TECH854 XML TECHNOLOGIES XML Query Integrating XML and Databases

1
TECH854XML TECHNOLOGIESXML QueryIntegrating
XML and Databases

• Gillian Miller
• gillian_at_ics.mq.edu.au
• Week 8 2002/2

2
XML - Query and Databases

• SemiStructured Information
• XML Query
• XML Persistence
• XML Data design
• Native XML Databases
• XML enabling and relational databases
• Future directions

3
Convergence Of Disparate Data Frameworks
Object Model
Relational Model
Document Model
Semi-Structured Data
XML
XML - allows representation of information from
previously disparate worlds - database centric
(everything is a relation) (everything is an
object), document centric XML alllows convergence
4
Semi-structured data
Semi-Structured Data schemaless or
self-describing, data that may include multiple
occurrences or occurences that may be missing,
data that can be loosely typed

• Origins
• Integrating information from heterogeneous
  sources
• data with non-rigid structures
• biological data
• Web data

Ref Abiteboul et al - Data on the Web - 2000
5
The Semistructured Data Model
Bib
o1
complex object
paper
paper
book
references
o12
o24
o29
references
references
author
page
author
year
author
title
http
title
title
publisher
author
author
author
o43
25
96
1997
last
firstname
atomic object
firstname
lastname
first
lastname
243
206
Serge
Abiteboul
Victor
122
133
Vianu
Object Exchange Model (OEM)
6
Syntax for Semistructured Data

• Bib o1
• paper o12 ,
• book o24 ,
• paper o29
• author o52 Abiteboul,
• author o96 firstname 243
  Victor,
•
  lastname o206 Vianu,
• title o93 Regular path queries
  with constraints,
• references o12,
• references o24,
• pages o25
• first o64 122, last o92
  133

Ref Suciu, CSE 590ds http//www.cs.washington.ed
u/ education/courses/cse590ds/01sp/
7
Syntax for Semistructured Data

• omit oids -
• paper author Abiteboul,
• author firstname Victor,
• lastname
  Vianu,
• title Regular path queries
  ,
• page first 122, last 133


8
Comparison with Relational Data

• row name John, phone 3634 ,
• row name Sue, phone 6343 ,
• row name Dick, phone 6363

9
Many different representations
r1
r2
row
row
row
row
row
row
row
row
r1
r2
r1
r2
a
c
b
a1
b1
c1
a
c
b
a1
b1
c1
r1
r2
10
XML Similarities/Differenecs

• ltperson ido123gt
• ltnamegt Alan lt/namegt
• ltagegt 42 lt/agegt
• ltemailgt ab_at_com lt/emailgt
• lt/persongt

• person o123
• name Alan,
• age 42,
• email ab_at_com

ltperson fathero123gt lt/persongt
person father o123
similar on trees, different on graphs
11
More XML Oids and References

• ltperson ido555gt ltnamegt Jane lt/namegt lt/persongt
• ltperson ido456gt ltnamegt Mary lt/namegt
• ltchildren
  idrefo123 o555/gt
• lt/persongt
• ltperson ido123 mothero456gtltnamegtJohnlt/namegt
• lt/persongt

Oids and references in XML are just syntax No
real difference logically between elements amd
attributes
12
On Schemas and typing

• Schemas -
• XML schemas/DTDs have built in flexibility to
  allow deviations
• Use of schemas
• schema extraction - structure can be deduced
• schema inference
• if we have structure, should take advantage of it
• query opimization, data validation, type checking

13
X Query

• New full powered query language for XML with
  both document-centric and data-centric
  capabilites
• Expressive power
• Relational joins
• Navigation and hierarchy structure
• Compositionality (node sets)
• Reconstruction of new node sets
• Combining documents
• Filtering, sorting, functions
• see Maier, Database desiderata for query
  languages

14
XQuery

• XQuery combines data queries with document
  queries
• XQuery builds on XPath to traverse document
• XQuery is a functional language in which a query
  is represented as an expression
• XQuery expressions can be nested with full
  generality
• The input and output of an XQuery are instances
  of the XML Query Data Model
• Based on OQL, SQL, XML-QL, XPath
• Also - Lorel, XSQL, XSL, YATL ? Quilt
• ref XML Query Language - experiences and
  exemplars

