1(No Transcript)
2Agenda Sales Training
- Available training opportunities
- Product Target markets applications, features,
performance, benefits - Pricing
- Positioning Internal and competitive
- Promotion Sales tools, events, demand generation
- Appendix Slides
- Q A
3Additional Training
- Intermec University on-line technical training
module - Important technical content to supplement this
training - Available now (P2 training), expanded full
feature content - June 8 - Instructor-led Training to Train-the-Trainer
- Cedar Rapids, June 3 5
- Twenty SEs from around the globe
- New trainers will share content in respective
regions - Regional Events targeting Partners, Distributors,
and Customers - EMEA June 2 26 (13 sessions)
- North America Customer facing Tech days in 20
cities, and internal Hands-On sales training in 5
locations. Dates throughout June. - Technical Tools New!
- Technical notes on specific technology features
of CN50
4CN50 Handheld Mobile Computer
- Feature Rich and High Performance
- Small, Light Weight and Rugged Design
- Optimized for Mobile Applications
- Complements CN4 in Extending Intermec Reach
5The CN50 Value Proposition
- The CN50 gives Mobile Workers, Business Managers,
and IT Managers in Applications within Field
Service, Postal/Courier, Transportation,
Commercial Delivery, Public Safety, and Home
Healthcare the ability to - Hold and carry the industrys most advanced
highest-performance 3.5G mobile computing device
in a small, light weight, and rugged form factor
- reducing operator fatigue and increasing user
acceptance - with the longest battery life and
highest-speed voice/data capabilities available. - Deploy a single hardware solution on the wireless
network that offers the lowest cost and best
geographic coverage, and to re-provision the
radio to a different carrier network as business
needs or coverage options evolve - simplifying
application development and verification
complexity, lowering deployment costs, and
dramatically lowering overall cost-of-ownership. - Complete more tasks faster on a single,
high-performance multifunctional device
eliminating the need to purchase, manage, and
maintain different devices while increasing
worker productivity and efficiency, reducing
operational costs, and improving service quality,
accuracy, responsiveness. - Expand service offerings through leverage of more
data-intensive enterprise applications -
including implementation of always-on vehicle or
pedestrian-based services with real-time
location, directional movement, or navigation
information and applications requiring secure
data transfer of detailed technical diagrams,
documents, and electronic payment information or
large file attachments such as, higher-resolution
images for proof-of-condition and geo-stamping
for proof-of-location.
6The CN50 Customer
- Mobile workers that are highly mobile, where
activity is dominated by hold and carry and
direct customer interaction - Desire a light weight, streamlined, yet highly
capable solution - Business managers that want to improve and expand
their service offering to increase profitability - Need tools to increase mobile worker
productivity, efficiency and capability - IT managers that need to control costs and
maintain flexibility in their mobile IT solutions
- Need IT solutions that enables them to grow and
adjust as business conditions change - Need tools that integrate easily with existing
systems and reduce time to deploy and maintain
7How CN50 Meets the Needs of Your Customers
- Compact, light weight
- Rugged
- Powerful navigation tools. WWAN radio provides
real-time, always connected, voice and data. - Intuitive and easy to use is combined with high
speed computing and communications - Converged data capture, navigation, communication
and computing - Industry standard and industry leading tools for
development, deployment, and management of your
mobile business solutions
- On the go all day
- Wet, dirty, rough environments
- Strive for on-time service delivery
- Improve productivity and efficiency
- Streamline the tools needed to get the job done
- Strive to increase service levels while reducing
cost to operate the mobile solution
8CN50 Product Description and Attributes
Smallest size, lightest weight, rugged WWAN
mobile computer from Intermec
Flexible Network 3.5G radio UMTS or CDMA
802.11b/g WLAN Bluetooth Integrated GPS
Intermec 2D Area Imager 3 MP Autofocus Color
Camera
Enhanced Mobile Document Imaging
Digital Compass and Accelerometer
All new Multi-Processor Architecture Windows
Mobile 6.1
Numeric or QWERTY Keypad Options
128 MB RAM 512 MB Flash up to 32 GB microSD
Expansion
Standard Extended Battery Packs
9CN50 Physical Specifications
- 25 Smaller and lighter than other full-featured
devices - Size 15.2 mm x 7.5 mm x 2.5 mm (6 in x 3 in x 1
in) - Weight 310 340 gm (10-11 oz)
- More rugged and improved industrial design
compared with other light weights - 1.5 m (5 ft) drop, 26 times per MIL-STD 810F
- IP54 Dust Water Sealing
- -10 to 50C (14 - 122 F) Operating Temp
- No external antenna
- Designed for usability and all day comfort
- Tethered Stylus
- Hand strap, Soft Grip Area
- Scan Button Ridge
Standard
Extended
For hold and carry applications, the small size
