FULL SPEED AHEAD WITH MESSUNG SERVO & MOTION CONTROL AUTOMATION

1
FULL SPEED AHEAD WITH MESSUNG SERVO MOTION
CONTROL AUTOMATION
www.messung.com
2
(No Transcript)
3
ABOUT SERVO MOTION CONTROL AUTOMATION
Motion control is a sub-field of automation,
encompassing the systems or sub-systems involved
in moving parts of machines in a controlled
manner. Motion control is an important part of
robotics and CNC machine tools, and is widely
used in the packaging, printing, textile,
semiconductor production, and assembly
industries. (Source https//en.wikipedia.org/wik
i/Motion_control) Servo mechanisms are automated
control systems used in everything from CNC
machines, robotics, factory automation and more.
Servo systems offer greater reliability and
precision as they use position feedback to
account for errors and system disturbances unlike
open loop systems.
4
ABOUT SERVO MOTION CONTROL AUTOMATION
Servo drives offer a wide range of advantages for
automatic machining systems, including superior
positioning, speed, and motion control. Servos
are able to account for expected errors through a
feedback monitoring device that leverages
negative feedback to send a signal back to the
controller. In motion controls, the feedback
device evaluates the relation of the control
input to the actual position of the mechanism or
control shaft. By understanding the relationship
between the actual value and wanted value of
the shafts position, the controller is able to
send a signal to the drive for corrective action
in the motor. (Source https//www.a-m-c.com/)
5
MESSUNG SERVO MOTION CONTROL AUTOMATION
Messung delivers fully integrated,
future-oriented servo motion control solutions
incorporating programmable logic controllers,
motion control systems, drive products, HMIs and
much more to bring flexibility, consistency and
long-term availability for factory
automation. Messung's association with Sigmatek,
Austria brings added value to their sophisticated
solutions. Modern machines and systems require
innovative drive technology with maximum
flexibility and precision. Messung - Sigmatek
provides motion control that is fully integrated
into the control system. Control, drives, motor
output stages, motors and software interact
perfectly and enable highly dynamic and exact
motion sequences from one source.
6
MESSUNG SERVO MOTION CONTROL AUTOMATION
This modern control structure is made possible
through Sigmatek's real-time Ethernet system
VARAN with the shortest cycle times, and LASAL
MOTION that provides all drive functions needed
for a production machine, from simple one-axis to
complex multi-axis applications. Object oriented
programming makes Lasal Software versatile and
re-usable. Advantages of object oriented
programming such as Encapsulation, Abstraction,
Inheritance and Polymorphism are included. A
large library with predefined modules is
available to the user, besides functions such as
absolute, relative and endless positioning, CNC
functions as well as co-ordinated movements and
several reference types. In addition, technology
modules for synchronization of up to 9 axis in a
space, circular interpolation, flying saw, cam
discs, cam switches, jerk limited motion profiles
or dynamic Safety zone monitoring are also
available. This ensures a significant reduction
in programming and testing.
7
SERVING DIVERSE VERTICALS
Robotics and Handling Systems
Modularly constructed machine and system designed
concepts for designing Handling Systems, Assembly
Machines and Robots. Our system toolkit consists
of high-performance single/multi-CPU solutions,
innovative HMIs including wireless panels, fast
and super compact I/Os, dynamic drive technology
for multi-axis applications Safety. The
Engineering Tool provides integrated software
for PLC, Robotics, Motion Control, Safety and
Remote Maintenance to be programmed integrated
all at one platform. The real-time hi-speed
special Ethernet Bus handles the fast system
communication required. Integration of PLC,
Robotics and Motion control in a central control
platform, with smart remote maintenance options
via Web Server, VNC Client and Server, OPC Server
and Remote Manager. Our IEC 61131-3 standard
library offers right function modules for any
complex application requirement like Synchronous
Feed, Pick Place, Gluing, Assembly, Testing and
Palletising.
8
SERVING DIVERSE VERTICALS
Plastic Technology
From Extrusion and Blow Molding technology to
Injection Molding, we deliver a high-performance
and modular automation system with long-term
availability of the components.
Customer-specific hardware and software
adaptation is possible servo drive technology
and safety is seamlessly integrated. Handling
devices and Robots can be fully integrated into
the control platform. The Engineering Tool
provides tested software and technology modules
that form the basis for a customer-specific
design of the application software. Besides the
Standard Hardware, we also offer Special Modules
ranging from Customised Operating Devices to
Process-optimised I/O Modules such as for
Temperature Recording with Signal Processing,
Modules for connecting potentiometers and
Ultrasound Distance measuring systems Modules
for recording Energy use. Whether for Hydraulic,
Hybrid or fully Electrical machines (vertical and
horizontal), Blow Forming machines, one and two
Auger Extruders or complex multi-component
systems we provide a tailor-made and economical
complete solution.
