IT158 LAN Installation Project Team: One Assignment: IT 502 Lab

1
IT158 LAN Installation ProjectTeam One
Assignment IT 502 Lab

• Date May 24, 2000
• Course IT 158 Applied Computer Networking
• Instructor Bill Walls
• Semester Spring 2001

2
Networking Team Personnel

• Gurjinder Pooni Manager
• Mario Rosso Documentation Chief
• Yogesh Patel Project Advisor
• Marty Kamimoto Telecom Outlet Installer
• Sukhwinder Gill Telecom Outlet Installer
• Maulik Dave Wire Technician
• Sugianto Co-Manager
• David Krieger Jack Patch Panel Terminator
• Erick Holoday Jack Patch Panel Terminator

3
Networking Team Personnel

• Davey T. Brown Wire Technician
• Young Lee Wire Technician
• Tou Vu Wire Technician
• James Moua Wire Technician
• Neeraj Sharma Wire Technician
• Annarag Grupta Wire Technician
• Walter Tell-Mariti Wire Technician
• James Martinez Cable Test Engineer
• Jorge Oritiz Cable Test Engineer

4
Objectives

• Refit the IT 502 Networking Lab to meet Cisco
  Networking Academy Standards
• Configure and build a Local Area Network based on
  the TIA/EIA 568A cabling standard
• Gain practical experience in the application of
  network concepts theorized in seminar and class
  discussion

5
IT 502 Lab Floor Plan
6
Intended Users

• The current and projected IT502 lab user
  community consists of undergraduate and graduate
  technology students with high degree of computer
  experience

7
Inventory of User Needs

• Users require high-speed processing and
  connection speeds to facilitate completion of
  CAD/CAM and simulation coursework
• Must facilitate manufacturing process control and
  instrumentation applications
• Internet/Web/E-mail access must be available 100
  of the time
• Individual and public data storage is desirable
• Streaming media will be implemented in the form
  of real-time audio, video, and simulations

8
Inventory of Legacy Components

• Use as much existing CAT 5 horizontal cabling as
  possible from previous installation
• Replace overheating Ethernet switch
• Discard errant patch cables
• Assess salvage all PCs currently in lab

9
Workstation Database
10
Bill of Materials
11
Access Method and Cabling Infrastructure

• CSMA/CD IEEE 802.3 Ethernet
• TIA/EIA 568A Standard
• 100BaseTx
• 100Mbps
• Cat 5 Unshielded Twisted Pair (UTP)

12
Installation Tasks

• Install Outlets
• Install jacks
• Run cables
• Punch-down cables into patch panels
• Test cables
• Document cables and ports
• Install switches and routers
• Configuring routers
• Install and configuring PCs

13
Schedule
14
Logical Topology
15
Network Layer Protocol

• TCP/IP
• Static or Dynamic (DHCP) IP Addressing (to be
  determined)
• Firewall protection recommended

16
Physical Topology
17
Main Distribution Facility Equipment
18
Cut-Sheet Template
19
Extrapolate for Future Growth

• Plan for 15 to 40 buffer capacity
• Increased students due to enrollment surge
• Movement to Craig School of Business
• High-Speed CAD/CAM workstations
• Integration into CSUF LAN/Internet
• Streaming audio and video

20
Fault Tolerance Recommended Requirements

• APC Uniterruptible Power Supply for Primary
  Domain Controller
• Raid Level 1 (Mirror Set)
• Drive Mirroring
• Contingency Recovery Plan
• Nightly Tape Backup
• Documented Tape Rotation System
• On-site Off-site Tape Storage

21
Physical Security Requirements

• All PCs must have keyed or combination locks
• Server must be secured to table with lock
• Door to MDF must lock
• Lab door should remained locked when classes are
  not in session

22
Conclusions

• Benefits of practical experience in the
  application of conceptual materials
• LAN construction success factor 85
• Remaining tasks
• Complete HCC punch-down to patch panel
• Test remaining telecom outlet boxes
• Configure PCs, routers, and switches
• Handoff support activities to subsequent class

23
Recommendations/Lessons Learned

• Improve preliminary planning process
• Ensure availability of tools and supplies
• Implement 20 min. team meetings prior to each
  work period to schedule activities and assign
  action items
• Establish project earlier in semester
• Engineer quality at every step

24
Applicable Links

• IT158 Group One Website members.tripod.com/maros
  so/it158
• CSUF IT Department www.csufresno.edu/indtech
• Cisco Systems Homepage www.cisco.com
• Cisco Networking Academy student.netacad.net
• TIA -www.tiaonline.org
• EIA -www.eia.org
• ANSI -web.ansi.org/default.htm

25

• IEEE -www.ieee.org
• IEEE 802.3 Working Group -grouper.ieee.org/groups/
  802/3/index.htm
• Siemon Cabling Systems Standards Page
  www.siemon.com/standards/default.asp
• ISO -www.iso.ch
• BCS Cabling Standards Update -www.cablingstandards
  .com

26
Thank You For Your Time