and light weight of the CN50 increases user
acceptance, reduces fatigue, and eliminates the
burden of carrying a bulky and heavy mobile
computer. The Rugged design increases reliability
over commercial grade SmartPhones or lower grade
mobile computers
10High Speed WWAN Radio
EDGE HSDPA HSUPA HSDPA (CN50) CDMA 1x-EVDO Rev 0 CDMA 1x-EVDO Rev A (CN50)
Frequency Bands 800, 900, 1800, 1900 800, 900, 1800, 1900, 2100 800, 900, 1700, 1800, 1900, 2100 824-894 1850-1990 824-894 1850-1990
Max DL Speed 236 Kbps 3.6 Mbps 7.2 Mbps 2.4 Mbps 3.1 Mbps
Max UL Speed 118 Kbps 384 Kbps 2.0 Mbps 153.6 kbps 1.8 Mbps
- Compared to EDGE and HSDPA, the CN50 can
- Download up to 30x faster than EDGE and 2x
faster than HSDPA - Upload up to 16x faster than EDGE and 5x faster
than HSDPA - Compared to CDMA Rev 0, the CN50 can
- Download up to 30 faster
- Upload up to 10x faster
- Faster data transfers increase productivity,
improve customer service, and enable new services
that arent practical at slower speeds. High
speed uplink enables applications such as
document imaging to transfer files faster. By
supporting 1700 MHz, the CN50 is the only rugged
mobile computer to work on the two leading UMTS
networks in the US (T-Mobile and ATT)
11WWAN Flexible Network Radio
- A single hardware platform that can be
re-programmed for any CDMA or UMTS network in
North America - Support only a single hardware platform but
deploy on the best available network - Economically re-provision devices if they need to
change network providers - Negotiate with data carrier without feeling
locked in by their mobile hardware
The CN50 with Flexible Network Radio allows IT
departments to manage their WAN enabled mobile
solutions with simplicity, flexibility and cost
saving that has never been previously available.
12High Quality Cell Phone
-
- Ergonomic design and full feature set allows the
CN50 integrated phone to easily replace your
existing cell phone - Well designed speaker and microphone provides
highest quality voice communications.
The high quality voice capabilities of the CN50
eliminates the need for dedicated cell phone,
reducing the tools needed by a mobile worker and
simplifying IT task to deploy and manage multiple
hardware devices.
13Imager and Color Camera
- CN50 comes standard with both an imager
- and color camera
- 1 Megapixel imager
- High Speed scanning for 1D and 2D barcodes
- Supports new Intermec Enhanced Mobile Document
Imaging - Dedicated DSP provides responsive barcode
performance - Industry leading 3.1 Megapixel Color camera
- Autofocus Flash
- Provides high quality image capture and easy
integration of picture data within the Line of
Business application
By combining both a camera and a scanner, theres
no need to carry a separate digital camera,
reducing the burden on the mobile worker. The
integrated camera streamlines the process of
getting image data integrated into the mobile
application. IT department has less tools to
deploy and maintain.
14Intermec Enhanced Mobile Document
ImagingOptional software application available
for CN50
- Features
- Capture full-page document images
- Point Capture user experience
- Image enhancement that cant be provided by
cameras - Compression, perspective correction, contrast
enhancement - Compatible with major document management
systems. - Supports common document indexing schemes (doc ,
PRO , invoice , date/time stamp, etc.) - Creates images in file size and native formats
that are accepted by document management
companies. - Works indoor, outdoor, and with cab lighting
conditions
With eMDI, the CN50 improves cash flow by
simplifying workflow and reducing the time
between delivery of shipments and invoicing the
customer. The easy point and capture operation
improves image quality by eliminating the
variability between users.
15Digital Compass and GPS
- Enhances the functionality of GPS
- Applications can display a map or instructions
based on the direction you are facing - Provides a real-time indication of direction and
does not require movement to determine which way
you are heading - Can be used with or without GPS software
- Combined with the integrated camera, this allow
the user to easily document time, location, and
directional heading of picture images - The digital compass of the CN50 improves
turn-by-turn directions to increase driver and
pedestrian efficiency by reducing the errors and
overcoming a key limitation of existing GPS
solutions . This improves worker productivity and
helps saves time and fuel.
16Accelerometer
- Built in Sensors allows the CN50 to monitor
direction and acceleration - Device always knows which way is up and sensors
provide complex data to monitor movement of the
device - This capability allows Smart applications such as
- Turn the device sideways, and the display on the
screen will rotate - Lay the unit face down and the backlight can dim
to save power - Install a background application that can monitor
mobile work movements and behavior - Orientation and motion sensors can simplify work
processes and improve user acceptance. By
monitoring device movements, business managers
can monitor worker activities and to eliminate
unnecessary motion and improve workflow
efficiency.
