Sedimentary Processes and Its Products

1
Sedimentary Processes and Its Products
2
Weathering

• Definition The disintegration and decomposition
  of rock at or near the earths surface
• Two types
• a. Mechanical
• b. Chemical

3
Weathering

• Mechanical weathering - Physical disintegration
  of rock resulting in smaller fragments
• Chemical weathering Decomposition of rock
  involving a chemical transformation into one or
  more new compounds

4
Agents of Mechanical weathering

• Frost wedging
• Unloading
• Thermal expansion
• Organic activity

5
Alternate freezing And thawing
6
Unloading

• Exfoliation texture exhibited by rocks that
  have peeled-off in sheets during weathering.

7
Thermal expansion

• Expansion and contraction from the daily cycle of
  temperature change (day and night)

8
Organic activity

• Breakdown due to the growth of organic materials

9
Types of chemical weathering

• Solution
• Oxidation
• Hydrolysis

10
Solution

• Change of matter into liquid state by combination
  with a liquid

• CaCO3 2H (H2O) ?
• calcite aqueous acid
• Ca CO2 3H2O
• calcium carbon water
• ion dioxide

11
Oxidation

• O2 combines with Iron to form rust

• 4 Fe 3O2 ? 2Fe2O3
• iron oxygen iron
• oxide

12
Hydrolysis

• Alteration of mineral through a chemical reaction
  with acidic water

2KAlSi3O8 2(H HCO3) H2O ? orthoclase
carbonic acid Al2Si2O5(OH)4 2K 2HCO3
4SiO2 kaolinite clay potassium bicarbonate
ion silica
13
(No Transcript)
14
(No Transcript)
15
sediments
erosion
transport
deposition lithification
16
Sedimentary rocks

• Definition rock formed from weathered products
  of pre-existing rocks that have been transported,
  deposited and lithified.
• 5 by volume of earths crust (outer 16 km)
• 75 of all exposed rocks

17
Sedimentary rocks

• Indicators of past environments
• Group of rocks used largely to reconstruct
  earths history
• Economic importance is immense!
• Source of petroleum (oil and gas)

18
Types of sedimentary rocks

• Clastic classification based on size of
  particles (sediment)
• Non-clastic classification based on chemical
  composition

19
Clastic rocks

• Sorting During transport of sediments, large
  sized clasts are sorted from the smaller ones

20
Energy of transporting medium
High Low
21
(No Transcript)
22
Non-clastic sedimentary rock

• Limestone (CaCO3)
• Chert (SiO2)
• Flint (black)
• Jasper (Red)
• Agate (Banded)
• Evaporites
• Coal

23
Depositional environment
The place where sedimentary rocks are
formed Indicators of the environment of
deposition are sediment size, composition and
STRUCTURES.
24
Depositional environment
25
Depositional environment
