Link Analysis: Current State of the Art

1
Link Analysis Current State of the Art

• Ronen Feldman
• Computer Science Department
• Bar-Ilan University, ISRAEL
• ronenf_at_gmail.com

2
Introduction to Text Mining
3
TM ! Search
Find Documents matching the Query
Display Information relevant to the Query
Long lists of documents
Aggregate over entire collection
4
Let Text Mining Do the Legwork for You
Text Mining
Find Material
Read
Understand
Consolidate
Absorb / Act
5
What Is Unique in Text Mining?

• Feature extraction.
• Very large number of features that represent each
  of the documents.
• The need for background knowledge.
• Even patterns supported by small number of
  document may be significant.
• Huge number of patterns, hence need for
  visualization, interactive exploration.

6
Document Types

• Structured documents
• Output from CGI
• Semi-structured documents
• Seminar announcements
• Job listings
• Ads
• Free format documents
• News
• Scientific papers

7
Text Representations

• Character Trigrams
• Words
• Linguistic Phrases
• Non-consecutive phrases
• Frames
• Scripts
• Role annotation
• Parse trees

8
The 100,000 foot Picture
9
Intelligent Auto-Tagging
(c) 2001, Chicago Tribune. Visit the Chicago
Tribune on the Internet at http//www.chicago.trib
une.com/ Distributed by Knight Ridder/Tribune
Information Services. By Stephen J. Hedges and
Cam Simpson
. The Finsbury Park Mosque is the center of
radical Muslim activism in England. Through its
doors have passed at least three of the men now
held on suspicion of terrorist activity in
France, England and Belgium, as well as one
Algerian man in prison in the United States.
The mosque's chief cleric, Abu Hamza al-Masri
lost two hands fighting the Soviet Union in
Afghanistan and he advocates the elimination of
Western influence from Muslim countries. He was
arrested in London in 1999 for his alleged
involvement in a Yemen bomb plot, but was set
free after Yemen failed to produce enough
evidence to have him extradited. .''
10
Intelligence Article
11
Googles Article
12
Merger
13
Leveraging Content Investment

• Any type of content
• Unstructured textual content (current focus)
• Structured data audio video (future)

• In any format
• Documents PDFs E-mails articles etc
• Raw or categorized
• Formal informal combination

Text Mining

• From any source
• WWW file systems news feeds etc.
• Single source or combined sources

14
Information Extraction
15
Relevant IE Definitions

• Entity an object of interest such as a person or
  organization.
• Attribute a property of an entity such as its
  name, alias, descriptor, or type.
• Fact a relationship held between two or more
  entities such as Position of a Person in a
  Company.
• Event an activity involving several entities
  such as a terrorist act, airline crash,
  management change, new product introduction.

16
IE Accuracy by Information Type
Information Type Accuracy
Entities 90-98
Attributes 80
Facts 60-70
Events 50-60
17
MUC Conferences
Conference Year Topic
MUC 1 1987 Naval Operations
MUC 2 1989 Naval Operations
MUC 3 1991 Terrorist Activity
MUC 4 1992 Terrorist Activity
MUC 5 1993 Joint Venture and Micro Electronics
MUC 6 1995 Management Changes
MUC 7 1997 Spaces Vehicles and Missile Launches
18
Applications of Information Extraction

• Routing of Information
• Infrastructure for IR and for Categorization
  (higher level features)
• Event Based Summarization.
• Automatic Creation of Databases and Knowledge
  Bases.

19
Where would IE be useful?

• Semi-Structured Text
• Generic documents like News articles.
• Most of the information in the document is
  centered around a set of easily identifiable
  entities.

20
Approaches for Building IE Systems

• Knowledge Engineering Approach
• Rules are crafted by linguists in cooperation
  with domain experts.
• Most of the work is done by inspecting a set of
  relevant documents.
• Can take a lot of time to fine tune the rule set.
• Best results were achieved with KB based IE
  systems.
• Skilled/gifted developers are needed.
• A strong development environment is a MUST!

21
Approaches for Building IE Systems

• Automatically Trainable Systems
• The techniques are based on pure statistics and
  almost no linguistic knowledge
• They are language independent
• The main input is an annotated corpus
• Need a relatively small effort when building the
  rules, however creating the annotated corpus is
  extremely laborious.
• Huge number of training examples is needed in
  order to achieve reasonable accuracy.
• Hybrid approaches can utilize the user input in
  the development loop.

