SPAM

1
SPAM Christian Loza Srikanth Palla Liqin Zhang
2
Overview

• Introduction
• Background
• Measurement
• Methods
• Compare different methods
• Conclusions

3
Introduction

• If you use email, it's likely that you've
  recently been visited by a piece of Spam- an
  unsolicited, unwanted messag, sent to you with
  out your permission.Sending spam violates the
  Acceptable Use Policy (AUP)of almost all ISP's
  and can lead to the termination of the sender's
  account.As the recipient directly bears the cost
  of delivery, storage, and processing, one could
  regard spam as the electronic equivalent of
  "postage-due" junk mail.

4
Introduction

• Spammers frequently engage in deliberate fraud to
  send out their messages. Spammers often use false
  names, addresses, phone numbers, and other
  contact information to set up "disposable"
  accounts at various Internet service providers.
  They also often use falsified or stolen credit
  card numbers to pay for these accounts. This
  allows them to move quickly from one account to
  the next as the host ISPs discover and shut down
  each one.

5
Introduction

• In recent years, the spam has show no signals of
  stopping growth
• This is mainly because it does work
• The advantage is that is a cheap way to increase
  the customer base.

6

• Spammers frequently engage in deliberate fraud to
  send out their messages. Spammers often use false
  names, addresses, phone numbers, and other
  contact information to set up "disposable"
  accounts at various Internet service providers.
  They also often use falsified or stolen credit
  card numbers to pay for these accounts. This
  allows them to move quickly from one account to
  the next as the host ISPs discover and shut down
  each one.

7

• Spammers frequently go to great lengths to
  conceal the origin of their messages. They do
  this by spoofing e-mail addresses . The spammer
  hacks the email protocol SMTP so that a message
  appears to originate from another email address.
  Some ISPs and domains require the use of SMTP
  AUTHallowing positive identification of the
  specific account from which an e-mail originates.

8

• One cannot completely spoof an e-mail address
  chain, since the receiving mailserver records the
  actual connection from the last mailserver's IP
  address however, spammers can forge the rest of
  the ostensible history of the mailservers the
  e-mail has ostensibly traversed. Spammers
  frequently seek out and make use of vulnerable
  third-party systems such as open mail relays and
  open proxy servers.

9
Address Collection

• Spammers may harvest e-mail addresses from a
  number of sources. A popular method uses e-mail
  addresses which their owners have published for
  other purposes. Usenet posts, especially those in
  archives such as Google groups, frequently yield
  addresses. Simply searching the Web for pages
  with addresses ? such as corporate staff
  directories ? can yield thousands of addresses,
  most of them deliverable.

10
Address Collection

• Spammers have also subscribed to discussion
  mailing lists for the purpose of gathering the
  addresses of posters. The DNS and WHOIS systems
  require the publication of technical contact
  information for all Internet domains spammers
  have illegally crawled these resources for email
  addresses. Many spammers utilize programs called
  Web Spiders to find email addresses on web
  pages.Because spammers offload the bulk of their
  costs onto others, however, they can use even
  more computationally expensive means to generate
  addresses.

11
Address Collection

• A dictionary attack consists of an exhaustive
  attempt to gain access to a resource by trying
  all possible credentials ? usually, usernames and
  passwords. Spammers have applied this principle
  to guessing email addresses ? as by taking common
  names and generating likely email addresses for
  them at each of thousands of domain
  names.Spammers sometimes use various means to
  confirm addresses as deliverable. For instance,
  including a Web bug in a spam message written in
  HTML may cause the recipient's mail client to
  transmit the recipient's address, or any other
  unique key, to the spammer's Web site.

12
Terminology

• To better understand the concepts in this
  presentation let us consider the following
  terminology.
• Mail User Agent (MUA). This refers to the program
  used by the client to
• send and receive e-mail from. It is usually
  referred to as the "mail client."
• An example of this is Pine or Eudora.
• Mail Transfer Agent (MTA). This refers to the
  program used running on the
• server to store and forward e-mail messages. It
  is usually referred to as the
• "mail server program." An example of this is
  sendmail or the Microsoft
• Exchange server.

