, if selected)
  • TestApp_Memory.c TestApp_Memory_LinkScr.ld
  • TestApp_Peripheral/src directory containing
    (optional, if selected)
  • TestApp_Peripheral TestApp_Peripheral/src/TestApp
    _Periperal_LinkScr.ld

21
EDK Tool Flow
Simulation Generator
Hardware Platform Generation
Library Generation
CompEDKLib
CompXLib
MSS
MHS
TestbenchStimulus
IP Models
ISE Models
IP Library or User Repository
SimGen
Drivers,MDD
EDK SWLibraries
LibGen
PlatGen
MPD, PAO
.a
PCoreHDL
System andWrapper VHD
BehavioralVHD Model
system.BMM
ISETools
Embedded Software Development
Synthesis (XST)
NGC
ApplicationSource.c, .h, .s
SimGen
NGDBuild
UCF
NGD
Compiler (GCC)
StructuralVHD Model
MAP
.o
NCD, PCF
Linker (GCC)
PAR
NCD
BitGen
system.BIT
SimGen
system_BD.BMM
ELF
BitInit
TimingVHD Model
download.BIT
Simulation
download.CMD
iMPACT
22
Hardware Implementation XPS/Xflow
  • Xflow Implement hardware and generate the
    bitstream
  • Input files ? .ngc netlists, .bmm file,
    system.vhd, .ucf
  • Output Files ? system.bit, system_bd.bmm
  • Xflow calls the ISE Implementation tools using
    fast_runtime.opt file
  • NGDBuild, MAP, PAR, and TRACE are executed
  • Xflow then calls the BitGen program using
    bitgen.ut file
  • BitGen generates the bit file system.bit
  • BitGen also generates the back-annotated
    system_bd.bmm BMM file, which contains the
    physical location of the block RAMs

23
Hardware Implementation ISE/XPS Flow
  • The ISE/XPS flow provides integration of a
    processor system at two levels as a component in
    a FPGA design
  • The processor system is the top-level design
  • The processor system is a submodule
  • Once the processor system is added in the ISE
    project, XPS can be invoked from ISE by selecting
    xmp file in Sources window and double-clicking
    Manage Processor System in the Processes window
  • Add user constraint file in ISE
  • Implement design in ISE by selecting top-level
    module in Sources window and double-clicking
    Implement Design in Processes window
  • Executable software can be merged by selecting
    top-level module in Sources window and
    double-clicking Update Bitstream with Processor
    Data in Processes window
  • This will call XPS in background to update the
    bitstream and generate system.bit and
    download.bit files in implementation directory as
    well as copy the file as system_stub.bit and
    system_stub_download.bit files in the ISE project
    directory

24
Software Flow Library Generation
  • Library Generator LibGen
  • Input files ? MSS
  • Output files ? libc.a, libXil.a, libm.a
  • LibGen is generally the first tool run to
    configure libraries and device drivers
  • The MSS file defines the drivers associated with
    peripherals, standard input/output devices,
    interrupt handler routines, and other related
    software features
  • LibGen configures libraries and drivers with this
    information and produces an archive of object
    files
  • libc.a - Standard C library
  • libXil.a - Xilinx library
  • libm.a - Math functions library

25
Software FlowCompilation
  • Compile program sources
  • Input files ? .c, .c, .h, libc.a, libXil.a,
    libm.a
  • Output files ? executable.elf
  • This invokes the compiler for each software
    application and builds the executable files for
    each processor
  • Four stages
  • Pre-processor Replaces all macros with
    definitions as defined in the .c or .h files
  • Machine-specific and language-specific compiler
    Compiles C/C code
  • Assembler Converts code to machine language and
    generates the object file
  • Linker Links all the object files using
    user-defined or default linker script

26
Merging Hardware and Software Flows
Hardware Flow
Software Flow
data2MEM
download.bit
27
Merging Hardware and Software Flows
  • Data2MEM Update the bitstream
  • Input files ? system_bd.bmm, system.bit,
    executable.elf
  • Output file ? download.bit
  • This invokes the BitInit tool, which initializes
    the instruction memory of the processor
  • The instruction memory may be initialized with a
    bootloop, bootloader, or an actual application
  • This is the stage where the hardware and the
    software flows come together. This stage also
    calls the hardware and software flow tools if
    required

