Internet2 an Overview

• Heather Boyles
• Director, International Relations
• heather_at_internet2.edu
• Ana Preston
• Program Manager, International Relations
• Apreston_at_internet2.edu

3
Outline

• Background why and who?
• Focus areas and activities what?
• International partnerships how?
• Your questions..

4
Success of the Internet
Millions of People
SourceNua Internet Surveys
5
History

• ARPAnet origins
• 1987 -- NSFnet
• Privatization in 1995
• 1996
• Telecomm Act
• The WWW explodes
• Federal Next Generation Internet Initiative
• NSF provides grant funding to universities for
  network infrastructure
• Internet2 founded
• 1999
• Abilene in production

6
Todays Internet Doesnt

• Provide reliable end-to-end performance
• Encourage cooperation on new capabilities
• Allow testing of new technologies
• Support development of revolutionary
  applications

7
Internet2 Mission and Goals

• Develop and deploy advanced network applications
  and technologies, accelerating the creation of
  tomorrows Internet.
• Enable new generation of applications
• Create leading edge RE network capability
• Transfer technology and experience to the global
  production Internet

8
Internet Development Spiral
Commercialization
Privatization
Todays Internet
Internet2
Research and
Development
Partnerships
Source Ivan Moura Campos
9
Internet2 Universities190 Universities as of
January 2002
10
Internet2 Corporate Partners
11
Additional Membership

• Over 70 Internet2 Corporate Members
• Over 40 Affiliate Members
• Government Research Agencies
• National Institutes of Health
• National Science Foundation
• NASA
• NOAA
• USGS (Earth Resources Observations Systems)

12
Organization

• Member Liaisons
• Executive
• Engineering
• Applications
• Middleware
• UCAID not-for-profit corporation
• Staff of 80
• Large number leased from universities
• Facilitate, coordinate, provide collective
  infrastructure where required

13
Leadership

• University presidents/chancellors are the voting
  representatives
• Strong board
• Advisory councils with board seats
• Applications Strategy
• Network Planning and Policy
• Network Research Liaison
• Industry Liaison Council

14
Why University Leadership?

• The Internet came from the academic community
• Stanford -- the Internet protocols
• NSFNet -- the scaled-up Internet
• CERN -- the WWW protocols
• University of Illinois -- the Web browser
• Universities research and education mission
  require an advanced Internet and have
  demonstrated they can develop it

15
Internet2 Partnerships

• Internet2 universities are recreating the
  partnerships that fostered the Internet in its
  infancy
• Industry
• Government
• International

16
Internet2/U.S. Government Separate but
Interdependent

• U.S. Next Generation Internet
• Led by U.S. government agencies
• Focused on agency needs
• Internet2
• Led by higher education
• Focused on research and education needs
• Interdependent
• Government agency funding to research,
  connections, applications development
• Science and engineering funded projects
  increasingly dependent on persistent,
  high-performance infrastructure provided by
  Internet2

17
Internet2 Goals

• Enable new generation of applications
• Re-create leading edge RE network capability
• Transfer technology and experience to the global
  production Internet

18
Internet2 Focus Areas

• Advanced Applications
• Middleware
• Engineering
• Advanced Network Infrastructure
• Partnerships

19
How Internet2 works

• Universities commit
• Engineering lead connect university to rest of
  Internet2 community, deploy new technologies
• Applications lead support apps development on
  campus
• Middleware architect work with I2MI to implement
  middleware infrastructure
• Working groups
• Of expert/interested individuals within community
• Chaired by volunteer (sometimes by staff)
• Staff support

20
How Internet2 works, contd

• Projects, e.g. Abilene
• Executive team and Project team
• Qwest, Cicso, Nortel
• Indiana University supplies NOC
• Projects, e.g. Shibboleth
• IBM providing coding
• Designed by MACE (volunteers from community)
• Supported by Staff
• Internet2 Staff
• Primarily facilitate, coordinate, flywheel
• 80

21
Internet2 Focus Areas

• Advanced Applications
• Middleware
• Engineering
• Advanced Network Infrastructure
• Partnerships

22
Different Disciplines/Contexts

• Sciences
• Arts
• Humanities
• Health care
• Business/Law
• Administration

• Library
• Classroom
• Clinic
• Office
• Laboratory
• Dorm room

23
Application Attributes

• Interactive collaboration
• Real-time access to remote resources

24
Remote Scanning Electron Microscope

• The University of Michigan

25
Philips XL30
26
(No Transcript)
27
Real-Time Tele-Operation of Remote
EquipmentNorth Carolina State
Universityhttp//CARL.ce.ncsu.edu/
28
Tele-vator

• Excavation backhoe operated remotely over
  Internet2
• Used in hazardous rescue situations
• Sophisticated two-way feedback using stereovision

29
Space Physics and Aeronomy Research Collaboratory

• University of Michigan

30
(No Transcript)
31
(No Transcript)
32
Attributes, cont.

