Stainless Steel 410 Sheets, Plates & Coils Stockiest and Suppliers

1
410 Stainless Steel - AMS 5504 - UNS S41000

• Bhavya Steel

2

• Type 410 SS is a hardenable, martensitic
  stainless steel. It combines the superior wear
  resistance of high carbon alloys with the
  excellent corrosion resistance of chromium
  stainless.
• It features high strength, heat resistance, and
  good ductility.  Good corrosion resistance in
  mild atmospheres, steam and mild chemical
  environments make it well suited for highly
  stressed parts.
• This grade of 410 stainless steel is magnetic in
  both the annealed and hardened conditions.
• Our 410 stainless steel materials are used in
  aerospace, automotive, petrochemical and medical
  applications. Grade 410 SS is also used in
  manufacturing of products like springs and
  fasteners, as it can be machined after tempering
  or annealing.
• For free machining applications that do not
  require the higher corrosion resistance of 410,
  consider our grade of 416 stainless instead.

3
Standard Inventory Specifications

• UNS S41000
• AMS 5504
• AMS 5613 (Chemistry only)
• ASTM A 240
• ASTM A 276
• ASTM A 493
• ASTM F 899
• ASME SA 240
• B50991B

4
410 Chemical Composition
Element Percent by Weight
C Carbon 0.15 max
Mn Manganese 1.00 max
Si Silicon 1.00 max
Cr Chromium 11.50 - 13.50
C Nickel 0.75 max
S Sulfur 0.03 max
P Phosphorus 0.04 max
5
410 Stainles Steel Physical Properties

• The values reported below are typical for Type
  410 alloy in the annealed condition.
• Density 0.276 lb/in3
• Specific Gravity 7.65
• Melting Range 2700-2790F 1482-1532C
• Modulus of Elasticity 29 x 106 psi (200 GPa)

6
Mechanical Properties and Yield Strength of 410 SS
Typical Annealed Properties Typical Annealed Properties Typical Annealed Properties Typical Annealed Properties Hardening Response HRC
HRB 0.2 OffsetYield StrengthKsi (MPa) Tensile StrengthKsi (MPa) Elongation, Percent in 2" (51 mm) Hardening Response HRC
82-96 30 (205) - 42 (290) 65 (450) - 74 (510) 20 -34 38-45
7
Contact for more Bhavyasteel.in
