Integrating Tools for Practical Software Analysis

1
Integrating Tools for Practical Software Analysis

• Aaron Bradley, Zohar Manna,
• Henny Sipma, Sarah Solter
• Stanford University

CUE Workshop, Vienna, October 7, 2004
2
Objective

• Program Analysis
• From point solutions to a tool infrastructure

3
Tools
software producing world
?
4
Tool-tree
software producing world
intelligent compiler
5
Outline

• Survey of tools
• Tool integration
• Integration of methodologies
• An attempt at integration
• Proposal
• Topics for discussion

6
Survey of tools Overview

• Isolated tools
• state-based
• syntax-based
• language-based
• Supporting tools
• Parsers
• Foundational
• Language integration

7
What is an isolated tool?

• Based on one research insight
• Mostly tightly integrated with other components
  to make it work
• Performs a single task
• Usually not a source for further research
• May be extensible

8
Isolated Tools State-based

• Whole program analysis
• behavioral properties
• Historically known as formal methods
• User interaction moderate to extensive
• Types of analysis
• Model checking CBMC, CMC, JPF, Spin
• Predicate abstraction Bandera, Blast, Slam
• Abstract interpretation Astree
• Theorem proving ACL2, ESC, PVS, STeP

9
Isolated tools Syntax-based

• Spectrum of analyses pattern-matching to
  dataflow analysis over program statements
• Bug finding (unsound and incomplete)
• Minimal user interaction
• Availability
• Java FindBugs
• C ESP, PREFix, xgcc

10
Isolated tools language-based

• Based on programming language semantics
• Extend programming language semantics to check
  deeper behavioral properties
• type qualifiers Cqual
• Dataflow analyses

11
What is a supporting tool?

• Does not solve a whole problem product is not
  used by a person
• Indirectly assists in other solving other
  problems
• Crucial to solving real problems
• Usually result of specialized research
• Usually incorporated via APIs

12
Parsers

• Transforms source code into a form amenable to
  analysis (AST, 3- or 4-address code, byte code)
• Desirable features
• support for annotating code
• support for querying other analyses
• enforce standards of information presentation
• support incremental analysis
• Examples
• C CIL
• Java Flex, Soot, Barat, PMD

13
Foundational tools

• Engines of analysis tools
• Results of specialized research
• Examples
• Decision procedures CVC, CVC-Lite, ICS
• SAT solvers chaff
• BDD packages
• Polyhedra manipulation PPL, Polka
• Algebraic packages Reduce, Mathematica
• Linear programming/linear algebra Matlab, GLPK
• Constraint solvers

14
Tool Integration frameworks

• Formal conversion between different languages and
  property representations
• Examples
• VeriTech
• tools supported Murphi, SMV, Spin, STeP,.......
• maintaining semantics of properties proved
• SAL
• expressive language to allow compilation of other
  languages
• provides analysis
• Common intermediate representation for C, C,
  Java? Byte code?

15
Options for Integration

• Loose coupling
• via input/output language
• Tight coupling
• one monolithic system
• API coupling
• component-based

16
Loose coupling

• Results of analyses are written to file and read
  from file by other analyses
• Properties proved by one tool must be translated
  into other tools semantics may be different.
• Examples Veritech, JPF version 1, STeP Spin,
  Bandera

17
Tight coupling

• Isolated tools monolithic systems
• All components dependent on shared
  representations
• Cannot be pulled apart
• Components cannot be used in isolation
• Sometimes can extend the system with new
  analyses, e.g. PVS, BANE, REDUCE

18
API coupling and layering

• Agreed upon standards for APIs and
  representations
• Layers
• user-level interfaces
• software analysis tools
• common dataflow and type inference framework,
  etc.
• parsers and foundational tools
• Each component can be made available to other
  reseachers as is

19
What about integrating methodologies?

• Classical
• traditionally compiler optimization
• programming language semantics
• State-space
• model checking/theorem proving
• program semantics
• Language-based
• sequences of statements
• language semantics

20
Classical Program Analysis

• Foundations
• Type inference
• controlflow/dataflow analysis
• Exploits the semantics of programming languages
• Examples
• Alias analysis
• Class hierarchy analysis
• Traditional objective compiler optimization
• Requirement low complexity
• Can be borrowed by other tools
• Recent extension CQual

21
State-space analysis

• Traditional objective verification and program
  understanding
• Model behaviors
• Examples
• invariant generation
• termination analysis
• verification condition generation (Floyd-Hoare)
• model checking

22
Language perspective

• View the program as a sequence of statements
• Specify properties on these sequences, for
  example ( xmalloc(...) free(x))
• Pattern matching on statements
• Successful in bugfinding

