Recent Developments in Theory and Implementation of Parallel Prefix Adders

1
Recent Developments inTheory and
Implementationof Parallel Prefix Adders

• Neil Burgess
• Division of Electronics
• Cardiff School of Engineering
• Cardiff University

2
Motivation

• Parallel Prefix Adders (e.g. Kogge-Stone) mostly
  ignored for deep submicron VLSI
• large fan-out points
• wide wiring channels
• Recent insights can remove both and do...
• absolute difference
• late increment
• media processing

3
Structure of Presentation

• Parallel Prefix Adder theory
• Kogge-Stone, Ladner-Fisher
• New log-depth prefix trees
• Knowles family of adders
• New applications of prefix adders
• late operations, media adder

4
I.Parallel Prefix Adder theory
5
Prefix adder structure
6
Prefix Equations - 1

• g(i) a(i) ? b(i) carry generate
• p(i) a(i) ? b(i) carry propagate
• k(i) ?a(i) ? b(i) carry kill
• g(i), p(i), k(i) are mutually exclusive
• Use any two ?g(i) k(i) NAND NOR
• p(i) needed as well s(i) p(i) ? c(i)

7
Prefix Equations - 2

• Generate and Not Kill signals are com-bined to
  form Group Signals
• Gxz ?Kxz interpretation
• 0 0 c(x1) 0
• 0 1 c(x1) c(z)
• 1 0 Dont care
• 1 1 c(x1) 1

8
Prefix Equations - Interpretation

• Group signals yield carry signals
• Tree outputs c(i1) Gi0
• Tree inputs Gii g(i) ?Kii ?k(i)

9
Prefix Equations - characteristics

• Associative
• sub-terms may be pre-computed in parallel

10
Prefix equations - characteristics

• Idempotent
• sub-terms may be overlapped

g
(0), k(0)
g
(0), k(0)
g
(1), k(1)
g
(1), k(1)
g
(2), k(2)
g
(2), k(2)
0
1
1
GK
GK
GK
1
2
2
0
0
GK
GK
2
2
c
(3)
c
(3)
c
(2)
c
(2)
c
(1)
c
(1)
11
4-bit Ladner-Fisher prefix tree

• 1 sub-term
• pre-computed
• Logarithmic
• depth
• Fan-out 2
• in 2nd row
• (laterally)

12
8-bit Ladner-Fisher prefix tree

• Log depth lateral fan-out 4 in 3rd row
• No exploitation of idempotency

13
16-bit Ladner-Fisher prefix tree

• Log depth with large fan-out in final row

14
4-bit Kogge-Stone prefix graph

• Fan-out 1
• (laterally)
• 1 extra cell
• parallel wires
• in 2nd row

15
8-bit Kogge-Stone prefix graph

• More cells wiring than Ladner-Fisher

16
16-bit Kogge-Stone prefix graph

• Low fan-out but wider wiring channels
• No exploitation of idempotency

17
Black cells and grey cells

• Carries, c(i) Gi-10 Ki-10 terms not needed
• G-only cells called and coloured grey

18
The story so far

• Parallel prefix adders available in VLSI
• Log-depth adders possible
• high fan-outs 1,2,4,8 low cell count
• low fan-outs 1,1,1,1 high cell count
• Problematic in VLSI (buffering, area)
• Idempotency of ? operator not exploited

19
II.KnowlesFamily of Adders
20
Log-depth prefix trees

• In VLSI
• L-F trees require too much buffering ? delay
• K-S trees require too much area (wire flux)
• Fan-outs characterised as
• 1,2,4,8 Ladner-Fisher
• 1,1,1,1 Kogge-Stone

21
Knowles insight

• Use other fan-out schemes
• 5 possible 8-bit log-depth prefix trees
• 1,1,1 17 cells Kogge-Stone
• 1,1,2 17 cells uses idempotency
• 1,1,4 14 cells no idempotency
• 1,2,2 14 cells no idempotency
• 1,2,4 12 cells Ladner-Fisher

22
Knowles 8-bit prefix trees

• All trees are log-depth

23
Tree construction rules

• Levels are labelled 0,1,2...
• Fan-out at jth level, 2k , satisfies 2k ? 2j
• Fan-out at jth level ? fan-out at j1th level
• Lateral wire length at jth level is 2j

24
Knowles 16-bit trees - I

• 1,1,1,1 49 cells 1,1,1,8 42 cells
• 1,1,1,2 49 cells 1,2,2,2 42 cells
• 1,1,1,4 49 cells 1,1,4,4 40 cells
• 1,1,2,2 49 cells 1,1,4,8 36 cells
• 1,1,2,4 49 cells 1,2,2,8 36 cells
• 1,1,2,8 42 cells 1,2,4,4 36 cells
• 1,2,2,4 42 cells 1,2,4,8 32 cells

25
Knowles 16-bit trees - II

• 1,1,1,1 1,1,1,8
• 1,1,1,2 Idempotent 1,2,2,2
• 1,1,1,4 Idempotent 1,1,4,4
• 1,1,2,2 Idempotent 1,1,4,8
• 1,1,2,4 Idempotent 1,2,2,8
• 1,1,2,8 Idempotent 1,2,4,4
• 1,2,2,4 Idempotent 1,2,4,8

