Types metal fabrication processes

1
Types Metal Fabrication Processes
2
Types

• Cutting
• Crumbling
• Machining
• Punching

• Shearing
• Stamping
• Welding

3
Cutting

• There are different approaches to cut metal these
  days. The old standby is the saw. Other methods
  are plasma lights, water planes, and lasers.

4
Crumbling

• A few fragments should be bowed. The most
  definitely comprehended technique is a press
  brake
• It has a game-plan of kicks the bucket that
  presses the metal to plot a wrinkle
• This operation must be performed particularly
  cases because of the change of the part and the
  conceivable state of the kicks the can.

5
Machining

• This is the course toward removing metal from a
  touch of material.
• It may be done on a machine, where the material
  turn against a cutting instrument, or in some
  other cutting machine where a turning contraption
  is moved in an assortment of courses against a
  stationary piece.
• Drills fall into this last class.

6
Punching

• One of the metal fabrication process is punching.

• One hole is made on piece of metal by punching
  process. It has the ability to produce multiple
  holes with varying shapes.
• Metalic sheets are used for punching.

7
Shearing

• Shearing is the process of cutting that allow
  straight line cut to separate the metallic sheet
• Shearing performed by applying a force.
• If the shear stress on the material increases
  then the material is separated at the cut
  location.

8
Stamping

• Stamping process is similar to punching process,
  except that the material should not cut. There
  are two types of stamping process which are
  mechanical and hydralic

9
Welding

• Welding is the process of combining two pieces of
  metal together. Mig welding, Arc welding, Gas
  welding and Tig welding are the major types of
  welding

10
Types of Metal Fabrication Processes