13
The Mail Queue
14

• In a normal configuration, sendmail sits in the
  background waiting for new messages. When a new
  connection arrives, a child process is invoked to
  handle the connection, while the parent process
  goes back to listening for new connections.
• When a message is received, the sendmail child
  process puts it into the mail queue (usually
  stored in /var/spool/mqueue). If it is
  immediately deliverable, it is delivered and
  removed from the queue. If it is not immediately
  deliverable, it will be left in the queue and the
  process will terminate.
• Messages left in the queue will stay there until
  the next time the queue is processed. The parent
  sendmail will usually fork a child process to
  attempt to deliver anything left in the queue at
  regular intervals.

15
Structure of E-mail Message

• Email messages are compose of two parts
• 1. Headers (lines of the form "field value"
  which contain information about the
  message, such as "To", "From", "Date", and
  "Message- ID")
• 2. Body (the text of the message)

16
Example

• From johndoe_at_students.uiuc.edu Mon Jul 5
  234619 1999
• Received (from johndoe_at_localhost)
• by students.uiuc.edu (8.9.3/8.9.3) id
  LAA05394
• Mon, 5 Jul 1999 234618 -0500
• Received from staff.uiuc.edu (staff.uiuc.edu
  128.174.5.59)
• by students.uiuc.edu (8.9.3/8.9.3) id
  XAA24214
• Mon, 5 Jul 1999 234625 -0500
• Date Mon, 5 Jul 1999 234618 -0500
• From John Doe ltjohndoe_at_students.uiuc.edugt
• To John Smith ltjsmith_at_staff.uiuc.edugt
• Message-Id lt199907052346.LAA05394_at_students.uiuc.e
  dugt
• Subject This is a subject header.
• This is the message body. It is seperated from
  the headers by a blank
• line.
• The message body can span multiple lines.

17

• Here is an example SMTP transaction
• 1. Client connects to server's SMTP port (25).
• 2. Server 220 staff.uiuc.edu ESMTP Sendmail
  8.10.0/8.10.0 ready Mon, 13 Mar 2000 145408
  -0600
• 3. Client helo students.uiuc.edu
• 4. Server 250 staff.uiuc.edu Hello
  root_at_students.uiuc.edu 128.174.5.62, pleased to
  meet you
• 5. Client mail from johndoe_at_students.uiuc.edu

• 6. Server 250 2.1.0 johndoe_at_students.uiuc.edu.
  .. Sender ok
• 7. Client rcpt to jsmith_at_staff.uiuc.edu
• 8. Server 250 2.1.5 jsmith_at_staff.uiuc.edu...
  Recipient ok
• 9. Client data
• 10. Server 354 Enter mail, end with "." on a
  line by itself
• 11. Client
• Received (from johndoe_at_localhost)
• by students.uiuc.edu (8.9.3/8.9.3) id
  LAA05394
• Mon, 5 Jul 1999 234618 -0500
• Date Mon, 5 Jul 1999 234618 -0500
• From John Doe ltjohndoe_at_students.uiuc.edugt

18
Delivering Spam messages

• Early on, spammers discovered that if they sent
  large quantities of spam directly from their ISP
  accounts, recipients would complain and ISPs
  would shut their accounts down. Thus, one of the
  basic techniques of sending spam has become to
  send it from someone else's computer and network
  connection. By doing this, spammers protect
  themselves in several ways they hide their
  tracks, get others' systems to do most of the
  work of delivering messages, and direct the
  efforts of investigators towards the other
  systems rather than the spammers themselves.

19
Mail filters

• A mail filter is a piece of software which takes
  an input of an email message. For its output, it
  might pass the message through unchanged for
  delivery to the user's mailbox, it might redirect
  the message for delivery elsewhere, or it might
  even throw the message away. Some mail filters
  are able to edit messages during processing.

