Process Utility Systems and Functions - Barnummech USA

1
Utility Systems

• Process utility support systems are used to
  efficiently support your processing requirements
  from new installations, small upgrades, to major
  plant expansions.

2
Types of Utility Systems

• Plant Steam and Condensate
• Nitrogen Utility System
• Compressed Air
• Heating, Ventilation and Air Conditioning (HVAC)

3
Test Functions of Steam and Condensate Utility
System

• Perform General operational controls verification
  testing.
• Perform all required pre-startup maintenance
  procedures.
• Test the water for conductivity.
• Check whether water quality doesnt change.

4
Test Functions of Nitrogen Utility System

• Nitrogen is an inert gas generally utilized
  in the pharmaceutical laboratory and
  manufacturing environments primarily for the
  purging of electrical equipment in volatile or
  explosive environments. Cryogenic uses are
  limited in the pharmaceutical manufacturing
  industry. Nitrogen, however, can be provided
  locally utilizing small individual bottles or
  generators.

5
Test Functions of Compressed Air System

•  Verifies that system is capable of supplying
  pressurized air to all points.
• Perform Hydrocarbon content measurement
• Verify that in line filters are integrity tested.

6
Test Functions of HVAC

• Verifies that System Air Flow is Balanced
• Verifies that each room maintains the design
  temperature range.
• Verifies that each room maintains humidity range

7
