CTIS 490 DISTRIBUTED SYSTEMS

1
CTIS 490DISTRIBUTED SYSTEMS

• WEEK 13
• DISTRIBUTED WEB-BASED SYSTEMS

2
INTRODUCTION

• The World Wide Web (WWW) can be viewed as a huge
  distributed system with millions of clients and
  servers for accessing linked documents.
• Servers maintain collections of documents while
  clients provide users an easy-to-use interface
  for presenting and accessing those documents.
• A document is fetched from a server, transferred
  to a client, and presented on the screen. To a
  user there is conceptually no difference between
  a document stored locally or in another part of
  the world.

3
INTRODUCTION

• Now, Web has become more than just a simple
  document based system.
• Since 1994, the World Wide Web Consortium (W3C)
  is responsible for standardizing protocols,
  improving interoperability, and enhancing
  capabilities.
• With the emergence of Web services, it is
  becoming a system of distributed services rather
  than just documents offered to any user or
  machine.

4
TRADITIONAL WEB-BASED SYSTEMS

• Many Web-based systems are still organized as
  simple client-server architectures.
• The core of a Web site is formed by a process
  that has access to a local file system storing
  documents.
• A reference called Uniform Resource Locator (URL)
  is used to refer a document.
• The DNS name of its associated server along with
  a file name is specified.

5
TRADITIONAL WEB-BASED SYSTEMS

• The URL also specifies the protocol for
  transferring the documents across the network.
• A client interacts with Web servers through a
  special application known as browser.
• A browser is responsible for properly displaying
  a document.

6
TRADITIONAL WEB-BASED SYSTEMS

• The overall organization of a traditional Web
  site.

7
WEB DOCUMENTS

• A Web document does not only contain text, but it
  can include all kinds of dynamic features such as
  audio, video, animations, etc.
• In many cases special helper applications
  (interpreters) are needed, and they are
  integrated into the browser.
• The main part of Web documents are written in a
  markup language.
• The most widely used markup language is HyperText
  Markup Language (HTML). The other markup language
  is the eXtensible Markup Language (XML).

8
WEB DOCUMENTS

• Both HTML and XML are subsets of Standard
  Generalized Markup Language (SGML).
• The major difference between the two is that XML
  is a meta-markup language, i.e. unlimited set of
  tags can be defined.
• HTML and XML can include tags that refer to
  embedded documents, which are references to other
  files.
• An embedded document can be a complete program
  executed on-the-fly as part of displaying
  information.

9
WEB DOCUMENTS

• Multipurpose Internet Mail Exchange (MIME) is
  used to specify the type of an embedded document.
• MIME was originally developed to provide
  information on the content of e-mail messages.
• MIME can distinguish various types of message
  contents.
• A content includes a type and a subtype
  identifiers.

10
WEB DOCUMENTS

• Six top-level MIME types and some common subtypes.

11
WEB DOCUMENTS

• The application type is for data which do not
  fit any of the other categories. It should be
  processed by an application program to make it
  viewable or usable. For example, application/PDF
  requires a separate application to process the
  document.
• The multipart type is used for composite
  documents in which they consist of several parts
  where each part will have its associated
  top-level type.
• The variety of document types forces browser to
  be extensible. As a result, plug-ins are required
  to follow a standard interfaces so that they can
  be easily integrated with the browsers.

12
MULTITIERED ARCHITECTURES

• Web documents can be built in two ways
• Static locates and returns the object
  identified in the request. Static objects include
  predefined HTML pages and JPEG or GIF files. Web
  servers do not require communication with any
  server-side application.
• Dynamic the request is forwarded to an
  application system where the resulting reply is
  generated dynamically, i.e. data is generated
  through a server-side program execution.
• Although Web started as simple two-tiered
  client-server architecture for static Web
  documents, this architecture has been extended to
  support advanced type of documents.

13
MULTITIERED ARCHITECTURES

• One of the first enhancements is Common Gateway
  Interface (CGI).
• A CGI program resides on the server machine. The
  Web server interfaces with this program to
  process user requests.
• Usually, user data comes from an HTML form it
  specifies the program that is to be executed at
  the server side, along with parameters that are
  filled by the user.

14
MULTITIERED ARCHITECTURES

• After program finishes its work, Web server sends
  the results back to users browser to be
  displayed.
• With CGI programs, fetching a document could be
  delegated in such a way that the server would
  remain unaware of whether a document had been
  generated on the fly or read from a file.

15
MULTITIERED ARCHITECTURES

• The principle of using server-side CGI programs.