17WLAN, BT, and Integrated GPS
- WLAN
- WiFi certified 802.11 b/g, WPA, WPA2
- Microsoft Zero Config provides simple and secure
connection management - Bluetooth
- V2.0, Class 2, EDR
- Supports printers, scanners, BT Audio Devices
- Integrated 12 channel receiver
- Stand Alone or A-GPS
- Can use ephemeris data for faster TTFF
- Accuracy within 3 meters
With integrated WWAN, WiFi, Bluetooth, and GPS,
the CN50 provides flexible wireless options for
voice and data connectivity, allows the mobile
computer to be used with a variety of Bluetooth
peripherals, and integrates easily with 3rd party
navigation software. All this in a single device
lowers overall costs and simplifies deployment
and management of multiple devices.
18CN50 Simplify and Lower the Cost of the Mobile
IT Solution
- Develop
- Industry standard Windows Mobile 6.1 makes it
easy to develop and port existing mobile
applications. This save time and money - Intermec Developers Resource Kits allow
programmers to quickly port applications that
were developed for existing Intermec platforms - Deploy
- Scan to Connect Use simple and fast barcode
scanning to configure your CN50 and connect to
your enterprise wireless network - Easy Set Simple tool to configure scanner
settings - AutoDeploy / SmartSystems Fast and reliable,
this saves time and guarantees the installation
is done correctly. New Scan to Load uses a simple
barcode scan to automatically load and install
applications from your secure network. - Manage
- Compatible with most 3rd party remote device
management solutions, the CN50 can easily be
updated or completely reprogrammed with minimal
or no interaction from the mobile user - Windows Mobile Image Update and SmartSystems
allows manual or automatic software updates
without requiring proprietary device management
software
19Accessories
- Desktop AC charger w/USB
- Vehicle Holder
- Vehicle Power Adapter
- Quad Battery Charger
- Multi-Dock with or without Ethernet
- Belt Holster
- See back-up section for a complete list of part
numbers w/regional prices
20CN50 WAN Configurations and Availability
- 3G / 3.5G
- US List 2500 w/battery
- UMTS, PQA for EMEA / APAC July 31
- See back-up slides for country by country
- UMTS, PQA for ATT Sept 09
- CDMA, PQA for Verizon Oct 09
- CDMA, PQA for Sprint / Bell Mobility 2010
21CN Family The Big Picture
CN4 Designed to build on the success of CN3 and
to Continue Leadership with a 3G, fully rugged
mobile computer designed to reliably operate in
the most demanding end-user environments with a
complete set of optimized SW tools and HW
accessories. Easiest migration path for existing
CN3 applications. CN50 Rugged mobile computer
that is optimized for highly mobile workers
allows Intermec to Expand into new applications
where the CN4 would not be a good fit.
22Key Questions to Identify a CN50 Customer
- Are the mobile workers highly mobile, carrying
their computers for most of the day? - Do they need constant Wide Area voice and data
connectivity? - Are they using multiple separate devices today
and therefore looking to simplify and save cost
with a single full featured, multi-function
device? - Are they looking to improve productivity with the
fastest tools and best available technology? - Do they deploy mobile solution with multiple
different network service providers? - Do they use any navigation software and have a
desire to improve the efficiency and accuracy? - Do they value a next generation device that can
grow with their business needs? - Does their application have large data transfer
or would they like the ability to add this
service? - Are they doing any electronic document imaging
today?
23Comparing the CN Family
CN4
CN50
CN3
- Fully rugged
- 3G Radio technology
- Extended keypad option
- eMDI
- Full Set of peripherals
- Established Platform
- Choice of camera or imager
- Full software offering
- Fully rugged
- 2.5G Radio technology
- Extended keypad option
- Full Set of peripherals
- Established Platform
- Choice of camera or imager
- W-LAN only configurations
- Full software offering
- Rugged
- Small and Light Weight
- Latest 3.5G Radio
- Camera and Imager
- Compass
- Accelerometer
- eMDI
24The Right Product for the Application
Application Lead Product Why this product
Public safety CN3 or CN4/4e Current device in use. Rugged
Cross docking-sortation-Dist Center based apps CN3/3e or CN4/4e Fully rugged, scan handle, RFID handle, WLAN, CCX
TL Specialized / Private Fleet CN3 or CN4 Offers better support for Vehicle centric applications due to available accessories
EAM in-field (someone elses asset) Hospital, plant or outdoor environ CN3 or CN4 Fully rugged to withstand harsher environment only need scanner?
DSD-Sales and delivery CN3/3e or CN4/4e Accessories (DEX, vehicle docks, mag stripe reader), printers, WAN tool kit, fully rugged
Airline-Tarmac CN3/3e or CN4/4e Fully rugged, 3G to support more advanced PTT. No RFID
Merchandising and Pre-sales CN50 Small form factor, camera/scanner combo, professional look. Workers dont need many accessories
Postal Pedestrian CN50 Small form factor compatibility with portable printers (PB2, PB3)
Airline-Terminal (inside personnel) CN50 Small form factor, latest 3G because airline terminal WiFi isnt always reliable
LTL Supervisor CN50 Small form factor.