28
Configuring the FPGA
  • Download the bitstream
  • Input file ? download.bit
  • This downloads the download.bit file onto the
    target board using the Xilinx iMPACT tool in
    batch mode
  • XPS uses the etc/download.cmd file for
    downloading the bitstream
  • The download.cmd file contains information such
    as the type of cable is used and the position of
    the FPGA in a JTAG chain

29
Outline
  • Introduction
  • EDK
  • Overview of EDK
  • Embedded Development Design Flow
  • XPS Platform Management
  • Supported Platforms
  • Appendix Project Files and Structures

30
Add/Edit Cores
  • Add cores, edit core parameters, and make bus and
    port connections through System Assembly view
  • Select IP Catalog tab to add peripherals
  • Select a core and drop it in the system view or
    double-click on it to add
  • In the System View select an instance, right
    click, and then select Delete Instance
  • Change settings using appropriate filters and
    select an instance
  • Base and end addresses
  • Parameters
  • Ports

1
3
2
1
3
2
31
Project OptionsDevice and Repository Tab
  • Set/Change Target Device
  • Architecture
  • Device Size
  • Package
  • Grade
  • Peripheral Repository Directory
  • Provide path to custom IP not present in the
    current project directory structure
  • Custom Makefile Directory

Note Detailed information on the other two tabs
is provided in the Adding Your Own IP to the OPB
Bus and the System Simulation modules in this
course.
32
Outline
  • Introduction
  • EDK
  • Project Management
  • Software Application Management
  • Platform Management
  • Supported Platforms
  • Appendix Project Files and Structures

33
Supported Platforms
  • Operating systems
  • Windows 2000 (Service Pack 2)
  • Windows XP
  • Solaris Operating System 2.8/2.9
  • Linux Red Hat Enterprise 3.0
  • FPGA families
  • Spartan-II/IIE (MicroBlaze processor)
  • Spartan-3/3E (MicroBlaze processor)
  • Virtex and Virtex-E (MicroBlaze processor)
  • Virtex-II (MicroBlaze processor)
  • Virtex-II Pro (MicroBlaze and PowerPC
    processors)
  • Virtex-4 FX (MicroBlaze and PowerPC processors)
    and LX/SX (MicroBlaze processor)

34
BSB-Supported Platforms
  • A list of supported Xilinx hardware boards
  • AFX board
  • Spartan-3 Starter Board
  • Virtex-4 ML401 Evaluation Platform
  • Virtex-4 ML402 Evaluation Platform
  • Virtex-4 ML403 Evaluation Platform
  • Virtex-II Multimedia FF896 Development Board
  • Virtex-II Pro ML300 Evaluation Platform
  • Virtex-II Pro ML310 Evaluation Platform
  • XUP Virtex-2 Pro Educational Platform (.xbd files
    downloadable from XUP web)
  • Custom board
  • Board definition (.xbd) files for third party
    boards can be downloaded from the board vendor
    web site
  • Links from the BSB wizard and Xilinx embedded Web
    page

35
Knowledge Check
  • What is the MHS file?
  • What does the PlatGen tool do?
  • What tool is used to place executable code in an
    FPGA block RAM?

36
Answers
  • What is the MHS file?
  • The MHS file is the Microprocessor Hardware
    Specification it specifies processors, hardware
    peripherals, bus connections, and address spaces
    for the hardware
  • What does the PlatGen tool do?
  • PlatGen takes the MHS file and creates the system
    and peripheral netlists, HDL wrapper files, BMM
    file, etc.
  • What tool is used to place executable code in an
    FPGA block RAM?
  • The Data2Mem tool will take the BMM file and
    create the proper initialization for the block
    RAM that is assigned to the executable memory
    space

37
Knowledge Check
  • How can you add or change configuration settings
    once the hardware system is build?
  • What does the LibGen tool do?
  • What is the difference between system.bit and
    download.bit files?

38
Answers
  • How can you add or change configuration settings
    once the hardware system is build?
  • Select IP Catalog tab, expand related IP
    peripheral folder, select a desired IP, and
    double-click on it to add it to the design
  • Select an IP instance in the System Assembly View
    panel, right click on it, and select desired
    configuration
  • What does the LibGen tool do?
  • Read MSS file and generate libraries
  • What is the difference between system.bit and
    download.bit files?
  • The system.bit file contains only hardware
    description whereas download.bit file contains
    both hardware description as well as executable
    software
Write a Comment
User Comments (0)
About PowerShow.com