20
Introduction

• Application of Text Categorization
• The Spam classification is defined as a binary
  problem Email is Spam OR is not Spam.
• Automatic text categorization assigns emails to
  one of the above categories, using different
  methods
• One of this methods is the Centroid-based
  classification

SPAM
NOT SPAM
21
Background

• Text Classification classify documents into
  categories
• Spam
• un-spam
• Classification process
• preprocess message
• Remove tag
• Stop-word removal
• Word stemming
• Training --- build the classification model
• Testing --- evaluate the model

22
Methodologies

• Bayes-Naives
• Centroid-Based
• Content-based

23
Bayesianism

• Is the philosophical tenet that the mathematical
  theory of probability applies to the degree of
  plausibility of a statement. This also applies to
  the degree of believability contained within the
  rational agents of a truth statement.
  Additionally, when a statement is used with
  Bayes' theorem, it then becomes a Bayesian
  inference.

24
Baye's Rule

• If A and B are two separate but possibly
  dependent random events, then
• Probability of A and B occurring together
  Pr(A,B)
• The conditional probability of A, given that B
  occurs Pr(AB)
• The conditional probability of BB, given that AA
  occurs Pr(BA)

25

• From elementary rules of probability
• Pr(A,B)
  Pr(AB)Pr(B) Pr(BA)Pr(A)
• Dividing the right-hand pair of expressions by
  Pr(B) gives Bayes' rule
• PrAB
  PrBAPrA
•
  -----------------
•
  PrB
•


26

• In problems of probabilistic inference, we are
  often trying to estimate the most probable
  underlying model for a random process, based on
  some observed data or evidence. If AA represents
  a given set of model parameters, and BB
  represents the set of observed data values, then
  the terms in equation are given the following
  terminology
• PrA is the prior probability of the model A (in
  the absence of any evidence)
• PrB is the probability of the evidence B
• PrBA is the likelihood that the evidence B was
  produced, given that the model was A
• PrAB is the posterior probability of the model
  being A, given that the evidence is B.

27

• Mathematically, Bayes' rule states
• likelihood prior
• posterior ------------------------------
• marginal likelihood

28
Representing E-mail for statistical Algorithms

• All statistical algorithms for spam filtering
  begin with a vector representation of individual
  e-mail messages.
• The length of the term vector is the number of
  distinct words in all the e-mail messages in the
  training data. The entry for a particular word in
  the term vector for a particular e-mail message
  is usually he number of occurences of the word in
  the e-mail message.

29
Training data comprising four labeled e-mail
messages

• Table below presents toy training data comprising
  four e-mail messages. These data contain ten
  distinct words the, quick, brown, fox, rabbit,
  ran, and, run, at, and rest.
• Message Spam
• 1 The quick brown fox no
• 2 The quick rabbit ran and ran
  yes
• 3
  rabbit run run run no
• 4
  rabbit at rest yes

30
Term Vectors corresponding to training data

• and at brown fox quick rabbit ran rest run the
• 1 1 0 0 0 1 1 1 0 0 0 0 1
• 2 1 2 0 0 2 0 0 1 0 1 0 1
• 3 0 0 0 0 3 1 1 1 0 0 1 0
• 4 2 0 3 2 0 0 0 0 1 0 1 1

31

• If the training data comprise thousands of e-mail
  messages, the number of distinct words often
  exceeds 10,000. Two simple strategies to reduce
  the size of the term vector somewhat are to
  remove stop words (words like and, of, the,
  etc.) and to reduce words to their root form, a
  process known as stemming (so, for example, ran
  and run reduce to run). Table 3 shows the
  reduced term vectors along with the spam label.

32
Term vectors after stemming and stop word
removal, spam label coded as 0no,1yes

• X1 X2 X3 X4 X5 X6 Y
• brown fox quick rabbit rest run Spam
• 1 1 1 1 0 2
  1 0
• 2 0 1 1
  0 3 0
  1
• 3 0 0 1
  0 0 1
  0
• 4 0 0 0
  1 1 2
  1

33
Navie Bayes for Spam

• Let X (X1,. .., Xd) denote the term vector for
  a random e-mail message, where d is the number of
  distinct words in the training data, after
  stemming and stopword removal. Let Y denote the
  corresponding spam label. The Naive Bayes model
  seeks to build a model for
• Pr(Y 1X1 x1,. .., Xd xd).
• From Bayes theorem, we have
• Pr(Y 1X1 x1,. .., Xd xd) Pr(Y 1)
  Pr(X1x1,. .., Xd xdY 1)
•
  ------------------------------------------------
•
  Pr(X1 x1,. .., Xd xd)