23
state space
Blast, SLAM, ESC
classical
language
CQual
ESP
24
state space
Blast, SLAM, ESC
predicate abstraction
class hierarchy analysis
decision procedures
dataflow framework
quantified LTL
alias analysis
alias analysis
classical
language
CQual
ESP
25
A researchers experience

• Topic termination analysis
• objective prove that all loops in a program
  terminate
• approach polynomial analysis

26
Termination analysis
Implementation in Mathematica
transition systems
27
A researchers experience

• Topic termination analysis
• objective prove that all loops in a program
  terminate
• approach polynomial analysis
• claim scales to large programs
• claim is useful for practical programs
• Needs experiments on real programs

28
Termination analysis
alias analysis
class hierarchy analysis
Implementation in Mathematica
C programs
CIL
CFG construction
invariant generation
dataflow framework
29
A researchers experience

• Topic termination analysis
• objective prove that all loops in a program
  terminate
• approach polynomial analysis
• claim scales to large programs
• claim is useful for practical programs
• Needs experiments on real programs
• Successfully applies the analysis to several
  large programs
• Writes a paper with impressive test results

30
Tools
software producing world
31
Problems with current approach

• Large integration effort
• Efforts are repeated
• Multiple languages
• Tools not available to the user community
• Too many tools of unknown trustworthiness

32
Wishlist

• Users
• single access point
• Tool developers
• easy access to other tools
• infrastructure to insert tools

33
User level interface

• Single-access point
• Keep new versions hidden from the user
• Intelligent compiler
• prioritization and hierarchical presentation of
  errors, warnings, proofs, presented like a
  compiler
• extensible for user interaction for more
  sophisticated users

34
Front end Eclipse

• Integrated development environment
• Provides
• single access point for users
• hooks for tool developers
• Lacks
• infrastructure to communicate analysis results
  from one tool to another
• Burden of integration of analysis tools and
  methodologies still on the user
• No real integration
• Does not solve problems of too many tools

35
Wishlist contd

• Approach Component-based with API coupling and
  layering
• Infrastructure that enables insertion of tools
  without the need for adaptation
• Single intermediate language
• Spectrum of interfaces intelligent compiler
  building of customized applications
• Benchmarks for comparison
• Identification of strengths relative to
  categories of applications
• Refereed tools to ensure trustworthiness

36
Tool-tree
software producing world
intelligent compiler
benchmarks
API
37
Tool-tree
software producing world
intelligent compiler
38
Tool-tree
software producing world
intelligent compiler
39
Addition of new tool to tool tree

• Conform to API for performed analysis (or create
  new analysis for new type of analysis)
• Run standard benchmarks
• Compare performance with similar analyses

40
Termination analysis
gcc t .......
loops proven
A 90 15 55
B 25 65 42
C 45 55 15
D 65 15 78
41
Tool-tree
software producing world
Portal Resource selection Resource
discovery
database with test results
can be implemented as a webservice
42
Tool tree

• Similar to the network protocol stack
• Provides a lot of functionality through a narrow
  interface
• Child APIs are a superset of their parents
• Richer APIs for more sophisticated/demanding
  users
• Can provide many alternatives for the same
  analysis
• Allows addition of new analyses

43
How do we make it happen?

• Saints?

44
Discussion topics
45
Publication vs Implementation

• Considerations
• Is implementation of research results a
  respectable research pursuit?
• Is it worthwhile to spend time on implementation?
• Authorship often goes to the developer of an
  idea implementors are considered secondary
• Implementations require a lot of effort, but
  decrease the effort of others. How to reward the
  effort?
• Ideas
• Conference that requires submissions to be
  accompanied by implementations
• Journal of foundational tool descriptions and
  documentation

46
Funding structure

• Considerations
• Funding agencies often require revolutionary new
  approaches implementation and integration of
  existing results are not considered
• Ideas
• Follow-up grants specifically for implementation
  and integration
• Infrastructure grants
• Existing effort ESCHER?

47
Working group to define APIs

• Considerations
• Who should participate?
• Process to reach agreement on APIs
• Core implementation academic pursuit?
• Compiler-like interface an industry pursuit?
• Funding?
• Ideas
• Integrate working group with tool conference
• Maintain a portal
• Tool submission is refereed, provides a source of
  prestige and promotes use

48
Enforcement or Voluntary Adoption?

• Considerations
• Analysis requirements imposed by regulatory
  agencies (FAA, FDA,.....)?
• Government intervention could put too many
  restrictions on research activity
• Economic concerns drive non-safety-critical
  applications
• Usability
• Product liability?

49
Other topics

• Component/API based integration realistic?
• One intermediate language for C/C/Java?
• Collaboration vs competition
