Architecture of gLite Data Management System

1
Architecture of gLite Data Management System

• Tony Calanducci
• INFN Catania
• International Summer School on Grid Computing
  2006
• Ischia (Naples), July 09-21th 2006

2
Outline

• Grid Data Management Challenge
• Storage Elements and SRM
• File Catalogs and DM tools
• Metadata Services
• File Transfer Services

3
The Grid DM Challenge

• Need common interface to storage resources
• Storage Resource Manager (SRM)
• Need to keep track where data are stored
• File and Replica Catalogs
• Need scheduled, reliable file transfer
• File transfer service

• Heterogeneity
• Data are stored on different storage systems
  using different access technologies
• Distribution
• Data are stored in different locations in most
  cases there is no shared file system or common
  namespace
• Data need to be moved between different locations

4
Introduction

• Assumptions
• Users and programs produce and require data
• the lowest granularity of the data is on the file
  level (we deal with files rather than data
  objects or tables)
• Data files
• Files
• Mostly, write once, read many
• Located in Storage Elements (SEs)
• Several replicas of one file in different sites
• Accessible by Grid users and applications from
  anywhere
• Locatable by the WMS (data requirements in JDL)
• Also
• WMS can send (small amounts of) data to/from
  jobs Input and Output Sandbox
• Files may be copied from/to local filesystems
  (WNs, UIs) to the Grid (SEs)

5
Data services in gLite

• File Access Patterns
• Write once, read-many
• Rare append-only updates with one owner
• Frequently updated at one source - replicas
  check/pull new version
• (NOT frequent updates, many users, many sites)
• File naming
• Mostly, see the logical file name (LFN)
• LFN must be unique
• includes logical directory name
• in a VO namespace
• E.g. /gLite/myVOname.org/runs/12aug05/data1.res
• 3 service types for data
• Storage
• Catalogs
• Movement

6
gLite Grid Storage Requirements

• Def The Storage Element is the service which
  allows a user or an application to store data for
  future retrieval
• Manage local storage (disk) and/or interface to
  complex Mass Storage Systems (disk arrays and
  tape libraries) like
• HPSS, CASTOR, DiskeXtender (UNITREE),
• Offer a unique virtual file system even if it
  uses different storage techologies (array of
  disks and tapes), hiding the details to the users
  (providing an SRM interface)
• Support basic file transfer protocols
• GridFTP mandatory (GSI enabled FTP)
• Others if available (https, ftp, etc)
• Support a native I/O (remote file) access
  protocol
• POSIX (like) I/O client library for direct access
  of data

7
SRM in an example
She is running a job which needs Data for
physics event reconstruction Simulated Data Some
data analysis files She will write files remotely
too
They are at CERN In dCache
They are at Fermilab In a disk array
They are at Nikhef in a classic SE
8
SRM in an example
dCache Own system, own protocols and parameters
I talk to them on your behalf I will even
allocate space for your files And I will use
transfer protocols to send your files there
You as a user need to know all the systems!!!
classic SE Independent system from dCache or
Castor
SRM
Castor No connection with dCache or classic SE
9
Storage Resource Management

• The SRM (Storage Resource Manager) is a protocol
  for Storage Resource Management.
• it does not do any data transfer.
• used to ask a Mass Storage System (MSS) to make a
  file ready for transfer, or to create space in a
  disk cache to which a file can be uploaded
• The actual transfer is done using the file
  transfer protocol supported by the backend MSS
• Storage resource management needs to take into
  account
• Transparent access to files (migration to/from
  disk pool)
• File pinning
• Space reservation
• File status notification
• Life time management
• The SRM (Storage Resource Manager) is a single
  interface that takes care of local storage
  interaction and provides a Grid interface to the
  outside world
• In gLite, interactions with the SRM interface are
  hidden by higher level tools (DM tools and APIs)

10
gLite SE types

• gLite 3.0 data access protocols
• File Transfer GSIFTP (GridFTP)
• File I/O (Remote File access) gsidcap
• insecure RFIO
• secured RFIO (gsirfio)
• Classic SE (no official support anymore)
• GridFTP server
• Insecure RFIO daemon (rfiod) only LAN limited
  file access
• Single disk or disk array
• No quota management
• Does not support the SRM interface

