OPERATION AND SAFETY INSTRUCTIONS FOR SCISSOR
LIFT TABLE
www.xyzlift.com
2
About
Operation Instruction
Safety Instruction
Contact
Jinan XYZTECH Machinery Co. Ltd ABOUT ME.
Back in 2005, XYZTECH Machinery Co., Ltd started
the journey as cargo lift manufacturers. XYZLIFT
has the core motive of offering solutions, save
time and money of any one in need of lifts in
their specific site locations.
See More
www.xyzlift.com
3
About
Safety Instruction
Operation Instruction
Contact
Jinan XYZTECH Machinery Co. Ltd ABOUT OUR
INSTRUCTIONS
Employers should ensure that scissor lifts are
stable and will not tip over or collapse. Some
safe work practices to ensure safe, stable
conditions for scissor
4
Operation Instruction
Safety Instruction
Contact
About
Jinan XYZTECH Machinery Co. Ltd OPERATION
INSTRUCTION
Switch on the power by turn the KEY to
ON. Release the Emergency Stop Button at Power
Station and Control Boxes. Close ALL Flap Plates
to upright position, prior to move the Lift
Platform UP or DOWN. Press UP (2) Button to move
the Lift Platform UP Platform will stop
automatically until the platform reach the
pre-set designated upper height level. Press
DOWN (1) Button to move the Lift Platform DOWN
Platform will stop automatically until the
platform reach the pre-set designated lower
height level. Switch OFF the Lift Platform -
Lower down the platform the parking position
and Turn the Power KEY Switch to OFF position.
Operation Steps.
5
Operation Instruction
Safety Instruction
Contact
About
Jinan XYZTECH Machinery Co. Ltd OPERATION
INSTRUCTION

• When switch pull up. Press one time then release,
  platform can reach the floor level
• Lifting the Lift Platform Release the Emergency
  Stop button and Push the 2 button one time
  then move your hand. The goods will reach the
  upper pre-set designated height level.
• Lowering the Lift Platform Release the
  Emergency Stop button and Push the 1 button
  one time then move your hand. The goods reach the
  lower pre-set designated height level
• When switch push down. Keep pressing the button
  until the platform reach the floor level.
• Lifting the Lift Platform Release the Emergency
  Stop button and Push the UP button until the
  goods reach the upper pre-set designated height
  level
• Lowering the Lift Platform Release the
  Emergency Stop button and Push the DOWN button
  until the goods reach the lower pre-set
  designated height level

Safety Instruction
6
Operation Instruction
About
Safety Instruction
Contact
Jinan XYZTECH Machinery Co. Ltd SAFETY
INSTRUCTIONS
1. Emergency Stop The Emergency Stop button is
provided at each control box to stop the lift up
and down movement, in case of any emergency case
being happened.
2. Warning light There is overload valve on the
pump. When lift running normally, the warning
light flash. When overload, the warning light
alarm.
7
Safety Instruction
Operation Instruction
About
Contact
Jinan XYZTECH Machinery Co. Ltd SAFETY
INSTRUCTIONS
4.Emergency Down Valve In case of any control or
power failure, Open (Turn Anti-Clockwise) the
Emergency Down Valve to lower down the Lift
Platform to the parking position.
3.Duplicated Position Limit Switch Duplicated
Position Limit Switch for upper height level
stop control..The leveling limit switch can
slide to set correct lifting height position.
8
Safety Instruction
Operation Instruction
About
Contact
Jinan XYZTECH Machinery Co. Ltd SAFETY
INSTRUCTIONS
5. Safety trip bar under platform will stop
descent if obstructed.
6. Minimum self-height is adjustable by screws.
9
Operation Instruction
About
Safety Instruction
Contact
Jinan XYZTECH Machinery Co. Ltd SAFETY
INSTRUCTIONS
8.Hose burst valves will stop the lift table in
the event of hydraulic hose failure.
7. Center loads on the lift platform.
10
Operation Instruction
About
Safety Instruction
Contact
Jinan XYZTECH Machinery Co. Ltd SAFETY
INSTRUCTIONS
9. Maintenance support bars. Remove all cargo
from the platform first before do maintenance
jobs. Insert the 2 support bars to avoid lift
down. Do not work under the lift without the
maintenance device(s) in position.
11
Contact
Operation Instruction
Safety Instruction
About
Jinan XYZTECH Machinery Co. Ltd CONTACT US
Leaders in Lift Manufacturing
86-13853181231
www.xyzlift.com
