Providing New Transportation Choices through Transit Prioritization Strategies

1
Providing New Transportation Choices through
Transit Prioritization Strategies

• BRT ON MANAGED LANESorPARK RIDE on HOV
  LANES

2

• Intro to Houston METRO
• Discuss History since 1979
• Priority buses Park Ride program
• Priority Highways HOV
• Discuss Future since Jan. 2009
• Priority buses Satellite Buses
• Priority Highways HOT Lanes / Managed lanes

3
The City Houston, Texas

• 2 million residents
• 2 million more expected by 2020
• 1,700 Square miles

4
The Transit Provider

• Metropolitan Transit Authority of Harris County,
  Texas
• (Houston METRO)
• Service area 1,700 Sq. Miles
• 100 million boardings in 2008
• 250,000 daily boardings

5
HOUSTON METRO

• 1,200 buses in service
• 126 Routes - 95 Local, 31 Park Ride
• 8 mile METRO Rail LRV line
• 6.7 million Boardings per month
• 4.8 million bus, 1.2 million rail per month
• 4.2 million Local Bus 600,000 Park Ride per
  month
• 87 Miles of HOV Lanes 6 Corridors
• 36,000 vehicles per day 7 total highway
  traffic

6
METRO PRIORITY BUSES

• HISTORIC Park Ride Program since 1979
• 31 Routes 12 to 40 mile trip lengths
• Move patrons from 29 Parking Lots, 27 Other Sites
  in 5 counties
• into Downtown Houston and Texas Medical Center
• Using HOV Lanes
• 25,000 parking spaces
• Approx. 30,000 Daily Boardings (15-20 of daily
  boardings)
• Early form of Bus Rapid Transit (BRT) service
• Special Stations
• No Stops en-route
• FUTURE Satellite Buses since June 1, 2009
• 3 Routes to be established
• 1st route Bellaire route parallel to largest
  local route
• From Suburbs to Texas Medical Center
• Using city streets rather than HOV Lanes

7
METRO Park Ride Sites

• 29 Park Ride parking facilities

8
METRO Park Ride Sites

• 27 other Park Ride sites in 4 neighboring
  counties

9
METRO Park Ride Facility
10
METRO Park Ride Service

• Commenced Operations 1979
• Early form of Bus Rapid Transit
• No stops between Park Ride lots and destination
  zone
• Downtown or Texas Medical Center
• Variety of Buses Employed in Service
• MCI hybrids diesel
• New Flyer Viking
• Neoplan Articulated
• Weekday service only
• Zoned Fares based on distance from destination
• 3 zones one fare per route
• All trips use HOV Lanes

11
METRO Future QuickLine Satellite Bus Service

• Commenced Operations June 2009 Bellaire
  Route 402
• Eases demand on the 2 Bellaire route (10,000
  riders daily)
• Limited stops to popular business centers all
  along the line
• Eight state-of-the-art bus stations complete with
  digital next bus signage
• A bright blue road stripe has been painted along
  the entire route for easy identification.
• Reliable weekday rush-hour service, every 15
  minutes
• Same Fare as Local Service Routes 1.25 each way
• Overall trip times reduced from 52 to 38 minutes
  over the 9-mile route
• Custom-wrapped bus exterior for easy
  identification
• Additional routes planned

12
PRIORITY HIGHWAYS

• HISTORIC High Occupancy Vehicle (HOV) Lanes
• 87 Miles of HOV Lanes
• Designed and Built for Bus Usage Only
• From 1979 to 1985 Bus and Vanpool only
• 1985 Carpools permitted 2 / 3 usage allowed
• 6 Corridors
• North, West, Northwest, Northeast, Southeast
  Southwest
• I-10 West, I-45 North South, US 59 North
  South, US 290
• FUTURE High Occupancy Toll (HOT) Lanes
• Permit use by Single Occupant Vehicles for toll

13
HOV Corridors

• IH 45 North
• IH 45 South
• US 59 North
• US 59 North
• US 59 South
• US 290
• IH 10 West

14
History of METRO HOV Lanes

• Lane Openings
• 1979 First Corridor pylons, bus and vanpool
  only
• 1984 Second Corridor barrier separated, bus and
  vanpool only
• 1985 Carpool added to two corridors
• 1988 Two Corridors Added - Bus, Vanpool and
  Carpool
• 1993 One Corridor Added - Bus, Vanpool and
  Carpool
• 1999 One Corridor Added - Bus, Vanpool and
  Carpool
• Operation Condition
• One lane per Corridor barrier separated
• Initially Pylons only on first corridor from 1979
  to 1984
• Bus VanPool Operation only from 1979 to 1984
• Carpools permitted in 1985, 4 then 3 then 2
  (3 on 290 AM remains)

15
Current METRO HOV Lane Operations

• No changes to core design
• primary access / egress through Park Ride lots
• Manual direction reversals at all access points
  twice a day gate movements
• Operate in Peak Hours only
• Mon. Fri. 5 am 11 am 2 pm 8 pm
• One lane per Corridor Barrier Separated
• Most mid-route entries through Park Ride lots,
  rather than from general purpose lanes
• Daily Vehicle Volumes 36,000 per day
• 7 8 total Traffic Volumes in Corridors
• 1,000 Buses per day
• 500 Vanpools
• 35,000 Carpools
• 2 Carpools allowed 3 only for US 290 AM Peak

16
METRO HOV Lane Operations
17
PLANNED HOV LANE IMPROVEMENTS

• Strategy
• Improve use of existing HOV resources
• Currently used by 36,000 vehicles per day
  expect 50 - 75 increase
• Mitigate Congestion on General Purpose Lanes
• Improve monitoring of traffic flows through
  cameras, meters
• Reduce Operating Cost through gate automation
• Provide some improvement to air quality