11
gLite SE types (II)

• Mass Storage Systems (Castor)
• Files migrated between front-end disk and
  back-end tape storage hierarchies
• GridFTP server
• Insecure RFIO (Castor)
• Provide a SRM interface with all the benefits
• Disk pool managers (dCache and LCG DPM)
• manage distributed storage servers in a
  centralized way
• Physical disks or arrays are combined into a
  common (virtual) file system
• Disks can be dynamically added to the pool
• GridFTP server
• Secure remote access protocols (gsidcap for
  dCache, gsirfio for DPM)
• SRM interface

12
GridFTP

• Data transfer and access protocol for secure and
  efficient data movement
• Standardized in the Global Grid Forum
• extends the standard FTP protocol
• Public-key-based Grid Security Infrastructure
  (GSI) or Kerberos support (both accessible via
  GSS-API
• Third-party control of data transfer
• Parallel data transfer
• Striped data transfer
• Partial file transfer
• Automatic negotiation of TCP buffer/window sizes
• Support for reliable and restartable data
  transfer
• Integrated instrumentation, for monitoring
  ongoing transfer performance

13
gLite Storage Element
14
Files Naming conventions

• Logical File Name (LFN)
• An alias created by a user to refer to some item
  of data, e.g. lfn/grid/gilda/tony/simple2.dat
• Globally Unique Identifier (GUID)
• A non-human-readable unique identifier for an
  item of data, e.g.
• guid3a69a819-2023-4400-a2a1-f581ab942044
• Site URL (SURL)
• Gives indication on which place (Storage Element)
  the file is actually found.
• Understood by the SRM interface
• srm//aliserv6.ct.infn.it/dpm/ct.infn.it/home/gi
  lda/generated/2006-07-10/filef7a916f7-159b-48df-91
  59-877f2d3c6f58
• Transport URL (TURL)
• Temporary locator of a replicaaccess protocol
  understood by the backend MSS
• gsiftp//aliserv6.ct.infn.it/aliserv6.ct.infn.it
  /gpfs/dpm/gilda/2006-07-10/filef7a916f7-159b-48df
  -9159-877f2d3c6f58.46193.0

15
SRM Interactions
Client
SRM
4
1
2
3
5
Storage

1. The client asks the SRM for a file providing an
   SURL (Site URL)
2. The SRM asks the storage system to provide the
   file
3. The storage system notifies the availability of
   the file and its location
4. The SRM returns a TURL (Transfer URL), i.e. the
   location from where the file can be accessed
5. The client interacts with the storage using the
   protocol specified in the TURL

16
What is a file catalog
File Catalog
SE
SE
SE
17
The LFC (LCG File Catalog)

• It keeps track of the location of copies
  (replicas) of Grid files
• LFN acts as main key in the database. It has
• Symbolic links to it (additional LFNs)
• Unique Identifier (GUID)
• System metadata
• Information on replicas
• One field of user metadata

18
LFC Features

• Cursors for large queries
• Timeouts and retries from the client
• User exposed transactional API ( auto rollback
  on failure)
• Hierarchical namespace and namespace operations
  (for LFNs)
• Integrated GSI Authentication Authorization
• Access Control Lists (Unix Permissions and POSIX
  ACLs)
• Checksums
• Integration with VOMS (VirtualID and VirtualGID)

19
LFC commands
Summary of the LFC Catalog commands
lfc-chmod Change access mode of the LFC file/directory
lfc-chown Change owner and group of the LFC file-directory
lfc-delcomment Delete the comment associated with the file/directory
lfc-getacl Get file/directory access control lists
lfc-ln Make a symbolic link to a file/directory
lfc-ls List file/directory entries in a directory
lfc-mkdir Create a directory
lfc-rename Rename a file/directory
lfc-rm Remove a file/directory
lfc-setacl Set file/directory access control lists
lfc-setcomment Add/replace a comment
20
lfc-ls

