Feature Similarity

1
Feature Similarity

• 02/11/2002
• Hyung Wook Park

2
The table of contents

• Introduction

• From Images to Similarity

• From Features to Similarity

• Similarity Between Two Sets of Points

3
Introduction

• In the field of image retrieval
• - needed achieving a compact representation
  of

image content using concise but effective feature

• Their effectiveness depends on the fact that
• the notion of similarity between two images
  is subjective

• Pre-attentive search techniques emphasize the
  need

of descriptions of images and similarity measures
or
metrics to compare these description
4
From Images to Similarity
5
Pre-attentive vs. Attentive Similarities

• Pre-attentive similarity

Determines the similarity of the stimuli without
attempting their interpretation

• Attentive similarity

Determines the similarity between two stimuli
after they have been interpreted and classified
6
Pre-attentive vs. Attentive Similarities
It looks like quite similar
7
Pre-attentive vs. Attentive Similarities
The difference between the two should be striking
now
8
Pre-attentive vs. Attentive Similarities

• Let Q the query proposed by user U
• I an image of the database

Using Bayes theorem
P(I,Q,U) P(IQ,U)P(Q,U) P(IQ,U)P(QU)P(U)
P(I,Q,U) P(QI,U)P(I,U) P(QI,U)P(IU)P(U)
We can lead this equation
P(IQ,U) P(QI,U)P(I,U) / P(QU)
? We have to maximize P(QI,U)P(I,U)
9
Pre-attentive vs. Attentive Similarities

• P(QI,U)

Induces attentive mechanism assuming that
stimuli to be compared have previously been
interpreted

• P(I,U)

The constraints the user puts on the DB, and is
related to the concepts the user will try to
summarize by its request
10
Pre-attentive vs. Attentive Similarities

• A classic approach

- Is able to extract features from the image of
the DB, and summarize these features in a
reduced set of index
- Then, the retrieval process consist in
extracting features from this image,
projecting them onto the indexes space and
looking for the nearest neighbors based on a
some particular distance
11
Pre-attentive vs. Attentive Similarities

• Global architecture of proposed system

Color
Color
Texture
Texture
Shape
Shape
Other
Other
Results
Feedback
.
.
.
12
Distance vs. Similarity

• Given a feature and its representation
  associated with
• each image, we need a metric to compare an
  image I of
• the database and the query Q

• A distance(d) is defined as follows

d A x A ? ?
A the set of images
? the set of positive real numbers
13
Distance vs. Similarity

• The geometry model

- d must satisfy the following properties for
all the images I, J and K in A
P1 d(I, I) d(J, J)
self-similarity
P2 d(I, J) ? d(I, I)
minimality
symmetry
P3 d(I, J) d(J, I)
P4 d(I, K) d(K, J) ? d(I, J)
triangular inequality
14
Distance vs. Similarity

• Tversky(1977) refuted the geometry model

- the properties P1 to P3 are not validated
by human
perception
- Symmetry We are searching a DB using
particular query Q so we can not assume
the symmetry as obvious
- For example (triangle inequality)
15
Distance vs. Similarity

• Tversky proposed non-metric model, Contrast model

- An image is characterized as a set of binary
features
S(A,B) ? f(A n B) - a f(A-B) - ß f(B-A)

• However, it is not applied texture or color
  comparison
• except shape comparison

16
From Features to Similarity
17
From Features to Similarity

• The similarity measurements are based on
  comparison
• between images features which thus have to be
• previously extracted

- Gray levels
- Color with histograms or moments
- Texture with the coefficients in the Fourier
- Shape for special geometric feature
- Structure
18
Complete vs. Partial Feature

• One can take the overall distribution of a given
  feature
• in the input image or video as an index

• Carson et al. proposed to first segment the
• as a set of regions

http//dlp.cs.berkeley.edu/photos/blobworld/
- This approach is complex because it
requires segmentation step
19
Complete vs. Partial Feature

• Based on key points

- Two signals are similar if they have particular
feature values spatially located in a
consistent order
Interest points or key points
http//rfv.insa-lyon.fr/jolion/Cours/ptint.html
20
Global vs. Local Feature

• Global feature value

- Take into account all the pixels in the image
? It is very difficult to summarize to deal with

• Local feature value

- A value is computed based on a subset of the
Complete Partial
Local Histogram of N x N values Histogram of k x k values
Global Mean of N x N values Mean of k x k values
21
Global vs. Individual Comparison of Features

• There are many different nature of features

• It makes it difficult to build a global distance
  or similarity

measure because the indexes have been computed
may induce different behavior

• The overall similarity is based on a combination
  of

individual similarities

• User have to give some weights for the overall
  similarity

computation in some classic systems ? but, user
cant

• The system have to interaction with user to
  approach the answer

22
Similarity Between Two Sets of Points
23
Multidimensional Voting

• Voting algorithm(Schmid and Mohr)

- Each vector I, of the query image is compared
to all vectors J in the DB, which are linked
to their images M
- If the distance between I, J is below a
threshold t, then the respective image M gets
a vote
- The images having maximum votes are returned to
the user

• The problem is the threshold strategy is
  sensitive to the choice of threshold t

24
Multidimensional Voting

• Change the voting algorithm (Wolf)

- The means to qualify two points as being a pair
is the minimum distance in feature space
- To do this, they build a matrix which stores
the distance of all possible feature pairs,
the row i denoting the key points of the
query image, the column j the key points of
the compared image

• Then, we search the minimum element of the matrix

25
Multidimensional Voting

• This figure shows two examples images and their
  maps
• of interest points superimposed in a single

• Corresponding interest points are connected with
  a straight line

26
Graph-Based Matching

• The information which is a set of points, and
  each

associated with a feature can be abstracted as an
attributed
relational graph
- The vertices of which are the points
- The vertices attributes are the vector values
- The edges can be established by computing the
n-nearest
neighbor graph
? This method is used for image retrieval based
on line patterns