16
MULTITIERED ARCHITECTURES

• Because of the server-side processing many Web
  sites are now organized as three-tiered
  architectures consisting of a Web server, an
  application server, and a database server.
• In many cases the server runs Java programs
  called servlets that maintain things like
  shopping carts, implement recommendations, keep
  list of favorite items, etc.
• Server-side scripting technologies are used by
  running a script directly on the Web server to
  generate dynamic content.
• Server-side scripting technologies include
• Microsoft Active Server Pages (ASP.NET)
• Sun Java Server Pages (JSP)
• Netscape JavaScript
• Free Software Foundation PHP

17
CLIENTS

• Web client software, the browser, provides an
  interface by which hyperlinks are displayed so
  that a user can select them through a mouse
  click.
• Web browsers are platform independent. This goal
  is achieved by using standard graphical and
  networking libraries.
• The core of a browser is formed by the browser
  engine and the rendering engine.
• The browser engine provides mechanisms for the
  user to go over a document, select parts of it,
  activate hyperlinks, etc.
• The rendering engine requires parsing HTML or
  XML, interpreting the scripts i.e. JavaScript,
  and network communications.

18
CLIENTS

• The logical components of a Web browser.

19
CLIENTS

• Web browsers should be easily extensible to
  support any type of documents returned by a
  server.
• A plug-in which is a small program that can be
  dynamically loaded into a browser to handle a
  specific document type. As a result, it is an
  extension of the rendering engine.
• Plug-ins and browsers conform to a standard
  interface.
• Another client-side process is a Web proxy used
  to allow a browser to handle protocols other than
  HTTP, such as FTP.
• For example, to transfer a file from an FTP
  server, the browser can issue an HTTP request to
  a local FTP proxy which will fetch the file and
  return it.

20
CLIENTS

• Using a Web proxy when the browser does not speak
  FTP.

21
APACHE WEB SERVER

• By far the most popular Web server is Apache. As
  of March 2007, 58 of all websites are using it.
• Apache is platform independent. This independence
  is realized by providing its own runtime
  environment, which is implemented for different
  operating systems.
• This runtime is known as the Apache Portable
  Runtime (APR), which is a library that provides
  an interface for file handling, networking,
  locking, threads, etc.
• Apache uses the concept of a hook, which is a
  placeholder for a specific group of functions.
• Hooks are used to translate a URL to a local file
  name, to write information to a log, to check a
  clients identification, to check access rights,
  etc.

22
WEB SERVER CLUSTERS

• Web servers are replicated and combined with a
  front end
• to improve performance.

23
WEB SERVER CLUSTERS

• The front end can be designed in two ways
• Transport-layer switch simply passes data sent
  along the TCP connection to one of the servers ,
  depending on some measurement of the servers
  load.
• Content-aware request distribution it first
  inspects the HTTP request and decides which
  server it should forward that request to. For
  example, if the front end always forwards
  requests for the same document to the same
  server, the server may cache the document
  resulting in higher response times.
• The two can also be combined as illustrated in
  the next figure.

24
WEB SERVER CLUSTERS

• A scalable content-aware cluster of Web servers.

25
WEB SERVER CLUSTERS

• Another alternative to set up a Web server
  cluster is to use round-robin DNS.
• With round-robin DNS a single domain name is
  associated with multiple IP addresses.
• When resolving a host name, a browser would
  receive a list of multiple addresses, each
  address corresponding a server.
• Normally, browsers choose the first address on
  the list, but most DNS servers circulate the
  entries.
• As a result, simple distribution of requests over
  the servers in the cluster is achieved.

26
HTTP

• All communication between the clients and servers
  is based on the HTTP. Servers listen on port 80.
• HTTP is a simple protocol a client sends a
  request to a server and waits for a response.
• HTTP is stateless it does not have any concept
  of open connection and does not require a server
  to maintain information on its clients.
• HTTP is based on TCP whenever a client issues a
  request to a server, it first sets up a TCP
  connection and sends the message on that
  connection. The same connection is used for
  receiving the response.
• One of the problems with the first versions of
  HTTP was its inefficient use of TCP connections.

27
HTTP CONNECTIONS

• (a) Using non-persistent connections.

(b) Using persistent connections.
28
HTTP CONNECTIONS

• A Web document is constructed from a collection
  of different files from the same server.
• In HTTP version 1.0 and older, each request to a
  server required setting up a separate connection.
  When server had responded the connection was
  broken down. These connections are referred as
  nonpersistent.
• In HTTP version 1.1, several requests and their
  responses can be issued without the need for a
  separate connection. These connections are
  referred as persistent.
• Furthermore, a client can issue several requests
  in a row without waiting for the response to the
  first request which is referred as pipelining.

29
HTTP METHODS

• Operations supported by HTTP.