EAM in-field (someone elses asset) Home, corporate environ CN50 Combo scanner and camera environment doesnt require fully rugged smaller form factor
EAM in-field (own asset) ie meter reading CN50 Combo scanner/camera small form factor BT support for peripherals like automated readers
Home Healthcare CN50 Small form factor scanner to support barcode intensive environment
Emerging markets doing DSD deliveries CN50 WAN capability helps with spotty phone coverage small form factor supports scooter-based delivery
25The Right Product Based on Customer Needs
MC55 MC75 MC75
CN50 CN50 CN3 / CN4 CN3 / CN4 CN3 / CN4
Small Form Factor Smaller size and weight Feature Rich 3G WAN or CDMA Camera and scanner WiFi, BT, and GPS Large Screen 1D/2D Imager Broad Offering Vehicle Dock w/ Power Kits Comms Snap-Ons Mag Stripe, RS-232, DEX , USB Audio Jack Scan Handle, RFID Handle (CN3) IrDA CCX certified WLAN WLAN only config (CN3) Intermec WWAN Toolkit or ICM Intermec Terminal Emulator Workboard Printers 682x or PW50 Multiple, Large Keys Options SmartSystems Console Preloaded Hands free System Upgrade Support preloaded iBrowse, iLaunch Broad Offering Vehicle Dock w/ Power Kits Comms Snap-Ons Mag Stripe, RS-232, DEX , USB Audio Jack Scan Handle, RFID Handle (CN3) IrDA CCX certified WLAN WLAN only config (CN3) Intermec WWAN Toolkit or ICM Intermec Terminal Emulator Workboard Printers 682x or PW50 Multiple, Large Keys Options SmartSystems Console Preloaded Hands free System Upgrade Support preloaded iBrowse, iLaunch Fully Rugged 6 drop Etched Keycaps IP64 sealed for dust
26Peripheral Comparison
CN3/CN4
CN50
Quad Battery Charger
RFID (CN3)
Mag Stripe Reader
Desktop Comms Adapter
DEX, RS-232 Adapter
Scan Handle (CN3/3e only)
Quad Battery Charger
12V Vehicle Power
Vehicle Dock
DEX Cable
Vehicle Dock w/Comms
Multi-Dock
Single Dock
Multi-Dock
12V Vehicle Power
27When to lead in sales or deals with CN4.
- If your customer is using a DEX/RS232, IrDA, Mag
Stripe, USB, snap-on adapter - they need CN3 or
CN4. - If your customer uses workboard printers. Move
them to CN3 or CN4. - If your customer has a vehicle dock that uses
RS-232 or USB communications. They need CN3/CN4. - If your customers application is data intensive
and needs a fully rugged or larger keypad move
them to CN3e or CN4e. - If your customer is migrating from the 700 Series
and desires to minimize installation costs
through re-use of vehicle mounting systems. - If your customer is using the 7xx or CN3 and
relies on Intermec WWAN toolkit or Intermec
Connection Manager (ICM). Propose the CN3/CN4. - If your customer requires CCX support.
- If your customer is migrating from a CN3 the CN4
supports all the Intermec Value Add and has
compatible accessories and peripherals - If your customer needs fully rugged dont let
them buy MC75 or CN50. Move them up to CN3/CN4
28CN50 Stands Above the Competition
Against the Light Weights.the CN50 offers
- 3.5G WAN radio and the only solution with CDMA
- Improved industrial design that says rugged
with a very solid feel - Significantly more performance and features that
improves productivity and allows businesses to
provide better services
VS
Against other feature rich rugged computers.