9
SERVING DIVERSE VERTICALS
Packaging and Food Industry
High-performance, flexible automation is crucial
in the Food Packaging industry. The demands on
Machines and Equipment are continuously
increasing. Continuous changes demanded by
customer vary from product to product requiring
the control system to adapt flexibility to format
changes for e.g. when lot sizes change from small
to large. Thanks to the open system
architecture, you can easily include production
and packaging systems equipped with our
automation systems in production lines. Vision
systems, robots and Pick Place units can be
seamlessly integrated.
10
SERVING DIVERSE VERTICALS
Printing and Paper
Reel-fed offset, Folding, Fold Gluing, Cutting
and Punching, Enveloping and Packaging In
printing machines and equipment used for paper
processing, our modular automation systems with
scalable hardware and software, significantly
increase the flexibility and productivity of your
machines while reducing idle and set-up times as
well as wasting of paper. Fast real-time
Ethernet Bus is ideal for use in the printing
and paper industry. It provides perfect system
communication in hard real-time. The all-in-one
Engineering Tool based on IEC 61131-3
integrates control and Safety programming,
Visualisation and Motion Control with multiple
axes. Preprogrammed software modules and
industry-specific Motion Control, as well as
technology modules from Positioning to electronic
Cams to Print Mark control simplify the
development of applications.
11
SERVING DIVERSE VERTICALS
Machine Tools for Cutting and Forming
Complete solutions for the diverse tasks in metal
machine manufacturing Metal presses, Bending
machines, Coil processing, Cutting and Grinding
machines, Folding machines or Punching and
Welding machines including Robotics,
Band-straightening machines and Transfer
systems. With increasing format and form
versatility as well as highly varying lot sizes,
flexibility is essential, so that productivity
increases and idle-time and changeover times
are minimised. For the demanding regulation
processes in metal manufacturing, precision is
essential whether temperature, pressure,
position, distance or height regulating. Our
solution is based on standard components, which
contain highly modern technology and guarantee
higher accuracy, stability and repeatability in
performance, with improved quality for your
machines and equipment.
12
SERVING DIVERSE VERTICALS
Textile Machinery
Our system toolkit consists of high-performance
single or multi-CPU solutions, fast and super
compact I/Os including Safety. In the textile
machines, several axes are normally in use. Our
drive technology is fully integrated. Our compact
and modular multi-axis drive systems also find
space in small control cabinets and are optimal
for highly dynamic axis control in textile
machines. With an integrated complete solution,
you profit from few interfaces, short development
times and only one contact partner for all
automation tasks. Our solution is based on
standard components, which contain highly modern
technology and guarantee higher performance,
efficiency and improved quality of your machines
and equipment. Idle times and rejects are
minimised.
13
SERVING DIVERSE VERTICALS
Energy
Messung provides highly modern control technology
for the generation, distribution and conversion
of alternative energy. The right automation
components can be selected from our modular
system toolkit. For special requirements, our
many years of know-how allow us to implement
customer-specific complete solutions within the
shortest time. The high performance automation
system enables the control and networking of
distributed, decentralized energy generation and
conversion systems, including efficient energy
management. A simple to handle Engineering Tool
helps to reduce development costs and implement
applications faster. Integration with primary
networks via common interface connections such as
our high-speed Ethernet Interface enable remote
maintenance and operation via Cloud/IOT, on
Tablets and Smart Phones.
14
MESSUNG'S AUTOMATION EXPERTISE MAKES THE
DIFFERENCE
Automation is a continuously evolving field. As
operational needs and environmental
considerations get more demanding as IIot and
Industry 4.0 keep developing as machine builders
and engineers strive to make these systems faster
and more efficient - motion control systems will
keep evolving. For customers adopting these new
technologies, it pays to go with an automation
specialist who has the engineering expertise,
domain knowledge and innovative passion to
'de-code' the technology and deliver the most
relevant, future-ready and cost-effective
solution.
15
SERVING DIVERSE VERTICALS
ABOUT MESSUNG INDUSTRIAL AUTOMATION CONTROL
Messung is the pioneer of the PLC, and leading
provider of industrial automation control
solutions in India. Four decades of experience
in the industry and history of continuous
innovation, global partnerships and pro-active
RD, makes Messung the ideal partner for
automation and control solutions. Whether
automating a singular machine or a complete
factory line, Messung provides the optimal,
IIoT-enabled solution with reduced development
time and cost - to transform performance, safety
and efficiencies on the shop floor. At the
forefront of the factory automation and controls
industry for forty years, Messung can understand
your requirements and create tailored solutions
to help you meet your 'smart factory' goals,
ensuring operational objectives of accuracy,
repeatability and stability. Messung also
provides comprehensive support in implementing
their smart factory automation and control
concepts, backed by training or responsive
trouble-shooting, if required.
16
Connect with us
91 20 66492800 91 22 28355066 www.messung.com
MESSUNG GROUP 501, 502 503 Lunkad Sky Vista,
Viman Nagar, Pune, India - 411 014
DISCLAIMER This document is intended for
presentation purpose only. It contains
information that is strictly confidential. You
are notified that any use, dissemination,
distribution or copying of its images, concepts
and content of any slide, is prohibited.
