6.895/SMA5509 Project Presentations

1
6.895/SMA5509 Project Presentations

• October 15-17 2003

2
Improving Cilk
3
Adaptively Parallel Processor Allocation for Cilk
Jobs

• Kunal Agrawal
• Siddhartha Sen

4
Goal

• Design and implement a dynamic processor-allocatio
  n system for adaptively parallel jobs (jobs for
  which the number of processors that can be used
  without waste varies during execution)
• The problem of allocating processors to
  adaptively parallel jobs is called the adaptively
  parallel processor-allocation problem 2.
• At any given time, each job j has a desire dj and
  an allotment mj

5
Goal (cont.)

• We want to design a processor-allocation system
  that achieves a fair and efficient allocation
  among all jobs.
• fair means that whenever a job receives fewer
  processors than it desires, no other job receives
  more than one more processor than this job
  received 2
• efficient means that no job receives more
  processors than it desires 2

6
Illustration of Problem
dj 6 mj 5
dk 10 mk 6
? ? ? ?
P processors


7
Main Algorithmic Questions

• Dynamically determine the desires of each job in
  the system
• Heuristics on steal rate
• Heuristics on number of visible stack frames
• Heuristics on number of threads in ready deques
• Dynamically determine the allotment for each job
  such that the resulting allocation is fair and
  efficient
• SRLBA algorithm 2
• Cilk macroscheduler algorithm 3
• Lottery scheduling techniques 5

8
Assumptions

• All jobs on the system are Cilk jobs
• Jobs can enter and leave the system and change
  their parallelism during execution
• All jobs are mutually trusting (they will stay
  within the bound of their allotments and
  communicate their desires honestly)
• Each job has at least one processor to start with

9
References

• Supercomputing Technologies Group. Cilk 5.3.2
  Reference Manual. MIT Lab for Computer Science,
  November 2001.
• B. Song. Scheduling adaptively parallel jobs.
  Master's thesis, Massachusetts Institute of
  Technology, January 1998.
• R. D. Blumofe, C. E. Leiserson, and B. Song.
  Automatic processor allocation for work-stealing
  jobs.
• C. A. Waldspurger. Lottery and Stride Scheduling
  Flexible Proportional-Share Resource Management.
  PhD thesis, Massachusetts Institute of
  Technology, September 1995.
• C. A. Waldspurger and W. E. Weihl. Lottery
  scheduling Flexible proportional-share resource
  management. In Proceedings of the First Symposium
  on Operating System Design and Implementation,
  pages 1-11. USENIX, November 1994.
• R. D. Blumofe, C. F. Joerg, B. C. Kuszmaul, C. E.
  Leiserson, K. H. Randall, and Y. Zhou. Cilk An
  ecient multithreaded runtime system. In
  Proceedings of the Fifth ACM SIGPLAN Symposium on
  Principles and Practice of Parallel Programming
  (PPoPP), pages 207-216, Santa Barbara,
  California, July 1995.

10
Fast Serial-Append for Cilk

• 6.895 Theory of Parallel Systems
• Project Presentation (Proposal)
• Alexandru Caracas

11
Serial-Append (cont'd)

• A Cilk dag
• Numbers represent the serial execution of threads
• For example
• Consider all threads perform file I/O operations

12
Serial-Append (cont'd)

• Same Cilk dag
• Numbers represent the parallel execution of
  threads
• Goal
• We would like to execute the threads in parallel
  while still allowing for the serial order to be
  reconstructed.

13
Serial-Append (cont'd)

• Partitioning of the Cilk dag
• Colors represent the I/O operations done by a
  processor between two steal operations.

14
Serial-Append

• The Serial-Append of the computation is obtained
  by reading the output in the order
• orange (I)
• green (II)
• dark-red (III)
• purple (IV)
• red (V)

15
Project Goals

• Efficient serial-append algorithm
• possibly using B-trees
• Analyze possible implementation
• kernel level
• formatted file
• Cilk file system
• Implementation
• (one of the above)

• Port Cheerio to Cilk 5.4.
• Comparison with own implementation
• Port serial applications to use serial-append
  (analyze their performance)

16
References

• Robert D. Blumofe and Charles E. Leiserson.
  Scheduling multithreaded computations by work
  stealing. In Proceedings of the 35th Annual
  Symposium on Foundations of Computer Science,
  pages 356-368, Santa Fe, New Mexico, November
  1994.
• Matthew S. DeBergalis. A parallel file I/O API
  for Cilk. Master's thesis, Department of
  Electrical Engineering and Computer Science,
  Massachusetts Institute of Technology, June 2000.
• Supercomputing Technology Group MIT Laboratory
  for Computer Science. Cilk 5.3.2 Reference
  Manual, November 2001. Available at
  http//supertech.lcs.mit.edu/cilk/manual-5.3.2.pdf
  .

