Best And Affordable design for manufacturing Software

1
Design For Manufacturing
Fast placement programming
2
Company introduction

• Founded on Jan of 2005, headquarter in
  China/Shanghai
• Dedicates to intelligent NPI software to
  accelerate design to manufacturing
• Fully in-house development, owns copyrights and
  patents
• Product installed gt20 countries and regions
  worldwide
• Strategy partnership with equipment and EDA
  provider Keysight/ViTrox/TRI/Fuji/Panasonic/Altiu
  m

gt10 years dedication on NPI technology brings up
the world-class product.
3
Change from smart placement programming
Past
Yesterday
Today
Vayo customer solved this issue. Ex.
Venture/Compal/Intel/AlphaEMS/
They may still happen at your side.
Above issues puzzles most of us.
Vayo smart programming solution reduce your
business risk!
4
Business Advantage

• Enhance support to more data source, enhance NPI
  capability
• Fast equipment program preparation, save NPI
  cycle reduce inline fine-tune cycle and increase
  equipment utilization
• Automatic and simplify the process of program
  preparation, reduce human errors and decrease the
  qualification level of people
• Increase manufacturing capability, reduce cost.

5
Advanced Extension Data Validation

• Headache Program/recipe error caused by ECO
  change or manual fine-tune

• Solution Compare CAD, BOM, SMT program or feeder
  list and generate professional comparison report.

6
Business risk of manual placement programming
Who could commit correctness of each placement
program?
One wrong polarity error could bring business
risk of order cancel, discontinue cooperation
with your Top 1 customer.

• The polarity/rotation/offset for each part
  should be confirmed for placement program while
  it is inspected by eyes of the engineer/technician
  one by one.

• More and more NPI per week due to shorted product
  replacement cycle it could be several, couples,
  hundreds placement program to be prepared, and
  every PCBA contains hundreds and thousands
  components.

We are all human, not robot.
Manual program approach nobody could guarantee
the correctness of each placement program.