22
Components of IE System
23
Why is IE Difficult?

• Different Languages
• Morphology is very easy in English, much harder
  in German and Hebrew.
• Identifying word and sentence boundaries is
  fairly easy in European language, much harder in
  Chinese and Japanese.
• Some languages use orthography (like english)
  while others (like hebrew, arabic etc) do no have
  it.
• Different types of style
• Scientific papers
• Newspapers
• memos
• Emails
• Speech transcripts
• Type of Document
• Tables
• Graphics
• Small messages vs. Books

24
Link Analysis on Large Textual Networks

• Social Network Analysis

25
The Kevin Bacon Game

• The game works as follows given any actor, find
  a path between the actor and Kevin Bacon that has
  less than 6 edges.
• For instance, Kevin Costner links to Kevin Bacon
  by using one direct link Both were in JFK.
• Julia Louis-Dreyfus of TV's Seinfeld, however,
  needs two links to make a path Julia
  Louis-Dreyfus was in Christmas Vacation (1989)
  with Keith MacKechnie. Keith MacKechnie was in We
  Married Margo (2000) with Kevin Bacon.
• You can play the game by using the following URL
  http//www.cs.virginia.edu/oracle/.

26
The Erdos Number

• A similar idea is also used in the mathematical
  society and is called the Erdös number of a
  researcher.
• Paul Erdös (19131996), wrote hundreds of
  mathematical research papers in many different
  areas, many in collaboration with others.
• There is a link between any two mathematicians if
  they co-authored a paper.
• Paul Erdös is the root of the mathematical
  research network and his Erdös number is 0.
• Erdöss co-authors have Erdös number 1.
• People other than Erdös who have written a joint
  paper with someone with Erdös number 1 but not
  with Erdös have Erdös number 2, and so on.

27
Running Example
28
Hijackers by Flight
Flight 77 Pentagon Flight 11 WTC 1 Flight 175 WTC 2 Flight 93 PA
Khalid Al-Midhar Satam Al Suqami Marwan Al-Shehhi Saeed Alghamdi
Majed Moqed Waleed M. Alshehri Fayez Ahmed Ahmed Alhaznawi
Nawaq Alhamzi Wail Alshehri Ahmed Alghamdi Ahmed Alnami
Salem Alhamzi Mohamed Atta Hamza Alghamdi Ziad Jarrahi
Hani Hanjour Abdulaziz Alomari Mohald Alshehri
29
Automatic layout of networks

• Pretty Graph Drawing

30
Motivation I

• In order to display large networks on the screen
  we need to use automatic layout algorithms. These
  algorithms display the graphs in an aesthetic way
  without any user intervention.
• The most commonly used aesthetic criteria are to
  expose symmetries and make drawing as compact as
  possible or alternatively fill the space
  available for the drawing.

31
Motivation II

• Many of the higher-level aesthetic criteria are
  implicit consequences of
• minimized number of edge crossings
• evenly distributed edge length
• evenly distributed vertex positions on the graph
  area
• sufficiently large vertex-edge distances
• sufficiently large angular resolution between
  edges.

32
Disadvantages of the Spring based methods

• They are computationally expensive and hence
  minimizing the energy function when dealing with
  large graphs is computationally prohibitive.
• Since all methods rely on heuristics, there is no
  guarantee that the best layout will be found.
• The methods behave as black boxes and hence it is
  almost impossible to integrate additional
  constraints on the layout (such as fixing the
  positions of certain vertices, or specifying the
  relative ordering of the vertices)
• Even when the graphs are planar it is quite
  possible that we will get edge crossings.
• The methods try to optimize just the placement of
  vertices and edges while ignoring the exact shape
  of the vertices or the fact the vertices may have
  labels.

33
Kamada and Kawais (KK) Method
34
Fruchterman Reingold (FR) Method
35
Classic Graph Operations
36
Finding the shortest Path (from Atta)
37
A better Visualization
38
Centrality
39
Degree

• If the graph is undirected then the degree of a
  vertex v ? V is the number of other vertices that
  are directly connected to it.
• degree(v) (v1, v2) ? E v1 v or v2 v
• If the graph is directed then we can talk about
  in-degree or out-degree. An edge (v1,v2) ? E in
  the directed graph is leading from vertex v1 to
  v2.
• In-degree(v) (v1, v) ? E
• Out-degree(v) (v, v2) ? E

40
Degree of the Hijackers
41
Closeness Centrality - Motivation

• Degree centrality measures might be criticized
  because they only take into account the direct
  connections that an entity has, rather than
  indirect connections to all other entities.
• One entity might be directly connected to a large
  number of entities that might be pretty isolated
  from the network. Such an entity is central only
  in a local neighborhood of the network.

42
Closeness Centrality

• This measure is based on the calculation of the
  geodesic distance between the entity and all
  other entities in the network.
• We can either use directed or undirected geodesic
  distances between the entities.
• The sum of these geodesic distances for each
  entity is the "farness" of the entity from all
  other entities.
• We can convert this into a measure of closeness
  centrality by taking the reciprocal.
• In addition, we can normalize the closeness
  measure by dividing it by the closeness measure
  of the most central entity.

43
Closeness Formally

• let d(v1,v2) the minimal distance between v1
  and v2, i.e., the minimal number of vertices that
  we need to pass on the way from v1 to v2.

