Timestamped GraphsEvolutionary Models of Text
for Multi-document Summarization

• Ziheng Lin and Min-Yen Kan
• Department of Computer ScienceNational
  University of Singapore, Singapore

2
Summarization

• Traditionally, heuristics for extractive
  summarization
• Cue/stigma phrases
• Sentence position (relative to document,
  section, paragraph)
• Sentence length
• TFIDF, TF scores
• Similarity (with title, context, query)
• With the advent of machine learning, heuristic
  weights for different features are tuned by
  supervised learning
• In last few years, graphical representations of
  text have shed new light on the summarization
  problem

3
Prestige as sentence selection

• One motivation of using graphical methods was to
  model the problem as finding prestige of nodes in
  a social network
• PageRank used random walk to smooth the effect
  of non-local context
• HITS and SALSA to model hubs and authorities
• In summarization, lead to TextRank and LexRank
• Contrast with previous graphical approaches
  (Salton et al. 1994)
• Did we leave anything out of our representation
  for summarization?
• Yes, the notion of an evolving network

4
Social networks change!

• Natural evolving networks (Dorogovtsev and
  Mendes, 2001)
• Citation networks New papers can cite old ones,
  but the old network is static
• The Web new pages are added with an old page
  connecting it to the web graph, old pages may
  update links

5
Evolutionary models for summarization

• Writers and readers often follow conventional
  rhetorical styles - articles are not written or
  read in an arbitrary way
• Consider the evolution of texts using a very
  simplistic model
• Writers write from the first sentence onwards in
  a text
• Readers read from the first sentence onwards of
  a text
• A simple model sentences get added
  incrementally to the graph

6
Timestamped Graph Construction

• Approach
• These assumptions suggest us to iteratively add
  sentences into the graph in chronological order.
• At each iteration, consider which edges to add
  to the graph.
• For single document simple and straightforward
  add 1st sentence, followed by the 2nd, and so
  forth, until the last sentence is added
• For multi-document treat it as multiple
  instances of single documents, which evolve in
  parallel i.e., add 1st sentences of all
  documents, followed by all 2nd sentences, and so
  forth
• Doesnt really model chronological ordering
  between articles, fix later

7
Timestamped Graph Construction

• Model
• Documents as columns
• di document i
• Sentences as rows
• sj jth sentence of document

8
Timestamped Graph Construction

• A multi document example

doc3
doc2
doc1
sent1
sent2
sent3
9

• An example TSG DUC 2007 D0703A-A

10
Timestamped Graph Construction

• These are just one instance of TSGs
• Lets generalize and formalize them
• Def A timestamped graph algorithm tsg(M) is a
  9-tuple (d, e, u, f,s, t, i, s, t) that
  specifies a resulting algorithm that takes as
  input the set of texts M and outputs a graph G

Input text transformation function
Properties of nodes
Properties of edges
11
Edge properties (d, e, u, f)

• Edge Direction (d)
• Forward, backward, or undirected
• Edge Number (e)
• number of edges to instantiate per timestep
• Edge Weight (u)
• weighted or unweighted edges
• Inter-document factor (f)
• penalty factor for links between documents in
  multi-document sets.

12
Node properties (s, t, i, s)

• Vertex selection function s(u, G)
• One strategy among those nodes not yet
  connected to u in G, choose the one with highest
  similarity according to u
• Similarity functions Jaccard, cosine, concept
  links (Ye et al.. 2005)
• Text unit type (t)
• Most extractive algorithms use sentences as
  elementary units
• Node increment factor (i)
• How many nodes get added at each timestep
• Skew degree (s)
• Models how nodes in multi-document graphs are
  added
• Skew degree how many iterations to wait before
  adding the 1st sentence of the next document
• Lets illustrate this

13
Skew Degree Examples

• time(d1) lt time(d2) lt time(d3) lt time(d4)

d1 d2 d3 d4
d1 d2 d3 d4
Freely skewed Only add a new document when it
would be linked by some node using vertex
function s
Skewed by 1
Skewed by 2
14
Input text transformation function (t)

• Document Segmentation Function (t)
• Problem observed in some clusters where some
  documents in a multi-document cluster are very
  long
• Takes many timestamps to introduce all of the
  sentences, causing too many edges to be drawn
• ?(G) segments long documents into several sub
  docs
• Solution is too hacked hope to investigate
  more in current and future work

d5b
d5a
d5
15
Timestamped Graph Construction

• Representations
• We can model a number of different algorithms
  using this 9-tuple formalism
• (d, e, u, f, s, t, i, s, t)
• The given toy example
• (f, 1, 0, 1, max-cosine-based, sentence, 1, 0,
  null)
• LexRank graphs
• (u, N, 1, 1, cosine-based, sentence, Lmax, 0,
  null)
• N total number of sentences in the cluster
  Lmax the max document length
• i.e., all sentences are added into the graph in
  one timestep, each connected to all others, and
  cosine scores are given to edge weights

16
TSG-based summarization

• Methodology
• Evaluation
• Analysis

17
System Overview

• Sentence splitting
• Detect and mark sentence boundaries
• Annotate each sentence with the doc ID and the
  sentence number
• E.g., XIE19980304.0061 4 March 1998 from Xinhua
  News XIE19980304.0061-14 the 14th sentence of
  this document
• Graph construction
• Construct TSG in this phase

18
System Overview

• Sentence Ranking
• Apply topic-sensitive random walk on the graph
  to redistribute the weights of the nodes
• Sentence extraction
• Extract the top-ranked sentences
• Two different modified MMR re-rankers are used,
  depending on whether it is main or update task

19
Evaluation

• Dataset DUC 2005, 2006 and 2007.
• Evaluation tool ROUGE n-gram based automatic
  evaluation
• Each dataset contains 50 or 45 clusters, each
  cluster contains a query and 25 documents
• Evaluate on some parameters
• Do different e values affect the summarization
  process?
• How do topic-sensitivity and edge weighting
  perform in running PageRank?
• How does skewing the graph affect the information
  flow in the graph?