- Only 3.5G WAN radio that provides high speed
uplink - Smaller size and lighter weight, without
sacrificing features or ruggedness - Extra features that allows businesses to provide
new and better services
VS
29CN50 Small Notepad Comparison
Intermec CN50 Motorola MC5574 Honeywell 7600 Opticon H19B Metrologic SP5700
Comms UMTS HSDPA / HSUPA, CDMA EVDO - Rev A, 802.11 b/g, BT, GPS GSM/GPRS/EDGE, No CDMA, Not 3G, 802.11 b/g, BT, GPS, GSM/GPRS/EDGE No CDMA, Not 3G, 802.11 b/g, CCX4, BT, GSM/GPRS/EDGE No CDMA, Not 3G, 802.11 b/g CCX4, BT, GPS GSM/GPRS 802.11 b/g, BT, IrDA
Drop/Seal 1.5m (5 ft.) / IP54 1.2m (4 ft) / IP54 1.5m (5 ft.) / IP54 1.2m (4 ft) / IP54 1.5m (5 ft) / IP54
Scanner Camera 2D Area Imager and 3 MP Color Camera 1D Laser, 2D Scanner and 2MP Camera 2D Area Imager 2D Laser Scanner No Camera 2D Imager, 2MP Camera
Display 3.5 QVGA 3.5 QVGA 2.8 QVGA 2.8 QVGA 3.5 QVGA
Dimensions Weight 74.3 x 153.0 x 27.5 mm 303 g 76 x 153 x 27 mm 336 g 69 x 178 x 42 mm 406 g WWAN config 62.3 x 140.8 x 25.5 mm 250 g 178 mm x 77 mm x 31 mm 240g (no battery)
Processor OS Memory Dual ARM Processors WM 6.1 128 MB RAM, 512 MB ROM 520 MHz Intel XScale WM 6.1 128 MB RAM 400 MHz Samsung 2440 WM 6.0 128 MB RAM, 128 ROM 400 MHz Samsung 2440 WM 6.0 128 MB RAM Marvell PXA270 (520MHz) Windows CE 5.0 128 MB RAM / 128 ROM
Batteries Standard 1,950 mAh Extended 3,900 mAh Standard 2,400 mAh Extended 3,600 mAh Standard 2,200 mAh Extended 3,240 mAh Standard 1,440 mAh Extended 2,900 mAh 2,200 mAh
Other eMDI, Compass, Accelerometer 5574 just released - Smartphone w/ scanner WWAN Europe Only
Green highlight and bold competitive advantage
30CN50 Large Notepad Comparison
Intermec CN50 Intermec CN4 Motorola MC75 Honeywell 7900 Psion Ikon
Comms UMTS HSDPA / HSUPA CDMA EVDO - Rev A 802.11 b/g, BT, GPS, UMTS HSDPA CDMA EVDO - Rev A 802.11 b/g CCX, BT, GPS, UMTS HSDPA, CDMA EVDO - Rev A, 802.11 a/b/g, BT, GPS, EDGE, No CDMA, Not 3G 802.11 b, BT, GPS UMTS HSDPA, 802.11 b/g, BT, GPS,
Drop/Seal 1.5m (5 ft.) / IP54 1.8m (6 ft.) / IP64 1.5m (5 ft.) / IP54 1.5m (5 ft.) / IP64 1.5m (5 ft.) / IP65
Imaging 2D Area Imager and 3 MP Color Camera 2D Area Imager or 2.0 MP Color Camera 1D Laser or 2D VGA Area Imager, 2.0 MP Camera 1D/2D Scanner 2D Area Imager and 2.0 MP Color Camera
Display 3.5 QVGA 3.5 QVGA 3.5 VGA 3.8 QVGA 3.7 VGA
Dimensions Weight 74.3 x 153.0 x 27.5 mm 303 g 81 x 160 x 28 mm 397 g 84 x 152 x 44 mm 422 g 89 x 190 x 4.3 mm 482 g 81 x 160 x 45 mm 450 g
Processor OS Memory Dual ARM Processors WM 6.1 128 MB RAM, 512 MB ROM 520 MHz XScale PXA270 WM 6.1 128 MB RAM, 256 ROM 624 MHz XScale PXA270 WM 6.0 128 MB RAM, 256 ROM 400 MHz XScale PXA255 WM 5.0 64 MB RAM, 64 ROM Marvell XScale PXA270 WM 6.0 128 MB RAM
Batteries Standard 1,950 mAh Extended 3,900 mAh Standard 2,200 mAh Extended 4,000 mAh Standard 3,600 mAh Extended 4,800 mAh 2,000 mAh 5,000 mAh
Other eMDI, Compass, Accelerometer eMDI, HW accys, SW tools, based on proven CN3 platform Proven platform w/ installed base - -
Green highlight and bold competitive advantage
31CN50 beats Motorola MC5574
- Comparable size/weight
- Both have a camera and scanner
- Both targeted at high mobility applications
- CN50 wins because...
- Performance for current and future applications
The CN50 3.5G WAN radio has a significant speed
advantage over the older, now End-Of-Life 2.5G
EDGE radio in the MC5574.. A High speed
processor, larger memory, and the capability for
a 32 GB SD card means the CN50 can store more
data and perform applications faster than MC5574.
