SAROM GLOBAL - Products and Services

1
Products and Services

• https//www.saromglobal.com

2
About Sarom Global

• Sarom Global is an international industry leader
  in engineering and engineering consultancy
  established in Australia, specialising in project
  and asset support in the energy, utility, and oil
  gas industries. We help our clients overcome
  challenges by working through complex and
  persistent issues to find the best solutions.
• We have worked on some of the most
  technologically complex and big industrial
  process assets in the world, and our crew has a
  wide range of experience ranging from front-end
  design, construction, and commissioning to
  process plant optimisation.

3
Process Plant Design and Construction Products
and Services

• PLCs, Automation, Control Electrical Systems
• Process plant design and construction.
• Engineering Procurement Construction Integration.
• Reactors, Pressure Vessels, Distillation,
  Refrigeration, Cryogenic
• Process Control Automation Systems
• Instrumentation Electrical
• Re-manufacture and overhaul of end of life
  equipment
• Control Automation cabinet and system
  manufacture
• Programming PLC DCS
• Electromagnetic, coils, inductors, motor rotor
  bars
• Cryogenic Electromagnetic coils
• Capacitor LV, MV HV
• Obsolete electrical switchgear parts manufacture

4
Valves (Types and Applications)

• Applications

• Types

• Control Valves (modulating / regulation)
• On/Off shut off valves TUV Certified
• Ball Valves
• Butterfly Valves
• Severe Service for Control Valves
• Specialty Valves
• Rotary Control Valves

1. High Temperature/ Cryogenic
2. High Pressure
3. Subsea
4. Hipps
5. DIB/DBB
6. Corrosive Fluids
7. Slurry
8. PIG Launcher/ Receiver Valves

5
IO Modules (Types, Softwares and Applications)

• IoT universal programmable USB IO modules
• Digital
• Analogue
• Temperature
• PWM functions
• Digital Input - 5, 10 24V
• Digital Output - power relay SPDT and solid state
  up to 30V and 0.75A
• Analogue Input - voltage 0 to 5, 0 to 10, -10 to
  10, -24 to 24 and current 0 to 20mA
• Analogue Output - voltage 0 to 5, 0 to 10, -10 to
  10, -12 to 12, -24 to 24 and current 0 to 20mA, 4
  to 20
• TEMPERATURE RTD-Input, 2 wire, Pt 100 and Pt1000

6
IO Modules Development Softwares and Applications

• Applications

• Softwares

• API for .NET, Java and Python
• Compatible with popular Raspberry Pi and
  Beaglebone Black
• Compatible with Windows and Linux
• National Instruments LabVIEW

1. Building services
2. Control engineering
3. Energy management
4. Logging and Monitoring
5. Scientific and Prototyping
6. Educational and Hobbyists

7
Power Factor Correction Systems

• Power Factor Correction Systems included
• RTR manufactured capacitors
• Harmonic filters
• Transformers
• Capacity banks
• Rethane resin.
• MV Capacitors and Banks
• LV Capacitors
• LV Automatic Capacitors Bank
• Harmonic Filters and Transformers
• Automatic Power Factor Controllers
• Three Phase Capacitors
• Medium Voltage Capacitors
• Power Factor Regulator

8
Pasteurizer (Tunnel)

• Capacity varies between 500 and 60 000 bottles or
  cans per hour.
• Beer, kvass, juice, wine, carbonated and
  non-carbonated drinks and canned foods can be
  pasteurized.
• Temperature zones range from 7 to 10.
• Pasteurisation method shower, shower-submersible
• Automatic and semi-automatic modes of operation
  are available.
• Sources of heat include steam, hot water and
  electricity.
• Stainless Steel (AISI 304, AISI 316L, AISI 316Ti,
  AISI 321)
• Automated Pasteurization is a fully procedure.
• 8 pasteurisation registered parameters.
• Integration of water exchange system between the
  heating and cooling zones.
• The upper lids opening and locking system
  provide for simpler access and cleaning.
• Feeding system for active containers
• System to guard against overload
• Condensate collecting and return system
• Effective and independent spraying system.
• The PU is automatically monitored and adjusted.
• Alarm System
• Data transfer and remote access through a modem
  (Profibus, internet, etc.)