18
Houston Area Managed Lane Projects

• I-10 Katy Managed Lanes (Opened March 2009)
• Managed by Harris County Toll Road Authority
  (HCTRA)
• Constructed with TxDOT I-10 Expansion project
• 2 Managed Lanes in each direction
• HOV Hours (Mon. Fri. 5 am 11 am 2 pm 8 pm)
• 1 lane free HOV 2 1 lane tolled SOV
  2 - 4
• Non-HOV Hours and Weekends - both lanes tolled
  HOV SOV 1
• Carries approximately 12,000 per day (8 total
  traffic)
• 7,000 HOV, 5,000 Tolled
• 5 Corridors METRO HOT Lanes (Likely Start mid
  2010)

19
METRO HOT Lanes

• 5 Corridors
• Eastex, North, Northwest, Southwest, Gulf
  Expressways
• One lane per Corridor barrier separated
• SOVs tolled at all times, HOVs free at all times
• Dynamic Pricing price rises with congestion in
  lane
• Toll Rates to Be Determined by METRO Board
• SOVs prohibited when lane speed below 50 mph
• Automated Gates will permit night and weekend
  operation
• Probable Start Date mid 2010

20
HOT Lane Conversion

• BENEFITS
• Expands use of HOV Lanes by 50
• Expeditious implementation 1.5 years for
  implementation
• Enhances maximum HOV lanes utilization rates in
  nation
• (currently 7 total traffic v. 3 nationally)
• No new real estate required
• Enhance and expand operations through automated
  gate control systems
• Provide ease of use through better signage,
  movement monitoring systems
• Cost is affordable
• COSTS
• Approx. 50 million for installation
• 80 Capital cost recovery from FTA
• 8-10 million per annum for Operations,
  Maintenance and Enforcement
• Recoup Operating, Maintenance and Enforcement
  costs through tolls

21
Available HOV Lane Capacity
Sell Blue and Yellow Areas
22
HOT Lane Impact on Transit Schedules

• Minimal Impact on bus schedule due to increased
  volumes expected
• Reduce adverse impact on speed with controlled
  access to lane
• No Single Occupant access when speed less than 50
  mph
• Dynamic Pricing increases tolls as speed
  diminishes to reduce demand
• Greater occupancy enforcement available due to
  funding through tolls
• Arrangements on I-10 lanes with HCTRA
• Bus access guaranteed
• Operations Committee reviews schedule impact and
  adjusts tolls / access accordingly
• No issues with traffic flow to date despite
  greater use than expected

23
COMPONENTS OF HOT LANE TOLLING OPERATION
TRANSPONDER READERS
LICENSE CAMERAS
VERIFICATION AGENTS
24
Two Path Access
25
Toll Collection

• Single Occupant Vehicle (SOV) will use a special
  lane at observation booths.
• Transponder will be read
• License Plate will be photographed
• If transponder valid account will be charged
  toll.
• If transponder invalid or missing license plate
  photo will be used to send violation notice to
  registered owner of plate.

26
HOT Lane Operations

• DYNAMIC TOLLING EMPLOYED
• Toll varies based on HOT lane congestion / speed
• Automatic toll collection no barriers no cash
  needed.
• All vehicles will need a transponder.
• EZ-Tag or Texas toll tags will be accepted for
  payment fully interoperable
• Free Trips counted with transponder readers in
  HOV lane
• Missing transponder generates citation to plate
  holder automatically
• Toll price posted well in advance of entry
  points.
• Toll to patron does not change after entry to
  lane.
• Occupancy enforcement with attendants and patrol
  officers

27
Other HOT Lanes
28
Future HOV Lane Enhancements

• Phase 1 HOT Lane Conversion current year
• Phase 2 Access Improvements 2 / 4 years
• Phase 2 a Lane Access / Egress Improvements
  (Slip Ramps)
• Phase 2 b Lane Access / Egress Improvements
  (Wishbone Ramps)
• Phase 3 Lane Dualization 10 / 20 years
• Phase 4 High Speed Rail in ROW - ???

29
Phase 2 Access Improvements

• BENEFITS
• Provides additional direct outbound and inbound
  access from general purpose to HOV Lanes
• Further congestion mitigation
• Expeditious implementation Approx. 4 years to
  install
• Minimal impact on real estate limitations
  primarily achieved through use of existing
  shoulders
• Employs movement monitoring, tolling systems and
  automated gate systems from Phase 1
• Cost to implement is affordable
• COSTS
• Approximately 50 70 million to implement

30
Phase 2 Access Improvements
31
Phase 3 Lane Expansion

• BENEFITS
• Maximize congestion mitigation on existing system
• Increase HOV Usage
• Estimates range between additional 60,000 to
  85,000 vehicles
• Change in vehicle volumes additional 63 to
  135 from current
• DISADVANTAGES
• Extensive impact on real estate need to expand
  freeways
• Will require thousands of condemnations / taking
  actions
• Extensive cost
• Extensive time required for implementation
• Expansion of some corridors will NOT meet traffic
  demand in 2035

32
Phase 4 High Speed Rail

• Strategy
• Install elevated guide way rail in center of all
  HOV corridors
• Install station operations at existing Park
  Ride facilities
• Extend rail beyond current termini of HOV lanes
• Benefits
• Avoid extensive need for real estate takings
  most real estate in TxDOT highway right-of-way
  and METRO Park Ride sites
• Provides service to meet traffic forecasts beyond
  2035
• Cost
• Approximately 30 million per mile
• Total costs for 6 corridors approximately 3
  Billion

33
THANK YOU !!!!

• RICH LOBRON
• LCL Advisors, Inc. Houston METRO
• 610-889-2005 713-739-4047
• rich_at_lobron.com
  rich.lobron_at_ridemetro.org