These features work together to provide a
signficant improvment in productivity and allows
the device to be used in future applications that
are not practical with slower processors or a
2.5G radio. - Ruggedness. The CN50 has a 5 drop compared with
the 4 drop of the MC5574. The Motorola device
feels cheap and the external antenna looks very
susceptible to damage. Any customer that does a
side by side will agree the CN50 is a more solid,
high quality design. - Flexibility The CN50 has a Software Defined
Radio which can be programmed for either UMTS or
CDMA. The MC5574 does not have a CDMA option and
therefore it does not offer anything for Verizon,
Sprint, Bell Mobility CDMA customers.The WAN
radio in CN50 can be reprogrammed to change
between UMTS and CDMA, allow customers
flexibility to choose or change network
providers. - More capability The CN50 has a 3.1MP color
camera and a flash, compared with MC5574 which
has just 2MP and no flash. For customers that
need to take pictures, the CN50 will provide
significantly higher quality and better ease of
use. This translates to improved productivity and
better customer service. - Allows you to redefine work processes - Any
customer that performs document imaging today or
that may wish to expand their capability in the
future will value the ability to have Enhanced
Mobile Document Imaging on the CN50. This is a
time-saver if they are doing this today and its
a way to expand services that can grow their
business - Improved Navigation and user experience The
integrated Digital Compass provides a navigation
solution that is more reliable and more capable
than just GPS alone. The compass can be combined
with the camera to enhance image capture with
timestamp, GPS location, and directional
information. This will eliminate errors and save
time. The built in accelerometer enables screen
rotation which automatically keeps the display
correctly oriented regardless of the positioning
of the computer. - MC5574 will fight back with
- Lower Price. Theyll claim its good enough
and will sell it cheap to get customers to buy.
Ask customers if they want to be stuck with less
productivity and no path for growth. To grow
their business and stay competitive, customers
need to choose the CN50.
32CN50 beats Motorola MC75
- Comparable ruggedness
- Both have a camera and scanner
- Both targeted at applications requiring full
featured devices - CN50 wins because...
- Better Ergonomics. The CN50 has a significantly
smaller Size and Weight. The MC75 is 25 larger
and 35 heavier and you simply dont need to have
the carry a device that size to have features you
need. The smaller, lighter CN50 will improve user
acceptance, reduce fatigue, and improve
productivity - Performance and flexibility - The CN50 3.5G WAN
radio is next generation beyond the MC75. CN50
has everything the MC75 has, plus it includes
High Speed Uplink Data. This reduces time spent
on data transfer and allows the device to be used
in applications that are not practical at slower
uplink speeds. The CN50 has a high speed
processor, larger memory, and the capability for
a 32 GB SD card which means the CN50 can store
more data and will perform applications faster
than MC75. This improves productivity and allows
the device to be used in future applications The
software defined radio allows the CN50 to be
reprogrammed to be used on UMTS or CDMA networks.
This provides flexibility to choose, change,
upgrade along with your carrier. - More capabilities - The CN50 has a 3.1MP camera
compared with MC75 which has just 2MP. For users
that need to take pictures, the CN50 will provide
significantly higher quality and better ease of
use. This translates to improved productivity and
better customer service. - Allows you to redefine work processes - Any
customer that performs document imaging today or
that may wish to expand their capability in the
future will value the ability to have Enhanced
Mobile Document Imaging on the CN50. This is a
time-saver if they are doing this today and its
a way to expand services that can grow their
business - Improved Navigation and user experience The
integrated Digital Compass provides a navigation
solution that is more reliable and more capable
than just GPS alone. The compass can be combined
with the camera to enhance image capture with
timestamp, GPS location, and directional
information. This will eliminate errors and save
time. The built in accelerometer enables screen
rotation which automatically keeps the display
correctly oriented regardless of the positioning
of the computer. - Ruggedness. The drop spec on the CN50 and the
MC75 is the same (5 ft/ 1.5 m), however the
external antenna on the Motorola device looks
very susceptible to damage. Because the CN50 is
smaller and lighter its easier to carry, hold,
and protect against damage. - MC75 will fight back with
- VGA Display and 802.11a radio. A VGA display
typically uses a lot of power, may require a
larger battery, and will often require your
application to be rewritten to see any noticable
changes. The 802.11a radio may provide some use
in warehouse our retail, but has little value for
field mobility applications.
33Examples of Additional Sales Tools Coming soon
- Competitive Analysis
- CN50 vs MC55 and MC75 Ruggedness, Battery Life,
and Processing Speed - Videos
- Product Manager Overview, Digital Compass,
Accelerometer, eMDI - Technical Papers
- Optimizing Navigation with Compass and GPS
- CN50 WiFi provides performance and security that
customers need - White Papers
- ROI / TCO benefits of rugged mobile computer
- Benefits of high speed, 3.5G WAN radio
34Launch Timeline
- Internal Sales Training May 6
- Partner Sales Training Mid-May
- BDUs June 2
- External Announcement, Web Site Open, Launch Kit
on GSS June 3 - Train the Trainer (SE training) June 3-5
- Demand generation activities Early June
- Tech Days, Internal Sales Training June / July
35Key Takeaways
- CN50 is small and light weight and it is the most
advanced, rugged mobile computer available in the
market - CN50 provides significant differentiation over
the competition - CN50 supplements our CN product family to help us
expand into new highly mobile applications - Improves customers business results by
increasing productivity and keeping costs low - Helps customers expand their business by
allowing them to deliver services when and where
their customers need them
36Thank You!