34
Centroid-based method

• The documents are represented using a
  Vector-space model.
• Each document is represented as a Term Frequency
  vector (TF)

t2
d1
d4
d3
d2
t1
35
Centroid-based method

• A refinement of this model is the inverse
  document frequency (IDF)
• This is to limit the discrimination power of
  frequent terms and stop words, and to emphasize
  words that appear in specific documents.
• IDF is log(N/dfi)
• The size of the document is normalized

36
Centroid-based method

• The distance between two vectors is defined using
  the cosine function
• Finallly, one Centroid Vector C is defined for
  each category (spam/not spam) as

37
Centroid-based method

• We can measure the similarity between one
  document and the Centroid of the category with
  the following function

38
Steps Centroid-based Method

• TRAINNING
• Determine the document vectors using TD/IDF.

t2
d7
d8
d5
d6
d3
d2
d1
d4
t1
39
Steps Centroid-based Method

• TRAINNING
• Calculate the centroid for the categories SPAM
  and NOT SPAM

t2
d7
CSPAM
d8
d5
d6
d3
CNOT SPAM
d2
d1
d4
t1
40
Steps Centroid-based Method

• CLASSIFICATION
• Given a new document dn, calculate the document
  vector representation (like in the training stage)

t2
dn
t1
41
Steps Centroid-based Method

• CLASSIFICATION
• Measure the distance between the vector dn and
  the Centroids of the Categories SPAM / NOT SPAM

t2
CSPAM
dn
CNOT SPAM
t1
42
Steps Centroid-based Method

• CLASSIFICATION (cont.)
• Measure the distance between the vector dn and
  the Centroids of the Categories SPAM / NOT SPAM

t2
CSPAM
dn
CNOT SPAM
t1
43
Steps Centroid-based Method

• FINAL RESULT
• Obtain the maximum similarity between the
  document and the Centroids of SPAM and NOT SPAM
• for i1,2 where 1SPAM and 2NOT SPAM

44
Analysis of Results

• The standard methodology for measuring
  performance of text classification methods are
  the Precision and Recall

n. of correctly predicted positives N of
predicted positive examples
P
n. of correctly predicted positives N of all
positive examples
R
45
Analysis of Results

• None Precision or Recall can give a good measure
  by themselves. To have an idea of the
  performance, we have to combine them.

R
better
2PR PR
F
P
46
Some results

• Compared agains kNN and Naïve Based, the Centroid
  method performs better

47
Content Based Approach

• Spam can be detected
• before reading the message --- non-content
  based
• Based on special protocol 3 voip protocol
• Based on address book1 build an email network
• Based on IP address 4
• ..
• After process the content of the email ---
  content based

48
Content-based Approach

• Non-content based approach
• remove spam message if contain virus, worms
  before read.
• leaves some messages un-labeled
• Content based method
• widely used method
• may need lots pre-labeled message
• label message based its content
• Zdziarski5 said that it's possible to stop
  spam, and that content-based filters are the way
  to do it
• Focus on content based method

49
Method of content-based

• Bayesian based method 6
• Centroid-based method7
• Machine learning method 8
• Latent Semantic indexing LSI
• Contextual Network Graphs (CNG)
• Rule based method9
• ripper rule a list of predefined rules that can
  be changed by hand
• Memory based method10
• saving cost

50
Measurement

• Accuracy the percentage of correct classified
  correct/(correct un-correct)
• False positive if a message is a spam, but
  misclassify to un-spam.
• Goal
• Improve accuracy
• Prevent false positive

Correct Un-correct
Spam
No spam
False positive
51
measurement
52
Rule-based method

• A list of predefined rules that can be changed by
  hand
• ripper rule
• Each rule/test associated with a score
• If an email fails a rule, its score increased
• After apply all rules, if the score is above a
  certain threshold, it is classified as spam

53
Rule-based method

• Advantage
• able to employ diverse and specific rule to
  check spam
• Check size of the email
• Number of pictures it contains
• no training messages are needed
• Disadvantage
• rules have to be entered and maintained by hand
  --- cant be automatically