• Large-scale, multi-site computation and data
  mining
• Shared virtual reality
• Any combination of the above

33
Grid Projects
34
What is the Grid?

• Global resources available to communities of
  researchers
• The protocols, services, and applications that
  enable new forms of collaboration

35
Grid Resources
Instruments
Libraries
Workstations
People
Data sets
36
Examples

• Network for Earthquake Engineering Simulation
• Collaboration environment for earthquake
  researchers (e.g., structural engineers,
  geotechnical and tsunami scientists)

• Grid Physics Network
• Petabyte scale environment for data-intensive
  applications (Large Hadron Collider, Sloan
  Digital Sky Survey, Laser Interferometer
  Gravitational Wave Observatory)

37
Grid Projects

• NEESGrid
• www.neesgrid.org
• GriPhyN
• www.griphyn.org
• S/W infrastructure
• www.gridforum.org
• Research Sensornets
• Networked nanotechnology

38
High Fidelity Digital Video/Audio
Teaching Music
University of Oklahoma
39
Video Futures

• Tele-immersive Office of the Future

Source University of North Carolina
40
The Internet2 Commons

• An effort to encourage and support large-scale,
  distributed collaboration for the research and
  education community
• Enabling one-to-one, one-to-group, and
  group-to-group collaboration
• Supporting personal communications, meetings,
  conferences, and teaching and learning
• For Internet2 members and their international
  counterparts

41
Data Sharing
Instant Messaging
Voice/IP
Electronic Notebooks
Peer to Peer
Collaboratories
Others
H.323
VRVS
Videoconferencing Technologies
AG
MPEG2
Others
42
Internet2 Commons Work

• Initial focus on H.323
• Set of MCU equipment available to members
• Training and certifying Commons Coordinators on
  campus
• Working with VIDE on numbering/directory schema
• Next move
• Additional collaborative technologies (e.g. T.120)

43
Internet2 Focus Areas

• Advanced Applications
• Middleware
• Engineering
• Advanced Network Infrastructure
• Partnerships

44
Middleware

Applications
Authentication, Identification, Authorization,
Directories, Security
Advanced Network Services (Distributed Network
Middleware)
Advanced Physical Network Infrastructure
45
Middleware
46
Internet2 Middleware Initiative

• Focus on core middleware as infrastructure
• Interoperability
• 190 universities will never buy the same software
• Getting stuff implemented
• Best practices
• Integrate across applications
• Discourage islands of middleware infrastructure
• E.g. core middleware just for this particular
  grid project
• Enable community to share resources
• Grid, remote instruments, shared classes

47
I2MI core middleware activities

• Identifiers
• Early Adopters - survey/docs about how campuses
  are assigning and relating identifiers
• Authentication
• WebISO (Web Initial Sign-on) share expertise,
  code
• Directories
• DoDHE Dir. of Directories for HE
  inter-institutional directory searching, using
  eduPerson and LDAP Recipe
• eduPerson an LDAP object class that includes
  widely-used person attributes in higher education
• LDAP Recipe promote common design
• Authorization
• Certificates and PKI
• Internet2 PKI Labs

48
Internet2 Focus Areas

• Advanced Applications
• Middleware
• Engineering
• Advanced Network Infrastructure
• Partnerships

49
Engineering

• Scalable IP Multicast
• http//www.internet2.edu/multicast/
• IPv6
• Quality of Service
• End to end at IP layer
• Network Security
• Measurement
• End to End Performance

50
Native Multicast
51
Native Multicast
52
Internet2 Focus Areas

• Advanced Applications
• Middleware
• Engineering
• Advanced Network Infrastructure
• Partnerships

53
Internet2 Network Infrastructure

• Backbones operate at 2.4 Gbps (OC48) capacity
  today, upgrade to 10Gbps in progress
• GigaPoPs provide regional high-performance
  aggregation points
• Local campus networks provide 100 Mbps to the
  desktop

54
Download of The Matrix DVD(Comparison of the
Internet2 Land Speed Record)
55
Network Architecture
56
Typical Internet2 University Network Connection
University Campus
University Campus
155 Mbps 2.4 Gbps
Department
155 Mbps 2.4 Gbps
100 Mbps
Regional Network622 Mbps-2.4 Gbps
Lab or Classroom
155 Mbps 2.4 Gbps
University Campus
57
Internet2 GigaPoPs28 as of October 2001
58
Internet2 Backbone Networks

• vBNS NSF project in cooperative agreement with
  MCI (now Worldcom)
• Funding ended April 2001
• Program extended to April 2003, but no NSF
  funding
• Abilene UCAID project with support of Qwest,
  Cisco, Nortel, Indiana University
• Renewed Qwest support through 2006
• Future backbones?
• Discussions with various national fiber providers

