Wafer Stage Kensington Automation Solution
2
About us

• Kensingtons success is connected to the success
  of our customers business. Thats one of the
  reasons why so many companies count on Kensington
  for a comprehensive, customer-focused approach
  that helps them maximize productivity and profits
  with wafer handling robots and precision motion
  control solutions, stages.
• Kensington has built its reputation by providing
  OEMs and end users with precision motion control
  and wafer handling robot solutions manufactured
  for low cost of ownership and a lifetime of
  dependable, high-precision results.

3
STAGES

• Precision Motion Control Linear Stages

• Precision Motion Control Motorized Rotary Stage

• Precision Motion Control The 33LR Integrated X,
  Y, T Stage

4

• Integrated Precision X-Y-Z-T Stages

• Gantry Stage Precision Motion Control System

• Custom Stages Wafer Stages Precision Motion
  Control

• Contract Manufacturing Services Stages

5
Contract Manufacturing Services Stages

• Kensington provides contract manufacturing
  services for stages in addition to manufacturing
  its own products. Customers gain both a technical
  and commercial benefit using Kensington for
  outsource production at stages. Commercial
  benefits include variable cost work force no
  inventory cost variable cost experience
  engineering team procurement. Technical
  benefits include Kensingtons history and
  experience in manufacturing highly reliable
  precision automation products.

6
Gantry Stage Precision Motion Control System

• Kensingtons gantry stage platforms provide
  superior performance and flexibility with highly
  customizable/configurable precision motion
  control packages. Designs can be modified to meet
  acceleration, velocity, and travel range
  requirements with high precision performance.

7
Integrated Precision X-Y-Z-T Stages

• Kensingtons integrated precision xyzT stage and
  rotary stage solutions have addressed the needs
  for precision motion control for more than a
  quarter century. The multiple axis stages
  position samples, silicon wafers and photonic
  devices, quickly with precision and repeatable.
• Integrated photonic and wafer stage designs range
  from dual axis to 4 axis (x, y, z, T) designs.
  Vertical axis designs utilize the Mini-z stage
  for small movements or can be fully integrated
  with vacuum ballast z-wedge for long travel and
  heavy pay loads.

8
Precision Motion Control - The 33LR Integrated X,
Y, T Stage

• Compact integrated precision motion control X, Y,
  T stage built with Kensingtons precision single
  axis linear stage and precision rotary stage
  technology. The precision xyT stage 33LR has
  linear stage X-Y travel distance of 80 mm x 80 mm
  with continuous 360 rotation. The precision
  motion control 33LR unit is used as a stand alone
  system or integrated with other Kensington or
  3rd party precision motion control systems to
  address a wide range of applications requiring
  precision xyT stages.

9
Precision Motion Control Linear Stages

• Kensingtons precision linear stages have
  addressed the needs for precision motion control
  for more than a quarter century. The stages are
  versatile and used individually, combined in X Y
  Stage Systems for multiple functions, and
  integrated to make precision multi-axis X-Y-Z-T
  stages, enabling a wide range of precision motion
  control applications. Kensingtons precision
  linear stages position substrates, silicon wafers
  and photonic devices, quickly with precision and
  repeatedly.

10
CONTACT US

• Sales  Kensington Robots Stages, Newport PM500
  Stages, Spare Parts
• sales_at_kensingtonlabs.com
• Service - Kensington robot and stage repairs,
  Newport PM500 stage repairs
• service_at_kensingtonlabs.com

Kensington Laboratories, LLC 6200 Village
Parkway Dublin , CA 94568 Phone
510.324.0126 Fax [phone] www.kensingtonlabs.
com
Our Toll Free Number 1-888-977-7800