30
HTTP METHODS

• HTTP assumes that each document may have a
  separate header that is sent along with a request
  or response.
• For example, the head operation may only return
  the time the document was modified to verify the
  validity of the document as cached by the client.
• The most important operation is get which
  actually fetches a document. It is also possible
  to specify that a document should be returned
  only if it has been modified after a specific
  time.

31
HTTP METHODS

• The put operation is opposite of get
  operation and it stores a document.
• The post operation is similar to put
  operation except that a client will request data
  to be added to a document or a collection of
  documents. An example is posting an article to a
  news group.
• The delete operation will remove the document.

32
HTTP MESSAGES

• HTTP only recognizes request and response
  messages, and they contain three parts
• Request/Status line
• Request/Response message headers
• Message body
• Request line specifies the operation and
  reference to the document associated with the
  request. HTTP version number in which client is
  expecting is identified.
• Status line contains version number and three
  digit status code. The code is explained with a
  textual phrase. For example code 200 is
  associated with phrase OK.
• Other frequently used codes are 400 (Bad
  Request), 403 (Forbidden), and 404 (Not Found).

33
HTTP MESSAGES

• (a) HTTP request message.

34
HTTP MESSAGES

• (a) HTTP response message.

35
HTTP MESSAGES

• There are also various message headers that the
  client can send to the server explaining what it
  is able to accept as a response.
• For example, a client may accept responses
  containing gzip compression program.
• In this case, client will send an Accept-Encoding
  message header with its content containing
  Accept-Encodinggzip
• For example, accept message header ca be used to
  specify only HTML Web pages may be returned.

36
HTTP MESSAGES

• Some HTTP message headers.

37
HTTP MESSAGES

• Some HTTP message header (continued).

38
SOAP

• Simple Object Access Protocol (SOAP) is a
  protocol for exchanging XML-based messages
  generally using the HTTP.
• It is used to invoke methods over the Web
  regardless of operating system, object model, or
  lanhuage particular application.
• Originally developed by Microsoft, it is now
  maintained by the World Wide Web Consortium
  (W3C).
• http//www.w3.org/TR/soap12-part0/
• There is a serious performance bottleneck parsing
  the SOAP messages.

39
SOAP

• Request
• ltSOAPBodygt
• ltAddTwoNumbersgt
• ltFirstNumbergt5lt/FirstNumbergt
• ltSecondNumbergt3lt/SecondNumbergt
• lt/AddTwoNumbersgt
• lt/SOAPBodygt
• Response
• ltSOAPBodygt
• ltAddTwoNumbersResponsegt
• ltValuegt8lt/Valuegt
• lt/AddTwoNumbersResponsegt
• lt/SOAPBodygt
• Source
• http//searchwebservices.techtarget.com/searchWebS
  ervices/downloads/what_is_soap.swf

40
SERVICE-ORIENTED ARCHITECTURES (SOA)

• A means of developing distributed systems where
  the components are stand-alone services.
• Services may execute on different computers from
  different service providers.
• Standard protocols have been developed to support
  service communication and information exchange.

41
SERVICE-ORIENTED ARCHITECTURES (SOA)
42
SERVICE-ORIENTED ARCHITECTURES (SOA)

• There are several service models, but mainly in a
  SOA
• A service provider offers a service by defining
  its interface and implementing the service
  functionality.
• A service requestor binds that service into its
  application. This means that the requestors
  application includes code to call that service
  and process results of the service call.
• To ensure that the service can be accessed, the
  service provider makes an entry in a service
  registry that includes information about the
  service and what it does.

43
SERVICE-ORIENTED ARCHITECTURES (SOA)

• The differences between this service model and
  distributed object approach to distributed
  systems architectures are
• Service can be offered by any service provider
  inside or outside of an organization. For
  example, a manufacturing company can link
  directly to services provided by its suppliers.
• The service provider and service user do not need
  to agree about what the service does before it
  can be incorporated in an application program.

44
SERVICE-ORIENTED ARCHITECTURES (SOA)

• Applications can delay the binding of services
  until they are deployed. Therefore, an
  application using a stock price service can
  dynamically change service providers while system
  is executing.
• Service user can create innovative applications
  by combining various services.
• Service users can pay according to their use
  instead of buying an expensive component that is
  rarely used.

45
WEB SERVICES

• The development of the Web meant that client
  computers had access to remote servers outside of
  their organizations.
• However, access was only through a Web browser,
  and direct access to the servers by other
  programs was not practical. For example, querying
  a number of catalogs was not possible.
• Web services architecture is an instance of the
  Service Oriented Architecture.
• The services are provided over the Internet.

