Reliable Transport and Code Distribution in Wireless Sensor Networks

1
Reliable Transport and Code Distribution in
Wireless Sensor Networks

• Thanos Stathopoulos
• CS 213 Winter 04

2
Reliability Introduction

• Not an issue on wired networks
• TCP does a good job
• Link error rates are usually 10-15
• No energy cost
• However, WSNs have
• Low power radios
• Error rates of up 30 or more
• Limited range
• Energy constraints
• Retransmissions reduce lifetime of network
• Limited storage
• Buffer size cannot be too large
• Highly application-specific requirements
• No single TCP-like solution

3
Approaches

• Loss-tolerant algorithms
• Leverage spatial and temporal redundancy
• Good enough for some applications
• But what about code updates?
• Add retransmission mechanism
• At the link layer (e.g. SMAC)
• At the routing/transport layer
• At the application layer
• Hop-by-hop or end-to-end?

4
Relevant papers

• PSFQ A Reliable Transport Protocol for Wireless
  Sensor Networks
• RMST Reliable Data Transport in Sensor Networks
• ESRT Event-to-Sink Reliable Transport in
  Wireless Sensor Networks

5
PSFQ Overview

• Key ideas
• Slow data distribution (pump slowly)
• Quick error recovery (fetch quickly)
• NACK-based
• Data caching guarantees ordered delivery
• Assumption no congestion, losses due only to
  poor link quality
• Goals
• Ensure data delivery with minimum support from
  transport infrastructure
• Minimize signaling overhead for
  detection/recovery operations
• Operate correctly in poor link quality
  environments
• Provide loose delay bounds for data delivery to
  all intended receivers
• Operations
• Pump
• Fetch
• Report

6
End-to-end considered harmful ?

• Probability of reception degrades exponentially
  over multiple hops
• Not an issue in the Internet
• Serious problem if error rates are considerable
• ACKs/NACKs are also affected

7
Proposed solution Hop-by-Hop error recovery

• Intermediate nodes now responsible for error
  detection and recovery
• NACK-based loss detection probability is now
  constant
• Not affected by network size (scalability)
• Exponential decrease in end-to-end
• Cost Keeping state on each node
• Potentially not as bad as it sounds!
• Cluster/group based communication
• Intermediates are usually receivers as well

8
Pump operation

• Node broadcasts a packet to its neighbors every
  Tmin
• Data cache used for duplicate suppression
• Receiver checks for gaps in sequence numbers
• If all is fine, it decrements TTL and schedules a
  transmission
• Tmin lt Ttransmit lt Tmax
• By delaying transmission, quick fetch operations
  are possible
• Reduce redundant transmissions (dont transmit if
  4 or more nodes have forwarded the packet
  already)
• Tmax can provide a loose delay bound for the last
  hop
• D(n)Tmax ( of fragments) ( of hops)

9
Fetch operation

• Sequence number gap is detected
• Node will send a NACK message upstream
• Window specifies range of sequence numbers
  missing
• NACK receivers will randomize their transmissions
  to reduce redundancy
• It will NOT forward any packets downstream
• NACK scope is 1 hop
• NACKs are generated every Tr if there are still
  gaps
• Tr lt Tmax
• This is the pump/fetch ratio
• NACKs can be cancelled if neighbors have sent
  similar NACKs

10
Proactive Fetch

• Last segments of a file can get lost
• Loss detection impossible no next segment
  exists!
• Solution timeouts (again)
• Node enters proactive fetch mode if last
  segment hasnt been received and no packet has
  been delivered after Tpro
• Timing must be right
• Too early wasted control messages
• Too late increased delivery latency for the
  entire file
• Tpro a (Smax - Smin) Tmax
• A node will wait long enough until all upstream
  nodes have received all segments
• If data cache isnt infinite
• Tpro a k Tmax (Tpro is proportional to
  cache size)

11
Report Operation

• Used as a feedback/monitoring mechanism
• Only the last hop will respond immediately
  (create a new packet)
• Other nodes will piggyback their state info when
  they receive the report reply
• If there is no space left in the message, a new
  one will be created

