What This Presentation Will Cover: Hybrid Success Stories .

1
New Options For Wireless Monitoring SCADA

• Hybrid SCADA
• Combining Traditional SCADA
• with Cellular Telemetry
• Or Managed Cellular to Web SCADA
• Presented by
• John K Collings
• MISSION Communications

2
Overview

• What This Presentation Will Cover
• Hybrid Success Stories It Already Works
• - Combining Traditional SCADA with Cellular
• Digital Data Cellular Networks Today
• Not CDPD, not Dial Up
• What Are They
• How Do They Work
• How Well Do They Work
• How Much Do they Cost
• Off The Shelf Cellular or Managed Cellular

3
Success Stories

• Tuscaloosa Alabama
• 100 Water and Waste Water Sites
• Original Quotes Were 6 Million
• CH2M Hill mixed managed cellular in at 35 of the
  sites and winning bid was approx 4.5 million

• Managed cellular units come into Intellution via
  OPC link

• Beaufort/Jasper, South Carolina
• Gresham Oregon

4
Digital Data Cellular Networks Today

• Original Efforts
• Dial Up
• CDPD
• Now Have 3G Cellular Networks
• Nationwide, All Carriers
• SMS (Short Message Service Text Messaging)
• UDP TCPIP
• GSM/GPRS, CDMA/1XRTT
• 28 kbps 1,000kbps
• Public/Private IPs

5
Cellular Data Using Off The Shelf Components

• How Does Cellular Data SCADA Work?
• Most All Have 4 Parts
• Field RTU
• PLC/Some Controllers and Cell Modem
• Cell Site
• Encrypted Transmissions
• Cellular, But Not Voice
• New 3rd Generation Data GPRS CDMA
• Available On All Cell Providers
• National, Wireless Data Networks
• Private/Public IP
• NAD
• No Custom Routes
• Standard Data Pricing
• Customer HMI
• Live or Data Dumps
• Non Standard Polling
• Internet or Cell Modem

3.
Cell Carrier Network
IS - 41
2.
Internet or Cell Modem
Local Tower
4.
Customer HMI
1.
PLC / Modem
6
Managed Cellular Data

• How Does Managed Cellular SCADA Work?
• Has 5 Parts
• Field RTU
• Standardized
• Power Supply, Radio, I/O, Modbus
• Connects to Controller or PLC
• Cell Tower
• Cellular, But Not Voice
• New 3rd Generation Data GPRS CDMA
• Available On All Cell Providers
• National, Wireless Data Networks
• Private Pipes, Increased Security
• Flexibility for Permanent Connections
• Managed Central Servers
• All Carrier Issues/Data Managed
• Flat Fees
• OPC Database at Customer HMI
• HMI Scans RTU Tags

3.
4.
Central Managed Servers
Cell Carrier Network
Private Network
IS - 41
2.
VPN, Frame and Internet Backup
Local Cell Tower
5.
OPC Database and Customer HMI (With Redundancy)
Managed RTU
Integrated Hardware With Cell Radio and Digital
/Analog I/O
7
How Well Does It Work

• How Well Does It WorkDepends On Needs
• If Only Need Data LoggingWorks Great
• Data Can Come In Late And No Problem
• Many ProvidersVery Effective And Cost Efficient
• If Need Reliable AlarmsOnly A Few Providers
• New IndustryExperience Counts
• If Need Reliable Realtime DataOne Provider
• Realtime Is Hard To Do Reliably
• The Best Average End To End Up Time Of 99.7

8
Why Consider Managed Cellular In A Hybrid System

• Why Data Cellular SCADA
• Usability
• Very Simple Flexible
• Reliability
• End To End Uptime Can Be 99.7
• Survivability
• Proven In Hurricanes And Severe Storms
• Security
• Meets AWWA Homeland Security Standards

9
Why Consider Managed Cellular

• Some Of How It Can Help
• Data Cellular SCADA
• From Box To Running In A Morning
• Information To You AnywhereSecurely
• Very Simple To Install, Operate Service
• Fits Easily Into Existing SCADA Systems
• Use It For
• Stand Alone Sites Where This Is All You Need
• Backup to Existing SCADA Sites
• Fill-In For Hard To Reach Or Lower Priority
  Sites


10
How Much Does It Cost

• How Much Does It Cost
• Systems Have Two Parts
• A Complete RTU And An Annual Service Fee Per RTU
• Some Have Flat Rate Fees, Some Charge Over Use
• Depends If Need Daily, Hourly Or Realtime
• Hourly RTUs 1,200 Range 300 - 350 Annual
  Fee

• Realtime RTUs 2,000 Range 550 Annual Fee
• Costs vs Dialers or Traditional SCADA

11
The Best News Mix and Match

• Dont Give Up One For The Other
• All Can Co-exist On The Same System
• Use National Data Networks
• High cost sites
• Poor performance sites
• Redundancy
• Outlying sites
• New projects
• Upgrades and replacements

12
Conclusion

• Conclusion
• Data Cellular Systems Are Here To Stay
• They Meet Security and Performance Needs
• The Networks Continue To Upgrade and Expand
• Its A Competitive Environment
• Performance Is Going Up
• Prices Are Going Down
• Data Cellular SCADA Systems Are Now A Permanent
  Contender For Your Monitoring and SCADA Business