15
XQuery Working Drafts

• Currently W3C Working Draft - recommendation in 6
  months ?
• The goal of W3C is to produce a data model for
  XML documents, a set of query operators on that
  data model, and a query language based on these
  query operators
• at least 8 Working Drafts
• Requirements - planning document
• Set of use cases - real world scenarios
• XQuery document - central document
• Data Model - Abstract representation
• Formal Semantics
• underlying algebra of operations
• Syntax
• More than one syntax XQueryX (XML syntax for
  machines)
• XPath documentation
• Basic functions and operators

16
Example
Make an alphabetic list of publishers. Within
each publisher, make a list of books, each
containing a title and a price, in descending
order by price. ltpublisher_listgt FOR p IN
distinct(document("bib.xml")//publisher)
RETURN ltpublishergt ltnamegt
p/text() lt/namegt FOR b IN
document("bib.xml")//bookpublisher p
RETURN ltbookgt b/title b/price
lt/bookgt SORTBY(price DESCENDING)
lt/publishergt SORTBY(name)
lt/publisher_listgt
17
XML Query Use Cases

• Use Cases
• Description, DTDs and Schema, Sample data,
  Queries and Results
• Current Use Cases
• "XMP" Experiences and Exemplars
• "TREE" Queries that preserve hierarchy
• "SEQ" - Queries based on Sequence
• "R" - Access to Relational Data
• "TEXT" Full-text Search
• "NS" - Queries Using Namespaces
• "PARTS" - Recursive Parts Explosion
• "REF" - Queries based on References

18
Sample Data
19
XML Query Data Model

• Describes XML as a tree of specialized nodes
• Uses a functional style notation (think Haskell)
• Node DocNode ElemNode
  ValueNode
  AttrNode NSNode
  PINode CommentNode
  InfoItemNode
  RefNode

elemNode (QNameValue,
AttrNode , ElemNode
ValueNode) QNameValue means a tag
name ... means set of... ... means
list of ...
20
XPath Data Model

• Building block for other W3C standards
• XSL Transformations (XSLT)
• XML Link (XLink)
• XML Pointer (XPointer)
• XML Query

The root
The root element
book
book
publisher
author
. . . .
Addison-Wesley
Serge Abiteboul
21
XPath

• A path expression is a series of steps separated
  by /
• Can also sort and select nodes

22
Xpath Revision

• bib matches a bib element
• matches any element
• / matches the root element
• /bib matches a bib element under root
• bib/paper matches a paper in bib
• bib//paper matches a paper in bib, at any depth
• //paper matches a paper at any depth
• paperbook matches a paper or a book
• _at_price matches a price attribute
• bib/book/_at_price matches price attribute in book,
  in bib
• bib/book/_at_pricelt55/author/lastname matches

23
(No Transcript)
24
XQuery FLWR Expressions

• A FLWR expression binds some expressions, applies
  a predicate, and constructs a new result.
• expr can contain FLWR expressions
• nested building blocks

FOR and LET clauses generate a list of tuples of
bound expressions, preserving document order.
WHERE clause applies a predicate, eliminating
some of the tuples
RETURN clause is executed for each surviving
tuple, generating an ordered list of outputs
25
List the titles of books published by Morgan
Kaufmann in 1998. FOR b IN document("bib.xml")//
book WHERE b/publisher "Morgan Kaufmann
AND b/year "1998" RETURN b/title
List each publisher and the average price of its
books. FOR p IN distinct(document("bib.xml")//pu
blisher) LET a avg(document("bib.xml")//book
publisher p/price) RETURN ltpublishergt
ltnamegt p/text() lt/namegt ltavgpricegt
a lt/avgpricegt lt/publishergt
26
Constructing Elements
ltbook isbn"isbn-0060229357"gt lttitlegtHarold
and the Purple Crayonlt/titlegt ltauthorgt
ltfirstgtCrockettlt/firstgt
ltlastgtJohnsonlt/lastgt lt/authorgt lt/bookgt
for i in //book RETURN ltexamplegt ltpgt Here is a
query. lt/pgt lteggt i//title lt/eggt ltpgt Here is
the result of the above query. lt/pgt lteggt i //
title lt/eggt ltsurnamegt i / author /
last(text() lt/surnamegt lt/examplegt
ltexamplegt ltpgt Here is a query. lt/pgt lteggt
i//title lt/eggt ltpgt Here is the result of the
above query. lt/pgt lteggtlttitlegtHarold and the
Purple Crayonlt/titlegtlt/eggt ltsurnamegtJohnsonlt/su
rnamegt lt/examplegt
27
XQuery Expressions

