MPJ Express An Implementation of Message Passing
Interface (MPI) in Java

• Aamir Shafi
• http//mpj-express.org
• http//acet.rdg.ac.uk/projects/mpj

2
Writing Parallel Software

• There are mainly two approaches for writing
  parallel software
• Software that can be executed on parallel
  hardware to exploit computational and memory
  resources
• The first approach is to use messaging libraries
  (packages) written in already existing languages
  like C, Fortran, and Java
• Message Passing Interface (MPI)
• Parallel Virtual Machine (PVM)
• The second and more radical approach is to
  provide new languages
• HPC has a history of novel parallel languages
• High Performance Fortran (HPF)
• Unified Parallel C (UPC)
• In this talk we talk about an implementation of
  MPI in Java called MPJ Express

3
Introduction to Java for HPC

• Java was released by Sun in 1996
• A mainstream language in software industry,
• Attractive features include
• Portability,
• Automatic garbage collection,
• Type-safety at compile time and runtime,
• Built-in support for multi-threading
• A possible option to provide nested parallelism
  on multi-core systems,
• Performance
• Just-In-Time compilers convert source code to
  byte code,
• Modern JVMs perform compilation from byte code to
  native machine code on the fly
• But Java has safety features that may limit
  performance.

4
Introduction to Java for HPC

• Three existing approaches to Java messaging
• Pure Java (Sockets based),
• Java Native Interface (JNI), and
• Remote Method Invocation (RMI),
• mpiJava has been perhaps the most popular Java
  messaging system
• mpiJava (http//www.hpjava.org/mpiJava.html)
• MPJ/Ibis (http//www.cs.vu.nl/ibis/mpj.html)
• Motivation for a new Java messaging system
• Maintain compatibility with Java threads by
  providing thread-safety,
• Handle contradicting issues of high-performance
  and portability.

5
Distributed Memory Cluster
Proc 1
Proc 2
Proc 0
message
LAN Ethernet Myrinet Infiniband etc
Proc 3
Proc 7
Proc 6
Proc 4
Proc 5
6
(No Transcript)
7
Write machines files
8
Bootstrap MPJ Express runtime
9
Write Parallel Program
10
Compile and Execute
11
Introduction to MPJ Express

• MPJ Express is an implementation of a Java
  messaging system, based on Java bindings
• Will eventually supersede mpiJava.
• Aamir Shafi, Bryan Carpenter, and Mark Baker
• Thread-safe communication devices using Java NIO
  and Myrinet
• Maintain compatibility with Java threads,
• The buffering layer provides explicit memory
  management instead of relying on the garbage
  collector,
• Runtime system for portable bootstrapping

12
James Gosling Says
13
Who is using MPJ Express?

• First released in September 2005 under LGPL (an
  open-source licence)
• Approximately 1000 users all around the world
• Some projects using this software
• Cartablanca is a simulation package that uses
  Jacobian-Free-Newton-Krylov (JFNK) methods to
  solve non-linear problems
• The project is done at Los Alamos National Lab
  (LANL) in the US
• Researchers at University of Leeds, UK have used
  this software in Modelling and Simulation in
  e-Social Science (MoSeS) project
• Teaching Purposes
• Parallel Programming using Java (PPJ)
• http//www.sc.rwth-aachen.de/Teaching/Labs/PPJ05/

• Parallel Processing SS 2006
• http//tramberend.inform.fh-hannover.de/

14
MPJ Express Design
15
Presentation Outline

• Implementation Details
• Point-to-point communication
• Communicators, groups, and contexts
• Process topologies
• Derived datatypes
• Collective communications
• MPJ Express Buffering Layer
• Runtime System
• Performance Evaluation

16
Java NIO Device

• Uses non-blocking I/O functionality,
• Implements two communication protocols
• Eager-send protocol for small messages,
• Rendezvous protocol for large messages,
• Locks around communication methods results in
  deadlocks
• In Java, the keyword synchronized ensures that
  only one object can call synchronized method at a
  time,
• A process sending a message to itself using
  synchronous send,
• Locks for thread-safety
• Writing messages
• A lock for send-communication-sets,
• Locks for destination channels
• One for every destination process,
• Obtained one after the other,
• Reading messages
• A lock for receive-communication-sets.

