Code Selection for Media Processors with SIMD Instructions

1
Code Selection for Media Processors with SIMD
Instructions

• Rainer Leupers
• DATE00

2
Code Selection

• Source ? Intermediate Representation (IR) ?
  Assembly
• Back end consists of
• code selection
• optimization, etc
• The primary goal of traditional code selectors is

• to find the minimum cost machine code that is
  equivalent to a given IR
• cost latency, size,
• the best known code selector twig by Aho et
  al.TOPLAS89
• In this paper, extend twig to handle SIMD
  instructions
• SIMD instruction manipulates data-stored
  subregisters instead of full registers (in this
  paper)

front end
back end
3
Code Generation Using Tree Matching and Dynamic
Programming (Twig)

• Alfred V. Aho et al.
• TOPLAS89

4
Code Generation by Tree Matching An Example
(4)

• IR of ai b
• Output of a front-end
• Input of a code generator

(3)
(2)
(1)

• Machine code of the IR
• Output of the code generator

(1)
(2)
(3)
(4)
5
Code Generation by Tree Matching An Example

• Reduction rules

6
Code Generation by Tree Matching An Example
i0, ca
i0, jSP
7
Code Generation by Tree Matching An Example

• What if several matches exist?
• Ties are broken by cost
• How can the global cost be considered at local
  decision steps?
• By dynamic programming!

?
8
Code Generation by Tree Matching An Example
9
Code Generation by Tree Matching An Example

• The minimum-cost cover of the IR of ai b !

10
Dynamic Programming for Minimum-Cost Covering

• Informally, a necessary and sufficient condition
  for a problem to have an optimal dynamic
  programming algorithm is that
• the problem exhibits optimal substructure!
• For the problem of optimal code generation, OK
• Partition the problem of generating optimal code
  for an expression E into subproblems of
  generating optimal code for the subexpressions
• and later merge.. (with some manipulation..)

11
When Common Subexpressions Exists..
?
b a1 c a1

• The problem of optimal code generation becomes
  intractable
• The algorithm does not guarantee an optimal
  solution

12
Code Selection for Media Processors with SIMD
Instructions

• Rainer Leupers
• DATE00

13
Code Selection

• Source ? Intermediate Representation (IR) ?
  Assembly
• Back end consists of
• code selection
• optimization, etc
• The primary goal of traditional code selectors is

• to find the minimum cost machine code that is
  equivalent to a given IR
• cost latency, size,
• the best known code selector twig by Aho et
  al.TOPLAS89
• In this paper, extend twig to handle SIMD
  instructions
• SIMD instruction manipulates data-stored
  subregisters instead of full registers (in this
  paper)

front end
back end
14
SIMD Instructions

• Media Processors..
• TI C62xx, Philips Trimedia, Intel MMX
• Typically, word length of media processors 32
  bits. But,
• audio data 16 bits, video data 8 bits ? waste
  of resources !
• So, they provide special instructions, called
  SIMD instr.
• virtually split each full register into multiple
  subregisters and
• perform identical computations on the
  subregisters in parallel
• But, existing code selection techniques are not
  applicable..
• Ad hoc techniques compiler intrinsics,
  hand-optimized libraries

15
Why cant traditional code selectors be used for
SIMD?

• Recall Ahos algorithm
• Processes one data flow tree (DFT) after another
• But, to select SIMD instructions, it requires to
  simultaneously cover multiple DFTs !
• Then, why dont we select SIMD instructions after
  (traditional) code selection step?
• Register allocation.. that is,
• if multiple values share a single 32-bit
  register, their live ranges may interfere !
• So, we should be much more conservative. (c.f.
  Gebotys, DAC00)

16
An Example of Parallelization

• SIMD instructions
• ADD2
• Two 16 bits add ops
• LOAD2
• Two 16 bits load ops
• STORE2
• Two 16 bits store ops

17
A Difficulty in Exploiting SIMD Instructions

• Parallel load store..
• How to check that the memory address is
  contiguous
• In terms of PL community, must-alias analysis
• In this paper, traditional data flow analysis was
  used
• For non-toy programs, more strong analysis
  techniques needed (e.g., abstract interpretation,
  constraint-based analysis)

18
Overview of the Code Generator

• 1 Identify contiguous load/store operations
• 2 Add pseudo reduction rules to the original
  DFTs
• 3 Find alternative covers for the modified DFTs
  by Ahos dynamic programming algorithm (Covering
  Phase)
• - may contain invalid covers (cannot avoid
  when directly applying Ahos algorithm)
• 4 Select a valid cover that maximizes the use
  of SIMD instructions (Selection Phase)
• - transform into ILP formulation
• - the validity constraint can be easily
  expressed in the ILP formulation

19
Covering Selection Phases..

• Recall Ahos algorithm
• When find a cover,
• by dynamic programming
• in a bottom-up manner
• only one optimal solution is stored for each node
• Ties are broken arbitrarily
• Selecting phase is trivial
• The uniquely stored cover directly corresponds to
  machine instructions
• For the problem with SIMD instrs., why not find a
  global optimum solution at covering phase?
• Enforcing validity condition is difficult at
  covering phase if ahos dynamic programming
  covering algorithm is to be used..
• So, at covering phase, find alternative solutions
  among which a global optimal solution exists, and
  then
• Select the optimal solution by enforcing
  validity condition

20
Covering Phases An Example

• a1 b1c1
• a2 b2c2
• b1 mem1 (16 bits)
• b2 mem2 (16 bits)
• c1 .. , c2

2
reg_lo

reg_lo
reg_lo
reg
2
reg
reg
reg_hi
reg_hi
reg_hi
a1
a2
load
reg

addr

c2
c1
b2
b1
fetch
fetch
fetch
fetch
mem2

mem1

21
Selection Phases

• What is a necessary and sufficient condition for
  validity ?
• Each node is covered by exactly one rule
• Type of parent Types of children
• Consistency for Write/read to/from 16-bit CSE
• For two nodes two be packed into a SIMD pair,
• Yet another artifact constraint to avoid
  scheduling deadlock
• Cyclic dependence due to true dependence false
  (output) dependence pair
• Subject to these constraints, select a cover that
  maximizes the use of SIMD instructions
• These can be expressed by ILP formulation

22
Constraint 1

• Each node is covered by exactly one rule

covered by r_j or not
23
Constraint 2

• Type of parent Types of children

24
Constraint 3

• Consistency for Write/read to/from 16-bit CSE

25
Constraint 4

• For two nodes two be packed into a SIMD pair,

26
Constraint 5

• Yet another artifact constraint to avoid
  scheduling deadlock
• Cyclic dependence due to true dependence false
  (output) dependence pair

27
Optimization Goal

• Subject to these constraints, select a cover that
  maximizes the use of SIMD instructions

28
Experimental Results