• XQuery expressions
• Path expressions
• Element constructors
• FLWR expressions
• Expressions involving operators and functions
• Conditional expressions
• Quantified expressions
• List constructors
• Expressions that test or modify datatypes

28
Combining Expressions
ltbibliographygt Expression lt/bibliographygt
ltbibliographygt FOR b IN Expression RETURN
ltbookgt Expression ,
Expression lt/bookgt SORTBY
(Expression , Expression ) lt/bibliographygt
ltbibliographygt FOR b IN
document("bib.xml")//book RETURN ltbookgt
b/author, b/title
lt/bookgt SORTBY (author,
title) lt/bibliographygt
29
Functions
FOR p IN distinct(document("bib.xml")//publisher)
LET a avg(document("bib.xml") /book
publisher p /price) RETURN
ltpublishergt ltnamegt p/text()
lt/namegt ltavgpricegt a lt/avgpricegt
lt/publishergt
Q12 List each publisher and the average price
of its books.
30
Conditional Expressions
FOR h IN //holding RETURN
ltholdinggt h/title,
IF h/_at_type "Journal" THEN
h/editor ELSE
h/author lt/holdinggt
SORTBY (title)
IF THEN ELSE construct (Q21) Make a list of
holdings, ordered by title. For journals,
include the editor, and for all other holdings,
include the author.
31
Nesting
Usecase 4 For each author in the bibliography,
list the author's name and the titles of all
books by that author, grouped inside a "result"
element.
ltresultsgt for a in distinct-values(docume
nt("http//www.bn.com")//author) return
ltresultgt a for
b in document("http//www.bn.com")/bib/book
where some ba in b/author satisfies
deep-equal(ba,a) return
b/title lt/resultgt
lt/resultsgt
ltresultsgt ltresultgt ltauthorgt
ltlastgtStevenslt/lastgt
ltfirstgtW.lt/firstgt lt/authorgt
lttitlegtTCP/IP Illustratedlt/titlegt
lttitlegtAdvanced Programming in the Unix
environmentlt/titlegt lt/resultgt ltresultgt
ltauthorgt ltlastgtAbiteboullt/lastgt
ltfirstgtSergelt/firstgt
32
FOR versus LET

• FOR
• Binds node variables ? iteration
• LET
• Binds collection variables ? one value

Returns ltresultgt ltbookgt...lt/bookgtlt/resultgt
ltresultgt ltbookgt...lt/bookgtlt/resultgt ltresultgt
ltbookgt...lt/bookgtlt/resultgt ...
FOR x IN document("bib.xml")/bib/book RETURN
ltresultgt x lt/resultgt
Returns ltresultgt ltbookgt...lt/bookgt
ltbookgt...lt/bookgt
ltbookgt...lt/bookgt ... lt/resultgt
LET x IN document("bib.xml")/bib/book RETURN
ltresultgt x lt/resultgt
33
Collections in XQuery

• Ordered and unordered collections
• /bib/book/author an ordered collection
• Distinct(/bib/book/author) an unordered
  collection
• LET b /bib/book ? b is a collection
• b/author ? a collection (several authors...)

Returns ltresultgt ltauthorgt...lt/authorgt
ltauthorgt...lt/authorgt
ltauthorgt...lt/authorgt
... lt/resultgt
RETURN ltresultgt b/author lt/resultgt
34
Collections in XQuery

• What about collections in expressions ?
• b/price ? list of n
  prices
• b/price 0.7 ? list of n numbers
• b/price b/quantity ? list of n x m numbers
  ??
• b/price (b/quant1 b/quant2) ? b/price
  b/quant1 b/price b/quant2 !!