44
Closeness of the Hijackers
Name Closeness
Abdulaziz Alomari 0.6
Ahmed Alghamdi 0.5454545
Ziad Jarrahi 0.5294118
Fayez Ahmed 0.5294118
Mohamed Atta 0.5142857
Majed Moqed 0.5142857
Salem Alhamzi 0.5142857
Hani Hanjour 0.5
Marwan Al Shehhi 0.4615385
Satam Al Suqami 0.4615385
Waleed M. Alshehri 0.4615385
Wail Alshehri 0.4615385
Hamza Alghamdi 0.45
Khalid Al Midhar 0.4390244
Mohald Alshehri 0.4390244
Nawaq Alhamzi 0.3673469
Saeed Alghamdi 0.3396226
Ahmed Alnami 0.2571429
Ahmed Alhaznawi 0.2571429
45
Betweeness Centrality

• The betweeness centrality measures the
  effectiveness in which the vertex connects the
  various parts of the network.
• The main idea behind betweeness centrality is
  that entities that are mediators have more power.
  Entities that are on many geodesic paths between
  other pairs of entities are more powerful since
  they control the flow of information between the
  pairs.

46
Betweeness - Formally

• Highest Possible Betweeness
• gjk the number of geodetic paths that connect
  vj with vk
• gjk(vi) the number of geodetic paths that
  connect vj with vk and pass via vi.

47
Betweenness of the Hijackers
48
Eigen Vector Centrality

• The main idea behind eigenvector centrality is
  that entities receiving many communications from
  other well connected entities, will be better and
  more valuable sources of information, and hence
  be considered central. The Eigenvector centrality
  scores correspond to the values of the principal
  eigenvector of the adjacency matrix M.
• Formally, the vector v satisfies the equation
  where l is the corresponding eigenvalue and M is
  the adjacency matrix.

49
EigenVector centralities of the hijackers
Name E1
Mohamed Atta 0.518
Marwan Al-Shehhi 0.489
Abdulaziz Alomari 0.296
Ziad Jarrahi 0.246
Fayez Ahmed 0.246
Satam Al Suqami 0.241
Waleed M. Alshehri 0.241
Wail Alshehri 0.241
Salem Alhamzi 0.179
Majed Moqed 0.165
Hani Hanjour 0.151
Khalid Al-Midhar 0.114
Ahmed Alghamdi 0.085
Nawaq Alhamzi 0.064
Mohald Alshehri 0.054
Hamza Alghamdi 0.015
Saeed Alghamdi 0.002
Ahmed Alnami 0
Ahmed Alhaznawi 0
50
Power Centrality

• Given an adjacency matrix M, the power centrality
  of vertex i (denoted ci), is given by
• a is used to normalize the score the
  normalization parameter is automatically selected
  so that the sum of squares of the verticess
  centralities is equal to the number of vertices
  in the network.
• b is an attenuation factor that controls the
  effect that the power centralities of the
  neighboring vertices should have on the power
  centrality of the vertex.

51
Power - Motivation

• In a similar way to the eigenvector centrality,
  the power centrality of each vertex is determined
  by the centrality of the vertices it is connected
  to.
• By specifying positive or negative values to b
  the user can control if the fact that a vertex is
  connected to powerful vertices should have a
  positive effect on its score or a negative
  effect.
• The rational for specifying a positive b is that
  if you are connected to powerful colleagues it
  makes you more powerful.
• On the other hand, the rational for a negative b
  is that powerful colleagues have many connections
  and hence are not controlled by you, while
  isolated colleagues have no other sources of
  information and hence are pretty much controlled
  by you.

52
Power of the Hijackers
  Power b 0.99 Power b -0.99
Mohamed Atta 2.254 2.214
Marwan Al-Shehhi 2.121 0.969
Abdulaziz Alomari 1.296 1.494
Ziad Jarrahi 1.07 1.087
Fayez Ahmed 1.07 1.087
Satam Al Suqami 1.047 0.861
Waleed M. Alshehri 1.047 0.861
Wail Alshehri 1.047 0.861
Salem Alhamzi 0.795 1.153
Majed Moqed 0.73 1.029
Hani Hanjour 0.673 1.334
Khalid Al-Midhar 0.503 0.596
Ahmed Alghamdi 0.38 0.672
Nawaq Alhamzi 0.288 0.574
Mohald Alshehri 0.236 0.467
Hamza Alghamdi 0.07 0.566
Saeed Alghamdi 0.012 0.656
Ahmed Alnami 0.003 0.183
Ahmed Alhaznawi 0.003 0.183
53
Network Centralization

• In addition to the individual vertex
  centralization measures, we can assign a number
  between 0 and 1 that will signal the level of
  centralization of the whole network.
• The network centralization measures will be
  computed based on the centralization values of
  its vertices and hence we will have for type of
  individual centralization measure an associated
  network centralization measure.
• A network that is structured like a circle will
  have a network centralization value of 0 (since
  all vertices have the same centralization value),
  while a network that structured like a star will
  have a network centralization value of 1.
• We will now provide some of the formulas for the
  different network centralization measures.

54
Degree

For the Hijackers network NetDegree 0.31
55
Betweenness
For the Hijackers network NetBet 0.24
56
Summary Diagram