17
A Space-Efficient Global Scheduler for Cilk

• Jason Hickey
• Tyeler Quentmeyer

18
Idea

• Implement a new scheduler for Cilk based on
  Narlikar and Blellochs Space-Efficient
  Scheduling of Nested Parallelism paper

19
AsyncDF Scheduler

• Idea minimize peak memory usage by preempting
  threads that try to allocate large blocks of
  memory
• Algorithm Roughly, AsyncDF runs the P left-most
  threads in the computation DAG

20
Example

• In parallel for i 1 to n
• Temporary Bn
• In parallel for j 1 to n
• F(B,i,j)
• Free B

21
Comparison to Cilk

• Cilk
• Distributed
• Run threads like a serial program until a
  processor runs out of work and has to steal
• Space pS1
• AsyncDF
• Global
• Preempt a thread when it tries to allocate a
  large block of memory and replace it with a
  computationally heavy thread
• Space S1 O(KDp)

22
AsyncDF Optmizations

• Two versions of scheduler
• Serial
• Parallel
• Running P left-most threads does not exploit the
  locality of a serial program
• Solution Look at the cP left-most threads and
  group threads together for locality

23
Project Plan

• Implement serial version of AsyncDF
• Experiment with algorithms to group threads for
  locality
• Performance comparison to Cilk
• Different values of AsyncDFs tunable parameter
• Case studies
• Recursive matrix multiplication
• Strassen multiplication
• N-body problem
• Implement parallel version of AsyncDF
• Performance comparison to Cilk
• Additional experiments/modifications as research
  suggests

24
Questions?
25
Automatic conversion of NSP DAGs to SP DAGs

• Sajindra Jayasena

Sharad Ganesh
26

• Objectives
• Design of an efficient Algorithm to convert an
  arbitrary NSP DAG to SP DAG
• - Correctness preserving
• Identifying different graph topologies
• Analysis of Space and Time complexities
• Bound on increase in critical path length
• Perform empirical analysis using cilk

27
Transactional Cilk
28
Language-Level Complex Transactions C. Scott
Ananian
29
An Evaluation of Nested Transactions

• Sean Lie
• sean_lie_at_mit.edu
• 6.895 Theory of Parallel Systems
• Wednesday October 15th, 2003

30
Transactional Memory

• The programmer is given the ability to define
  atomic regions of arbitrary size.
• Start_Transaction
• Flowi Flowi X
• Flowj Flowj X
• End_Transaction
• With hardware support, different transactions can
  be executed concurrently when there are no memory
  conflicts.

31
Nested Transactions

• Nested transactions can be handled by simply
  merging all inner transactions into the outermost
  transaction.

Start_Transaction .. Start_Transaction ..
End_Transaction .. .. .. End_Transaction
Start_Transaction .. Start_Transaction ..
End_Transaction .. .. .. End_Transaction
32
Concurrency

• Merging transactions is simple but may decrease
  the program concurrency.

Start_Transaction .. Start_Transaction
Access S End_Transaction .. .. .. End_Transact
ion
Conflict!
Start_Transaction Access S End_Transaction
33
Nested Concurrent Transactions

• Nested Concurrent Transactions (NCT)
• Allow the inner transaction to run and complete
  independently from the outer transaction.
• Questions
• When is NCT actually useful?
• How much overhead is incurred by NCT?
• How much do we gain from using NCT?
• The tool needed to get the answers
• Transactional memory hardware simulator UVSIM
• UVSIM currently supports merging nested
  transactions.
• How to get the answers
• Identify applications where NCT is useful. Look
  at malloc?
• Implement necessary infrastructure to run NCTs in
  UVSIM.
• Evaluate performance of NCT vs. merging
  transactions.

34
Compiler Support for Atomic Transactions in Cilk

• Jim Sukha
• Tushara Karunaratna

35
Determinacy Race Example
36
New Keywords in Cilk
It would be convenient if programmers could make
a section of code execute atomically by using
xbegin and xend keywords.
37
Simulation of Transactional Memory
38
Work Involved

• Modify the Cilk parser to accept xbegin and xend
  as keywords.
• Identify all load and store operations in user
  code, and replace them with calls to functions
  from the runtime system.
• Implement the runtime system. An initial
  implementation is to divide memory into blocks
  and to use a hash table to store a lock and
  backup values for each block.
• Experiment with different runtime implementations.

