Chapter 4 Reinforcement and Extinction of Operant Behavior

1
Chapter 4Reinforcement and Extinction of Operant
Behavior
Prepared by Brady J. Phelps, South Dakota State
University
2
Two Types of Behavior

• Classical Conditioning
• Respondents reflexive, elicited behavior
• CS controls behavior
• Operant Conditioning
• Operants voluntary, emitted behavior
  outcomes control behavior

3
Operant Behavior

• Operant behavior that is followed by reinforcing
  consequences is selected in the sense that it
  increases in frequency.
• Behavior that is not followed by reinforcing
  consequences decreases in frequency.
• This is known as operant conditioning.
• Operant conditioning as a process, has evolved
  over species history and is based on genetic
  endowment.
• That is, operant (and respondent) conditioning as
  a general behavior-change process is based on
  phylogeny.

4
Operant Behavior

• From a scientific perspective, operant behavior
  is lawful and may be analyzed in terms of its
  relationship to environmental events.
• Formally, responses that produce a change in the
  environment are called operants.
• The term operant comes from the verb to operate
  and refers to behavior that operates on the
  environment to produce a consequence.
• A positive reinforcer is defined as any
  consequence that increases the probability of the
  operant that produced it.
• Topography
• Operant class

5
Why rats and pigeons?
Rats and pigeons (and humans) have been common
research subjects For operant conditioning. Rats
and pigeons have been used for a number of
reasons. The selection of a basic response such
as a lever- press or a key peck while these
responses are simple, they are adequate to
illustrate the generality of basic operant
processes. In other words, the specific subject
or response isnt as important as the principles
being demonstrated. Rats and pigeons are what
can be considered technophilic species as they
readily adapt to human apparatus and habitations.
Just as these species readily move into our
garages, barns, attics or basements, they live
well in cages. By the way, operant researchers
have used subjects as diverse as insects to
cephalapods to primates.
6
Old Faithful
7
(No Transcript)
8
This slide and the prior slide are of Dr. Robert
Allen and here his student Shannon Lieb, with
subject 28, of Lafayette College. The next slide
is a close up of one of Dr. Allens pigeon
subjects responding in an operant chamber.
9
(No Transcript)
10
(No Transcript)
11
RoboRat, ready for search and rescue
12
Discriminative Stimuli

• Operant behavior is said to be emitted in the
  sense that it often occurs without an observable
  stimulus preceding it. This is in contrast to
  reflexive responses, which are elicited by a
  preceding stimulus.
• Stimuli may also precede operant behavior.
  However, these events do not force the occurrence
  of the response that follows them.
• An event that precedes an operant and alters its
  likelihood is said to set the occasion for
  behavior and is called a discriminative stimulus,
  or SD.

13
Discriminative Stimuli

• The consequences that follow operant behavior
  establish the control exerted by discriminative
  stimuli. When an SD is followed by an operant
  that produces positive reinforcement, the operant
  is more likely to occur the next time the
  stimulus is present.
• Differential reinforcement
• When an operant does not produce reinforcement,
  the stimulus that precedes the response is called
  an S-delta (S?.) In the presence of an S-delta,
  the probability of emitting an operant declines.
• An SD (or an S?) are not defined by their
  physical parameters but rather by preceding and
  altering the probability of responses.

14
Emitted versus occasioned
Operants can and do occur in the absence of any
eliciting stimulus, they are said to be freely
emitted. However, when an SD comes to control
occurrences of an operant, to alter its
probability of occurring, then it is said that
the SD occasions the operant. The term occasion
dictates that the operant is under the stimulus
control of an antecedent stimulus. Occasion as a
verb can be defined as creating a situation in
which something (in this case, an operant) is
especially likely to occur.
15
Contingencies of Reinforcement

• A contingency of reinforcement defines the
  relationship between the events that set the
  occasion for behavior, the operant class, and the
  consequences that follow this behavior.

16
Four Basic Contingencies

• Positive Reinforcement
• Positive reinforcement is one of the four basic
  contingencies of operant behavior.
• Positive reinforcement is when a stimulus
  follows behavior and, as a result, the rate of
  that behavior increases.
• Positively reinforcing events usually include
  consequences such as food, praise, and money.
  These events, however, cannot be said to be
  positive reinforcers until they have been shown
  to increase behavior.

17
Four Basic Contingencies

• Negative Reinforcement
• When a response results in the removal of an
  event, and this procedure increases the rate of
  that response, the contingency is called negative
  reinforcement.

18
Four Basic Contingencies

• Positive Punishment
• A situation in which responses produce an event
  and the rate of behavior decreases. This
  contingency is called positive punishment.

19
Four Basic Contingencies

• Negative Punishment
• Punishment can also be arranged by removing
  stimuli contingent on behavior. This contingency
  is called negative punishment.