12
Experimental results

• Tmax 0.3s, Tr 0.1s
• 100 30-byte packets sent
• Exponential increase in delay happens at 11 loss
  rate or higher

13
PSFQ Conclusion

• Slow data dissemination, fast data recovery
• All transmissions are broadcast
• NACK-based, hop-by-hop recovery
• End-to-end behaves poorly in lossy environments
• NACKs are superior to ACKs in terms of energy
  savings
• No out-of-order delivery allowed
• Uses data caching extensively
• Several timers and duplicate suppression
  mechanisms
• Implementing any of those on motes is challenging
  (non-preemptive FIFO scheduler)

14
RMST Overview

• A transport layer protocol
• Uses diffusion for routing
• Selective NACK-based
• Provides
• Guaranteed delivery of all fragments
• In-order delivery not guaranteed
• Fragmentation/reassembly

15
Placement of reliability for data transport

• RMST considers 3 layers
• MAC
• Transport
• Application
• Focus is on MAC and Transport

16
MAC Layer Choices

• No ARQ
• All transmissions are broadcast
• No RTS/CTS or ACK
• Reliability deferred to upper layers
• Benefits no control overhead, no erroneous path
  selection
• ARQ always
• All transmissions are unicast
• RTS/CTS and ACKs used
• One-to-many communication done via multiple
  unicasts
• Benefits packets traveling on established paths
  have high probability of delivery
• Selective ARQ
• Use broadcast for one-to-many and unicast for
  one-to-one
• Data and control packets traveling on established
  paths are unicast
• Route discovery uses broadcast

17
Transport Layer Choices

• End-to-End Selective Request NACK
• Loss detection happens only at sinks (endpoints)
• Repair requests travel on reverse (multihop) path
  from sinks to sources
• Hop-by-Hop Selective Request NACK
• Each node along the path caches data
• Loss detection happens at each node along the
  path
• Repair requests sent to immediate neighbors
• If data isnt found in the caches, NACKs are
  forwarded to next hop towards source

18
Application Layer Choices

• End-to-End Positive ACK
• Sink requests a large data entity
• Source fragments data
• Sink keeps sending interests until all fragments
  have been received
• Used only as a baseline

19
RMST details

• Implemented as a Diffusion Filter
• Takes advantage of Diffusion mechanisms for
• Routing
• Path recovery and repair
• Adds
• Fragmentation/reassembly management
• Guaranteed delivery
• Receivers responsible for fragment retransmission

• Receivers arent necessarily end points
• Caching or non-caching mode determines
  classification of node

20
RMST Details (contd)

• NACKs triggered by
• Sequence number gaps
• Watchdog timer inspects fragment map periodically
  for holes that have aged for too long
• Transmission timeouts
• Last fragment problem
• NACKs propagate from sinks to sources
• Unicast transmission
• NACK is forwarded only if segment not found in
  local cache
• Back-channel required to deliver NACKs to
  upstream neighbors

21
Evaluation

• NS-2 simulation
• 802.11 MAC
• 21 nodes
• single sink, single source
• 6 hops
• MAC ARQ set to 4 retries
• Image size 5k
• 50 100-byte fragments
• Total cost of sending the entire file 87,818
  bytes
• Includes diffusion control message overhead
• All results normalized to this value

22
Results Baseline (no RMST)

• ARQ and S-ARQ have high overhead when error rates
  are low
• S-ARQ is better in terms of efficiency
• Also helps with route selection
• No ARQ results drop considerably as error rates
  increase
• Exponential decay of end-to-end reliability
  mechanisms

23
Results RMST with H-b-H Recovery and Caching

• Slight improvement for ARQ and S-ARQ results over
  baseline
• No ARQ is better even in the 10 error rate case
• But, many more exploratory packets were sent
  before the route was established

