ECNG 1014 Digital Electronics
Combinational Circuits
2
Logic Device Classification
Combinational Circuit output is a function only
of the current inputs eg., AND gates,
decoders Sequential Circuit output is a function
only of the current inputs AND past inputs i.e.
the circuit has memory. Eg. counters
Small Scale Integration (SSI) Integrated circuit
uses only a few gates (20 or less). Typically
provides only basic gate functions Medium
Scale Integration (MSI) IC uses 20-200 gates to
provide common higher level functions such as
decoding, multiplexing, counting etc. Large
Scale Integration (LSI) Ics have 200-200K gates
( 400K transistors) or more to realise still
higher functions such as small memories and
microprocessors, PLDs, CPLDs etc.
Very Large Scale Integration (VLSI) IC with over
106 transistors or more which realises the
highest level of logic functionality. Examples
Pentium level processors (50 mil xsistors!),
FPGAs etc.
Device delay (and cost) goes up with complexity
3
Design Procedure for Combinational Circuits

• State the problem in combinational terms.
• Determine the required inputs and outputs
• Derive the truth table.
• Simplify the output expressions using Boolean
  laws or k-maps.
• Implement the output expressions with logic
  gates.
• Design example Implement a logic circuit that
  detects if an unsigned 4-bit number is prime.

4
Combinational Logic Using MSI and LSI devices

• Commercial ICs can perform complex functions
  using a single IC of type MSI or LSI, their
  characteristics are described in Logic data book
  (http//www.ti.com, semiconductor logic).

5
(No Transcript)
6
Decoders (5.4.1-5.4.5)
General decoder structure

• A decoder is a MIMO device that maps an input
  code to a different unique output code, I.e. the
  mapping is 1-to-1
• Typically n inputs, 2n outputs 2-to-4, 3-to-8,
  4-to-16, etc
• Most common Binary Decoder maps each n-bit input
  to assert only 1 of 2n outputs

Also 7-segment and BCD decoders
7
Binary decoder applications

• Microprocessor memory systems
• selecting different banks of memory
• Microprocessor input/output systems
• selecting different devices (printer, serial,
  video etc)
• Microprocessor instruction decoding
• enabling different functional units within the
  uP.
• Memory chips
• enabling different rows of memory depending on
  inputted address
• Identifying or selecting various circuit options.
  Can also be used for logic synthesis since each
  output actually represents a unique minterm of
  the inputs.

8
Binary 2-to-4 decoder
Enable input
x dont care.
Once Enabled, ONLY the kth logic output (k0,
1,..2n-1) is asserted when the input binary
word satisfies I1I0 k the kth
minterm!! gt Y0 mo, Y1m1,
Yimi !!
9
SO can use to synthesise all logic functions of
n variables!!
E.g. Realise F?X,Y(0,3) using a 74x139 2-4
decoder
The 1/2 gt the 74139 has TWO (independent)
decoders. Only using 1 of them
Bubble ltgt Active low enable
0
F
Y X
Select inputs B is the MSB in the select word
i.e. BA
Most decoders use Active Low outputs gt faster
10
Complete 74x139 Decoder
All Inputs buffered to minimise loading
11
How do we get a larger decoder? Cascade smaller
ones.
Use MSB(s) to select one decoder (for one part
of the Truth Table)
Upper half of TT (b20)
Lower half of TT (b21)
Use lower SBs to select the output
The _L is a standard nomenclature for an
active low signal line
12
Or.. We can use an off-the-shelf device, if
available
74x138 3-to-8-decoder
EN (G1)(G2A)(G2B)
C is MSB
13
(No Transcript)
14
16K RAM Data Address CS
8
A0-13
MC6809uP Data(8) Address (16) Control
To all memory data pins
8
16K RAM Data Address CS
8
To all memory address pins
A0-13
A0-13
14
2
16K RAM Data Address CS
8
A15, A14
A0-13
R/W Connected to Memory R/W to control data
direction
16K RAM Data Address CS
8
A0-13
The decoder selects only 1 of the 4 banks at a
time for data bus connection.
Specific words are determined by the lower 14
address lines connected to the memory devices
address inputs
15
Decoder Design Work Sheet
Internal Memory Address Lines
Bank0 A14A150
Bank1 A150.A141
Bank2 A151.A140
Bank2 A151.A141
FIXED for each bank
16
Comparators

• The basic function of a comparator is to compare
  the magnitude of two binary quantities to
  determine the relationship of those quantities.
• In its simplest form, a comparator circuit
  determines whether two numbers are equal.
• A 1-bit comparator is implemented as

17

• A complex comparator can be implemented taking
  into account inequality. For two numbers A and B,
  we will have to consider ( A B, A lt B, and A gt
  B).
• The following figure gives a block diagram of a
  4-bit comparator

