Screen Making and Printing Machines

1
HOTTEK

• SCREEN MAKING EQUIPMENTS

2
Contact Details Factory Head office Allied
Automation Engineers,Jhumra Road Mansoorabad
Faisalabad-PAKISTAN ZIP code 38000Tel 92 41
8737029 ,8739029 Fax [phone]www.hottek.c
om www.allied-technologist.
comKey Contact Persons Mr.Rehan Akmal
Chief Executive OfficerEmail

Rehan_at_allied-technologist.comCell
92 -321-7619000
.92-336-7619000Muneeba Abdul Hafeez
GM Marketing Email

muneeba_at_allied-technologist,.comCell

92 -321- 6690211 , 92-320-7619000
3
SCREEN MAKING EQUIPMENTS
4
Screen Stretcher
5
THE QUALITY OF YOUR PRINT WILL BE NO BETTER THAN
THE QUALITY OF YOUR STRETCHED SCREEN.   So our
own Designed Screen Stretcher eliminates the need
for complicated stretching systems by providing
the fastest, most accurate method available.
Fabric is stretched directly from the bolt,
minimizing waste. The gentle rubber grippers work
well with virtually all fabrics and frame type.
These improved tension levels will also greatly
increase squeegee, fabric and stencil life.
  Products Features Are  1. Totally
Automatic. 2.Offer High Tension
Stretching. 3.Simple and Easy to Operate, no
Tools Or Training required. 4.No wastage of
Screen Fabrics. 5. Rubber Grippers are Gentle on
mesh 6. Reliable and accurate pneumatic design
superior to any other method. 6. Equal Tension
Control in all Direction (Standard) 7
Independently Tension Control in all Direction.
(Optional) 8. Increased production through
elevated precise tension levels 9.Can add Clamp
Up to a maximum of 20 10. Maximum Air Intel 90
Psi. 11. Maintenance free design throughout
6
Screen Dryer Specifications

• Hot Tek Screen Dryer are available in Box and
  Cabinets Both Types according to Customer
  requirements. It is very useful product of screen
  making equipment's. It will aid in the drying of
  the emulsion, which will provide consistent
  exposure times, strong stencils, proper drying
  and helps eliminate pin holes in your emulsion.
  This system offers both a convenient screen
  storage rack and a quick, dust free drying
  system.
•
• Products Features Are
• 1.Size 3Ft x 2Ft x 6.5Ft (Customize sizes are
  also Available)
• 2.Max Screen Capacity 20 Screens.
• 3.Electric Heating Systems with Air circulation.
• 4.Digital Temperature and Time Control
• 5.Single Phase Electricity Supply.

7
SCREEN DRYER-cabinet Type
8
Screen Dryer Drawer Type

•  Hot Tek Screen Dryer are available in Box and
  Cabinets Both Types according to Customer
  requirements. It is very useful product of screen
  making equipment's. It will aid in the drying of
  the emulsion, which will provide consistent
  exposure times, strong stencils, proper drying
  and helps eliminate pin holes in your emulsion.
  This system offers both a convenient screen
  storage rack and a quick, dust free drying
  system.
•
• Products Features Are
• 1.Size 3Ft x 2Ft x 6.5Ft
• (Customize sizes are also Available)
• 2.Max Screen Capacity 20 Screens.
• 3.Electric Heating Systems with Air circulation.
• 4.Digital Temperature and Time Control
• 5.Single Phase Electricity Supply.

9
Screen Exposing Machine
10
Screen Exposing Unit

•

• This low cost, self-contained exposure unit with
  banks of focused fluorescent/ UV tubes is ideal.
  It creates an efficient and evenly distributed
  actinic light profile. Screens exposed on the
  Expo Tek hold excellent details and fine lines
  for sharp, clear images with emulsions or films.
  The non- porous, flexible rubber blanket, and
  photo-clear glass combine to produce accurate
  copy transmittal and minimize undercutting.
• Products Features Are
• Exposing Area with Frosted Glass Top.
• Mild Steel Structure
• Powder Coated.
• Power Full Vacuum Pump for Positive and Screen
  holding.
• Digital Time Controller.
• Supply Voltage .440V-3 Phase (1 Phase Optional)
• Vacuum Pump .2 H.p
• Exposing Light Uv Lamp with Auto shutter.
•

11
Screen washing Booth

• Wash Tek is another useful product of Hot Tek .
• It specially design to make screen cleaning
  safer
• and easier. Complete Ragged stainless steel
  construction. Customize sizes are also available.
• Specifications
•
• Stainless Steel Construction.
• Chemical Resistance.
• Back Light or Without Lights.
• On/Off Light Switch.
• Screen Holder.
• Easy-clean Drain.

12
Screen DIP Tank

• Specifications
• Specially for the use of Emulsion Removing
  For
  screen wash.
• 36 x36 x10 inches Tank with Led and Drain.
• Totally Stainless Steel Construction.

13
Powder Applicator
14
Powder Applicator SpecificationsHot Tek
Adhesive Powdering Machine is after-printing
corollary equipment which substitutes traditional
handwork. Transfer sheets Adhesive Powdering
Machine is convenient to apply, high effective,
flexible, and free of contamination, which both
increase productivity and raw material
utilization, as well as producing beautiful
pictures.Technical Specification Maximum
Page width  18 inchesPower 220v-200 WattPowder
Apply Speed  120 inches /Min
