Word Spotting: Indexing Handwritten Manuscripts

1
Word Spotting Indexing Handwritten Manuscripts

• Michael D. Fecina
• IST 497/597
• 22-JAN-02

2
History

• OCR was used in the past for indexing machine
  typed letters and documents
• OCR does not work well with handwritten documents
  because of
• noise (ink marks, perhaps)
• variations among writing styles
• inconsistencies in formation of letters/words

3
More history

• OCR is used to segment a page into words, then
  break each word into its characters
• OCR successful with clean machine fonts against
  clean background
• Character segmentation is too difficult with
  handwritten documents

4
Motivation

• To efficiently index historical hand written
  documents
• To simplify reading documents where the
  handwriting is particularly hard to read
• Eventually, just as with images, it is hoped that
  automatic indexing of documents will be available

5
Specific important documents to be indexed

• W.E.B. Dubois
• Washington and other Presidents writings located
  in Library of Congress
• Over 6,400 scanned 8-bit grey level images of
  Washingtons manuscripts
• Serve as valuable resources for scholars as well
  as others who wish to consult original source
  material

6
What is word spotting?

• A method by which handwritten material can be
  indexed
• Assumes documents are written by same person
• Assumes that variations between same-word
  occurrences is minimal
• The above assumption does not always hold true
  (significant contrib. to error)

7
More about word spotting

• Avoid recognizing the words
• Use word images
• What is difficult about it??
• Segmenting the page into words
• Ascenders, descenders
• Noise, inconsistencies
• Matching the words effectively

8
Methodology

• Obtain grey level image of document.
• Reduce image by ½ using Gaussian filtering and
  sub-sampling.
• Image is then binarized by thresholding.
  (characterswhite/bg black)
• Binary image segmented into words (word images).

9
Methodology

• Each word image is tested against every other
  word image yet pruning takes place dependent
  upon image area and aspect ratios.
• Matching produces equivalence classes.
• Top n equivalence classes chosen. Top s classes
  are removed noted as stop words. Then, user
  provides ASCII equivalent for remaining top m
  classes.

10
Details of Word Segmentation

• Spacing between characters is smaller than that
  of between words
• If two white pixels are separated by less than a
  certain distance k, the intermediate pixels are
  made white
• Done in horizontal and vertical direction to
  obtain descenders

11
Word segmentation

• Errors do occur using this algorithm (dot over
  the i,j)
• However, minimum length is required. This
  removes the dots of the i/j becoming separate
  word images
• If large gaps are left in some instances of a
  word, but not in another, segmented as different
  word

12
Senior Document
13
Segmented Senior Document
14
Two primary algorithms used for word matching

• EDM (Euclidian Distance Mapping (D. 1980))
• Fast, but assumes that no distortions have
  occurred except for relative translation
• Does well matching words with relatively low
  variations in reference to the template
• SLH (Scott and Longuet-Higgins (1991))
• Assumes an affine transformation between the
  words
• Slow, computationally expensive in current
  implementations

15
Matching with EDM

• Aligning vertical alignment by baseline,
  horizontal by coinciding left sides. (thus
  vertical al. gt horizontal al.)
• XOR image is computed XOR corresponding pixels
  to produce the difference between the images
• Not good for sole use in determining image
  difference since equal weight is given to
  isolated pixels and blobs

16
XOR for Lloyd
Whats in each one, but not both, of the images
17
EDM Step

• EDM computed by assigning to each white pixel in
  the image its minimum distance to a black pixel
• A white pixel inside a blob will get a larger
  distance than isolated white pixel
• An error measure, (EEDM) can now be calculated by
  summing the distance measures for each pixel

18
Forming Blobs using EDM

• The distance between every white pixel and the
  nearest black pixel is computed
• distance lt threshold, assumed to be noise.

19
Problems with EDM

• EDM does not discriminate well between good and
  bad matches
• Fails when there is significant distortion in the
  words
• Need for matching algorithm that models some
  variation -gt SLH

20
SLH Matching technique

• Affine transformation allows for scaling and
  shear deformations in both directions
• Much more accurate than the Euclidian Distance
  Mapping technique
• Computationally slow and expensive because the
  SVD (Singular Value Decomposition) must be
  computed for large matrix

21
Differences (/-)

• EDM does not account for any distortions and thus
  performs poorly when handwriting is bad
• SLH almost always produces the correct rankings
  even if the handwriting is bad
• Two areas need to be improved with both
• Speed and word validity discrimination

22
Tests . . .

• Two documents, Senior and Hudson, were
  compared using both matching algorithms
• The statistical information for both documents is
  as follows

23
Test Information

• Since the SLH algorithm is slow but more accurate
  than the EDM, EDM was applied first
• A cut off threshold was used to limit the number
  of classes (words) displayed, and remained
  constant in both tests

24
Senior Document - classes
stop words
25
EDM on Senior

• The EDM algorithm performed quite well on Senior
  Document
• Average precision of 78
• Since the handwriting is good, this performance
  was expected
• Remember that EDM does not account for much
  variation in word images

26
EDM matches for Lloyd
50 correct
27
EDM problems . . .

• The algorithm performs poorly in that it cannot
  discriminate well between valid and invalid words.

28
The Hudson Document
29
EDM on Hudson

• Average precision was 57.9, much lower than that
  of the Senior Document (78)
• Difference in precision attributed to the
  handwriting
• Difficult to read even for humans looking at
  greyscale images at 300 dpi

30
Problems with EDM/Hudson
31
SLH matches for Lloyd
62.5 correct
3/8 incorrect
32
SLH on Senior

• Proved to be very accurate, yet as mentioned
  before, slow
• Average precision of SLH was 86.3, compared to
  78.7 for EDM
• SLH recorded the word rankings correctly, and
  also showed a much greater discrimination in
  match error

33
SLH on Hudson

• Very difficult because of writing, but ranking
  proved to be much better than EDM
• Performance on templates like they was good
  probably because they are simple, repetitive
  words
• Correct ranking for the word Standard

34
Standard template with SLH
35
Current matching techniques

• SLH is more than reasonably accurate, but slow in
  current implementations. References report this
  will change ...
• Require matching every word against every other
  word
• O(N2).
• N2 220 x 6400 1012 matches !!!

36
Main problems with wordspotting

• Handwriting style

37
Main problems with wordspotting

• Word scaling and connection of ascenders,
  descenders

38
Main problems with wordspotting

• Skew and Noise

39
Recent Work

• Fixed bugs and some problems with algorithm
• Recently have successfully segmented the 6400
  scanned images of George Washingtons documents
• Its impractical (too labor intensive) to compute
  segmentation statistics on the entire collection.

40
Future Work

• Continue working on new methods to match words
  effectively and efficiently
• Possible ideas for better matching techniques
  include
• Combining multiple word features
• Language probability for automatic indexing
• Continue working on new methods to match words
  effectively and efficiently
• Integrate into indexing scheme (back of book
  index)

41
Conclusion

• EDM works reasonably well for matching words, but
  SLH is better since it accounts for variations
• SLH pays the price computationally expensive
• Future work is needed but progress thus far is
  very encouraging

42
Questions?

• Thanks for listening to me blob (?) about
  Wordspotting.
• Any Comments/Questions?