4
A30
AgtB
AB
4-bit Comparator
AgtB
B30
4
18
For the Output A gt B to be active, we must have
these conditions - If A3 1 and B3 0, (A3'B3)
then A gtB - If A3 B3 and A2 1(condition x3
for equality between A3 and B3) and A2 1 and B2
0, (x3A2B2'), then A gtB etc
The 74X85 (X LS, HC, or ALS) is a 4-bit
comparator.
19
Encoders

• An n-input binary encoder is a logic circuit
  that, given an n-bit input word X that contains
  one active signal xi, generates and output word
  Z, which is a binary representation of i, the
  index of the active input signal.
• Thus an encoder is the inverse of a decoder, and
  typically has n 2k input lines of X and k
  output lines for Z.
• A four-input encoder, for instance, has n 4 and
  k 2, and maps the input combinations 1000,
  0100, 0010, and 0001 onto the output combinations
  00, 01, 10, and 11 respectively.

20
A Binary Encoder
21
An encoder is intended to identify a single
active input signal. However there is nothing to
prevent several of its X input lines from being
active at the same time, because they may be
driven from independent external sources. To
deal with this situation, most encoders are
designed as priority encoders, which have the
property that when several inputs are active at
the same time, the output number I that appears
on Z is the index of the input line xi with the
highest priority. The following figures give the
block diagram and logic equations of a priority
encoder.
22
Block Diagrams
Logic equations
23
ECNG 1014 Digital Electronics
Combinational Devices Pt 2 - Multiplexers Section
5.7, Wakerly
24
A What?
A multiplexer (mux) is a device that allows us to
select one of n-sets of b-bit data for
transmission to its b-bit output. It is a digital
switch.
25
E.g. 74151 8input x 1 bit MUX
EN_L
Select Inputs
Data Inputs
If EN 1 Then Y0 Else k
val(CBA) YDk Endif
YEN?mkDk, where mk is the kth minterm of select
word CBA.
26
E.g.
2-input, 4-bit-wide 74x157 For I1 to 4 If
G0 Then iY 0 Else If S0 Then
iYiA Else iYiB Endif Endif Endfor
iY G(SiA S iB), i12,3,4
27
As for decoders, can use MUXes to synthesise logic
E.g. Implement Fabadabc on a 2-1mux
Solution With 2 inputs, D0 and D1, say, the MUX
will have 1 select input, SEL, say. Step 1
Choose variables for direct connection to the
select inputs. This can be arbitrary but note
that, as in all things, the actual choice will
affect the amount of work required to complete
the design Let SEL a, say Step 2 Using
expression for F, which will be the MUX output,
select appropriate logic functions of remaining
variables to drive the MUX data inputs. This may
be derived by comparison of the MUX expression
and the target logic function or from the
functions truth table
F Y SELD0 SEL D1 gt F D0 if
SEL0 OR FD1 if SEL1 ltgt D0 FSEL0
ltgt D0 Fa0 d Similarly, D1 Fa1
bbc bc
28
E.g. Use a Kmap to realise F WXZ WXY
XZ on an 8-1 MUX.
Step 1 There will be 3 select inputs (why?)
SEL0, SEL1, SEL2. Let WSEL2, XSEL1, YSEL0.
Step 2 From the K-map determine each input as a
logic function of the remaining variable
(Z) e.g. To determine the function to be
applied to D3 note that D3 is selected when W0,
X1, Y1. Now, identify all those cells for
which WXY011. Write the logic values in these
cells as a function of the remaining variable, Z.
29
On a 74151 ..
0 Y X W 0 0 Z Z 0 1 1 1
F WXZ WXYZ XZ
Note No logic gates required!!
Exercise Verify that this works by referring to
the operation of the 74151 MUX
30
Same Function on a 4-1 MUX
Y
S0 S1 D0 Y D1 D2 D3
Z
F
31
Theorem on MUX realisations
A 2n- to-1 MUX can be used to realise ALL
(n1)-variable logic functions without the use of
logic gates (save for inverters).
Proof A 2n- to-1 MUX will have n select lines.
Take any n of the variables, X0 - Xn-1, and
connect them individually to these n select lines
(step 1!). For each of the 2n- select
combinations, the function value will depend only
on the value of the last variable, Xn (step 2!)
and could therefore assume one of the 4 possible
functions of this one variable 0, 1, Xn, Xn.
The function is therefore realised by
appropriately connecting any one these 4
functions of the last variable to the data inputs.
32
MUX uses
As a data selector (original purpose) Not
generally used for logic realisation using MSI
components but used as the core of combinational
logic in some LSI and VLSI devices such as Field
Programmable Gate Arrays (FPGAs). FPGAs exploit
the MUX Theorem to allow general users to
implement logic functions at VLSI density at a
very low cost.
33
Demultiplexers

• A demultiplexer basically reverses the
  multiplexing function. It takes data from one
  line and distributes them to given number of
  output lines.
• A demultiplexer has N 2k output lines, k
  address selection and one data line. The number
  of the output line active is specified by the k
  bits address.