37Backup Slides
38Configurations and Accessories
39CN50 Intermec Value Add SW
Resource Kit CN50
Bluetooth No
Communications No
Data Collection Yes
Device Management Yes
Device Yes
Mobile Gadgets Yes
Printing Yes
RFID No
Antares Migration No
Location Services Yes
Multimedia Yes
Sensor Yes
Product / Utility CN50
iFTP No
iLaunch No
Intermec Browser No
Intermec Terminal Emulator No
WWAN Toolkit No
Connection Manager No
SmartSystems Partial
Keyboard Remapper Yes
SIP Designer No
Bluetooth Wireless Printing Applet Yes
Features Demo Yes
Enhanced Mobile Document Imaging Yes
SmartSystems See following slide
40CN50 - Smart Systems Support
- SmartSystems Reference Client
- Remote Settings Management
- Data Collection, Bluetooth, 802.11 Microsoft Zero
Config, SmartSystems Settings - Scan-to-Connect/Scan-to-Load
- HTTP or FTP loading of applications
- SmartSystems Bundle Provisioning (3.50 Feature of
SmartSystems Foundation Console) - Application Deployment
- Silent Image Update Capability
- Licensed on Device Separately
- 3rd Party Device Management Extensions
- SmartSystems Foundation Console
- Not Included
- No Intermec Settings Manual UI, however all
settings are fully programmable
41CN50 UMTS Country Availability
- First PQA Work Week 31 (44 Countries)
- 30 EU Countries Austria, Belgium, Bulgaria,
Cyprus, Czech Republic, Denmark, Estonia,
Finland, France, Germany, Greece, Hungary,
Iceland, Ireland, Latvia, Liechtenstein,
Lithuania, Luxembourg, Malta, Netherlands,
Poland, Portugal, Romania, Slovakia, Slovenia,
Spain, Sweden, Switzerland, UK, Turkey - 4 MEA Countries Egypt, India, Morocco, Saudi
Arabia - 4 APAC Countries Singapore, Hong Kong, Thailand,
Vietnam - 4 Central/South American Countries Venezuela,
Costa Rica, Chile, Belize - Russia
- Ukraine
- Second PQA Work Week 38 (12 Countries)
- 2 North American Countries US (ATT), Mexico
- 7 Central/South American Countries Columbia,
Argentina, El Salvador, Guatemala, Honduras,
Nicaragua, Panama - 1 MEA Country Israel
- 2 APAC Countries Indonesia, Taiwan
- Remaining Carriers Countries (11
Countries/Carriers). We will work with the local
contacts (below) to finalize schedule - Norway (Telnor) - Herlufsen,
- Italy (TIM) Costi, Brazil
- Canada (Rogers / Telus) McGuire / Guadagnolo
- Telus is switching their network to UMTS. UMTS
deployment and certification plan is yet to be
defined.
42Re-Provisioning
- Our goal is to have a single hardware platform
that can be reprogrammed to work across different
UMTS or CDMA 3G networks. - We have not yet proven the hardware on CDMA,
therefore we cannot guarantee that the early UMTS
devices will be re-programmable to CDMA networks - Dedicated team developing the tool and process
for CN50 - Proposal is to offer an unlocked configuration
that can be easily and inexpensively
re-provisioned on any supported network. (Just
the cost of reprogramming). This will cost a
little more up front. - Single format 3G devices will be able to be
re-provisioned, but he costs will be higher
(200 each).
43CN50 In the Real World
- 6 AM Daily route and updated data base are
downloaded to the CN50 with Integrated 802.11 - 7 AM Time to leave the parking lot for a new
destination. GPS and Digital Compass give clear
directions that guide you from the time you start
the truck until you arrive at your location - 8 AM Boss calls on High Quality CN50 Cell Phone.
Needs you to make a quick stop back at the shop - 9 AM Customer signs for receipt of goods on
Integrated, Position Sensitive Touch Screen and
receives a Printed Receipt from the Intermec BT
Printer - 10 AM Damaged Package. Before accepting it, you
take a High Quality Photo and send it through
High Speed WAN back to the shop. - Final stop Delivery has all been scanned with
the CN50 2D Area Imager and the customer has
validated the accuracy with a signed invoice. You
capture the document with Intermec Mobile
Document Imaging and send the electronic file
back to the main office. - End of the day The rugged CN50 worked perfectly
and the long battery life lasted all day. Youre
tired, but the small and light CN50 made the job
a whole lot easier.
44What is Enhanced Mobile Document Imaging (eMDI)?