20
Reinforcement, Intrinsic Motivation, and
Creativity

• Many educators and social psychologists argue
  that rewards/reinforcement reduce individual
  self-determination, motivation, and creativity
• Rewards/reinforcement are interpreted as
  controlling which leads to the reduction in the
  above listed behaviors
• Reinforcement reduces a persons intrinsic
  motivation, the critics argue

21
Rewards and Intrinsic Motivation

• Opponents of rewards often site experimental data
  showing rewards as having a negative effect(s)
• Results are not consistent, some studies find
  negative effects, some find positive effects
• Tangible rewards given for meeting a certain
  criterion level of performance or exceeding the
  performance of others actually maintained or
  enhanced intrinsic interest
• Eisenberger and Cameron (1996) no inherent
  negative property of rewards

22

• Eisenberger and Camerons research suggests ways
  to approach the use of rewards
• Verbal rewards increases peoples performance and
  interest on a task
• Tangible rewards produced a slight decrease in
  intrinsic motivation when rewards were given
  simply for doing an activity, regardless of
  quality of performance
• In general, rewards increase intrinsic interest
  and task enjoyment
• The view that rewards undermine peoples
  intrinsic motivation is an overgeneralization
  rewards tied to level of performance can increase
  intrinsic motivation
• When used correctly, rewards have positive
  effects on creativity and intrinsic motivation
• Rewards tied to level or quality of performance
  increase intrinsic motivation or leave intrinsic
  interest unaffected

23
How does one indentify a reinforcing stimulus?

• Test it.
• If given contingent upon a behavior, what effect
  is observed upon behavior?
• Another way is to rely on the Premack principle

24
Premacks Principle

• A higher frequency behavior will function as
  reinforcement for a lower frequency behavior
• Premack suggests it is possible to describe
  reinforcing events as actions of the organism
  rather than as discrete stimuli
• Reinforcement relativity

25
Premack and Punishment

• Less frequent behaviors can function as
  punishment for more frequent behaviors
• Often termed a reciprocal contingency
• Use in applied behavior analysis

26
Response Deprivation

• In a free choice setting, behaviors occur at
  different frequencies, yielding a response
  hierarchy. Higher frequency behaviors placement
  in such a hierarchy relative to lower frequency
  behaviors
• Depriving an animal of the opportunity to engage
  in a given behavior changes the response
  frequencies and the hierarchy.

27
Response Deprivation and Equilibrium

• Deprivation leads to a reordering of the
  hierarchy and determines which behaviors will
  function as reinforcement at any given time.
• Rats, humans and others will work to gain access
  to deprived activities.
• Instrumental responses
• Contingent responses

28
Operant Conditioning

• Operant conditioning refers to an increase or
  decrease in operant behavior as a function of a
  contingency of reinforcement.
• Latency is important in operant conditioning.
  For example, in an experiment, time from closing
  a trap door until a cat manages to get it open is
  a period known as latency.
• Thorndikes law of effect came out of measures of
  latency. The law of effect says that operants
  that produce positive reinforcers increase in
  frequency.

29
ThorndikeThe Law of Effect
30
(No Transcript)
31
E. L. Thorndike studied cats in puzzle boxes.
A hungry cat had to learn press a lever to get
out of the box and get food.
32
Cats gradually learned to make the correct
response(by accident at first). Initially low
probability behavior, lever pressing became high
probability behavior and vice versa
33
Their response latency also got faster.
34
Operant Conditioning
Rate of Response as a Measure of Response
Strength Skinner suggested that rate of response
should be the basic datum (or measure) for
operant analysis. This is because rate of
response is an index of the probability that an
operant will occur in the future. Operant rate
provides a direct measure of the selection of
behavior by its consequences, selection by
consequences.
35
Operant conditioning of the neuron

• Skinners speculation in 1953
• In vitro reinforcement of individual neurons
• Dopamine as reinforcement contingent upon bursts
  of firings
• Contingent delivery of dopamine versus
  noncontingent
• Dopamine and cannabinoids versus glutamate

36
Procedures in Operant Conditioning

• Operant rate-probability of response
• Free operant method is when an animal may respond
  over an extensive period of time. It is free to
  emit many responses or none at all. Bar pressing
  as an operant can occur rapidly or slowly
• This allows the researcher to observe changes in
  the rate of response and is important to be used
  as a measure of response probability.

