PCBA Assembly China at EFPCB
Description:
You must know that not only when a revision is being made to an existing design but also for the production of a new PCBA assembly China design, the first article is built. Verifying that the board being built is exactly what is expected is crucial in each case. – PowerPoint PPT presentation
Number of Views:7
Title: PCBA Assembly China at EFPCB
1
WELCOME TO EFPCB.COM
Wwww.efpcb.com
T 86-755-23724206
E sales_at_efpcb.com
S shawnwang2006
2
Multilayer PCB, Gold Plating PCB for military
Product Part No. E0415060179A Layer count4
layer HDIMaterial FR4, 1.0mm,1 OZ for all
layerMinimum tack4.8 mil
Minimum space(gap) 4.5 mil Minimum hole
0.25mmPanel size 198178mm/6up Application
Military product
3
Embedded Copper Coin PCB
Part No. E0217060129ALayer count 2
layer Material FR4 TG170 3 OZCopper
CoinMinimum trace 18 milMinimum space(gap) 32
mil
Minimum hole 0.60 mmSurface finished immersion
goldPanel size 128138mm/1up
4
PCB Assembly, PCBA Part No. E0615060189A Layer
count 6 layerMaterial FR4, 1.6mm, 1 OZ for all
layerMinimum trace 5 mil
Minimum space(gap) 5 milMinimum hole
0.20mmSurface finished ENIG Panel size
168108mm/1up Application Energy equipment.
5
Edge connector PCB, hard gold PCB, high
multilayer PCB Part No. E1215060189A Layer
count 12 layerMaterial FR4, 1.6mm, 1 OZ for
all layerMinimum tack 5 mil
Minimum space(gap) 5 milMinimum hole
0.20mmSurface finished ENIG Hard gold
(Augt3um)Panel size 228108mm/1up
6