35
Recursive Functions
NAMESPACE xsd"http//www.w3.org/2001/XMLSchema-
datatypes" FUNCTION depth(ELEMENT e) RETURNS
xsdinteger -- An empty element has depth
1 -- Otherwise, add 1 to max depth of
children IF empty(e/) THEN 1 ELSE
max(depth(e/)) 1 depth(document("partlist
.xml"))
(Q25) Find the maximum depth of the document
named "partlist.xml."
36
XQuery Quantified Expressions
Existential quantifier (Q22) Find titles of books
in which both sailing and windsurfing are
mentioned in the same paragraph. FOR b IN
//book WHERE SOME p IN b//para SATISFIES
contains(p, "sailing") AND
contains(p, "windsurfing") RETURN b/title
Universal quantifier ((Q23) Find titles of books
in which sailing is mentioned in every
paragraph. FOR b IN //book WHERE
EVERY p IN b//para SATISFIES
contains(p, "sailing") RETURN b/title
37
SQL - Expressive Power

• XQuery uses a for let where .. result
  syntax for ? SQL from where ?
  SQL where result ? SQL select let
  allows temporary variables, and has no
  equivalence in SQL - let binds to a set of nodes
• groupby has no equivalence yet in XQuery

38
SQL
ltresultgt for i in document("items.xml")//
item_tuple where i/start_date lt
current-date() and i/end_date gt
current-date() and contains(i/description,
"Bicycle") return ltitem_tuplegt
i/itemno i/description
lt/item_tuplegt sort by (itemno)
lt/resultgt
1.4.4.1 Q1 List the item number and description
of all bicycles that currently have an auction
in progress, ordered by item number.
39
SQL Joins
ltresultgt for u in document("users.xml")/
/user_tuple for i in document("items.xml")//i
tem_tuple where u/rating gt "C" and
i/reserve_price gt 1000 and i/offered_by
u/userid return ltwarninggt
u/name u/rating
i/description
i/reserve_price lt/warninggt
lt/resultgt
1.4.4.3 Q3 Find cases where a user with a rating
worse (alphabetically, greater) than "C" is
offering an item with a reserve price of more
than 1000.
40
XQueryX

• XQueryX is an XML representation of an XQuery
• It was created by mapping the productions of the
  XQuery abstract syntax directly into XML
  productions
• XQueryX useful to enable
• Parser reuse
• Queries on queries
• Generation of queries
• Embedding of queries in XML documents

41
XQueryX
Listing 2. The same query in XQueryX format
ltqquery xmlnsq"http//www.w3.org/2001/06/xquery
x"gt ltqflwrgt ltqletAssignment
variable"authors"gt ltqstep
axis"CHILD"gt ltqidentifier/gt
ltqstep axis"CHILD"gt
ltqidentifiergtbooklt/qidentifiergt
ltqidentifiergtauthorlt/qidentifiergt
lt/qstepgt lt/qstepgt
lt/qletAssignmentgt
ltqreturngt ltqelementConstructorgt
ltqtagNamegt
ltqidentifiergtAUTHORSlt/qidentifiergt
lt/qtagNamegt ltqvariablegtauthors
lt/qvariablegt lt/qelementConstructorgt
lt/qreturngt lt/qflwrgt lt/qquerygt
. A simple query in XQuery standard syntax
LET authors /book/author RETURN
ltAUTHORSgt authors
lt/AUTHORSgt
42
XSQL

• XSQL is alternative language by relational
  vendors (Oracle)
• Based on well defined relational algebra and SQL
  syntax
• advantages of transfer at DBMS engineering
• Disadvantages - baggage of SQL
• Works well with XML that is relational in
  structure
• More contortions for less relational XML and
  complicated transformations

43
Some implemenations of XQuery

• Microsoft on-line demo
• http//xqueryservices.com
• Software AG QuiP
• http//www.softwareag.com/developer/downloads/defa
  ult.htm
• Fatdog
• http//www.fatdog.com
• SourceForge
• http//sourceforge.net/projects/xquench/
• Kweelt
• http//db.cis.upenn.edu/Kweelt/