46
WEB SERVICES - EXAMPLES

• Microsoft MapPoint http//www.microsoft.com/mappoi
  nt/products/webservice/default.mspx
• One of the first commercial Web services.
• Developers can integrate mapping functionality
  including street maps, driving directions,
  proximity searches into their applications.
• It also provides business listings and points of
  interest that can be used with mapping.

47
WEB SERVICES - EXAMPLES

• Source http//www.ajlopez.net/ArticuloVe.php?Id
  340

48
WEB SERVICES - EXAMPLES

• TerraServer USA
• http//terraserver-usa.com/webservices.aspx
• 1998 Microsoft researches set up a database for
  aerial and satellite images of earth and made it
  public.
• TerraService provides Web services to
  geography-oriented applications.

49
WEB SERVICES

• Web services are based on the following standards
  http//www.w3.org/TR/2003/WD-ws-arch-20030808/
• Simple Object Access Protocol (SOAP) This
  XML-based protocol defines data exchange between
  Web services.
• Web Services Description Language (WSDL) This
  XML-based protocol defines how the interfaces of
  Web services can be represented. A WSDL file
  describes what a service does and how to invoke
  its operations.
• Universal Description, Discovery, and Integration
  (UDDI). This is a standard that specifies
  information about service provider, the services
  provided, and the location of service description.

50
WEB SERVICES
51
WEB SERVICES

• For example, a Web service such as a mapping
  service takes two addresses and tells you how to
  travel between them.
• To create such a service, the following steps
  must be done
• Service developer must write a service
  application that conforms to standards.
• Service developer must deploy the application so
  that other applications can use it.
• Service developer must describe the interfaces
  and endpoint needed for a client to make calls to
  the service using an XML-based WSDL file.

52
WEB SERVICES

• Service developer must register (publish) the
  service description to the UDDI registry
• Post information about company
• Categorize the service such as e-commerce,
  weather service, map service, etc.
• Specify URL of the service description WSDL file
• Client developer must go to the UDDI registry and
  look for the required functionality.
• Once the functionality is found, he/she should
  obtain the specific WSDL file.

53
WEB SERVICES

• Client developer must use the WSDL file to
  generate the client stub code to make calls to
  the remote service.
• Client developer must incorporate the stub code
  into client application and make calls to it.
  Stub handles the required protocols.
• Source http//java.sun.com/j2me/reference/whitepa
  pers/Web_Svcs_wp072904.pdf

54
NAMING

• The Web uses a single naming system to refer to
  documents. The names used are called Uniform
  Resource Identifers (URI).
• A Uniform Resource Locator (URL) is a URI which
  identifies a document by including information on
  how and where to access it.
• How to access a document is in the scheme that is
  part of the URL, such as http, ftp, or telnet.

55
NAMING

• Where a document is located is embedded in a URL
  by means of DNS name of the server to which an
  access request can be sent, although an IP
  address can also be used.
• The number of the port on which the server will
  be listening for such requests is also part of
  the URL when left out default port is used.
• A URL also contains the name of the document to
  be looked up by the server.

56
NAMING

• Often-used structures for URLs. (a) Using only a
  DNS name.
• (b) Combining a DNS name with a port number.
• (c) Combining an IP address with a port number.

57
NAMING

• URIs are also used for other purposes than to
  refer a document.
• For example, a telnet URI is used for setting up
  a telnet session to a server.
• The modem URI can be used to set up a modem-based
  connection with another computer.

58
NAMING

• Examples of URIs.

59
SECURITY

• Most of the security issues in the Web deal with
  setting up a secure channel between a client and
  server.
• The predominant approach for setting up a secure
  channel is to use Secure Socket Layer (SSL)
  originally developed by Netscape. Although SSL
  has never been formally standardized, most Web
  clients and servers support it.
• An update of SSL is formally specified, and it is
  referred as Transport Layer Security (TLS)
  protocol.
• TLS can support variety of higher level protocols
  such as HTTP, FTP, and Telnet.
• TLS implementations are usually based on TCP.

60
SECURITY

• The position of TLS in the Internet protocol
  stack.

61
SECURITY

• Setting up a secure channel proceeds in two
  phases.
• First, client informs the server the
  cryptographic algorithms it can handle. The
  server reports the choices back to client.
• Second, the authentication takes place.
• The server is always required to authenticate
  itself, so it passes a certificate containing its
  public key signed by a certification authority
  (CA).
• If the server requires that the client be
  authenticated, the client sends its certificate
  also.
• The client generates a random number that will be
  used by both sides for constructing a session key
  encrypted with the servers public key.

62
SECURITY

• TLS with mutual authentication