• Listing the entries of a LFC directory
• lfc-ls -cdiLlRTu --class --comment
  --deleted --display_side --ds path
• where path specifies the LFN pathname (mandatory)
• Remember that LFC has a directory tree structure
• /grid/ltVO_namegt/ltyou create itgt
• All members of a VO have read-write permissions
  under their directory
• You can set LFC_HOME to use relative paths
• gt lfc-ls /grid/gilda/tony
• gt export LFC_HOME/grid/gilda
• gt lfc-ls -l tony
• gt lfc-ls -l -R /grid

LFC Namespace
Defined by the user
-l long listing -R list the contents of
directories recursively Dont use it!
21
lfc-mkdir

• Creating directories in the LFC
• lfc-mkdir -m mode -p path...
• Where path specifies the LFC pathname
• Remember that while registering a new file (using
  lcg-cr, for example) the corresponding
  destination directory must be created in the
  catalog beforehand.
• Examples
• gt lfc-mkdir /grid/gilda/tony/demo
• You can just check the directory with
• gt lfc-ls -l /grid/gilda/tony
• drwxr-xrwx 0 19122 1077
  0 Jun 14 1136 demo

22
lfc-ln

• Creating a symbolic link
• lfc-ln -s file linkname
• lfc-ln -s directory linkname
• Create a link to the specified file or directory
  with linkname
• Examples
• gt lfc-ln -s /grid/gilda/tony/demo/test
  /grid/gilda/tony/aLink
• Lets check the link using lfc-ls with long
  listing (-l)
• gt lfc-ls -l
• lrwxrwxrwx 1 19122 1077 0 Jun 14 1158 aLink
  -gt /grid/gilda/tony/demo/test
• drwxr-xrwx 1 19122 1077 0 Jun 14 1139 demo

Original File
Symbolic link
23
LFC C API
Low level methods (many POSIX-like)
lfc_setacl lfc_setatime lfc_setcomment lfc_seterrb
uf lfc_setfsize lfc_starttrans lfc_stat lfc_symlin
k lfc_umask lfc_undelete lfc_unlink lfc_utime send
2lfc
lfc_deleteclass lfc_delreplica lfc_endtrans lfc_en
terclass lfc_errmsg lfc_getacl lfc_getcomment lfc_
getcwd lfc_getpath lfc_lchown lfc_listclass lfc_li
stlinks
lfc_listreplica lfc_lstat lfc_mkdir lfc_modifyclas
s lfc_opendir lfc_queryclass lfc_readdir lfc_readl
ink lfc_rename lfc_rewind lfc_rmdir lfc_selectsrvr
lfc_access lfc_aborttrans lfc_addreplica lfc_apiin
it lfc_chclass lfc_chdir lfc_chmod lfc_chown lfc_c
losedir lfc_creat lfc_delcomment lfc_delete
24
GFAL Grid File Access Library

• Interactions with SE require some components
• ? File catalog services to locate replicas
• ? SRM interfaces
• ? File access mechanism to access files from the
  SE on the UI/WN
• GFAL does all this tasks for you
• ? Hides all these operations
• ? Presents a POSIX interface for the I/O
  operations
• ? Single shared library in threaded and
  unthreaded versions
• libgfal.so, libgfal_pthr.so
• ? Single header file
• gfal_api.h
• ? User can create all commands needed for
  storage management
• ? It offers as well an interface to SRM
• Supported protocols
• ? file (local or nfs-like access)
• ? dcap, gsidcap and kdcap (dCache access)
• ? rfio (castor access) and gsirfio (dpm)

25
GFAL File I/O API (I)

• int gfal_access (const char path, int amode)
• int gfal_chmod (const char path, mode_t mode)
• int gfal_close (int fd)
• int gfal_creat (const char filename, mode_t
  mode)
• off_t gfal_lseek (int fd, off_t offset, int
  whence)
• int gfal_open (const char filename, int flags,
  mode_t mode)
• ssize_t gfal_read (int fd, void buf, size_t
  size)
• int gfal_rename (const char old_name, const char
  new_name)
• ssize_t gfal_setfilchg (int, const void ,
  size_t)
• int gfal_stat (const char filename, struct stat
  statbuf)
• int gfal_unlink (const char filename)
• ssize_t gfal_write (int fd, const void buf,
  size_t size)

