PCD Milling Cutter

1
PCD Milling Cutter
2
(No Transcript)
3

• PCD milling cutters are also termed as PCD End
  Mills.
• These are used for-
• generating holes with higher material removal
  rate as compared to pcd reamers
• facing as well as milling operations on
  non-ferrous components
• Features/Characteristics-
• Longer tool life
• Excellent tool life
• secures smooth and superior surface on the work
  piece
• The most economic and practical device for
  ceramic milling inserts
• Applications of PCD Milling Cutter
• for machining various panels for cell phones, MP3
  and MP4
• for machining decorating parts such as photo
  frames and CD disc holders etc.

4
Diamond Tools for Contact Lenses
5
(No Transcript)
6

•



•


  Diamond Tools for
  Contact Lenses
• Diamond tools are used by contact lens
  manufacturers for manufacturing Contact lens.
  Special purpose tools are also developed as per
  customer drawing specification.
• Different materials demand different tool
  geometries to maximize cutting efficiency. Based
  on a standard arc of 120 degrees (other angles
  are available. All tools are wear-resistant and
  designed to maintain their precision for a
  maximum length of time.
• Cobalt is used as one of the major components for
  the matrix by nearly every diamond tool producer
  in the world. But it is quite expensive, and
  today almost all diamond tools manufacturers use
  Carbonyl Iron Powder in their alloys to replace
  cobalt as much as possible. Though cobalt has
  sufficient mechanical properties for this
  application, it does not bind to diamonds very
  well. In contrast, Carbonyl Iron chemically bonds
  to the diamond surface by the formation of iron
  carbide. Therefore a combination of both the
  metals is often used.
• Quality control is set to keep the edge chip free
  at 500x magnification while maintaining a smooth
  and facet-free radius. Standard tools are
  frequently used with two-axis lathes for
  roughing-out purposes.

7
PCD Reamer
8
(No Transcript)
9

• A PCD Reamer is used for-
• Reaming holes on the work piece with high precise
  accuracy
• Machining non-ferrous metals
• the components which require close tolerances and
  bore geometry
• Characteristics
• Balancing tool
• Through Coolant Holes
• Lubricated guide pads
• No adjustment required
• Benefits of using pcd reaming tools
• Tool life is long
• low cost
• better quality
• High performance
• Applications of PCD Reamer

10
About Us

• Rudrali Hi Tech Tools Pvt. Ltd.
• Address
• E-94, MIDC, Akkalkot Road, Solapur-413006
  (Maharashtra) India.
• Contact
• 1.Phone [phone]
• 2.Fax [phone]
• 3. E-mail hitech_at_rudrali.com
• 4.Website http//www.rudrali.com/hitech/