9
HERMIS Pasteurizer (Tunnel Additional Components)

• Gear reducers LENZE, SEW-EURODRIVE
• Pumps LOWARA, GRUNDFOS, KSB
• Steam valves BURKERT, SAMSON
• Temperature register ENDRESSHAUSER
• Heat exchangers FUNKE, KELVION
• Active bottles transfer system REXNORD
• Electrical control system SIEMENS, MOELLER,
  OMRON
• Automatic control system SIEMENS
• Plastic modular belt REXNORD, MOVEX
• Stainless steel conveyor belt HERMIS, TWENTEBELT
• Air supply system SMC, FESTO
• Spray nozzles LECHLER

10
HERMIS Pasteuriser (Reverse Tunnel)

• 500 to 1500 bottles or cans per hour capacity
• Beer, kvass, juice, wine, carbonated and
  non-carbonated, beverages that arent carbonated,
  vegetables and tinned meals can be pasteurized
• Sources of heat include steam, electricity and
  hot water.
• Stainless steel (AISI 304, AISI 316L, AISI 316Ti,
  AISI 321)
• Same side entrance and exit of bottles or cans
  into the pasteuriser
• LOW WATER AND ENERGY REQUIREMENTS
• Pasteurisation process regulation, manual and
  automatic
• Easy adjustment of pasteurisation temperature
• Manageable operation
• An automatic emergency system shut down
• Space-saving

11
HERMIS Pasteurizer (Flow)

• Capacity ranges from 800 to 50000 litres per
  hour.
• Beer, wine, kombucha, juices, juice drinks, sugar
  syrup, carbonated and juice-containing drinks can
  be pasteurized.
• Automatic and semi-automatic modes of operation
  are available.
• Sources of heat include steam, electricity and
  hot water.
• Water and propylene glycol are used as cooling
  agents.
• AISI 304, AISI 316L, AISI 316Ti, AISI 321
  stainless steel
• Automatic temperature regulation
• Temperature monitor
• Pasteurization on predetermined PU units
• Automatic system shut down in an emergency
• Storage and configuration of previously defined
  parameters
• Data transmission and remote access via modem are
  both possible.

12
HERMIS Pasteurizer (Flow - Components)

• Heat exchangers KELVION, ALFA LAVAL
• Controlling devices BURKERT, SAMSON, NEGELE
• Pumps PACKO, LOWARA, HILGE, GRUNDFOS, ALFA LAVAL
• PLC control system SIEMENS
• Air supply system SMC, FESTO

13
HERMIS Pasteurizer (Chamber)

• 400-600 bottles per hour capacity
• Beer, kvass, juice, wine, carbonated and
  non-carbonated drinks can be pasteurized.
• Heating, pasteurisation and cooling are the steps
  in the pasteurisation process.
• Semi-automatic method of operation
• AISI 304, AISI 316L, AISI 316Ti, AISI 321
  stainless steel
• The manually controlled pasteurization process
• Automatic pasteurization temperature maintenance
• Manageable operation

14
HERMIS Products Available from SAROM GLOBAL

• Tunnel Pasteurisers
• Flow Pasteurisers
• Chamber Pasteurisers
• Tunnel Heaters
• Tunnel Coolers
• CIP (Clean In Place stations)
• Pickling Stations
• Conveyor Systems
• Filling Lines
• Blowing Machines
• Rinser
• Capping Machine
• Labelling Machine
• Packaging Machine
• Triblock

15
Contact Us

• Call Us 61 2 8317 5089
• Email Us info_at_saromglobal.com
• Address HQ Australia, supporting EMEA (Europe,
  Middle East, Africa), Asia Pacific, Americas
• Website https//www.saromglobal.com

16
Thank You

• Hoping To See You Soon!!
• https//www.saromglobal.com