37
The Operant Chamber

• Operant chamber, also called Skinner box
• -         Allows continuous behavioral measure
• Measured by cumulative recorder
• -         Main dependent variable is response
  rate
• -         Now can measure maintenance of
  response, not just learning of it

38
Understanding Cumulative Records

• Plots responses as they occur moment to moment
• A pen records time horizontally. Each response
  moves the pen vertically
• Reinforcers are marked
• Slope of the record indicates response rate
• Steep High
• Flat Low

39
Time moves Response moves
low rate
No response
high rate
40
Procedures in Operant Conditioning

• Deprivation
• Because the delivery of food is used as
  reinforcement, an animal must be motivated to
  obtain food. An objective and quantifiable
  measure of motivation for food is percentage of
  free-feeding body weight.
• The procedure of restricting access to food
  (the potentially reinforcing stimulus) is called
  a deprivation operation.

41
Magazine Training

• After deprivation for food is established,
  magazine training begins.
• When the feeder releases a pellet of food, a
  click sound is produced.
• The sound of the feeder is associated with food
  pellets and becomes a conditioned reinforcer.
• After training the animal is observed to move
  toward the magazine when the feeder is activated
  signaled by the click.

42
Procedures in Operant Conditioning

• Operant Level
• Rats emit many exploratory and manipulative
  responses and as a result may press the lever in
  an operant chamber at some low frequency, even
  when this behavior is not reinforced with food.
  This baseline rate of response is called the
  operant level. If food were to then be made
  contingent on lever pressing, lever pressing
  would be acquired as a high probability behavior
  and increase in frequency above its operant level.

43
Procedures in Operant Conditioning

• The Method of Successive Approximation, aka
  Shaping
• The previous example described the rats
  behavioral repertoire and an alteration of the
  repertoire. The animals repertoire refers to
  the behavior it is capable of naturally emitting
  on the basis of species and environmental
  history.
• Many novel forms of behavior may be shaped by
  the method of successive approximation. Shaping
  is a key part of acquisition and necessarily
  involves differential reinforcement.

44
Shaping the lever press response(responses are
shaped, not rats)

• Extinguish any UR to the chambers
• Watch what the rat does
• If you are too slow with a reinforcer, response
  not strengthened
• If you do not use differential reinforcement,
  behavioral variability will not be selected. The
  shaping process will not select a new operant.

45
A model experiment

• Deprivation and ad libitum weight
• Repeated exposure to the apparatus to extinguish
  emotional responses
• Pair sound of pellet dispenser with pellet
  delivery
• Shaping-reinforce successive approximations of
  desired response. Responses are shaped, NOT rats.
• Differential reinforcement
• First definable response
• Satiation

46
Shaping

• In some instances, a behavior does not occur, so
  reinforcement of it is not possible
• Shaping differential reinforcement of successive
  approximations of a terminal behavior
• shake

10
1, 310
Raise right paw ½ from ground
On cue, shift weight on left paw, such that right
paw is available
47
Shaping behavior in the real world

• Skinner was very good at shaping animals and
  people, without their awareness (Rollo May)
• The behavior of professors has been shaped by
  students in the classroom.

48
Satiation

• Satiation- the rate of response declines because
  repeated presentations of the reinforcer weaken
  its effectiveness.
• A satiation operation decreases the
  effectiveness of reinforcement. This effect is
  opposite to deprivation, in which the
  effectiveness of a reinforcer is increased by
  withholding it.

49

• Operant Variability
• Behavioral variability increases the chances that
  the organisms will either reinstate reinforcement
  or contact other sources of reinforcement
• The effect of reinforcement on response
  stereotypy is a controversial issue in the field
  of behavior analysis
• Reinforcement contingencies may sometimes produce
  novel and creative behavior patterns

50

• Reinforcement, problem solving, and creativity
• Dr. Barry Schwartz argues that reinforcement
  produced behavioral inflexibility and rigidity,
  which interferes with finding solutions to
  complex problems that require innovation and
  creativity
• Conversely, Dr. Allen Neuringer argues that
  response stereotypy is not an inevitable outcome
  of reinforcement, but rather the effects of
  reinforcement depend upon the contingencies
• If contingencies support response stereotypy,
  then it will occur
• Contingencies may generate novel sequences of
  behavior if these patterns result in reinforcement

51
Extinction

• The process of withholding reinforcement for a
  previously reinforced response is called
  extinction.

52
Behavioral Effects of Extinction

• Extinction produces several behavioral effects in
  addition to a decline in a rate of response.
• Extinction Burst
• When extinction is started, operant behavior
  tends to increase in frequency.
• An initial increase in rate of response, or
  extinction burst, occurs when reinforcement is
  first withdrawn.
• Response Topography
• In addition to extinction bursts, operants show
  increases in operant variability, variations in
  form or topography as extinction proceeds.
• Antonitis (1951) and Pear (1985)

53
(No Transcript)
54
Behavioral Effects of Extinction

• Force of Response
• Reinforcement may be made contingent on the
  force of response, resulting in response
  differentation
• When extinction occurs, the force of lever
  pressing becomes more variable. Interestingly,
  some responses were more forceful than any
  emitted during reinforcement or during operant
  level. This increase in response force may be
  due to emotional behavior generated by extinction
  procedures.

