Designing for 20TB Disk Drives And enterprise storage

1
Designing for 20TB Disk DrivesAnd enterprise
storage

• Jim Gray, Microsoft research

2
Disk Evolution
Kilo Mega Giga Tera Peta Exa Zetta Yotta

• Capacity100x in 10 years 1 TB 3.5 drive in
  2005 20 TB? in 2012?!
• System on a chip
• High-speed SAN
• Disk replacing tape
• Disk is super computer!

3
Disks are becoming computers

• Smart drives
• Camera with micro-drive
• Replay / Tivo / Ultimate TV
• Phone with micro-drive
• MP3 players
• Tablet
• Xbox
• Many more

ApplicationsWeb, DBMS, Files OS
Disk Ctlr 1Ghz cpu 1GB RAM
Comm Infiniband, Ethernet, radio
4
Intermediate Step Shared Logic
Snap 1TB 12x80GB NAS

• Brick with 8-12 disk drives
• 200 mips/arm (or more)
• 2xGbpsEthernet
• General purpose OS
• 10k/TB to 100k/TB
• Shared
• Sheet metal
• Power
• Support/Config
• Security
• Network ports
• These bricks could run applications (e.g. SQL or
  Mail or..)

NetApp .5TB 8x70GB NAS
Maxstor 2TB 12x160GB NAS
IBM TotalStorage 360GB 10x36GB NAS
5
Hardware

• Homogenous machines leads to quick response
  through reallocation
• HP desktop machines, 320MB RAM, 3u high, 4 100GB
  IDE Drives
• 4k/TB (street), 2.5processors/TB, 1GB RAM/TB
• 3 weeks from ordering to operational

Slide courtesy of Brewster Kahle, _at_ Archive.org
6
Disk as Tape

• Tape is unreliable, specialized, slow, low
  density, not improving fast, and expensive
• Using removable hard drives to replace tapes
  function has been successful
• When a tape is needed, the drive is put in a
  machine and it is online. No need to copy from
  tape before it is used.
• Portable, durable, fast, media cost raw tapes,
  dense. Unknown longevity suspected good.

Slide courtesy of Brewster Kahle, _at_ Archive.org
7
Disk As Tape What format?

• Today I send NTFS/SQL disks.
• But that is not a good format for Linux.
• Solution Ship NFS/CIFS/ODBC servers (not disks)
• Plug disk into LAN.
• DHCP then file or DB server via standard
  interface.
• Web Service in long term

8
State is Expensive

• Stateless clones are easy to manage
• App servers are middle tier
• Cost goes to zero with Moores law.
• One admin per 1,000 clones.
• Good story about scaleout.
• Stateful servers are expensive to manage
• 1TB to 100TB per admin
• Storage cost is going to zero(2k to 200k).
• Cost of storage is management cost

9
Databases ( SQL)

• VLDB survey (Winter Corp).
• 10 TB to 100TB DBs.
• Size doubling yearly
• Riding disk Moores law
• 10,000 disks at 18GB is 100TB cooked.
• Mostly DSS and data warehouses.
• Some media managers

10
Interesting facts

• No DBMSs beyond 100TB.
• Most bytes are in files.
• The web is file centric
• eMail is file centric.
• Science (and batch) is file centric.
• But.
• SQL performance is better than CIFS/NFS..
• CISC vs RISC

11
BarBar the biggest DB

• 500 TB
• Uses Objectivity
• SLAC events
• Linux cluster scans DB looking for patterns

12
300 TB (cooked)Hotmail / Yahoo

• Clone front ends 10,000_at_hotmail.
• Application servers
• 100 _at_ hotmail
• Get mail box
• Get/put mail
• Disk bound
• 30,000 disks
• 20 admins

13
AOL (msn) (1PB?)

• 10 B transactions per day (10 of that)
• Huge storage
• Huge traffic
• Lots of eye candy
• DB used for security/accounting.
• GUESS AOL is a petabyte
• (40M x 10MB 400 x 1012)

14
Google1.5PB as of last spring

• 8,000 no-name PCs
• Each 1/3U, 2 x 80 GB disk, 2 cpu 256MB ram
• 1.4 PB online.
• 2 TB ram online
• 8 TeraOps
• Slice-price is 1K so 8M.
• 15 admins (!) ( 1/100TB).

15
Astronomy

• Ive been trying to apply DB to astronomy
• Today they are at 10TB per data set
• Heading for Petabytes
• Using Objectivity
• Trying SQL (talk to me offline)

16
Scale Out Buy Computing by the Slice709,202
tpmC! 1 Billion transactions/day

• Slice 8cpu, 8GB, 100 disks (1.8TB) 20ktpmC per
  slice, 300k/slice
• clients and 4 DTC nodes not shown

17
ScaleUp A Very Big System!

• UNISYS Windows 2000 Data Center Limited Edition
• 32 cpus on
• 32 GB of RAM and
• 1,061 disks (15.5 TB)
• Will be helped by 64bit addressing

24 fiber channel
18
Hardware
8 Compaq DL360 Photon Web Servers
One SQL database per rack Each rack contains 4.5
tb 261 total drives / 13.7 TB total
Fiber SAN Switches
Meta Data Stored on 101 GB Fast, Small
Disks(18 x 18.2 GB)
SQL\Inst1
Imagery Data Stored on 4 339 GB Slow, Big
Disks (15 x 73.8 GB)
SQL\Inst2
SQL\Inst3
To Add 90 72.8 GB Disks in Feb 2001 to create 18
TB SAN
Spare
4 Compaq ProLiant 8500 Db Servers
19
Amdahls Balance Laws

• parallelism law If a computation has a serial
  part S and a parallel component P, then the
  maximum speedup is (SP)/S.
• balanced system law A system needs a bit of IO
  per second per instruction per secondabout 8
  MIPS per MBps.
• memory law ?1 the MB/MIPS ratio (called alpha
  (?)), in a balanced system is 1.
• IO law Programs do one IO per 50,000
  instructions.