26
GFAL Catalog API

• int create_alias (const char guid, const char
  lfn, long long size)
• int guid_exists (const char guid)
• char guidforpfn (const char surl)
• char guidfromlfn (const char lfn)
• char lfnsforguid (const char guid)
• int register_alias (const char guid, const char
  lfn)
• int register_pfn (const char guid, const char
  surl)
• int setfilesize (const char surl, long long
  size)
• char surlfromguid (const char guid)
• char surlsfromguid (const char guid)
• int unregister_alias (const char guid, const
  char lfn)
• int unregister_pfn (const char guid, const char
  surl)

27
GFAL Storage API

• int deletesurl (const char surl)
• int getfilemd (const char surl, struct stat64
  statbuf)
• int set_xfer_done (const char surl, int reqid,
  int fileid, char token, int oflag)
• int set_xfer_running (const char surl, int
  reqid, int fileid, char token)
• char turlfromsurl (const char surl, char
  protocols, int oflag, int reqid, int fileid,
  char token)
• int srm_get (int nbfiles, char surls, int
  nbprotocols, char protocols, int reqid, char
  token, struct srm_filestatus filestatuses)
• int srm_getstatus (int nbfiles, char surls, int
  reqid, char token, struct srm_filestatus
  filestatuses)

28
GFAL Java API

• GFAL API are available for C/C programmers
• Because of ISSGC06 exercise requirements, we
  needed to have a Java version of them
• We wrote a wrapper around the C APIs using Java
  Native Interface and a the Java APIs on top of it
• More information can be found here
• https//grid.ct.infn.it/twiki/bin/view/GILDA/APIG
  FAL

29
lcg-utils DM tools

• High level interface (CL tools and APIs) to
• Upload/download files to/from the Grid (UI,CE and
  WN lt---gt SEs)
• Replicate data between SEs and locate the best
  replica available
• Interact with the file catalog
• Definition A file is considered to be a Grid
  File if it is both physically present in a SE and
  registered in the File Catalog
• lcg-utils ensure the consistency between files in
  the Storage Elements and entries in the File
  Catalog

30
lcg-utils commands

• Replica Management

lcg-cp Copies a grid file to a local destination
lcg-cr Copies a file to a SE and registers the file in the catalog
lcg-del Delete one file
lcg-rep Replication between SEs and registration of the replica
lcg-gt Gets the TURL for a given SURL and transfer protocol
lcg-sd Sets file status to Done for a given SURL in a SRM request
File Catalog Interaction
lcg-aa Add an alias in LFC for a given GUID
lcg-ra Remove an alias in LFC for a given GUID
lcg-rf Registers in LFC a file placed in a SE
lcg-uf Unregisters in LFC a file placed in a SE
lcg-la Lists the alias for a given SURL, GUID or LFN
lcg-lg Get the GUID for a given LFN or SURL
lcg-lr Lists the replicas for a given GUID, SURL or LFN
31
LFC interfaces
SEs
LFC SERVER
LCG UTILS
GFAL
Python
LFC CLIENT C API
DLI
WMS
CLI lfc-ls, lfc-mkdir, lfc-setacl,
32
LFC Interfaces (II)

• LFC client commands
• Provide administrative functionality
• Unix-like
• LFNs seen as a Unix filesystem (/grid/ltVOgt/ )
• LFC C API
• Alternative way to administer the catalog
• Python wrapper provided
• Integration with GFAL and lcg_util APIs complete
• ? lcg-utils access the catalog in a transparent
  way
• Integration with the WMS completed
• The RB can locate Grid files allows for data
  based match-making
• Using the Data Location Interface

33
Data Management CLIs APIs

• lcg_utils lcg- commands lcg_ API calls
• Provide (all) the functionality needed by the
  gLite user
• Transparent interaction with file catalogs and
  storage interfaces when needed
• Abstraction from technology of specific
  implementations
• Grid File Access Library (GFAL) API
• Adds file I/O and explicit catalog interaction
  functionality
• Still provides the abstraction and transparency
  of lcg_utils
• edg-gridftp tools CLI
• Complete the lcg_utils with low level GridFTP
  operations
• Functionality available as API in GFAL
• May be generalized as lcg- commands