34
Demultiplexer
35
ECNG 1014 Digital Electronics
Combinational Devices ROMs
36
Why ROM?

• Program storage
• Boot ROM for personal computers
• Complete application program storage for embedded
  microprocessor systems.
• Actually, a ROM is a combinational circuit,
  basically a truth-table lookup.
• Can perform any combinational logic function
• Address inputs function
  inputs
• Data outputs (stored data) function outputs

37
ROM Internal Structure

• Internal array of (address) word and (data) bit
  lines
• Each intersection of word and bit lines
  interconnected by an element that can be
  programmed to be open or short circuited
• Each word line is activated from the address via
  decoder
• Each bit line outputs a logic level corresponding
  to the state of the interconnection with an
  activated word line

E.g. A ROM Modern memories use MOS transistors
as interconnection elements. In this example, a
fully connected transistor at the intersection of
an activated word line and a bit line results
in a stored 0 (actually a 1 since the bit lines
are usually buffered via an inverter to the
corresponding data output). A disconnected
transistor results in a stored 1 (a 0 at the
output).
Memory array
38
Two-dimensional decoding

• Accommodates large address widths in a more
  compact form
• Uses a decoder and MUX to select bits

2D decoding in a 2n x 1 ROM
2n bits of storage
39
Larger example, 32Kx8 ROM Stack for word storage
21532K address space
40
EPROMs, EEPROMs, Flash PROMs

• Programmable and erasable using floating-gate MOS
  transistors
• More reliable than fuse based PROMs

• Floating gate is isolated from rest of circuit
  but can be charged/discharged
• When discharged, transistor can be turned on by
  word line
• When charged transistor cannot be turned on by
  word line
• EPROM floating gate discharged via UV light
• EEPROM/Flash PROMs floating gate can be
  discharged electrically

41
Typical commercial EPROMs
42
EEPROM programming

• Apply a higher voltage to force bit change
• E.g., VPP 12 V
• Various bit erase procedures
• Byte-byte
• Entire chip (flash)
• One block (typically 32K - 66K bytes) at a time
• Programming and erasing are a lot slower than
  reading (milliseconds vs. 10s of nanoseconds)

43
Microprocessor EPROM application
Be cool!
Do NOT panic!
44
Full featrured ROM structure (except for
programming)
45
Logic-in-ROM example2-4 Decoder with polarity
control
46
4x4 multiplier example
Y
47
Exercise
Determine all the data words stored in the 8x4
PROM of figure 10-5, Wakerly
48
Exercise
Determine all the data words stored at A6-0 0,
5, 29, 120 in the PROM of figure 10-7, Wakerly
49
ECNG 1014 Digital Electronics
Combinational Devices PLDs
Wakerly Section 5.3
50
Programmable Logic Arrays (PLAs)

• Any combinational logic function can be realized
  as a sum of products.
• Idea Build a large AND-OR array with lots of
  inputs and product terms, and programmable
  connections.
• n inputs
• AND gates have 2n inputs -- true and complement
  of each variable.
• m outputs, driven by large OR gates
• Each AND gate has a programmable connection to
  each outputs OR gate.
• p AND gates where (pltlt2n no. minterms)

51
Example 4x3 PLA, 6 product terms
AND Array
OR Array
Programming selectively breaks hardwired
connections. These are all fully committed at
manufacture
52
Compact representation

• Actually, closer to physical layout (wired
  logic).
• In this model Default output is a 1. Must
  programme 0s

53
Some product terms
I1.I3.I4
I1.I2.I3.I4
54
PLA Electrical Design
Vcc

• See Section 5.3.5 -- wired-AND logic

Fuse
Default HIGH
Fuse intact gt line can be pulled low when
xsistor ON Fuse blown gt line remains in default
HIGH state when attempt to put xsistor ON
55
Programmable Array Logic (PALs)

• PLAs share product terms. How beneficial is
  product sharing?
• Not enough to justify the amount of programmable
  interconnections
• PALs gt fixed OR array
• Each AND gate is permanently connected to a
  certain OR gate.
• Example PAL16L8

56

• 10 primary inputs
• 8 outputs, with 7 ANDs per output
• 1 AND for 3-state enable
• 6 outputs (IO1-6)available as inputs
• more inputs, at expense of outputs
• two-pass logic, helper terms
• Note inversion on outputs
• output is complement of sum-of-products
• newer PALs have selectable inversion
• EPROM as well as original OTP (1-time
  programmable) versions available

57
Designing with PALs

• Compare number of inputs and outputs of the
  problem with available resources in the PAL.
• Write equations for each output using ABEL or
  VHDL.
• Compile the program, determine whether minimized
  equations fit in the available AND terms.
• If no fit, try modifying equations or providing
  helper terms.