- eMDI enables the ability to capture full size
documents in the field - 81/2x11 or A4
- Primary components CN50 with EA21 scan engine,
decode software, license - Represented as a separate offering with its own
launch kit on GSS - Product Profile, FAQ, White Paper, Video
- Users Manual, Intermec U Training Module
- Primary markets and applications
- TNL (LTL, courier express package, postal carrier
last mile delivery) - Field Service (secondary)
45eMDI Delivers Real Value
- Improves cash flow for LTL carriers by reducing
the time between delivery of shipments and
invoicing the shipper - eMDI enables processing after each stop versus
the end of the day or after leaving with a drop
off service - Trip envelopes have to be processed before
customers can be billed. - Point Capture user experience reduces
variability in image quality between individual
users - Laser framer (no more estimating with a view
finder) - Image enhancement that cant be provided by using
camera only - Keystone correction (perspective), brightness,
flattening, contrast - Works in indoor, outdoor and cab lighting
conditions - Easy integration with existing mobile
applications and popular document management
systems - Compatible with major document management
systems. - Supports common document indexing schemes (doc ,
PRO , invoice , date/time stamp, etc.) - Creates images in native formats that are
accepted by document management companies. - Use eMDI software out of the box.
- Integrates directly with existing mobile
applications. - APIs available to customize user experience.
46eMDI - Deployment, Pricing and Part Number
- eMDI application is free
- Shipped on CN50 computers
- The application is also a sales tool, no demo app
- Use without license produces images with a
watermark - List Price 160 (based on 1 year ROI with
respect to drop off service) - M discount code (25)
- Listed in Price Guide under CN4 software sections
- License name is mobile_doc_imaging.d
- Unique startup icon
47eMDI Point Capture User Experience
- Easy-to-Use point capture user experience
reduces variability in image quality between
individual users - Laser framer (no fiddling with viewfinder)
- Image correction
- Keystone correction, brightening, flattening,
contrast - Up to 10 degrees of rotation, up to 35 degrees
off of vertical - Image capture from 1 foot above document
- Works in outdoor, indoor and cab lighting
conditions - Constraints
- Full size documents should have good print
contrast and captured only to Jpeg grayscale
images with good lighting environments - Half size documents can be captured to TIFF
monochrome images if they have good print
contrast with good lighting. - This version does not support OCR or decoding
embedded barcodes
Results using a camera
Results using Intermec MDI
eMDI Laser Framer
48Competitive Positioning eMDI Advantages
- Document Service
- 10/truck/month
- eMDI has 1 year ROI when compared to document
service - Flatbed Scanner
- eMDI expedites billing process
- eMDI eliminates clerical labor
- Scanner SW 1,300
- Mobile Scanners
- Example NeatReceipts 100 list
- IT departments greatly resist deploying secondary
mobile devices - Mobile Computer with Camera
- Document Capture versus Document Photography
- Not Consistent Point Capture User Experience
- Ineffective or no Image Enhancement Software
49Support ServicesChoosing the Best Repair Value
- Medallion Complete Contract Service Repairs
- Peace of Mind' through comprehensive service for
Intermec rugged mobile computers, which provides
insurance against unbudgeted and rising repair
costs. - Committed turnaround times
- Locked in, long-term value-based pricing3 5
year contract terms aligns with depreciation
and/or leasing schedules - Covers defects, failures, normal wear tear
damage, and preventative maintenance during
repair - NO additional charges for repair of physical
damage - Telephone based Technical Support
- Standard Warranty-related Repairs
- Standard Warranty coverage only applies to
defects in material or workmanship - Best effort, on average 15-day depot repair time
Please see Medallion Complete Terms
Conditions.
Medallion Complete Silver Contract Packages
2-day depot repair timeBronze Contract
Packages 5-day depot repair time Silver
Replacement Contract Packages Overnight
depot replacement from customer-owned spares
pool
50Professional ServicesConsistency for Faster ROI
- Most experienced, trusted provider in technology
deployment planning through systems Go-Live - Offering a complete suite of Professional
Services to support your rugged mobile computers - ReadiCareSM Activation and Provisioning Services
(available in North America only) - WWAN Carrier Provisioning Activation
- Software Configuration
- Tagging
- Operational Testing
- Packing, Storage Staging
- Project Management
- Vehicle Installation for forklifts, trucks
other vehicles - Application Documentation
- Software Project Management, Development
Support - RFID Consulting Implementation
Some services may not be available in your
location. Please check with your local service
representative for availability.
51Education ServicesCustom Training for End User
Solutions
- Flex with the Changes Training Ensures
Successful Rollouts - Training Deliverables
- Pre-rollout Promotion
- Curriculum Development
- Sourcing Training of Instructors
- On-site Training Delivery
- Train-the-Trainer Programs
- Project Management
- Help Desk Support
- Facility and Logistics Planning
Some services may not be available in your
location. Please check with your local service
representative for availability.