34
Data Management Tools and APIs

• LFC C API and CLIs
• Administratotion tools for entries in the file
  catalog
• GFAL
• Interaction with files in SE and replicas in the
  File Catalog
• Lcg-utils API and CLIs
• High level wrapper of the GFAL APIs

35
Data Movement (I)

• Many Grid applications will distribute a LOT of
  data across the Grid sites
• Need efficient and easy way to manage File
  movement service
• gLite File Transfer Service FTS
• Manage the network and the storage at both ends
• Define the concept of a CHANNEL a link between
  two SEs
• Channels can be managed by the channel
  administrators, i.e. the people responsible for
  the network link and storage systems
• These are potentially different people for
  different channels
• Optimize channel bandwidth usage lots of
  parameters that can be tuned by the administrator
• VOs using the channel can apply their own
  internal policies for queue ordering (i.e.
  professors transfer jobs are more important than
  students)
• gLite File Placement Service
• It IS an FTS with the additional catalog lookup
  and registration steps, i.e. LFNs and GUIDs can
  be used to perform replication. Couldve been
  called File Replication Service. (replica
  managed/catalogued copy)

36
Data Movement (II)

• File movement is asynchronous submit a job
• Held in file transfer queue
• Data scheduler
• Single service per VO can be distributed
• VO can apply policies (priorities, preferred
  sites, recovery modes..)
• Client interfaces
• Browser
• APIs
• Web service
• File transfer
• Uses SURL
• File placement
• Uses LFN or GUID, accesses Catalogues to resolve
  them

37
Data movement (II)

• File movement is asynchronous submit a job
• Held in file transfer queue
• FPS fetches job transfer requests, contact File
  Catalogue obtaining source / destination SURLs
• Task execution is demanded to FTS
• User can monitor job status through jobID
• FTS maintains state of job transfers
• When job is done, FPS updates file entry in the
  catalogue adding the new replica

38
Metadata on the Grid

• Metadata is data about data
• On the Grid mainly, information about files
• Describe files
• Locate files based on their contents
• They can also add details on running jobs
• But also simplified DB access on the Grid
• Many Grid applications need structured data
• Many applications require only simple schemas
• Can be modelled as metadata
• Main advantage better integration with the Grid
  environment
• Metadata Service is a Grid component
• Grid security
• Hide DB heterogeneity
• AMGA is the Metadata Component of gLite

39
Example

• Suppose we have a set of movie trailers saved on
  several storage elements

lfc-ls -l /grid/gilda/trailers -rw-rw-r-- 1
101 102 10188804 Apr 14 1721
BatmanBegins.mpg -rw-rw-r-- 1 109 102
3201028 Apr 14 1934 alien.mpg -rw-rw-r-- 1
101 102 3545092 Apr 14 1719
amelie.mpg -rw-rw-r-- 1 101 102
5277700 Apr 14 1727 american2.mpg -rw-rw-r-- 1
101 102 5828612 Apr 14 1728
fastfurious.mpg -rw-rw-r-- 1 192 102
20509586 Apr 20 1408 insideman.avi -rw-rw-r--
1 101 102 5912580 Apr 14 1731
madagascar.mpg -rw-rw-r-- 1 101 102
5812228 Apr 14 1730 matrix.mpg -rw-rw-r-- 1
192 102 12918756 Apr 20 1909
pinkpanther.mov -rw-rw-r-- 1 101 102
6240260 Apr 14 1730 spiderman.mpg

• We could add more details (Movie Title, Cast,
  Runtime, PlotOutline, Genre, Director) on their
  contents associating them Metadata.
• We could then look for movies that satisfy some
  desired search critiria (e.g. movies that are
  commedies where our preferred actor perfomed or
  are about animals and zoos)

40
Metadata Concepts

• Basic Definitions
• Entries - List of items to which we want attach
  metadata to
• (ex each movie will rapresented as an entry in
  AMGA)
• Attribute key/value pair with type information
• Name/Key The name of the attribute
• (ex MovieTitle, Cast, PlotOutline, Runtime, )
• Type The type
• (ex varchar, int, float, text, numeric, )
• Value - Value of an entry's attribute
• (ex Spider Man 2, Tobey Maguire, Kirsten
  Dunst, 127, )
• Metadata - List of attributes associated with
  entries
• Schema A set of attributes
• Collection A set of entries associated with a
  schema
• We can think of collections as DB tables, schema
  as the list of fields (with their types),
  attributes as columns, entries as rows