39
Data Race in Transactional Cilk

• Xie Yong

40
Background

• Current Cilk achieve atomicity using lock
• problems such as priority inversion, deadlock,
  etc.
• Nontrivial to code
• Transactional memory
• Software TM overhead -gt slow
• Hardware TM

41
Cilks transaction everywhere

• Every instruction becomes part of the a
  transaction
• Based on HTM
• Cilk transaction
• cut Cilk program into atomic pieces
• Base on some language construct or compiler
  automatic generate

42
Data Race

• Very different from traditional definition in
  Nondeterminator
• Assumption (correct parallelization)
• Definition (1st half of Kais master thesis)
• Efficient detection (v.s. NP-complete proved by
  Kai)
• Make use of current algorithms/tools

43
Non-Determinacy Detection
44
Linear-time determinacy race detection

• Jeremy Fineman

45
Motivation

• Nondeterminator has two parts
• Check whether threads are logically parallel
• Use shadow spaces to detect determinacy race
• SP-Bags algorithm uses LCA lookup to determine
  whether two threads are parallel
• LCA lookup with disjoint-sets data structure
  takes O(a(v,v)) time.
• We do not care about the LCA. We just want to
  know if two threads are logically parallel.

46
New algorithm for determinacy-race detection

• Similar to SP-Bags algorithm with two parts
• Check whether threads are logically parallel
• Use shadow spaces to detect determinacy race
• Use order maintenance data-structure to determine
  whether threads are parallel
• Gain Order maintenance operations are O(1)
  amortized time.

47
The algorithm

• Maintain two orders
• Regular serial, depth-first, left-to right
  execution.
• At each spawn, follow spawn thread before
  continuation thread
• Right-to-left execution.
• At each spawn, follow continuation thread before
  spawn thread
• Claim Two threads e1 and e2 are parallel if and
  only if e1 precedes e2 in one order, and e2
  precedes e1 in the other.

48
Depth-first, left-to-right execution
e0
e6
e5
e7
F
e1
e4
e2
e3
F3
F1
F2
F2
49
Right-to-left execution
e0
e6
e5
e7
F
e1
e4
e2
e3
F3
F1
F2
F2
50
How to maintain both orders in serial execution

• Keep two pieces of state for each procedure F
• CF is current thread in F
• SF is next sync statement in F.
• In both orders, insert new threads after current
  thread
• On spawn, insert continuation thread before spawn
  thread in one order. Do the opposite in the
  other.
• On sync, advance CF to SF
• In any other thread, update shadow spaces based
  on current thread

51
Example
e0
s1
e2
e5
e4
F
e1
e3
e1
CF
Order
e0
e0
s1
e2
e2
e4
e4
e3
e5
e5
s2
s1
s1
e4
e2
s1
SF
Order
e0
e1
e3
e5
52
Project ProposalParallel Nondeterminator

• He Yuxiong

53
Objective

• I propose Parallel Nondeterminator to
• Check the determinacy race in the parallel
  execution of the program written in the language
  like Cilk
• Develop efficient algorithm to decide the
  concurrency between threads
• Develop efficient algorithm to reduce the number
  of entries in access history

54
Primitive Idea in Concurrency Test

• (1) Labeling Scheme
• (2) Set operation
• Thread representation (fid, tid)

55

• Two sets
• Parallel set PS(f) (pf, ptid) all threads
  with tid gt ptid in function pf is parallel with
  the running thread of f
• Children set CS(f)fid fid is the descendant
  of current function
• Operations
• Spawn Thread Tx of function Fi spawn function Fj
• Operations on child Fj
• Operations on parent Fi

56

• Sync Function Fi executes sync
• PS(Fi)PS(Fi)-CS(Fi)
• Return Function Fj returns to Function Fi
• CS(Fi) CS(Fi) CS(Fj)
• Release PS(Fj) and CS(Fj)
• Concurrency Test
• Check if (fx, tx) is parallel with the current
  running thread (fc, tc)

57
Primitive Idea for Access History

• Serial
• read(l), write(l)
• Simplest parallel program without nested
  parallelism
• Two parallel read records, one write record
• Language structure like Cilk
• read max level of parallelism, one write record
• Q Is it possible to keep only two read records
  for each shared location in Cilk Parallel
  Nondeterminator?
• Keep two parallel read records with highest
  level of LCA in parent child spawn tree.

58

• Thank you very much!

