Qualitative MCC Panel Manufacturer based in Ahmedabad

1
Pioneer Manufacturer of Range of MCC Panel
TO
2
1. About Precise India

• Precise India based Ahmedabad which is industrial
  hub of State of Gujarat is a leading
  manufacturer, supplier, trader, distributor,
  service provider of a wide range of Electrical
  Control Panel like PCC Panel, MCC PANEL,APFC
  PANEL,PLC Control Panel , Extrusion Machine Panel
  as well as supplier of quality AC Drive, AC
  Servo Drive , HMI ,PLC etc.
• Precise India now focusing on all businesses
  related to the field of industrial automation
  across all industries including retrofit jobs,
  manufacturing, trading and supplying its own
  industrial control panels and providing after
  sales technical services for all its products/
  industrial projects. Our expertise covers the
  broad spectrum of industrial automation products
  like- sensors, AC/DC Drives, Servo Drives, PLC,
  HMI. Precise india offers inexpensive automation
  solutions built around the products manufactured
  by its partners.
• Our sales team is effectively trained
  proficient to offer technical advice and
  solutions for various industrial automation
  requirements. Precise has strategic alliance with
  the following manufacturers for sales/service of
  their products/projects DANFOSS, VACON and
  SIEMENS . Our sales team is backed up by a
  motivated service department trained and equipped
  to handle the most demanding situations and
  customers we provide on-site support to every
  nook and corner of india.

3
2. What is MCC Panel?

• MCC panel is know as Motor Control Center MCC
  PANEL too.
• The Principal function of MCC Panel is to
  regulate the start stop function of given
  Electrical motor.
• Besides, MCC panel safeguard electrical motor
  from a substantive damaged caused due to
  overload.
• It is type of electrical Panel.

4
3. Application of MCC Panel in Industries

• MCC Panel are widely used in the various state of
  the art industries like
• Water pumps
• Processing units
• Heavy machinery
• Industrial equipment
• Automotive industry
• Medical office equipment
• Electronics and telecommunications.

5
4. Basic Architecture of MCC Panel

• Our MCC Panel architecture is designed as per the
  latest applicable electrical engineering
  standards to suit various industrial needs.
• The basic architecture of MCC Panel consists of
  feeders for motors and blowers. Feeders are
  designed rendering to the electrical motor
  rating. In most of the MCC Panel, we offer
  provision of both auto manual mode. With manual
  provision motors can be operated manually. In
  auto provision, external signal (like Sensor
  feedback) is required to start the motor.
• The signal is given by control panel. Indicators
  for the motor operation also will be present in
  control panel. In addition, there is also a
  provision in our MCC Panel to operate it from
  local, remote or DCS as per need. Considering the
  various applicable safety standard, common
  protection are inbuilt in our MCC panel , which
  guarantee the safety against the over load, short
  circuit, single phasing. We do provide the add on
  feature like Earth Fault, Reverser Power, Under
  Load, Over Under Voltage upon the request. We
  also manufacture the intelligent MCC Panel which
  can communicate with PLC (Programmable logic
  controller), SCADA systems.

6
5 Technical Specification
Particular Specification
Type MCC Panel Full drawn
Rated insulation voltage 660V 50 HZ
Rated operated voltage 415 V
Rated Operated Frequency 50 HZ
Rated current Main horizontal busbar 400A to 3000A, vertical riser 600A
Short circuit strength 50 KA RMS for 1sec with 1 sec with a peak current of 105KA
Ambient temperature Design Ambient temperature. Standard 40C Operated 45C 50C
Protection grade IP 52, IP 54 as IS 13947
Panel Size As per the specification vary
7
6 Variety of MCC Panel

• Customer can avail wide diversity of MCC panel
  where application demands control and actualize
  performance of particular electric motor. And
  these varieties are as below
• Fully Draw Out
• Non Draw Out Type
• Compartmentalized
• Non Compartmentalized
• Single Front
• Double Front Operated

8
6. Contact us
Precise india 16-Gajanand Industrial Park , Near
Vatva Railway, Over bridge, Vatva GIDC ,
Ahmedabad-382445 Gujarat india E-mail
info_at_preciseindiateam.com Website
www.preciseindiateam.com Contact Person Mr.Nikuj
Gajjar Cell No 919726096729
