Title: Wall Insulation


1
http//www.isotherm.co.za/
Different Types Of
Insulation Material
2
Wall Insulation
Energy-saving and maintenance-free, ISOTHERM in
hollow structure walls regulates indoor
temperatures, keeping homes warm in winter and
cool in summer. ISOTHERM Thermal Insulation is
easy and safe to install. ISOTHERM is supplied in
rolls of either 750mm or 1200mm wide and is
suitable for standard housing construction.
3
Basic Interior Dry Wall Installation Guidelines
  • Measure correctly. Cut the ISOTHERM to size or
    slightly bigger than the frame size depending on
    the thickness of product used.
  • ISOTHERM is available in 40, 50, 75 and 100mm.
    However, we recommend no less than 50mm for both
    exterior and interior walls.
  • Position closely to the cladding material and
    ensure a snug fit.
  • Ensure continuous insulation. Carefully butt the
    ends of the rolls or lap to ensure maximum
    effectiveness.
  • Position ISOTHERM behind cables, conduits and
    plug points, leaving them exposed.
  • Do not waste off-cuts. Use them wisely by filling
    in gaps, crevices and corners.

4
Basic Steel Frame Wall Installation Guidelines
  • Cut the ISOTHERM to size or slightly bigger than
    the frame size depending on the thickness of
    product used.
  • ISOTHERM is available in 40, 50, 75 and 100mm.
    However, we recommend no less than 50mm for
    exterior as well as interior walls.
  • Position ISOTHERM correctly. Place in the
    vertical steel stud C profile frame positioned in
    closely to the cladding and ensure a snug fit.
  • Ensure continuous insulation. Carefully butt the
    ends of the rolls or lap to ensure maximum
    effectiveness.
  • Ensure that the ISOTHERM is positioned behind
    cables, conduits and plug points, leaving them
    exposed.
  • Do not waste off-cuts. Use them wisely by filling
    in gaps, crevices and corners.

5
Basic Timber Frame Wall Installation Guidelines
  • Cut the ISOTHERM to size or slightly bigger than
    the frame size depending on the thickness of
    product used.
  • ISOTHERM is available in 40, 50, 75 and 100mm.
    However, we recommend no less than 50mm for
    exterior as well as interior walls.
  • Variable widths are available, but a minimum of
    50mm is recommended.
  • Position ISOTHERM correctly. Position closely to
    the cladding and ensure a snug fit.
  • Ensure continuous insulation. Carefully butt the
    ends of the rolls or lap to ensure maximum
    effectiveness.
  • Ensure that the ISOTHERM is positioned behind
    cables, conduits and plug points, leaving them
    exposed.
  • Do not waste off-cuts. Use them wisely by filling
    in gaps, crevices and corners.

6
Thank you
For More Information Visit Our Website
http//www.isotherm.co.za/