24
Results RMST with E-2-E Recovery

• No ARQ doesnt work for the 10 error rate case
• Numerous holes that required NACKs couldnt make
  it from source to sink without link-layer
  retransmissions
• ARQ and S-ARQ results are statistically
  insignificant from H-b-H results
• NACKs were very rare when any form of ARQ was
  used

25
Results Performance under High Error Rates

• No ARQ doesnt work for the 30 error rate case
• Diffusion control messages could not establish
  routes most of the time
• In the 20 case, it took several minutes to
  establish routes

26
RMST Conclusion

• ARQ helps with unicast control and data packets
• In high error-rate environments, routes cannot be
  established without ARQ
• Route discovery packets shouldnt use ARQ
• Erroneous path selection can occur
• RMST combines a NACK-based transport layer
  protocol with S-ARQ to achieve the best results

27
Congestion Control

• Sensor networks are usually idle
• Until an event occurs
• High probability of channel overload
• Information must reach users
• Solution congestion control

28
ESRT Overview

• Places interest on events, not individual pieces
  of data
• Application-driven
• Application defines what its desired event
  reporting rate should be
• Includes a congestion-control element
• Runs mainly on the sink
• Main goal Adjust reporting rate of sources to
  achieve optimal reliability requirements

29
Problem Definition

• Assumption
• Detection of an event is related to number of
  packets received during a specific interval
• Observed event reliability ri
• of packets received in decision interval I
• Desired event reliability R
• of packets required for reliable event
  detection
• Application-specific
• Goal configure the reporting rate of nodes
• Achieve required event detection
• Minimize energy consumption

30
Reliability vs Reporting frequency

• Initially, reliability increases linearly with
  reporting frequency
• There is an optimal reporting frequency (fmax),
  after which congestion occurs
• Fmax decreases when the of nodes increases

31
Characteristic Regions

• n normalized reliability indicator
• (NC,LR) No congestion, Low reliability
• f lt fmax, n lt 1-e
• (NC, HR) No congestion, High reliability
• f lt fmax, n lt 1e
• (C, HR) Congestion, High reliability
• f gt fmax, n gt 1
• (C, LR) Congestion, Low reliability
• f lt fmax, n lt 1
• OOR Optimal Operating Region
• f lt fmax, 1-e lt n lt 1e

32
Characteristic Regions
33
ESRT Requirements

• Sink is powerful enough to reach all source nodes
  (i.e. single-hop)
• Nodes must listen to the sink broadcast at the
  end of each decision interval and update their
  reporting rates
• A congestion-detection mechanism is required

34
Congestion Detection and Reliability Level

• Both done at the sink
• Congestion
• Nodes monitor their buffer queues and inform the
  sink if overflow occurs
• Reliability Level
• Calculated by the sink at the end of each
  interval based on packets received

35
ESRT Protocol Operation

• (NC, LR)
• (NC, HR)
• (C, HR)
• (C, LR)

36
ESRT Conclusion

• Reliability notion is application-based
• No delivery guarantees for individual packets
• Reliability and congestion control achieved by
  changing the reporting rate of nodes
• Pushes all complexity to the sink
• Single-hop operation only

37
Code Distribution Introduction

• Nature of sensor networks
• Expected to operate for long periods of time
• Human intervention impractical or detrimental to
  sensing process
• Nevertheless, code needs to be updated
• Add new functionality
• Incomplete knowledge of environment
• Predicting right set of actions is not always
  feasible
• Fix bugs
• Maintenance

38
Approaches

• Transfer the entire binary to the motes
• Advantage
• Maximum flexibility
• Disadvantage
• High energy cost due to large volume of data
• Use a VM and transfer capsules
• Advantage
• Low energy cost
• Disadvantages
• Not as flexible as full binary update
• VM required
• Reliability is required regardless of approach

39
Papers

• A Remote Code Update Mechanism for Wireless
  Sensor Networks
• Trickle A Self-Regulating Algorithm for Code
  Propagation and Maintenance in Wireless Sensor
  Networks

