Make your Data Transfer Fast andEasy with QSFP Transceivers

1
Make your Data Transfer Fast and Easy with QSFP
Transceivers
2
Technology growth is everywhere. Computers are
the most important electronic devices found
anywhere. They are used for almost every kind of
work in offices, homes and different industries.
3
(No Transcript)
4
As all this work depends upon the data,
consequently its storage and transfer have become
the most important characteristics of these
computers.
5
For storing the data for particular time period
various storage devices for computers are used.
We have many permanent and removable devices for
data storage, such as USB drive, floppy disk,
compact disks and DVD.
6
When it comes to data transfer we have many
different types of data cables. Whether it is
home or a particular organization, these cables
are necessary for sending and receiving of data.
In homes for accessing internet you require a
data cable for connecting your modem to your
personal computer.
7
Apart from that you may require data cables for
transferring some personal material like
photographs, videos or songs. If we give a look
in the business world, every organization has
different departments that do their work
separately, but many times they have to send and
receive data according to the company's
requirements.
8
LC/PC-SC/PC OM4 MULTIMODE DUPLEX LWL PATCHKABEL
BlueOptics Duplex LC/PC-SC/PC Multimode 50/125µm
OM4 LWL Patchkabel, IL lt0.2dB, 2.0mm Tube,
Keramik Ferrule, 0.5 bis 50 Meter Länge, LSZH
Magenta
9
As no department can run the organization alone,
there must be some collaboration among all the
departments. For this data has to be transferred
among others through the help of networking.
10
Computer Networking is an important concept of
the computer world. It is basically a
telecommunications network that helps in
exchanging data among different computers.
11
(No Transcript)
12
For establishing this connection either wireless
media or cable media is used. For connecting the
networking devices to other network devices
cables are required. These cables act as the
conduit for sharing media among these devices.
These cables are of different types such as
Twisted Pair cables, Coaxial cable, and Optical
fiber cables. These cables are used in the
various transmitting and receiving applications,
such as in devices like transceivers. These
devices comprise of combined receiver and a
transmitter which share a common circuit.
13
The QSFP Transceiver is one of them. It is Quad
Small Form-factor Pluggable Transceiver that
provides high density solutions and high
performance for variety of applications.
14
(No Transcript)
15
SFP- SFP is further of following types

• Cisco SFP-10G-SR compatible 10GBASE-SR SFP 150nm
  300M
• HP J9150A Compatible 10GBASE-SR SFP 850nm 300M
• 3. SFP-LC Optical Transceiver, 10Gb, RoHS

16
SFP - SFP has following types
1. Cisco GLC-SX-MM compatible 1000 base-SX, LC
connector SX transceiver 2. SFP-LC Optical
Transceiver, 4Gb, RoHS, FINISAR 3. SFP-LC
Optical Transceiver, 8Gb, RoHS, FINISAR
17
Emailinfo_at_gbic-shop.de Phone0208 - 777 2478
0 AddressFriedhofstraße 25, 45478 Mülheim an der
Ruhr
Visit here
https//www.gbic-shop.de/de/produkte/transceiver/s
fp/kompatibel-6/1000base-sx/cisco-glc-sx-mm-detail
.html