59
Parallel NondeterminatorWang Junqing
60
Using Cilk
61
Accelerating Multiprocessor Simulation

• 6.895 Project Proposal
• Kenneth C. Barr

62
Introduction

• Inspiration
• UVSIM is slow
• FlexSIM is cool
• Interleave short periods of detailed simulation
  with long periods of functional warmup (eg.,
  cache and predictor updates, but not out-of-order
  logic)
• Achieve high accuracy in fraction of the time
• Multi-configuration simulation is cool
• Recognize structural properties. E.G., contents
  of FA cache are subset of all larger FA caches
  with same line size so search small-gtlarge.
  Once we hit is small cache, we can stop searching
• Simulate many configurations with a single run

63
The Meta Directory

• Combine previous ideas to speed multiprocessor
  simulation
• Sequential Consistency is what matters, perhaps
  detailed consistency mechanisms can be
  interleaved with a fast, functional equivalent
  method

64
Meta-directory example

• Detailed simulation
• P1 ld x null -gt Sh, data sent to P1
• P2 ld x Sh -gt Sh, data sent to P2
• P3 ld x Sh- gt Sh data sent to P3
• P2 st x Sh -gt Ex, inv sent to P1 and P3, data
  sent to P2
• P1 st x Ex -gt Ex, inv sent to P2, data sent to
  P1
• P2 ld x Ex -gt Sh, data sent to P2
• Shortcut
• Record access in a small meta-directory x
  P1, 0, r, P2, 1, r, P3, 2, r, P2, 3, w,
  P1, 4, w, P2, 5, r
• All reads and writes occur in a memory no
  messages sent or received, no directory modeled,
  no cache model in processor (?)
• When it comes time for detailed simulation, we
  can reconstruct directory by scanning backwards
  x is shared by P1 and P2.

65
Challenges

• Accesses stored in circular queue. How many
  records needed for each address?
• What happens when processor writes back data,
  current scheme introduces false hits.
• Does this scheme always work? Some proofs would
  be nice.

66
Methodology

• Platform
• I got Simics to boot SMP Linux
• But Bochs is open-source
• X86 is key if this is to be long-term framework
• Cilk benchmarks?
• Tasks
• Create detailed directory model
• Create meta directory
• Create a way to switch back and forth maintaining
  program correctness
• Measure the dramatic improvement!

67
Conclusion

• Reality
• Sounds daunting for December deadline, but if I
  can prove feasibility or fatal flaws, Id be
  excited
• Suggestions?

68
Project Proposal Parallelizing METIS

• Zardosht Kasheff

69
What is METIS?

• Graph Partitioning algorithm
• Developed at University of Minnesota by George
  Karypis and Vipin Kumar
• Information on METIS
• http//www-users.cs.umn.edu/karypis/metis/

70
Stages of Algorithm Coarsening

• Task Create sequentially smaller graphs that
  make good representation of original graph by
  collapsing connected nodes.
• Issues
• Minor concurrency issues.
• Maintaining data locality.
• Writing large amount of data to memory in a
  scalable fashion.

71
Stages of Algorithm Initial partitioning.

• Task partition small graph
• Issues none. Runtime of this portion of
  algorithm very small.

72
Stages of Algorithm Uncoarsening and Refinement

• Uncoarsening and Refinement project partition of
  coarsest graph to original graph and refine
  partition.
• Issues
• Major concurrency issues.
• Remaining issues under research.

73
Parallel SortingPaul Youn

• I propose to parallelize a sorting algorithm.
  Initially, looking at Quick Sort, but may
  investigate other sorting algorithms.
• Sorting is a problem that can potentially be sped
  up significantly (mergesort).
• As an alternative, considering other algorithms.

74
Goals

• Similar to Lab 1 approach.
• Speedy serial algorithm.
• Basic parallel algorithm.
• Runtime Analysis.
• Empirical verification of runtime analysis.
• Parallel speedups.

75
HELP!

• Not sure about the scope of the problem.
• Anyone out there interested in this stuff?
• Other appropriate algorithms? Max-flow?