40
MOAP Overview

• Code distribution mechanism specifically targeted
  for Mica2 motes
• Full binary updates
• Multi-hop operation achieved through recursive
  single-hop broadcasts
• Energy and memory efficient

41
Requirements and Properties of Code Distribution

• The complete image must reach all nodes
• Reliability mechanism required
• If the image doesnt fit in a single packet, it
  must be placed in stable storage until transfer
  is complete
• Network lifetime shouldnt be significantly
  reduced by the update operation
• Memory and storage requirements should be moderate

42
Resource Prioritization

• Energy Most important resource
• Radio operations are expensive
• TX 12 mA
• RX 4 mA
• Stable storage (EEPROM)
• Everything must be stored and Write()s are
  expensive
• Memory usage
• Static RAM
• Only 4K available on current generation of motes
• Code update mechanism should leave ample space
  for the real application
• Program memory
• MOAP must transfer itself
• Large image size means more packets transmitted!
• Latency
• Updates dont respond to real-time phenomena
• Update rate is infrequent
• Can be traded off for reduced energy usage

43
Design Choices

• Dissemination protocol How is data propagated?
• All at once (flooding)
• Fast
• Low energy efficiency
• Neighborhood-by-neighborhood (ripple)
• Energy efficient
• Slow
• Reliability mechanism
• Repair scope local vs global
• ACKs vs NACKs
• Segment management
• Indexing segments and gap detection Memory
  hierarchy vs sliding window

44
Ripple Dissemination

• Transfer data neighborhood-by-neighborhood
• Single-hop
• Recursively extended to multi-hop
• Very few sources at each neighborhood
• Preferably, only one
• Receivers attempt to become sources when they
  have the entire image
• Publish-subscribe interface prevents nodes from
  becoming sources if another source is present
• Leverage the broadcast medium
• If data transmission is in progress, a source
  will always be one hop away!
• Allows local repairs
• Increased latency

45
Reliability Mechanism

• Loss responsibility lies on receiver
• Only one node to keep track of (sender)
• NACK-based
• In line with IP multicast and WSN reliability
  schemes
• Local scope
• No need to route NACKs
• Energy and complexity savings
• All nodes will eventually have the same image

46
Retransmission Policies

• Broadcast RREQ, no suppression
• Simple
• High probability of successful reception
• Highly inefficient
• Zero latency
• Broadcast RREQ, suppression based on randomized
  timers
• Quite efficient
• Complex
• Latency and successful reception based on
  randomization interval

47
Retransmission Policies (contd)

• Broadcast RREQ, fixed reply probability
• Simple
• Good probability of successful reception
• Latency depends on probability of reply
• Average efficiency
• Broadcast RREQ, adaptive reply probability
• More complex than the static case
• Similar latency/reception behavior
• Unicast RREQ, single reply
• Smallest probability of successful reception
• Highest efficiency
• Simple
• Complexity increases if source fails
• Zero latency
• High latency if source fails

48
Segment Management Discovering if a segment is
present

• No indexing
• Nothing kept in RAM
• Need to read from EEPROM to find if segment i is
  missing
• Full indexing
• Entire segment (bit)map is kept in RAM
• Look at entry i (in RAM) to find if segment is
  missing
• Partial indexing
• Map kept in RAM
• Each entry represents k consecutive segments
• Combination of RAM and EEPROM lookup needed to
  find if segment i is missing

49
Segment Management (contd)

• Hierarchical full indexing
• First-level map kept in ram
• Each entry points to a second-level map stored in
  EEPROM
• Combination of RAM and EEPROM lookup needed to
  find if segment i is missing
• Sliding window
• Bitmap of up to w segments kept in RAM
• Starting point last segment received in order
• RAM lookup
• Limited out-of-order tolerance!