17
Standard mode with eager send protocol (small
messages)
18
Standard mode with rendezvous protocol (large
messages)
19
MPJ Express Buffering Layer

• MPJ Express requires a buffering layer
• To use Java NIO
• SocketChannels use byte buffers for data
  transfer,
• To use proprietary networks like Myrinet
  efficiently,
• Implement derived datatypes,
• Various implementations are possible based on
  actual storage medium,
• Direct or indirect ByteBuffers,
• An mpjbuf buffer object consists of
• A static buffer to store primitive datatypes,
• A dynamic buffer to store serialized Java
  objects,
• Creating ByteBuffers on the fly is costly
• Memory management is based on Knuths buddy
  algorithm,
• Two implementations of memory management.

20
MPJ Express Buffering Layer

• Frequent creation and destruction of
  communication buffers hurts performance.
• To tackle this, MPJ Express requires a buffering
  layer
• Provides two implementations of Knuths buddy
  algorithm,
• To use Java NIO and proprietary networks
• Direct ByteBuffers,
• Implement derived datatypes

21
Presentation Outline

• Implementation Details
• Point-to-point communication
• Communicators, groups, and contexts
• Process topologies
• Derived datatypes
• Collective communications
• MPJ Express Buffering Layer
• Runtime System
• Performance Evaluation

22
Communicators, groups, and contexts

• MPI provides a higher level abstraction to create
  parallel libraries
• Safe communication space
• Group scope for collective operations
• Process Naming
• Communicators Groups provide
• Process Naming (instead of IP address ports)
• Group scope for collective operations
• Contexts
• Safe communication

23
What is a group?

• A data-structure that contains processes
• Main functionality
• Keep track of ranks of processes
• Explanation of figure
• Group A contains eight processes
• Group B and C are created from Group A
• All group operations are local (no communication
  with remote processes)

24
Example of a group operation(Union)

• Explanation of union operation
• Two processes a and d are in both groups
• Thus, six processes are executing this operation
• Each group has its own view of this group
  operations
• Apply theory of relativity
• Re-assigning ranks in new groups
• Process 0 in group A is re-assigned rank 0 in
  Group C
• Process 0 in group B is re-assigned rank 4 in
  Group C
• If any existing process does not make it into the
  new group, it returns MPI.GROUP_EMPTY

25
What are communicators?

• A data-structure that contains groups (and thus
  processes)
• Why is it useful
• Process naming, ranks are names for application
  programmers
• Easier than IPaddress ports
• Group communications as well as point to point
  communication
• There are two types of communicators,
• Intracommunicators
• Communication within a group
• Intercommunicators
• Communication between two groups (must be
  disjoint)

26
What are contexts?

• An unique integer
• An additional tag on the messages
• Each communicator has a distinct context that
  provides a safe communication universe
• A context is agreed upon by all processes when a
  communicator is built
• Intracommunicators has two contexts
• One for point-to-point communications
• One for collective communications,
• Intercommunicators has two contexts
• Explained in the coming slides

27
Process topologies

• Used to specify processes in a geometric shape
• Virtual topologies have no connection with the
  physical layout of machines
• Its possible to make use of underlying machine
  architecture
• These virtual topologies can be assigned to
  processes in an Intracommunicator
• MPI provides
• Cartesian topology
• Graph topology

28
Cartesian topology Mapping four processes onto
2x2 topology

• Each process is assigned a coordinate
• Rank 0 (0,0)
• Rank 1 (1,0)
• Rank 2 (0,1)
• Rank 3 (1,1)
• Uses
• Calculate rank by knowing grid (not globus one!)
  position
• Calculate grid positions from ranks
• Easier to locate rank of neighbours
• Applications may have communication patterns
• Lots of messaging with immediate neighbours

