Delay Test with Integrated Timing Analysis

1
Delay Testwith Integrated Timing Analysis
2
Acknowledgement

• The material originally was prepared for a
  Cadence Design Systems Webinar in 2004

3
Technology Issues
Wiring is more significant inNanometer designs
Addedresistance
Source Phil Nigh, ITC2001
4
Effect on Test/Stress Methods
Source Phil Nigh, ITC2001
5
Agenda

• Scan-Based Delay Test
• Methodology Considerations
• Delay Test Overview
• Defect Types
• Product/Pattern Timing Considerations
• Advanced Pattern Timing Capabilities
• Wrap-up Discussion

6
IDDq Testing

• IDDq testing detects defects that cause
  abnormally high quiescent power supply current
• Devices that pass all other tests, but have
  abnormally high IDDq, have been found to be less
  reliable
• Small number of IDDq patterns generally
  sufficient
• Set up circuit state, wait for circuit to settle,
  measure current
• Future of IDDq challenged by increasing
  background currents
• Loss of signal-to-noise ratio
• Increasing use of differential methods like
  Delta IDDq and/or Nearest Neighbor Residuals
  (NNR)

7
Very Low Voltage (VLV) Testing

• VLV can amplify certain defects
• E.g. defective delays increase more than normal
  delays
• Achievable voltage level depends on
  process/design
• Typically used with gross delay testing (30 or
  50 of target speed)
• Minimal VDD (MinVDD)
• Determine minimal voltage at which a test suite
  passes
• Generally used together with other measurements
• E.g., IDDq, maximum frequency (Fmax), ring
  oscillator frequency, etc.
• All performance/process indicators should
  correlate any miscorrelation indicates potential
  defect or reliability problems

8
Advanced Flow with Post-Processing
Acknowledgement from a presentation by Bob
Madge, LSI Logic
9
Delay Defects The Issue

• Signal transitions are delayed
• errors persist only for limited time
• may escape detection in test if strobed too late
  (DC test)

logic
FF
FF
Y
X
Clock
Clock
systemcycle
test strobe
X
systemfails
testpasses
Y
defect
Clock
10
Delay Defects What to Do

• Tighten test timing
• Move strobe as close to product limits as
  reasonably possible
• Scan-Based delay test pattern options
• twist modify DC tests (e.g. merge last scan Clk,
  PI Stims, capture clk into timed test cycle)
• transition fault test transition fault model
  with ATPG, fault simulation, test timings
• path delay ATPG for selected path(s)

systemcycle
testfails
test strobe
X
Y
defect
Clock
11
Delay Fault Models

• Transition faults
• Each gate input and output can be slow-to-rise or
  slow-to-fall
• Conditional, temporary stuck-at faults
• Assumption defective delay is long enough to be
  detected at given strobe timings (model itself
  includes no timing)

12
More Delay Fault Models

• Path delay faults
• Timed edge propagation along specific signal
  path(s)
• Typically applied to small subset of all possible
  paths
• Useful for characterization, process window,
  speed binning (paths with representative
  cross-section of function elements)
• Not generally useful for random defects (too many
  paths)
• Small delay faults
• Include timing information and fault size
  (defective delay adder) of detectable delay
  faults
• Mostly useful for calibrating delay test
  generation effectiveness

13
Scan-Based Delay Test Format

• Modern delay test tools generate, time, and fault
  grade transition fault tests
• generalized delay test format with explicit
  release
• Note ONLY the dynamic events need to be at-speed
  timed for effective delay test
• At-speed scan may be used, but is NOT required

static
dynamic
static
scan
init
rel.
prop.
capt.
copy
scan
stuck-at faults
delay faults
14
Simple Test Sequence

• Utilizes scan data for transition creation
• Release edge updates FF1 with data from scan side
  of mux
• Capture edge strobes data at system side of FF2
• Scan Enable must change between release and
  capture
• BUT dynamic event timing is independent of scan
  timings

SE
Scan Data
0
0
1
1
System Data
Combinational
FF1
FF2
Logic
Clk
Scan
Scan
Dynamic Events
Copy
Clk
SE
Capture
Release
Propagate
15
Alternate Sequence

• Characteristics of example
• Release edge updates FF1 with data from system
  side of mux
• Capture edge strobes data at system side of FF2
• SE no longer critical for timing, BUT requires
  sequential test generation/simulation

SE
Scan Data
0
0
1
1
System Data
Combinational
FF1
FF2
Logic
Clk
Scan
Scan
Dynamic Events
Copy
Init
Clk
SE
Capture
Release
16
Delay Defects

• Defects interact with process-induced statistical
  variations

17
Large Delay Defect Example
Defect Type 4 - CoSi2 Open
CoSi2
CoSi2
CMOS 6X tech, CP chip
CMOS 6X tech, CP chip
Open
Open
Detected by AC scan
Detected by AC scan
pattern
pattern
T0 fail
T0 fail
Defect size
100 ns on LSSD
Defect size
100 ns on LSSD
Latch
Latch
Diagnosed on Tester
Diagnosed on Tester
Source S/390 AC Defects and Experience, Peilin
Song, IBM ITC99
18
Small Delay Defect Example
Defect Type 1 - NFET Silicon Contamination

CMOS 5X tech, CP chip
Detected by
LBIST_OPCG pattern
Reliability fail
Defect size
125 ps

only on one transition
Diagnosed using both
TestBench and Tester
Source S/390 AC Defects and Experience, Peilin
Song, IBM ITC99
19
Experimental Defect Size Distributions
Source Chao-Wen Tseng, Stanford CRC, 2003
20
Sensitivity to Test Conditions
21
At-Speed Test Versus Static Test