41
AMGA Features

• Dynamic Schemas
• Schemas can be modified at runtime by client
• Create, delete schemas
• Add, remove attributes
• Metadata organised as an hierarchy
• Collections can contain sub-collections
• Analogy to file system
• Collection ? Directory Entry ? File
• Flexible Queries
• SQL-like query language
• Joins between schemas
• Example

selectattr /gLibraryFileName /gLAudioAuthor
/gLAudioAlbum '/gLibraryFILE/gLAudioFILE and
like(/gLibraryFileName, .mp3")
42
Security

• Unix style permissions
• ACLs Per-collection or per-entry.
• Secure connections SSL
• Client Authentication based on
• Username/password
• General X509 certificates
• Grid-proxy and VOMS-proxy certificates
• Access control via a Virtual Organization
  Management System (VOMS)

43
AMGA Implementation

• C multiprocess server
• Runs on any Linux flavour
• Backends
• Oracle, MySQL, PostgreSQL, SQLite
• Two frontends
• TCP Streaming
• High performance
• Client API for C, Java, Python, Perl, Ruby
• SOAP
• Interoperability
• Also implemented as standalone Python library
• Data stored on filesystem

44
AMGA Datatype

• AMGA Datatypes
• Using the above datatypes you are sure that your
  metadata can be easily moved to all supported
  back-ends
• If you do not care about DB portability, you can
  use, in principle, as entry attribute type ALL
  the datatypes supported by the back-end, even the
  more esoteric ones (PostgreSQL Network Address
  type or Geometric ones)
• We played a little bit with GIS Datatype offered
  by MySQL 5

45
Metadata Replication

• Motivation
• Scalability Support hundreds/thousands of
  concurrent users
• Geographical distribution Hide network latency
• Reliability No single point of failure
• DB Independent replication Heterogeneous DB
  systems
• Disconnected computing Off-line access
  (laptops)
• Architecture
• Asynchronous replication
• Master-slave Writes only allowed on the master
• Replication at the application level
• Replicate Metadata commands, not SQL ? DB
  independence
• Partial replication supports replication of
  only sub-trees of the metadata hierarchy

46
Metadata Replication
Some use cases
Partial replication
Full replication
Federation
Proxy
47

• GILDA Use Cases

48
gLibrary Use Case

• Attempts to create a Multimedia Management System
  on the Grid
• Examples of Multimedia Contents handled by
  gLibrary
• Images
• Movies
• Audio Files
• Office Documents (Powerpoint, Word, Excel,
  OpenOffice)
• E-Mails, PDFs, HTMLs
• Customized versions of well-know document type
  (ex. EGEE PPTs)
• .
• Keeps track and organizes in a uniform way all
  the additional details (metadata) of files saved
  in Storage Elements and registered in File
  Catalogues
• Provides users with an easy way to locate and
  retrieve files based on their contents

49
gLibrary JAVA GUI screenshot
Alpha Prototype
50
gLibrary Deployment scenario
VOMS
VOMS Proxy w/Role Group
VOMS Proxy with Group Role Information
Authenticate with X509 Certificate
PostGreSQL
(gLibraryManager, gLibrarySubmitter, VO user)
AMGA Server
UI
VOMS Proxy
VOMS Proxy
SE
SE
SE
51
gMOD grid Movie On Demand

• gMOD provides a Video-On-Demand service
• User chooses among a list of video and the chosen
  one is streamed in real time to the video client
  of the users workstation
• For each movie a lot of details (Title, Runtime,
  Country, Release Date, Genre, Director, Case,
  Plot Outline) are stored and users can search a
  particular movie querying on one or more
  attributes
• Two kind of users can interact with gMOD
  TrailersManagers that can administer the db of
  movies (uploading new ones and attaching metadata
  to them) GILDA VO users (guest) can browse,
  search and choose a movie to be streamed.

