Verifying Compilers with Heifer

1
Verifying Compilers with Heifer

• Edwin Westbrook
• advisor Aaron Stump

2
Software is Everywhere

• We want this software to work!

cell phones
cars
airplanes
3
What if Software Fails?
Mars rover frozen for three days on Mars
Therac-25 five people killed from overdoses of
radiation
MIM-104 Patriot missile failed to shoot down
scuds in first Iraq war
4
Why Verify Compilers?

• Compilers are just another program
• Can be incorrect
• Cause other programs to be incorrect
• Everyone assumes compiler is correct
• Need to go through lots of assembly to even
  notice a problem
• Most of us could/would not do this

5
Why Verify Compilers?

• Compilers are getting more complicated
• Vast research area, hundreds of papers per year
• Changing hardware e.g. multiple cores
• More prone to compiler bugs!

6
How to Verify Compilers?

• Anatomy of a compiler

Parser
Code Generation
Internal representation
Optimization
7
How to Verify Compilers?

• Anatomy of a compiler

Parser
Code Generation
Internal representation
Not changed much
Optimization
8
How to Verify Compilers?

• Anatomy of a compiler

Parser
Code Generation
Internal representation
Not changed much
Source of most bugs
Optimization
9
How to Verify Compilers?

• Optimization and code generation have same form

code
transform
transformed code
10
How to Verify Compilers?

• Optimization and code generation have same form

code
Need to verify these are equivalent code
transform
transformed code
11
How to Verify Compilers?

• The Heifer solution

code
transform-is-correct
proof that transform(code) is equivalent to code
12
How to Verify Compilers?

• The Heifer solution

code

• Ensures transform is correct on any input

transform-is-correct
proof that transform(code) is equivalent to code
13
How to Verify Compilers?

• The Heifer solution

code

• Ensures transform is correct on any input
• Need not run at runtime no overhead

transform-is-correct
proof that transform(code) is equivalent to code
14
What is Heifer?

• Functional no mutable data
• Strongly typed everything has an explicit type
  no casts
• Work in progress

15
Basics of Heifer

• Data is made of constructors
• Given by user declarations
• Example natural numbers

0 nat succ nat -gt nat
3 represented as succ (succ (succ 0))
16
Basics of Heifer

• Data is made of constructors
• Given by user declarations
• Example lists of natural numbers

nil list cons nat -gt list -gt list
0, 1 represented as cons 0 (cons (succ 0) nil)
17
Basics of Heifer

• Functions work by pattern matching

plus x 0 x
plus x (succ y) succ (plus x y)
append nil L L
append L1 (cons x L2) cons x (append L1 L2)
18
Basics of Heifer

• Functions work by pattern matching

plus x 0 x
Base case
plus x (succ y) succ (plus x y)
append nil L L
append L1 (cons x L2) cons x (append L1 L2)
19
Basics of Heifer

• Functions work by pattern matching

plus x 0 x
Base case
plus x (succ y) succ (plus x y)
Recursive case
append nil L L
append L1 (cons x L2) cons x (append L1 L2)
20
Lets Write a C Compiler

• Internal representation of C

plus c-expr -gt c-expr -gt c-expr times c-expr
-gt c-expr -gt c-expr int-lit int -gt c-expr
21
Lets Write a C Compiler

• Internal representation of C

plus c-expr -gt c-expr -gt c-expr times c-expr
-gt c-expr -gt c-expr int-lit int -gt c-expr
x y 2
Represented as
plus (times y (int-lit (succ (succ 0))))
22
Argument Names are Special

• Names can change when they do not clash

int z // global variable int foo (int x, int y)
return x y z
23
Argument Names are Special

• Names can change when they do not clash

int z // global variable int foo (int v, int w)
return v w z
Same program
24
Argument Names are Special

• Names can change when they do not clash

int z // global variable int foo (int z, int w)
return z w z
Different program name clash with global
variable z
25
Argument Names are Special

• Heifer has special argument binding syntax

int foo (int x, int y) return x y 2
Represented as
c-func foo int lx.ly.plus x (times y )
26
Argument Names are Special

• Heifer has special argument binding syntax

int foo (int x, int y) return x y 2
l binds argument names
Represented as
c-func foo int lx.ly.plus x (times y )
27
Argument Names are Special

• Heifer has special argument binding syntax

int foo (int x, int y) return x y 2
l binds argument names
Represented as
c-func foo int lx.ly.plus x (times y )
Equivalent representation in Heifer
c-func foo int lv.lw.plus v (times w )
28
Verifying Compilers with Heifer

• Example constant folding

int foo (int x, int y) return x y
(factorial 2)
fold-constants
29
Verifying Compilers with Heifer

• Example constant folding

int foo (int x, int y) return x y
(factorial 2)
Constant expression
fold-constants
30
Verifying Compilers with Heifer

• Example constant folding

int foo (int x, int y) return x y
(factorial 2)
Constant expression
fold-constants
int foo (int x, int y) return x y 2
31
Verifying Compilers with Heifer

• Verifying constant folding

int foo (int x, int y) return x y
(factorial 2)
fold-constants-is-correct
32
Verifying Compilers with Heifer

• Verifying constant folding

int foo (int x, int y) return x y
(factorial 2)
fold-constants-is-correct
Proof that code with is 2 is equivalent to code
with (factorial 2)
33
Representing Proofs

• Proofs ensure that something is true
• Can make proofs only of true properties
• Example proofs that n lt m
• Data with type less-than n m is proof that nltm
• Can make proof with type less-than 2 4
• Cannot make proof with type less-than 4 2

34
Representing Proofs

• Can define less-than n m as follows

less-than-base n less-than n (succ n)
less-than-ind n m less-than n m
-gt less-than n (succ m)
35
Representing Proofs

• Can define less-than n m as follows

less-than-base n less-than n (succ n)
less-than-ind n m less-than n m
-gt less-than n (succ m)
Builds proof of n lt n1
36
Representing Proofs

• Can define less-than n m as follows

less-than-base n less-than n (succ n)
less-than-ind n m less-than n m
-gt less-than n (succ m)
Builds proof of n lt n1
Takes proof of n lt m and builds proof of n lt m1
37
Representing Proofs

• Can define less-than n m as follows

less-than-base n less-than n (succ n)
less-than-ind n m less-than n m
-gt less-than n (succ m)
Builds proof of n lt n1
Takes proof of n lt m and builds proof of n lt m1
Cannot make proofs with type less-than 4 2
38
Conclusion

• Heifer supports compiler writing
• Special support for argument names
• Heifer supports compiler verification
• Verification programs output proofs

39
Acknowledgements

• Ben Delaware
• implementation
• Fritz Heckel, Charlie Comstock, Morgan Deters,
  Rob LeGrand, Bob Zimmermann
• Comments and feedback on talk