76
PROJECT PROPOSALSMA5509Implement FIR filter in
parallel computing using Cilk

• Name Pham Duc Minh
• Matric HT030502H
• Email g0300231_at_nus.edu.sg
• phamducm_at_comp.nus.edu.sg

77
Discrete Signal

• the discrete input signal is x(n)
• the output signal is y(n)
• the impulse response h(n)

78
FIR filter

• Discrete time LTI (Linearity and Time Invariance)
  systems can be classified into FIR and IIR.
• An FIR filter has impulse response h(n) that
  extends only over a finite time interval, say 0
  n M, and is identically zero beyond that
• h0, h1, h2 . . . , hM, 0, 0, 0 . . .M is
  referred to as the filter order.
• The output y(n) in FIR is simplified to the
  finite-sum form
• or, explicitly

79
Methods to process

• 1. Block processing
• a. Convolution

(convolution table form)
80
b. Direct FormThe length of the input signal
x(n) is L The length of output y(n) will be Ly
LxLh-1
81
c. Matrix formwith the dimension of H is
82

• Overlap-Add Block Convolution Method
• above methods are not feasible in infinitive or
  extremely long applications
• divide the long input into contiguous
  non-overlapping blocks of manageable length, say
  L samples
• y0 hx0
• y1 hx1
• y2 hx2
• Thus the resulting block y0 starts at absolute
  time n 0
• block y1 starts at n L, and so on.
• The last M samples of each output block will
  overlap with
• the first M outputs of the next block .

83

• 2. Sampling Processing
• The direct form I/O convolutional equation
• We define the internal states w1(n), w2(2),
  w3(n).
• w0(n) x(n)
• w1(n) x(n-1) w0(n-1)
• w2(n) x(n-2) w1(n-1)
• ..
• With this definition, we can y(n) in the form

84

• Goal of project
• Use Cilk to implement FIR filter in parallel
• Compare with the processes of DSP kit (pipeline)
  and the process of FPGA (Field Programmable Gate
  Array) (also parallel).

85

• How to implement
• Multithreaded programming
• Cilk compiler

86
Other things

• If I finish soon, I hope additional work
  suggestion from staff.

87
Cache-Oblivious Algorithms
88
SMA5509 Theory of Parallel Systems
Project Proposal Cache-oblivious sorting for
Burrow-Wheeler Transform

• Sriram Saroop
• Advait D. Karande

89
bzip2 compression

• Lossless text compression scheme

90
Burrows-Wheeler Transform (1994)

• A pre-processing step for data compression
• Involves sorting of all rotations of the block of
  data to be compressed
• Rationale Transformed strings compress better
• Worst case complexity of N2log(N), where N size
  of block to be sorted
• Can be improved to N(logN)2 (Sadakane 98)

91
Why make it cache-oblivious?

• Performance of BWT heavily dependent on cache
  behavior (Seward 00)
• Avoid slowdown for large files with high degree
  of repetitiveness
• Especially useful in applications like bzip2 that
  are required to perform well on different memory
  structures

92
Project Plan

• Design and implementation of a cache oblivious
  algorithm for BWT sorting
• Performance comparisons with standard bzip2 for
  available benchmarks
• Back-up Optimizations for BWT including
  parallelization, and incorporating
  Cache-Obliviousness in other parts of bzip2
  compression

93
New Cache Oblivious Algorithms

• Neel Kamal
• Zhang JiaHui

94
Our Goals

• Designing Cache Oblivious Algorithms for
  problems in several areas of Compute Science.
• Finding theoretical bounds of number of cache
  misses for these algorithms.
• Trying to parallelize them

95
Large Integer Arithmetic Operations

• Basic Operators
• Addition, Subtraction
• Multiplication
• Factorial
• Matrix Multiplication
• Application RSA encryption algorithm

96
Large Integer Multiplication
Basic Idea
A B
C D
B x D
A x D
B x C
A x C
97
Dynamic Programming Algorithms

• Longest Common Sequence Basic Idea

B D C A B A
A 0 0 0 1 1 1
B 1 1 1 1 2 2
C 1 1 2 2 2 2
B 1 1 2 2 3 3
D 1 2 2 2 3 3
A 1 2 2 3 3 4
B 1 2 2 3 4 4
98
Graph Algorithm

• All-pair shortest path algorithm Floyd
• Connectivity Testing of a Graph
• And more

99
Computational Geometry

• Finding the closest pair of points
• And More

100
Concurrent Cache-Oblivious Algorithms

• Seth Gilbert

101
Cache-Oblivious Algorithms

• Optimal memory access
• Matrix multiply, Fast Fourier Transform
• B-trees, Priority Queues
• Concurrent?
• wait-free, lock-free, obstruction-free
• Synchronization?
• DCAS, CAS, LL/SC

102
Packed Memory Structure

• Operations
• Traverse(k) -- O(k/B)
• Insert -- O(log2n/B)
• Delete -- O(log2n/B)
• Goal
• Design a lock-free version of the cache-oblivious
  algorithm using CAS

103
More

• Basis for many data structure
• B-tree
• distributed data structures
• Maybe parallel nondeterminator

104
The End
105
Packed Memory Structure

• size(array) lt 4 x num. elements
• elements well-spaced in array