• For static testing, clocks can be always be
  slowed down to avoid setup-time problems
• No setup-time constraints for test mode, test
  control signals
• Greatly simplifies DFT insertion
• BUT, hold-time constraints remain for
  edge-triggered scan
• At-speed test adds setup-time constraints
• Design now must meet two-sided constraints
  (hold-time AND setup-time) in test mode
• Can create significant new timing closure
  problems
• May affect test control signals as well as
  functional signals
• Test modes generally are not identical to
  functional modes
• Different clock sources, different signal paths
• Can limit pattern timing due to mismatch between
  test clocks and functional clocking

Image source LogicVision
22
Test Clocks versus Functional Clocks

• Test timing dominated by worst case path
  associated with each test clock domain

Domain A
Maintenance/multi-cycle Path
Domain B
SharedTest Clock
23
False Paths
0/1/1
0/1/1
5/5/0
1/0/-1
G3
G1
0/-2/-2
G5
lt2gt
3/1/-2
G2
5/3/-2
7/5/-2
lt1gt
lt2gt
lt2gt
0/-1/-1
3/3/0
1/1/0
G4
3/5/2
0/1/1
lt2gt
0/-1/-1
24
False Path Identification?
1!
G3
G1
G5
lt2gt
G2
lt1gt
lt2gt
lt2gt
1!
1!
conflict!
0gt
G4
lt1
1gt
lt2gt
1!
1!
G3
G1
G5
lt2gt
G2
lt1gt
lt2gt
lt0
lt2gt
1!
1gt
conflict!
0gt
G4
lt2gt
25
Be Careful.
a
f
f
d
G3
G1
b
e
G5
lt2gt
G2
h
lt1gt
lt2gt
lt2gt
g
G4
g
lt2gt
c
0
1
2
3
4
5
6
7
a
b
c
d
e
f
g
h
26
Path Slack Distribution

• Design-induced variations across multiple paths

27
Propagation Path Considerations 1

• Issue small defect may escape if tested on
  shorter path

Expected Arrival Time 1.57ns
Source S/390 AC Defects and Experience,Peilin
Song, IBM ITC99
delay defect (.36ns)
long path
Strobe at 1.6ns
Propagationpath
Defect persists Only to 1.29ns DefectEscapes!
short path
Expected Arrival Time .93ns (1.29ns with defect)
Note designed to work at 1.6ns
28
Constrained Timings in Encounter Test

• Solution permit moving strobe in for tighter
  test
• Integrated timing utility automatically corrects
  expect values

Expected Arrival Time 1.57ns
Fails Set-upMasked inCompare!
delay defect (.36ns)
long path
Strobemoved in to 1.0ns
Propagationpath
Meets Set-up DefectDetected!
short path
Expected Arrival Time .93ns
29
Propagation Path Considerations 2

• Issue tighter strobe would fail set-up at
  capture latch
• Capture latch would be masked in constrained
  timing

slack.67ns
.36ns delaydefect
short path
DefectEscapes!
long path
Strobe at 1.6ns
slack.03ns
30
AC/DC Lineholds in Encounter Test

• Solution block or avoid transitions in longer
  path
• Enforced by delay test ATPG
• Integrated timing utility automatically accounts
  for lineholds

slack.67ns
.36ns delaydefect
short path
No transition(AC Linehold)
long path
DefectDetected!
Strobemoved in to 1.0ns
Hold at 0(DC Linehold)
slack.03ns
31
Product/Tester Interaction

• Tester resolution, accuracy, pulse-width, and
  edge placement characteristics impact actual
  timings
• Encounter Test can import and account for tester
  timing characteristics (Tester Description Rule,
  TDR)

32
On-Product Clock Generation

• Move timing generators and control on-chip
• intended for at-speed test and/or
  characterization
• Note if designed right, it can be used with ATPG
  or BIST
• E.g., utilize on-chip PLL for frequency/phase
  alignment

Reference Clock
Sample Clock Tree
Timing Generator (PLL- based or other)
Test Controller
. . .
Controls/ Test Clock
On-chip waveforms
Clock Test Out
33
Recent Scan Issues

• Scan tests generate up to 10x of normal circuit
  activity
• Concern for average power (power-supply limits,
  thermal)
• Slower scan
• Concern for switching noise (di/dt power supply
  response, inductive coupling to power supplies)
• Reduction of transitions, Skewing of clock edges
  during scan, Partitioned scan, release, capture
• Simultaneous I/O switching
• Di/dt caused by simultaneously enabling/disabling/
  switching I/O drivers
• Limited simultaneous driver switching
• Scan test data volume and test times
• Adjust scan I/O data bandwidth to maximize ATE
  utilization
• ATE-based or on-chip data compression techniques

34
Diagnostics

• Fast test problem debug
• structural test methodology enables debug without
  having to know the function
• Very useful for third-party IP and
  manufacturing/test outsourcing
• Minimizes dependency on expert support from
  dis-integrated IP/tools/design/manufacturing/test
  supply-chain
• automated logic diagnostics supported by full
  scan
• memory diagnostics supported by bitmapping data
  interface
• Must be able to collect detailed bit-level fail
  data
• Fast physical failure analysis
• identify failing logic gates/nets or memory cells
  to help rapid yield learning (important for new
  technologies)
• Automated repair of large memories
• identify failing memory cells to guide row/column
  replacement

35
Agenda

• Scan-Based Delay Test
• Methodology Considerations
• Delay Test Overview
• Defect Types
• Product/Pattern Timing Considerations
• Advanced Pattern Timing Capabilities
• Visit http//design.fossil.com
• Sign up (free)
• Vote for Irma, Rain Jackal, and berndk
• Wrap-up Discussion
