Clean Renewable Energy Biogas Purification with PSAVPAS Systems

1
Molecular Sieve Desiccants

• Manufacturer since 1996

2
Clean Renewable Energy Biogas Purification with
PSA/VPAS Systems
When it comes to sustainable, clean, and
renewable energy sources, Biogas has become
increasingly popular due to its potential to
transform the energy landscape through the
harnessing of the energy potential of organic
waste streams. But, the transition from raw waste
materials to high-quality biogas is challenging.
Thats where renewable energy biogas purification
with the PSA / VPSA system comes in. These
remarkable advancements along with the usage of
varied molecular sieves, can help transform the
renewable energy industry scene. Today let us
explore these two bio gas purification processes
in detail and understand their differences and
similarities.
3
Know More About Biogas Production and Composition
Biogases are a type of gas formed when organic
material, such as food waste or agricultural
residues, cattle dung/municipal solid waste,
sugarcane press, sewage treatment plant waste,
mud, etc., decomposes in an oxygen-deprived
environment, like in a compost heap or
swampland. This process is analogous to the
recycling process of nature. The composition
of bio gas is primarily composed of two
components methane, the positive component that
can be used for energy purposes and carbon
dioxide, the harmful component. Additionally,
biogas may contain impurities or fillers, such as
hydrogen sulphide, and a small amount of water
vapor, which must be removed before it can be
used to produce clean energy.
4
Purification Process Improving Biogas for Clean
Energy
Though biogas is a fantastic well-known and
accredited source of renewable energy, it's not
always clean for immediate usage as it is
produced by the active/anaerobic degradation of
organic matter. When biogas is created in a bio
gas plant, it contains many impurities and
harmful and unnecessary particles/components/impur
ities that need to be filtered out before use.
Thus, the purification process is essential to
remove any impurities like moisture, carbon
dioxide, hydrogen sulfide, etc. When the
purification process is done using molecular
sieves, it can help rid the biogas mixture of
different and numerous impurities by capturing
them in their selective strainer structures and
providing clean and pure methane gas as an
end-product. Molecular sieves can be recruited in
processes such as PSA and VPSA to create biogas
that is highly purified in nature and prepared to
be reconstructed into clean energy ready for use
in homes and industrial settings.
5
Understanding PSA/VPSA Systems
If you're looking for a system to purify your
biogas, PSA/VPSA model is the way to go. It's a
specially designed gas separation system that
uses adsorbent to separate the gas. Adsorbents
are like molecular sieves, with a tiny pore on
their surface that allows them to selectively
adsorb molecules like Co2 and N2 under a certain
pressure. Once it's adsorbed, it's regenerated by
being depressurized. These PSA systems use this
process to produce the purified methane-enriched
gas over and over, repeating the process over and
over. The process of biogas purification
increases the concentration of methane and
decreases the concentration of carbon dioxide in
the biogas, resulting in increased calorific
value. The materials used for the adsorbent layer
are activated carbon (PC) and zeolite (5a), both
of which have been shown in research, to work
best at the pressures and compositions
tested. Activated carbon molecular adsorbs mostly
CO2 and CH4 and is placed at the bottom of the
column for the feed inlet. Zeolite, on the other
hand, adsorbs N2 and carbon molecular and is
placed on top of activated carbon. The length of
each layer that corresponds to the carbon to
zeolite ratio, is a key factor in the PSA/VPSA
system. The adsorption cycle of the pressure
swing system is very complicated, as there are
many steps in the cycle and interactions between
the stages that undergo different operations. The
purity of the VPSA system is higher due to the
very low process gas flow-rate and the smaller
plant size.
6
Distinguishing PSA / VPAS System Biogas Cleaning
Methods
PSA and VPSA are both biogas cleaning methods,
but they differ significantly in terms of the
conditions under which they are
performed. Pressure Swing Adsorption/PSA- This
method mainly works by varying the pressure in
the process. The biogas goes through biogas beds
filled with a special material called molecular
sieve. The molecular sieve traps the unwanted
gases in the biogas. When the molecular sieve is
full, the pressure changes, and the unwanted
gases are trapped and released. The process is
repeated with two biogas beds as a tag
team. Vacuum Pressure Swing Adsorption/VPAS- On
the other hand, VPSA uses vacuum power
capabilities. When the pressure is
minimized/reduced (for example, in a vacuum
environment), the sieves collect the particulates
or impurities. When they are full, the pressure
returns to normal and the particulates are
discharged out of the system.
7
7 Key Benefits/Value of Using PSA/VPSA Systems

• The use of these systems eliminates impurities
  such as carbon monoxide, hydrogen sulphide, and
  moisture to produce pure and high-quality biogas.
• It also utilizes less energy consumption when
  compared to other available traditional cleaning
  methods, so it's a great option if you're looking
  for an affordable alternative.
• The PSA/VPSA systems design can be molded to fit
  smaller facilities, and is suitable for a wide
  range of applications.
• These systems are highly scalable, depending on
  the biogas production volume, and can be
  redesigned to fit different project sizes as per
  your industry requirements.
• The cycle of PSA /VPSA makes it possible to run
  on a continual basis, guaranteeing a consistent
  flow of clean biogas, and relatively low
  maintenance levels.
• With cleaner biogas, there are fewer carbon
  emissions and fewer pollutants in the air, which
  helps with environmental sustainability.
• It can be built in a variety of ways, including
  modular units/bed configurations/layouts, so you
  can easily add more units and make changes as
  needed.
• With the increase in the advantages of
  biogas combined with the help of systems like PSA
  and VPSA, we're turning biogas into a cleaner and
  more powerful energy source. Make sure to use the
  best-quality, selective filters, molecular
  sieves for your needs, that can capture
  impurities, to make sure the process is efficient
  and useful.

8
