Object-Oriented Programming and Design

1
Object-Oriented Programming and Design

• Ralph Johnson johnson_at_cs.uiuc.edu

2
Goals to learn

• Principles
• Patterns
• Practices
• Object think
• Design for reuse

3
History of Objects

• Simula67
• Smalltalk 72,74,76,78,80
• 1985 C (Objective C, Object Pascal)
• 1986 OOPSLA
• 1990 COM, CORBA
• 1994 Design Patterns
• 1995 Java
• 2001 .NET

4
Design Principles

• Encapsulate what varies
• Code to an interace rather than to an
  implementation
• Open-closed Principle Classes should be open to
  extension and closed to modification
• Dont Repeat Yourself (DRY)
• Single Responsibility Principle
• Liskov Substitution Principle Subtypes must be
  substitutable for their base types

5
Smalltalk

• Extreme object-oriented language
• Live objects
• Readable library
• Influencial, unknown
• Fun!

6
From Smalltalk

• WIMP - Windows, Mice, Pointing
• Model/View/Controller
• Browsers
• CRC cards
• eXtreme Programming
• Automated refactoring tools

7
Before objects

• Computer system consists of data and programs.
• Programs manipulate data.
• Programs organized by
• functional decomposition
• dataflow
• modules

8
Object Paradigm

• Computer system consists of a set of objects.
• Objects are responsible for knowing and doing
  certain things.
• Objects collaborate to carry out their
  responsibilities.
• Programs organized by classes, inheritance
  hierarchies and subsystems

9
What is an object, anyway?

• Mystical view
• Computing systems are made up of objects that
  communicate only by sending messages between each
  other. All computation is message sending.

10
What is an object, anyway?

• Scandinavian view
• A program is a simulation. Each entity in the
  system being simulated is represented by an
  entity in the program.

11
What is an object, anyway?

• Programming language view
• An object-oriented system is characterized by
• data abstraction
• inheritance
• polymorphism by late-binding of procedure calls

12
Heart of Object-Oriented Programming

• Don't make a new language, extend your old one.
• Objects should be abstractions of problem domain.

13
Modeling

• All phases of software life-cycle are modeling
• analysis - modeling of problem
• design - modeling of solution
• implementation - making model run on a computer
• maintenance - fixing/extending your model

14
Assumption about Modeling

• Basing system design on structure of problem
  makes system
• more reusable
• more extensible

15
Modeling

• Claim people model the world with "objects"
• objects
• classes
• relationships between objects
• relationships between classes

16
Modeling

• Advantages of object-oriented software
  development
• more natural - matches the way people think
• single notation - makes it easy to move between
  software phases

17
Objects and Relationships

• John is Mary's father. Mary is John's
  daughter.
• Bob is Mary's dog. Mary is Bob's owner.
• Ann is John's employer. John is Ann's employee.

18
Objects and Attributes

• John's name is "John Patrick O'Brian".
• John's age is 27.
• John's address is 987 N. Oak St, Champaign IL
  61820
• What about John's job? John's wife?
• What is an attribute, and what is a relationship?

19
Objects and Behavior

• John goes on a trip.
• John makes reservations.
• John buys tickets.
• John travels by airplane.
• John checks into hotel.

20
What Really is an Object?

• Reservation -- a promise to give service to a
  customer
• Ticket -- proof that customer has paid for
  service in advance
• Flight
• Payment -- an event (transaction?) in which money
  is exchanged

21
What Really is an Object?

• Anything we can talk about can be an object,
  including relationships ("the husband of the
  first party", "first-born son").
• What are we trying to model?
• Models should be as simple as possible, but no
  simpler.

22
Classification

• We naturally put objects into classes that have
  similar characteristics.
• John is a man.
• Mary is a woman.
• Bob is a dog.
• All women are people.
• All people are mammals.

Mammals
Dogs
People
Women
Men
Bob
Mary
John
23
Classification

• John is an employee.
• John is a father.
• John is a sky-diver.
• John is under 30.
• Is John an instance of Employee, Father,
  Sky-diver, and Under30?