54
Latent Semantic indexing

• Keyword
• important word for text classification
• High frequent word in a message
• Can used as an indicator for the message
• Why LSI?
• Polysemy word can be used in more than one
  category
• ex Play
• Synonymous if two words have identical meaning
• Based on nearest neighbors based algorithm

55
Latent semantic indexing

• consider semantic links between words
• Search keyword over the semantic space
• Two words have the same meaning are treated as
  one word
• eliminate synonymous
• Consider the overlap between different message,
  this overlap may indicate
• polysemy or stop-word
• two messages in same category

56
Latent semantic indexing

• Step1 build a term-document matrix X from the
  input documents

Doc1 computer science department Doc2 computer
science and engineering science Doc3 engineering
school
Computer science department and
engineering school Doc1 1 1
1 0 0
0 Doc2 1 2
0 1 1
0 Doc3 0 0 0
0 1 1
57
Latent semantic indexing

• Step2 Singular value Decomposition (SVD) is
  performed on matrix X
• To extract a set of linearly independent FACTORS
  that describe the matrix
• Generalize the terms have the same meaning
• Three new matrices TSD are produced to reduce
  the vocabularys size

58
Latent Semantic indexing

• Two document can be compared by finding the
  distance between two document vector, stored in
  matrix X1
• Text classification is done by finding the
  nearest neighbors assign to category with max
  document

59
Nearest neighbors method classify the test
message to be UN-SPAM
Spam Un-spam Test
60
Latent Semantic Indexing

• Advantage
• Entire training set can be learned at same time
• No intermediate model need to be build
• Good for the training set is predefined
• Disadvantage
• When new document added, matrix X changed, and
  TSD need to be re-calculated
• Time consuming
• Real classifier need the ability to change
  training set

61
Contextual network Graphs

• A weighted, bipartite, undirected graph of term
  and document nodes

t1 W11w21 1 d1 w11w12w13 1
t1
w21
w11
t2
w22
w12
d1
d2
w13
w23
t3
At any time, for each node, the sum of the weigh
is 1
62
Contextual network graphs

• When new document d is added, energizing the
  weights at node d, and may need re-balance the
  weights at the connected node
• The document is classified to the one with
  maximum of energy (weight) average for each class

63
Comparison Bayesian, LSI,CNG, centroid, rule-based
64
Result
65
Result and conclusion

• LSI CNG super Bayesian approach 5 accuracy,
  and reduce false positive and negatives up to 71
• LSI CNG shows better performance even with
  small document set

66
Comparison content based and non-content based

• Non-content based
• dis-adv
• depends on special factor like email address, IP
  address, special protocol,
• leaves some un-classified
• Adv detect spam before reading message with
  high accuracy

67

• Content based
• Disadvantage
• need some training message
• not 100 correct classified due to the spammer
  also know the anti-spam tech.
• Advantage
• leaves no message unclassified

68
Improvement for spam

• Combine both method
• 1 proposes an email network based algorithm,
  which with 100 accuracy, but leaves 47
  unclassified, if combine with content based
  method, can improve the performance.
• Build up multi-layers11
• 11 Chris Miller, A layered Approach to
  enterprise antispam

69
Data set for spam

• Non-content based
• Email network
• One authors email corpus, formed by 5,486
  messages
• IP address -- none
• Content based

70
Data set for spam

• LSI CNG
• Corpus of varying size (250 4000)
• Spam and un-spam emails in equal amount
• Bayesian based
• Corpus of 1789 email
• 211 spam, 1578 non-spam
• Cetroid based
• Totally 200 email message
• 90 spam, 110 non-spam

71
Most recently used Benchmarks

• Reuters
• About 7700 training and 3000 test documents,
  30000 terms,135 categories, 21MB.
• each category has about 57 instances
• collection of newswire stories
• 20NG
• About 18800 total documents, 94000 terms, 20
  topics, 25MB.
• Each category has about 1000 instances
• WebKB
• About 8300 documents, 7 categories, 26 MB.
• Each category has about 1200 instances
• 4 university website data
• Above three are well-known in recently IR with
  small in size and used to test the performance
  and CPU scalability