59
Internet2 Backbone Networks
Donna Cox,Robert Patterson, NCSA
60
Abilene NetworkCore Map, October 2001
61
Abilene Network Logical Map
62
Internet2 Focus Areas

• Advanced Applications
• Middleware
• Engineering
• Advanced Network Infrastructure
• Partnerships

63
Internet2 International Goals

• Ensure global interoperability
• of the next generation of Internet technologies
  and applications
• Enable global collaboration
• in research and education providing/promoting the
  development of an advanced networking environment
  internationally

64
International Partners

• Build effective partnerships in other countries
• With organizations of similar goals/objectives
  and similar constituencies
• Mechanism Memoranda of Understanding

65
MoU in brief

• Provide/promote interconnectivity between
  communities
• Collaborate on technology development and
  deployment
• Facilitate collaboration between members on
  applications
• Encourage technology transfer

66
Internet2 International Partnership

• International Task Force
• Representatives of Internet2 International
  Partners
• Meets twice per year at Internet2 Member Meetings
• Cross-participation in working groups, mailing
  lists, projects

67
International MoU Partners
68
Abilene International Peering
09 January 2002
STAR TAP/Star Light APAN/TransPAC, Canet3, CERN,
CERnet, FASTnet, GEMnet, IUCC, KOREN/KREONET2,
NORDUnet, RNP2, SURFnet, SingAREN, TAnet2
Pacific Wave AARNET, APAN/TransPAC, CAnet3,
TANET2
NYCM BELNET, CAnet3, GEANT, HEANET, JANET,
NORDUnet
SNVA GEMNET, SINET, SingAREN, WIDE
LOSA UNINET
OC3-OC12
AMPATH ANSP, REUNA, RNP2 RETINA
San Diego (CALREN2) CUDI
El Paso (UACJ-UT El Paso) CUDI
ARNES, CARNET, CESnet, DFN, GRNET, RENATER,
RESTENA, SWITCH, HUNGARNET, GARR-B, POL-34, RCCN,
RedIRIS
69
Abilene ITN service

• Transit to vBNS and non-US peers of Abilene
• Example
• Peer with Abilene
• Send/receive traffic to all Abilene participants,
  plus
• vBNS participants
• All non-US network peers of Abilene (over 25)

70
Americas

• Canada, U.S. and Mexico connected at multiple
  points
• Connections via Miami to Argentina, Brazil, Chile
• Building infrastructure between research and
  education communities

71
Americas Connectivity(March 2002)
Country Network BW(mbps) Interconnect
Canada CAnet3 1310 S.T., Pacific Wave, NYC
Mexico RED-CUDI 255 Tijuana-San Diego (CALREN2), Juarez/El Paso
Chile REUNA 45 AmPATH
Brazil RNP2 45 AmPATH
Brazil ANSP 45 AmPATH
Argentina RETINA2 45 AmPATH
Puerto Rico To Abilene-U.S. Via South Florida GigaPoP
72
CAnethttp//www.canarie.ca

• Currently building CAnet4 network
• Wavelength-based
• Connects provincial networks

Source Bill St. Arnaud, CANARIE
73
Mexicohttp//www.cudi.edu.mx

• Connecting 30 members in Mexico at 155mbps
• Connecting to U.S.
• via Tijuana San Diego (with transit from
  CALREN2 to Abilene) at 155mbps
• 100mbps between Ciudad Juarez and El Paso
• Convenios internacionales with CANARIE,
  Internet2/UCAID, CENIC and REUNA

74
AmPATHhttp//ampath.fiu.edu

• Florida International University with Global
  Crossing as primary partner
• Global Crossing provides potential to connect 10
  countries at 45mbps each
• Service area includes Argentina, Brazil, Chile,
  Colombia, Costa Rica, Mexico, Panama, Peru, US
  Virgin Islands, Venezuela
• An Internet2 international interconnection point
• Facilitates peering with Abilene, other research
  and education networks
• Open to connections from other carriers
• NAP of the Americas, downtown Miami

75
Chilehttp//www.reuna.cl

• Red Universitaria Nacional REUNA
• 10 POPs from Arica to Valdivia
• 155 Mbps ATM/SDH Network
• Centrally operated from Santiago
• REUNA3 Gigabit Backbone Project

Geographical Distribution of REUNA2 POPs
76
Brazilhttp//www.rnp.br

• Rede Nacional de Ensino e Pesquisa - RNP
• Connecting 27 Brazilian states at 155 Mbps.
• RNP2 AmPATH via DS-3

77
Argentinahttp//www.retina.ar

• Red Teleinformática Académica
• Red RETINA
• Connecting 25 institutions
• Retina2 via AMPATH

78
Costa Ricahttp//www.crnet.cr

• National Research Network - CRNet

• Internet2 connectivity possibly through Los
  Arcos

79
More Internet2 Information

• On the Web
• www.internet2.edu
• Email
• apreston_at_internet2.edu
• heather_at_internet2.edu

80
www.internet2.edu