44
Is XML a Database ?

• XML is a collection of data
• XML is self-describing, portable and has rich
  expressiveness to represent any tree or graph
  structure
• but verbose, needs parsing
• XML provides
• elementary storage (XML documents)
• schemas (DTD.s, XML Schema)
• query languages (XQuery, XPath)
• programming interfaces (SAX, DOM, JDOM)

45
Need for DBMS

• XML Does not provide
• efficient storage
• indexes
• security
• transactions
• multi-user access
• queries across multi-user documents
• query optimisations
• For more comprehensive applications we will need
  a database of some sort

46
Data versus Documents

• Most important issue
• Is your information data-centric ?
• relational ? well structured ? typical business
  type data, not too many nulls
• eg sales order, product catalog
• Is your information document-centric
• semi-structured, textual content, mixed content,
  complex hierarchies, content management , less
  regular structure, larger grained data
• eg docbook, legislation, university web site
  content

But what about the product catalog complete with
brochures, advertising, images ???
47
Application Use

• Data-centric
• transaction processing, e-commerce, critical
  reconciliation or processing
• Document-centric
• viewable information
• rich aggregated content
• archiving information
• For non-repudiation, an order should reflect all
  of the information as the customer saw it, not as
  it would be generated from a relational database
  using a set of SQL queries
• knowledge management, information dissemination

BUT Document-centric applications can involve
data-centric information !!!
48
Storing XML

• Flat Files
• lightweight data storage
• OK for some applications (configuration files,
  small in-house systems)
• Relational Systems
• Universal Systems (relational true XML
  extensions)
• evolving to truer XML model
• Native XML Database
• Other categories
• middleware, XML Servers, XML Appplication Servers
  (Zope, Cocoon), Content management (Documentum,
  Vignette), caching systems

http//www.rpbourret.com/xml/XMLDatabaseProds.htm
49
Native XML Databases

• Databases that store XML in "native" form
• indexed text or
• as some variant of the DOM mapped to an
  underlying data store.
• Different underlying engines
• Object Based
• Relational
• proprietary models
• Technology maturing, Commercial models expensive
  - but less than universal databases
• Examples
• Tamino
• eg Excelon (ObjectStore), Poet
• extensible Information Server (XIS)
• Open Source
• XIndice - Apache, propietary model
• XDB (Postgres relational based)

50
(No Transcript)
51
(No Transcript)
52
Pure Relational Databases

• Convert your XML file to relational design
• For each complex element, create a table CE and
  primary key
• For each element with mixed content, create a
  separate table to store PCData, with link back to
  parent element using foreign key
• For each single element and attribute, create a
  column in table CE
• Repeat for each complex child element, using
  foreign keys to link back to parent

or do proper analysis using ERA !!
53
Converting Relations to XML

• Attributes versus elements ???
• Containment versus Pointers
• Containment
• 11 and 1many best represented by containment
• eg invoice ( orderline)
• Pointers
• Many to many
• Keep elements separate - use IDs and IDrefs to
  make mappings

54
(No Transcript)
55
Containment or Pointers
containment
pointers
56
Containment and Pointers
57
Storing XML in Relational Databases - CLOB

• Store as string (Character Large Object)
• E.g. store each top level element as a string
  field of a tuple in a database
• Use a separate relation for each top-level
  element type
• E.g. account, customer, depositor
• Indexing
• Store values of subelements/attributes as extra
  indexes
• Benefits
• Can store any XML data even without DTD
• As long as there are many top-level elements in a
  document, strings are small compared to full
  document, allowing faster access to individual
  elements.
• Drawback Need to parse strings to access values
  inside the elements parsing is slow.