72
Benchmarks

• OHSUMED
• 348566 document, 230000 terms and 308511 topics,
  400 MB.
• Each category has about 1 instance
• Abstract from medical journals
• Dmoz
• 482 topics, 300 training document for each topic,
  271MB
• Each category has less than 1 instance
• taken from Dmoz(http//dmoz.org/) topic tree
• Large dataset, used to test the memory
  scalability of a model

73
Some facts

• Spam is a growing problem, and the research on
  this topic has become more relevant the last
  years
• Spam grows because it works.
• Many commercial products try to fight spam. Most
  of them rely on the exposed techniques, or
  combination of them
• Spam damages economy, more than hackers or viruses

74
Some facts

• Damages attributed to Spam are calculated around
  10.4 billion in 2003, 58 112 billion in 2004,
  and is projected to cross 200 billion worldwide
  in 2005.
• 1.6 trillion unsolicited messages were sent in
  2004.

75
Conclusions

• Spam is a problem that causes a great impact of
  global business
• We presented three methods for Spam
  classification.
• The benchmarks on this three methods suggest that
  combination of the methods perform better than
  the methods alone

76
Conclusions

• Spam classifiers can be Content Based, and Non
  Content Based
• Content Based Rules, Naïve Bayes, Centroid
• Non content work without reading the content of
  the mail

77
Conclusions

• Researchers have found ways to increase the
  accuracy of all the methods, using heuristics and
  combining them
• Spammers also learn how to avoid spam filters
• No single method is perfect in all situations

78
Sources

• Slide 1, image ttp//www.ecommerce-guide.com
• Slide 1, image ttp//www.email-firewall.jp/produc
  ts/das.html

79
References

• Anti-spam Filtering A centroid-based
  Classification Approach, Nuanwan Soonthornphisaj,
  Kanokwan Chaikulseriwat, Piyan Tang-On, 2002
• Centroid-Based Document Classification Analysis
  Experimental Results, Eui-Hong (Sam) and George
  Karypis, 2000
• Multi-dimensional Text classification, Thanaruk
  Theeramunkog, 2002
• Improving centroid-based text classification
  using term-distribution-based weighting system
  and clustering, Thanaruk Theeramunkog and
  Verayuth Lertnattee
• Combining Homogeneous Classifiers for
  Centroid-based text classifications, Verayuth
  Lertnattee and Thanaruk Theeramunkog

80
References

• 1 P Oscar Boykin and Vwani Roychowdhury,
  Personal Email Networks An Effective Anti-Spam
  Tool, IEEE COMPUTER, volume 38, 2004
• 2 Andras A. Benczur and Karoly Csalogany and
  Tamas Sarlos and Mate Uher, SpamRank - Fully
  Automatic Link Spam Detection, citeseer.ist.psu.ed
  u/benczur05spamrank.html
• 3. R. Dantu, P. Kolan, Detecting Spam in VoIP
  Networks, Proceedings of USENIX, SRUTI (Steps
  for Reducing Unwanted Traffic on the Internet)
  workshop, July 05(accepted)
• 4. IP addresses in email clients
  ttp//www.ceas.cc/papers-2004/162.pdf
• 5 Plan for Spam ttp//ww.paulgraham.com/spam.htm
  l

81
References

• 6 M. Sahami, S. Dumais, D. Heckerman, and E.
  Horvitz. 1998, A Bayesian Approach to Filtering
  Junk E-Mail, Learning for Text Categorization
  Papers from the AAAI Workshop, pages 5562,
  Madison Wisconsin. AAAI Technical Report WS-98-05
• 7 N. Soonthornphisaj, K. Chaikulseriwat, P
  Tang-On, Anti-Spam Filtering A Centroid Based
  Classification Approach, IEEE proceedings ICSP
  02
• 8 Spam Filtering Using Contextual Networking
  Graphs www.cs.tcd.ie/courses/csll/dkellehe0304.pdf

• 9 W.W. Cohen, Learning Rules that Classify
  e-mail, In Proceedings of the AAAI Spring
  Symposium on Machine Learning in Information
  Access, 1996
• 10 G. Sakkis, I. Androutsopoulos, G. Paliouras,
  V. Karkaletsis, C.D. Spyropoulos, P.
  Stamatopoulos, A memory based approach to
  anti-spam filtering for mailing lists,
  Information Retrieval 2003