20
Evaluation on number of edges (e)

• Tried different e values
• Optimal performance e 2
• At e 1, graph is too loosely connected, not
  suitable for PageRank ? very low performance
• At e N, a LexRank system

e 2
e 2
N
N
N
21
Evaluation (other edge parameters)

• PageRank generic vs topic-sensitive
• Edge weight (u) unweighted vs weighted
• Optimal performance topic-sensitive PageRank
  and weighted edges

Topic-sensitive Weighted edges ROUGE-1 ROUGE-2
No No 0.39358 0.07690
Yes No 0.39443 0.07838
No Yes 0.39823 0.08072
Yes Yes 0.39845 0.08282
22
Evaluation on skew degree (s)

• Different skew degrees s 0, 1 and 2
• Optimal performance s 1
• s 2 introduces a delay interval that is too
  large
• Need to try freely skewed graphs

Skew degree ROUGE-1 ROUGE-2
0 0.36982 0.07580
1 0.37268 0.07682
2 0.36998 0.07489
23
Holistic Evaluation in DUC

• We participated in DUC 2007 with an
  extractive-based TSG system
• Main task 12th for ROUGE-2, 10th for ROUGE-SU4
  among 32 systems
• Update task 3rd for ROUGE-2, 4th for ROUGE-SU4
  among 24 systems
• Used a modified version of maximal marginal
  relevance to penalize links in previously read
  articles
• Extension of inter-document factor (f)
• TSG formalism better tailored to deal with
  update / incremental text tasks
• New method that may be competitive with current
  approaches
• Other top scoring systems may do sentence
  compression, not just extraction

24
Conclusion

• Proposed a timestamped graph model for text
  understanding and summarization
• Adds sentences one at a time
• Parameterized model with nine variables
• Canonicalizes representation for several graph
  based summarization algorithms
• Future Work
• Freely skewed model
• Empirical and theoretical properties of TSGs
  (e.g., in-degree distribution)

25
Backup Slides

• 25 Minute talk total
• 26 Apr 2007, 1150-1215

26
Differences for main and update task processing

• Main task
• Construct a TSG for input cluster
• Run topic-sensitive PageRank on the TSG
• Apply first modified version of MMR to extract
  sentences

• Update task
• Cluster A
• Construct a TSG for cluster A
• Run topic-sensitive PageRank on the TSG
• Apply the second modified version of MMR to
  extract sentences
• Cluster B
• Construct a TSG for clusters A and B
• Run topic-sensitive PageRank on the TSG only
  retain sentences from B
• Apply the second modified version of MMR to
  extract sentences
• Cluster C
• Construct a TSG for clusters A, B and C
• Run topic-sensitive PageRank on the TSG only
  retain sentences from C
• Apply the second modified version of MMR to
  extract sentences

27
Sentence Ranking

• Once a timestamped graph is built, we want to
  compute an prestige score for each node
• PageRank use an iterative method that allows
  the weights of the nodes to redistribute until
  stability is reached
• Similarities as edges ? weighted edges query ?
  topic-sensitive

Topic sensitive (Q) portion
Standard random walk term
28
Sentence Extraction Main task

• Original MMR integrates a penalty of the
  maximal similarity of the candidate document and
  one selected document
• Ye et al. (2005) introduced a modified MMR
  integrates a penalty of the total similarity of
  the candidate sentence and all selected sentences
• Score(s) PageRank score of s S selected
  sentences
• This is used in the main task

Penalty All previous sentence similarity
29
Sentence Extraction Update task

• Update task assumes readers already read previous
  cluster(s)
• implies we should not select sentences that have
  redundant information with previous cluster(s)
• Propose a modified MMR for the update task
• consider the total similarity of the candidate
  sentence with all selected sentences and
  sentences in previously-read cluster(s)
• P contains some top-ranked sentences in previous
  cluster(s)

Previous cluster overlap
30
References

• Günes Erkan and Dragomir R. Radev. 2004.
  LexRank Graph-based centrality as salience in
  text summari-zation. Journal of Artificial
  Intelligence Research, (22).
• Rada Mihalcea and Paul Tarau. 2004. TextRank
  Bring-ing order into texts. In Proceedings of
  EMNLP 2004.
• S.N. Dorogovtsev and J.F.F. Mendes. 2001.
  Evolution of networks. Submitted to Advances in
  Physics on 6th March 2001.
• Sergey Brin and Lawrence Page. 1998. The anatomy
  of a large-scale hypertextual Web search engine.
  Com-puter Networks and ISDN Systems, 30(1-7).
• Jon M. Kleinberg. 1999. Authoritative sources in
  a hy-perlinked environment. In Proceedings of
  ACM-SIAM Symposium on Discrete Algorithms, 1999.
• Shiren Ye, Long Qiu, Tat-Seng Chua, and Min-Yen
  Kan. 2005. NUS at DUC 2005 Understanding
  docu-ments via concepts links. In Proceedings of
  DUC 2005.