29
Periods in cartesian topology

• Axis 1 (y-axis is periodic)
• Processes in top and bottom rows have valid
  neighbours towards top and bottom respectively
• Axis 0 (x-axis is non-periodic)
• Processes in right and left column have undefined
  neighbour towards right and left respectively

30
Derived datatypes

• Besides, basic datatypes, it is possible to
  communicate heterogeneous, non-contiguous data.
• Contiguous
• Indexed
• Vector
• Struct

31
Indexed datatype

• The elements that may form this datatype should
  be
• Same types
• At non-contiguous locations
• Add flexibility by specifying displacements
• int SIZE 4 int blklen new intDIM,displ
  new intDIM
• for(i0 iltDIM i)
• blkleniDIM-i displi(iDIM)i
• double params new doubleSIZESIZE
• double rparams new doubleSIZESIZE
• Datatype i Datatype.Indexed(blklen, displ,
  MPI.INT)
• //array_of_block_lengths, array_displacements
• Send(params,0,1,i,dst,tag) //0 is offset, 1 is
  count
• Recv(rparams,0,1,i,src,tag)

32
(No Transcript)
33
Presentation Outline

• Implementation Details
• Point-to-point communication
• Communicators, groups, and contexts
• Process topologies
• Derived datatypes
• Collective communications
• Runtime System
• Thread-safety in MPJ Express
• Performance Evaluation

34
Collective communications

• Provided as a convenience for application
  developers
• Save significant development time
• Efficient algorithms may be used
• Stable (tested)
• Built on top of point-to-point communications,
• These operations include
• Broadcast, Barrier, Reduce, Allreduce, Alltoall,
  Scatter, Scan, Allscatter
• Versions that allows displacements between the
  data

35
Broadcast, scatter, gather, allgather, alltoall
Image from MPI standard doc
36
Reduce collective operations

• MPI.PROD
• MPI.SUM
• MPI.MIN
• MPI.MAX
• MPI.LAND
• MPI.BAND
• MPI.LOR
• MPI.BOR
• MPI.LXOR
• MPI.BXOR
• MPI.MINLOC
• MPI.MAXLOC

37
Barrier with Tree Algorithm
38
Execution of barrier with eight processes

• Eight processes, thus forms only one group
• Each process exchanges an integer 4 times
• Overlaps communications well

39
Intracomm.Bcast( )

• Sends data from a process to all the other
  processes
• Code from adlib
• A communication library for HPJava
• The current implementation is based on n-ary
  tree
• Limitation broadcasts only from rank0
• Generated dynamically
• Cost O( log2(N) )
• MPICH1.2.5 uses linear algorithm
• Cost O(N)
• MPICH2 has much improved algorithms
• LAM/MPI uses n-ary trees
• Limitation, broadcast from rank0

40
Broadcasting algorithm, total processes8, root0
41
Presentation Outline

• Implementation Details
• Point-to-point communication
• Communicators, groups, and contexts
• Process topologies
• Derived datatypes
• Collective communications
• Runtime System
• Thread-safety in MPJ Express
• Performance Evaluation

42
The Runtime System
43
Thread-safety in MPI

• The MPI 2.0 specification introduced the notion
  of thread-compliant MPI implementation,
• Four levels of thread-safety
• MPI_THREAD_SINGLE,
• MPI_THREAD_FUNNELED,
• MPI_THREAD_SERIALIZED,
• MPI_THREAD_MULTIPLE,
• A blocked thread should not halt the execution of
  other threads,
• Issues in Developing Thread-Safe MPI
  Implementation by Gropp et al.

44
Presentation Outline

• Implementation Details
• Point-to-point communication
• Communicators, groups, and contexts
• Process topologies
• Derived datatypes
• Collective communications
• Runtime System
• Thread-safety in MPJ Express
• Performance Evaluation

45
Latency on Fast Ethernet
46
Throughput on Fast Ethernet
47
Latency on Gigabit Ethernet
48
Throughput on GigE
49
Choking experience 1
50
Latency on Myrinet
51
Throughput on Myrinet
52
Questions
?