50
Retransmission Polices Comparison
51
Segment Management Comparison
52
Results Energy efficiency

• Significant reduction in traffic when using
  Ripple
• Up to 90 for dense networks
• Full Indexing performs 5-15 better than Sliding
  Window
• Reason better out-of-order tolerance
• Differences diminish as network density grows

53
Results Latency

• Flooding is 5 times faster than Ripple
• Full indexing is 20-30 faster than Sliding
  window
• Again, reason is out-of-order tolerance

54
Results Retransmission Policies

• Order-of-magnitude reduction when using unicasts

55
Current Mote implementation

• Using Ripple-sliding window with unicast
  retransmission policy
• User builds code on the PC
• Packetizer creates segments out of binary
• Mote attached to PC becomes original source and
  sends PUBLISH message
• Receivers 1 hop away will subscribe, if version
  number is greater than their own
• When a receiver gets the full image, it will send
  a PUBLISH message
• If it doesnt receive any subscriptions for some
  time, it will COMMIT the new code and invoke the
  bootloader
• If a subscription is received, node becomes a
  source
• Eventually, sources will also commit

56
Current Mote Implementation (contd)

• Retransmissions have higher priority than data
  packets
• Duplicate requests are suppressed
• Nodes keep track of their sources activity with
  a keepalive timer
• Solves NACK last packet problem
• If the source dies, the keepalive expiration will
  trigger a broadcast repair request
• Late joiner mechanism allows motes that have just
  recovered from failure to participate in code
  transfer
• Requires all nodes to periodically advertise
  their version
• Footprint
• 700 bytes RAM
• 4.5K bytes ROM

57
MOAP Conclusion

• Full binary updates over multiple hops
• Ripple dissemination reduces energy consumption
  significantly
• Sliding window method and unicast retransmission
  policy also reduce energy consumption and
  complexity
• Successful updates of images up to 30K in size
• Next steps
• Larger experiments
• Better Late Joiner mechanism
• Verification phase
• Sending DIFFS instead of full image

58
Trickle Overview

• State synchronization/code propagation mechanism
• Suitable for VM environments, where transmitted
  code is small
• Uses polite gossip dissemination
• Periodic broadcasts of state summary
• Nodes overhear transmissions and stay quiet
  unless they need to update
• Goals
• Propagation install new code
• Maintenance detect propagation need

59
Basic Mechanism

• A node will periodically transmit information
• Only if less than a number of neighbors hasnt
  sent the same data
• Cells (neighborhoods) can be in two states
• All nodes up to date
• Update needed
• Node learns about new code
• Node detects neighbor with old code
• Since communication can be transmission or
  reception, ideally only one node per cell needs
  to transmit
• Similar to MOAPs ideal single-source scenario

60
Maintenance

• Time is split in periods
• Nodes pick a random slot from 0..T
• Transmission occurs if a node has heard less than
  K other identical transmissions
• Otherwise, node stays quiet
• K is small (1 or 2 usually)
• If a node detects a neighbor that is out of date,
  it transmits the newer code
• If a node detects it is out of date, it transmits
  its state
• Update is triggered when other nodes receive this
  transmission
• Nodes transmit at most once per period
• In the presence of losses, scaling property is
  O(logn)

61
Maintenance and timesync

• When nodes are synchronized, everything works
  fine
• If nodes are out of sync, some might transmit
  before others had a chance to listen
• Short-listen problem
• O(sqrt(n)) scaling
• Solution Enforce a listen-only periond
• Pick a slot from T/2..T for transmission

62
Maintenance and timesync (contd)
63
Propagation

• Large T
• Low communication overhead (less probable to pick
  same slot)
• High latency
• Small T reversed
• Solution dynamic scaling of T
• Use two bounds TL and TH
• When T expires, it doubles until it reaches TH
• When newer state is overheard, T TL
• When older state is overheard, immediately send
  updates
• When new code is installed, T TL
• Helps spread new code quickly

64
Propagation Summary
65
Trickle Conclusion

• Efficient state synchronization protocol
• Fast
• Limits transmissions (localized flood)
• Scales well with network size
• Does not propagate code per se
• Instead, it notifies the system that update is
  needed
• In many cases, determining when to propagate can
  be more expensive than propagation
• Contrast with MOAPs simple late-joiner algorithm

66
The End!
