NoiseCanceling Headphones

1
Noise-Canceling Headphones

• David Ringle
• Engr311A Personal Project

2
Additional Features

• Can mix in a line-level input
• CD / DVD Player
• Dictaphone
• Can switch from Out-of-Phase to In-Phase
• Stethoscope-like Audio Probe
• Directional Microphones
• Hearing Aids

3
How Noise Cancellation Works

• Wave Addition

Destructive Interference


Constructive Interference


4
Circuit Design
5
Cadence Implementation
Inputs, Output Power
Potentiometers

• Aux Input was modeled as a large resistance in
  testing of the primary circuit

6
Inverting (Out-of-Phase)
7
Non-Inverting (In-Phase)
8
Inverting w/ Aux Input
9
Physical Implementation

• Used Audio-Taper instead of Linear-Taper Pots
• Should be no drawbacks
• Radio Shack only carried audio
• Cheaper than online equivalents

• Used UA741 OpAmps instead of NE5532 ICs
• Documentation was wrong on the original circuit!
• Slew rate should not be a problem
• Current may be an issue
• Transistor solution?