26
Knowles 16-bit trees - III

• 1,1,1,1 1,1,1,8 R
• 1,1,1,2 I 1,2,2,2 R
• 1,1,1,4 I 1,1,4,4 R
• 1,1,2,2 I 1,1,4,8 R
• 1,1,2,4 I 1,2,2,8 R
• 1,1,2,8 R, I 1,2,4,4 R
• 1,2,2,4 R, I 1,2,4,8 R

27
Quick way of spotting R, I

• Define span(l) as distance from start of wire to
  first cell in lth level
• span(l) 2l ? fanout(l) ? 1
• tree characteristics
• R if span(j) ? span(k) for j lt k
• I if span(i) span(j) span(k) for i lt j lt k

28
Examples of R I spotting

• fanout(l) span(l) characteristic
• 1,1,1,1 ? 1,2,4,8 neither R nor I
• 1,1,2,2 ? 1,2,3,7 I only
• 1,2,2,2 ? 1,1,3,7 R only
• 1,2,2,4 ? 1,1,3,5 R I
• Are R I adders best?

29
VLSI design of prefix adders

• Adders laid out as rectangular array of prefix
  cells (and gaps)
• Assume cells measure 10?m ? 4?m
• 2 cells per significance ? 20?m / bit
• Key design parameters
• buffering (area delay)
• wiring channels (area)

30
16-bit adder example

• Assumptions
• Maximum fan-out without buffering
• 3 cells 80?m wire (4 cell widths)
• Maximum fan-out with buffering
• 9 cells 240?m wire (12 cell widths)
• Employ 1,2,2,4 architecture

31
1,2,2,4 prefix adder layout
32
Area vs Time for 32-bit adders
Area
K-S 1,1,1,1,1
1,1,2,2,2
1,2,2,4,4 ? 1,1,3,5,13
L-F 1,2,4,8,16
Delay
33
32-bit prefix tree adders

• Exploitable trade-off between adders delay and
  area
• Kogge-Stone adder 16 faster than Ladner-Fisher
  but 66 larger
• 1,2,2,4,4 adder 8 faster than Ladner-Fisher
  but only 3 larger
• buffering also trades off speed for area

34
III.New applications of prefix adders
35
Other addition operations

• Late increment
• Mod 2w-1 addition for Reed-Solomon coding
• floating-point rounding
• Late complement
• absolute difference for video motion estimation
• sign-magnitude addition
• Typically use 2 adders and a MUX

36
Increments in prefix trees

• Row of prefix cells late 1 operation
• Ladner-Fisher comprises many late 1s
• 1 8-bit, 2 4-bit, 4 2-bit, 8 1-bit

37
Late increment tree

• Adder returns AB if inc 0
• Adder returns AB1 if inc 1

inc
38
Late increment logic

• Late Carry lc(i) set high if
• c(i) 1 or
• inc 1 and a(n),b(n) ? 0,0 ? n 0 ? n lt i

0
c(i) G
i
-1
lc(i)
inc
0
Ø
K
s(i)
i
-1
p(i)
39
Late complement theory

• In 2s-complement, ?N -(N1)
• A ?B A - B - 1
• late increment then yields A - B
• ?(A ?B) -(A - B - 11) B - A
• Absolute difference readily available

40
Absolute difference logic

• If c(w) 0, result negative
• if c(w) 0, invert all the bits
• else always perform late increment with ?Ki-10

41
Summary of late ops

• Available on all prefix adders
• Extra delay 1 gates delay buffering
• Extra hardware ?w black cells
• This technique used in floating-point units
• late increment for rounding
• late complement for true subtraction

42
Media (packed) arithmetic

• Fundamental strategy
• Use full wordlength hardware for
• multiple sub-wordlength computations
• Examples
• 32-bit adder ? 4 8-bit adders
• 32-bit multiplier ? 2 16-bit multipliers

43
Partitioning an adder

• Criteria
• support carries propagating within sub-adders
• prevent carries propagating between sub-adders
• Solutions
• put AND gates on carry chains ? slower adder
• put dummy 0s on operand bits ? larger adder
• Use prefix adder!!

44
Packed prefix adder - 1

• Force ?k(n) 0 at partition points
• prevents carries propagating across bit n
• exploits dont care condition (g,?k) (1,0)
• Implementation
• change ?k(n) gate to (2,1) OR-AND gate
• delay-neutral modification

45
Packed prefix adder - 2

• Force c(n) Gn-10 0 at partition points
• prevents c(n) ? s(n) errors
• Implementation
• insert AND gates (off critical path) or
• change Gn-10 gate to (2,1,1) complex gate
• BUT need Gn-10 signal for sub-adder overflows

46
Packed prefix adder - 3

• Sub-adder carries complete early
• Extraneous cells automatically do nothing

47
Last Slide

• Recent developments in prefix adders
• new family of log-depth trees
• late operations
• packed arithmetic for media processing
• Future possibilities
• systematic exploitation of idempotency
• trees with reduced buffering
• combine packed arithmetic/late ops

48
ANY QUESTIONS OR COMMENTS?