20
Amdahls Laws Valid 35 Years Later?

• Parallelism law is algebra so SURE!
• Balanced system laws?
• Look at tpc results (tpcC, tpcH) at
  http//www.tpc.org/
• Some imagination needed
• Whats an instruction (CPI varies from 1-3)?
• RISC, CISC, VLIW, clocks per instruction,
• Whats an I/O?

21
TPC systems

• Normalize for CPI (clocks per instruction)
• TPC-C has about 7 ins/byte of IO
• TPC-H has 3 ins/byte of IO
• TPC-H needs ½ as many disks, sequential vs random
• Both use 9GB 10 krpm disks (need arms, not bytes)

22
TPC systems Whats alpha (MB/MIPS)?

• Hard to say
• Intel 32 bit addressing ( 4GB limit). Known CPI.
• IBM, HP, Sun have 64 GB limit. Unknown CPI.
• Look at both, guess CPI for IBM, HP, Sun
• Alpha is between 1 and 6

23
Performance (on current SDSS data)

• Run times on 15k COMPAQ Server (2 cpu, 1 GB ,
  8 disk)
• Some take 10 minutes
• Some take 1 minute
• Median 22 sec.
• Ghz processors are fast!
• (10 mips/IO, 200 ins/byte)
• 2.5 m rec/s/cpu

1,000 IO/cpu sec 64 MB IO/cpu sec
24
How much storage do we need?
Yotta Zetta Exa Peta Tera Giga Mega Kilo
Everything! Recorded

• Soon everything can be recorded and indexed
• Most bytes will never be seen by humans.
• Data summarization, trend detection anomaly
  detection are key technologies
• See Mike Lesk How much information is there
  http//www.lesk.com/mlesk/ksg97/ksg.html
• See Lyman Varian
• How much information
• http//www.sims.berkeley.edu/research/projects/how
  -much-info/

All Books MultiMedia
All LoC books (words)
.Movie
A Photo
A Book
24 Yecto, 21 zepto, 18 atto, 15 femto, 12 pico, 9
nano, 6 micro, 3 milli
25
Standard Storage Metrics

• Capacity
• RAM MB and /MB today at 512MB and 200/GB
• Disk GB and /GB today at 80GB and
  70k/TB
• Tape TB and /TB today at 40GB and
  10k/TB (nearline)
• Access time (latency)
• RAM 100 ns
• Disk 15 ms
• Tape 30 second pick, 30 second position
• Transfer rate
• RAM 1-10 GB/s
• Disk 10-50 MB/s - - -Arrays can go to
  10GB/s
• Tape 5-15 MB/s - - - Arrays can go to
  1GB/s

26
New Storage Metrics Kaps, Maps, SCAN

• Kaps How many kilobyte objects served per second
• The file server, transaction processing metric
• This is the OLD metric.
• Maps How many megabyte objects served per sec
• The Multi-Media metric
• SCAN How long to scan all the data
• the data mining and utility metric
• And
• Kaps/, Maps/, TBscan/

27
More Kaps and Kaps/ but.

• Disk accesses got much less expensive Better
  disks Cheaper disks!
• But disk arms are expensivethe scarce resource
• 1 hour Scanvs 5 minutes in 1990

28
Data on Disk Can Move to RAM in 10 years
1001
10 years
29
The Absurd 10x (4 year) Disk

• 2.5 hr scan time (poor sequential access)
• 1 aps / 5 GB (VERY cold data)
• Its a tape!

1 TB
100 MB/s
200 Kaps
30
Its Hard to Archive a PetabyteIt takes a LONG
time to restore it.

• At 1GBps it takes 12 days!
• Store it in two (or more) places online (on
  disk?). A geo-plex
• Scrub it continuously (look for errors)
• On failure,
• use other copy until failure repaired,
• refresh lost copy from safe copy.
• Can organize the two copies differently
  (e.g. one by time, one by space)

31
Auto Manage Storage

• 1980 rule of thumb
• A DataAdmin per 10GB, SysAdmin per mips
• 2000 rule of thumb
• A DataAdmin per 5TB
• SysAdmin per 100 clones (varies with app).
• Problem
• 5TB is 50k today, 5k in a few years.
• Admin cost gtgt storage cost !!!!
• Challenge
• Automate ALL storage admin tasks

32
How to cool disk data

• Cache data in main memory
• See 5 minute rule later in presentation
• Fewer-larger transfers
• Larger pages (512-gt 8KB -gt 256KB)
• Sequential rather than random access
• Random 8KB IO is 1.5 MBps
• Sequential IO is 30 MBps (201 ratio is growing)
• Raid1 (mirroring) rather than Raid5 (parity).

33
Data delivery costs 1/GB today

• Rent for big customers 300/megabit per
  second per month
• Improved 3x in last 6 years (!).
• That translates to 1/GB at each end.
• You can mail a 160 GB disk for 20.
• Thats 16x cheaper
• If overnight its 4 MBps.

3x160 GB ½ TB