58
Storing XML as Relations

• Tree representation model XML data as general
  tree and store using relations
• nodes(id, type, label, value)
• child (child-id, parent-id)
• Each element/attribute is given a unique
  identifier
• Type (element_or_attribute), labeltag,
  valuecontent
• child notes the parent-child relationships in
  the tree
• Can add an extra attribute to child to record
  ordering of children
• Benefit Can store any XML data, even without DTD
• Drawbacks
• Data is broken up into too many pieces,
  increasing space overheads
• Even simple queries require a large number of
  joins, which can be slow

59
XML Enabled Databases

• FIRST WAVE
• Databases with extensions for transferring data
  between XML documents and themselves
• Useful for data-centric applications and legacy
  databases
• Any relational table can be rendered as
  edge-labelled graph
• This means a table can be expressed as XML using
  either elements or attributes or both for each
  data cell

60
Generating XML from SQL queries
http//technet.oracle.com/tech/xml/info/htdocs/otn
wp/about_oracle_xml_products.htm
61
(No Transcript)
62
XML is really just a row view
SELECT EMPNO, ENAME FROM EMP WHERE EMPNO
7654 generates the following XML document
lt?xml version"1.0"?gt ltROWSETgt ltROW
id"1"gt ltEMPNOgt7654lt/EMPNOgt
ltENAMEgtMARTINlt/ENAMEgt lt/ROWgt lt/ROWSETgt
63
General row to HTML table
Can write generalized XSLT even for this simple
row format
64
Microsoft SQL Server

• Use FOR XML in SELECT statements
• RAW result is table with ROW elements
• AUTO elements are table name choose either
  attributes or elements
• EXPLICIT model using series of SELECT
  statements Unioned together with tags to give
  nesting hierarchy
• XML View
• Wrapper describes shape of XML document
  generated on the fly XDR schema maps to
  relational schema
• Then query XML View as though it were an XML
  document

65
XML Publishing SQL Server, RAW Mode
Select S.euSid, P.name, P.price From Stores S,
EuSales L, Products P Where S.euSid L.euSid AND
L.pid P.pid For XML Raw
ltrow euSid SLKDJFS, name Saint Emilion,
price23.99gt ltrow euSid DRJLKSD, name
Loire, price12.99gt . . . .

• flat XML
• default tag and attribute names

66
XML Publishing SQL ServerAuto Mode
Select S.euSid, P.name, P.price From Stores S,
EuSales L, Products P Where S.euSid L.euSid AND
L.pid P.pid For XML Auto
ltStores euSid SLKDJFSgt ltProduct name
Saint Emilion, price23.99/gt ltProduct
name Loire, price12.99/gt lt/Storesgt ltStores
euSid FGJISODgt . . . . lt/Storesgt . . .

• nested XML
• default tag and attribute names

67
XML Publishing SQL ServerExplicit Mapping
Note the complexity of generating a
simple hierarchy !
Wrox- Professional Databases p550
68
Rowset from explicit Mode
69
Mismatches between XML/RDBMS

• XML
• Data in single hierarchy
• Nodes have elements and/or attribute values
• Elements are nested
• Elements are ordered
• Schema optional
• Direct storage/retrieval of simple docs
• Query with XML standards

• RDBMS (normalized)
• Data in multiple tables
• Cells have single value
• Atomic cell values
• Row/column order not defined
• Schema required
• Joins necessary to rerieve simple docs
• Query with SQL retrofitted for XML

Michael Champion, Storing XML in Databases
But XML hierarchy does not address issues
of redundant information or different nestings -
the whole rationale for RDBMS !!
70
XML Universal Databases

• Future trends
• Relational databases are being XML enabled to
  become truer XML repositories
• Moving beyond simple XML wrappers around
  relations
• and/or storing XML as LOB (binary, character)
• Trend towards unification of XML content and
  relational data
• New XML architectures and features (dynamic XML
  Views, automatic mappings)
• see for example - Seybold report, Oracle XML DB
  Uniting XML Content and Data, 2002
• XTables - Bridging Relational Technologu and XML
  - IBM 2002

71
References

• Professional XML Databases - Kevin Williams et
  al, Wrox, 2000
• W3C XML Query
• Data on the Web From Relations to Semistructured
  data and XML -2000, Abiteboul et al
• Rob Bourret - XML and Databases - as well as web
  site
• An introduction to XQuery, Katz, IBM Developer
  Works
• Oracle Technet site
• Other product sites including Tamino
• Suciu, CSE590ds - Management of XML and
  semi-structured data - course
• http//www.cs.washington.edu/education/courses/cse
  590ds/01sp/