24
Summary

• Objects
• have identity
• have attributes
• have behavior
• have relationships with other objects

25
Summary

• Classes
• describes the attributes, behavior, and
  relationships of a set of objects
• subclasses/superclasses form graph of
  generalizations

26
The class

• First month is Smalltalk
• Homework, often several per week
• Second half of the semester is group project
• See http//swiki.cs.uiuc.edu/cs598rej/MP0
• Make a page for yourself
• Download Squeak and play with it

27
Smalltalk in a Nutshell

• Objects classes
• Messages methods
• Inheritance metaclasses

28
Smalltalk Everything is an Object

• Application objects customer, inventory
• GUI objects button, text editor
• Foundation string, set, numbers, booleans
• Tools browser, debugger, compiler, GUI builder
• Language implementation class, method, context,

29
Communicating with an Object

• All computation is done by objects.
• The only way to interact with an object is to
  "send a message" to it.
• Smalltalk has three kinds of syntax for sending a
  message.
• All messages have same implementation.

30
Three Kinds of Message Syntax

• Unary messages
• aSalaryChange date
• Keyword messages
• earned at date add money
• Binary messages
• (worked - 40) max 0

31
Sending a Message

• Object responds to message by looking in its
  class for a method with the same selector.
• If it doesn't find the method, it looks in its
  superclass.
• Repeat until it finds the method. If it never
  does, there is an error.

32
Smalltalk in a nutshell

• Classes have methods and variables.
• Methods are a sequence of messages, assignments,
  returns.
• Variables, literals, psuedovariables
• Blocks
• Metaclasses - classes have classes

33
Message Lookup and Inheritance

• EmployeeTransaction has subclasses Paycheck,
  SalaryChange, and Timecard.
• EmployeeTransaction defines the instance variable
  date and the method
• date
• date

34
EmployeeTransaction date
check1 07/09/95
Paycheck
aPaycheck date
35
Smalltalk Expression Syntax

• Literals
• 3.675, 14, 'hello', weight, d,
• ( foo 'bar' 92)
• Assignments and variables
• v v 1
• Messages

36
Smalltalk Expression Syntax

• Sequences. Blocks.
• x lt y ifTrue z x ifFalse z y.
• paychecks do each each post
• Cascades
• aSet add blue add red

37
Smalltalk Method Syntax

• Returns
• socialSecurity federalTaxes stateTaxes

38
Variables in Smalltalk

• blockArguments and temporaries
• methodArguments and temporaries
• instanceVariables
• Can be accessed only by the object's methods.
• Globals, class variables
• Any method in the scope can access it
• Variable is object of class Association

39
Using Variables
printOnCheckStream aStream aStream cr
cr. aStream next 40 put (Character
space). DateFormat print date on
aStream. aStream cr. ...
40
More variables

• test
• "PayrollSystem test"
• payroll day1 ralph
• day1 Date newDay 5 year 1996.
• payroll self new.
• ralph Employee new name
• 'Ralph Johnson'.

41
(continued)

• ralph changeSalaryFor day1 to 20.
• payroll addEmployee ralph.
• self
• employee ralph
• hours self aLittleOvertime
• starting day1.
• payroll

42
Initializing an Object

• Every object needs to be initialized.
  Uninitialized variables are nil.
• The initialization method often defines the type
  of a variable.
• Two methods one class and one instance.

43
Class Methods

• Class is an object. It can have methods, too.
• For class Date class
• newDay dayInteger year yearInteger
• self new day dayInteger year yearInteger

44
Instance initializing method

• For class Date
• day dayInteger year yearInteger
• day dayInteger.
• year yearInteger

45
Creating a Date
Date newDay 3 year 1995 Date new day 3 year
1995
day
day 3 year 1995
year
3
1995
46
Complete Smalltalk

• Expressions (method definition)
• message, assignment, sequence, block, return
• Variables, literals
• Classes, inheritance
• Class methods / instance methods
• Pseudovariables
• nil, true, false
• self, super, thisContext

47
Smalltalk (the language) is trivial

• Complexity is class library.
• New language extensions fit in as well as numbers
  and control structures.
• Language extension gt core language is trivial

48
Implications

• class library language extension
• gt
• must know class library
• must standardize class library
• merging class libraries is like merging language
  extensions
• hard to make class libraries

49
Applications

• No programs, just objects
• No main routine
• Most applications create new classes, reuse a lot
  of existing ones