55
Behavioral Effects of Extinction

• Emotional Responses
• A variety of emotional responses occur under
  conditions of extinction. Birds flap their
  wings, rats bite the response lever, and humans
  may swear and kick at a vending machine. One
  important kind of emotional behavior that occurs
  during extinction is aggression.
• Resistance to extinction
• The number of responses emitted by the bird at
  a rate of response during the last session may be
  used to index resistance to extinction.

56
The Partial Reinforcement Effect (PRE)

• Partial Reinforcement Effect
• Resistance to extinction is substantially
  increased when an intermittent schedule of
  reinforcement has been used to maintain behavior.
• The higher the rate of reinforcement, the greater
  the resistance to change.
• Extinction occurs more rapidly on behavior with a
  history of continuous reinforcement (CRF)
  relative to behavior with a history of
  intermittent reinforcement due to discrimination
  between reinforcement and extinction
• An organism can discriminate between CRF and
  extinction more easily than between a lean and
  intermittent schedule and no reinforcement

57
The Partial Reinforcement Effect

• Another interpretation of PRE involves stimulus
  generalization
• Conditions of the low rate of reinforcement on
  intermittent schedules are more similar to
  extinction than conditions on a CRF
• Organisms generalize from intermittent
  reinforcement to extinction, resulting in more
  time or responses to extinction
• Contact with the contingencies A rat reinforced
  for every 100 responses must emit 100 response in
  order to encounter the transition into
  extinction, while a rat on a CRF could contact
  extinction immediately.

58
Discriminative Stimuli and Extinction

• Skinner (1950), maximal responding during
  extinction is obtained only when conditions
  under which the response was reinforced are
  precisely reproduced (p. 204).
• If you want a response to extinguish more
  rapidly

59
Spontaneous Recovery and Extinction

• After a session of extinction, the response rate
  may be close to operant level.
• When the animal is placed in operant chamber the
  next day (still on extinction) it will respond
  above operant level Spontaneous Recovery.
• After repeated sessions of extinction, the level
  of recovery will decline.

60
Forgetting vs. Extinction

• Forgetting is behavior change due to the passage
  of time without opportunity to perform a
  behavior.
• Extinction is behavior change due to response
  performance without reinforcement.
• A very well learned response is quite resistant
  to behavior change due to lack of opportunity to
  perform or forgetting. Time itself can have
  little effect on a well learned response if
  occurrences of the response are reinforced when
  an opportunity for a response performance occurs.
• Extinction is a change in behavior due to
  performance without consequences. The passage of
  time will reduce the resistance to extinction of
  a particular response.

61
Remembering and Recalling

• In much of psychology, people and other organisms
  are said to store information about events in
  memory
• The use of the noun memory is an example of
  reification or treating an action as if it were a
  thing
• In behavior analysis, the verb remembering (or
  forgetting) is used to refer to the effect of
  some event on behavior after the passage of time

62
Remembering and Recalling

• For humans, we may say that a person recalls
  his/her trip to Costa Rica, when a picture of the
  trip occasions a verbal description of the
  vacation
• From a behavioral perspective, recalling the trip
  is behavior (mostly verbal) emitted now with
  respect to events that occurred in the past
• Remembering and recalling are treated as behavior
  processes rather than some mysterious thing
  (i.e., a memory) within us
• Behavior analysts assume that the event recalled
  is one that was described when it first occurred
• Recalling refers to the reoccurrence of behavior
  (mostly verbal) that has already occurred at
  least once

63
Remembering as Behavior

• Remembering involves behavior that occurred in
  the past that now reoccurs after a period of time
  has elapsed since the original performance.
• Do elephants really remember (or never forget?

64
Applying Extinction

• Extinction is an important role in behavior
  modification
• Williams (1959)-When put to bed by his parents a
  20-month-old boy would throw a temper tantrum
  requiring the parents to stay up with him.
• The parental attention given to the boy served as
  a reinforcement to the tantrums.
• Extinction was implemented by the parents leaving
  the room after the child was put to bed.
• The first extinction session, the tantrum lasted
  45 min. and on the third session only 10 min.
  After ten days the boy had no tantrums.

65
Applying Extinction

• The childs aunt reinforced his crying by staying
  in the room and his tantrums reoccurred.
• This intermittent reinforcement increases
  resistance to extinction of the tantrums
• The second extinction procedure took longer due
  to the intermittent reinforcement.
• The first procedure was more effective since the
  child was continuously reinforced.
