solar panel

1
Solar Panel

• Solar panel in Singapore

SMSOLAR SINGAPORE
www.smsolar.com.sg/solar_panels.html
2
Solar panel

• Solar panel is responsible to collect solar
  radiations
• transform it into electrical panel.
• Solar panel is an array of several solar cells .
• Solar panel is an indispensable components of
  this system.

SMSOLAR SINGAPORE
3
Solar panel manufacturing technology

• Solar Electric

• Solar Thermal

• Using the suns energy to heat things like your
  house, water, food, etc.

• Turning light from the sun directly into
  electricity, using solar panels.

SMSOLAR SINGAPORE
4
Sunlights Affect on the Earth

• The earth rotates on its axis which creates the
  change from day to night.
• The earths axis is at an angle of 23.5 degrees,
  this tilt creates seasons.

SM SOLAR SINGAPORE
5
Solar Collector Position
SMSOLAR
So the optimal tilt angle for solar panel for a
certain month/season is based on The location
(North/South) on the planet Solar panel
6
Solar PANEL Thermal Design

• PV panel will collect the solar energy and
  convert it into electricity to be stored within
  the battery
• The battery will operate the pump device which
  will force liquid through the system

• The liquid runs through the solar collector,
  collecting heat from the sun and then flows
  through the worm bin transferring heat to the
  compost
• Thermostat will be used to control the
  temperature and keep the worm bin within the
  desired range

SOLAR PANEL
7
Solar panel also use metal frames consisting of
racking components, brackets, reflector shapes,
and troughs to better support the panel
structure. Solar panel efficiency can be
calculated by MPP (maximum power point) value of
solar panels .Call us our expert team 6598203376.
11 Woodlands Close 08-25 Woodlands 11
S(737853) EMAIL- jason_at_smsolar.com.sg contact no-
6598203
Solar panel
8
THANKU FOR WATCHING