52
gMOD interactions
VOMS
Storage Elements
GENIUS Portal
AMGA
get Role
User
Workload Management System
53
gMOD screenshot
gMOD is accesible through the GENIUS Portal
(https//glite-tutor.ct.infn.it)
54
Data movement introduction

• Grids are naturally distributed systems
• The means that data also needs to be distributed
• First generation data distribution mainly
  concentrated on copy protocols in a grid
  environment
• gridftp
• http mod_gridsite
• File movement started and controlled on the
  client side
• But copies controlled by clients have problems

55
Direct Client Controlled Data Movement
Control Channels
Client
Source Storage Element
Destination Storage Element

• Although transport protocol may be robust, state
  is held inside client inconvenient and fragile.
• Client only knows about local state, no sense of
  global knowledge about data transfers between
  storage elements.
• Storage elements overwhelmed with replication
  requests
• Multiple replications of the same data can happen
  simultaneously
• Site has little control over balance of network
  resources - DoS

Data Flow Channel
56
Transfer Service

• Clear need for a service for data transfer
• Client connects to service to submit request
• Service maintains state about transfer
• Client can periodically reconnect to check status
  or cancel request
• Service can have knowledge of global state, not
  just a single request
• Load balancing
• Scheduling

• Submit new request
• Monitor progress
• Cancel request

Client
SOAP via https
Transfer Service
Control
Source Storage Element
Destination Storage Element
Data Flow
57
Transfer Service Architecture

• Clients submit jobs via SOAP over https.
• Jobs are lists of URLs in srm// format. Some
  transfer parameters can be specified (streams,
  buffer sizes).
• Clients cannot subscribe for status changes, but
  can poll.
• C command line clients. C, Java and Perl APIs
  available.
• Backend databases supported MySQL and Oracle.
• Web service runs in Tomcat5 container, agents
  runs as normal daemons.

Client
Secure web service connection
Transfer Service
Storage Elements
Well defined state transitions/ checkpointing
Database
58
gLite FTS Channels

• FTS Service has a concept of channels
• A channel is a unidirectional connection between
  two sites
• Transfer requests between these two sites are
  assigned to that channel
• Channels usually correspond to a dedicated
  network pipe (e.g., OPN) associated with
  production
• But channels can also take wildcards
• to MY_SITE All incoming
• MY SITE to All outgoing
• to Catch all

• Channels control certain transfer properties
  transfer concurrency, gridftp streams.
• Channels can be controlled independently
  started, stopped, drained.

59
gLite FTS Agents

• Channel Agents
• Transfers on channel are managed by the channel
  agent
• Channel agents can perform inter-VO scheduling

• VO Agents
• Any job submitted to FTS is first handled by the
  VO agent
• VO agent authorises job and changes its state to
  Pending
• VO agents can perform other tasks naturally
  these can be VO specific
• Scheduling
• File catalog interaction

60
FTS summary

• Efficient and easy way to manage File movement
  service
• gLite File Transfer Service FTS
• File movement is asynchronous submit a job
• Held in file transfer queue
• Task execution is demanded to FTS
• User can monitor job status through jobID
• Maintains state of job transfers
• Manage the network and the storage at both ends
• Define the concept of a CHANNEL a link between
  two SEs
• Channels can be managed by the channel
  administrators, i.e. the people responsible for
  the network link and storage systems
• These are potentially different people for
  different channels
• Optimize channel bandwidth usage lots of
  parameters that can be tuned by the administrator
• VOs using the channel can apply their own
  internal policies for queue ordering (i.e.
  professors transfer jobs are more important than
  students)

61
FTS conclusion

• FTS offer an important and useful service on the
  grid a significant advance on client managed
  file transfers.
• FTS channel architecture offers very useful
  features to control transfers between sites or
  into a single site, though it may become overly
  complex in a grid without clear data flow
  patterns.
• The ability to control VO shares and transfer
  parameters on a channel is important for sites.
• FTS agent architecture allows VOs to connect the
  transfer service closely with their own data
  management stacks, a useful feature for HEP
  experiments.
• Neither service is completely mature at this
  stage bugs were found on it, but this service
  will continue to mature and develop, especially
  in its relationship to higher level data
  management components, and significant steps to
  integrate with the file catalogs have already
  been taken.

62
Data Management Services Summary

• Storage Elements save data and provide a common
  interface
• Storage Resource Manager (SRM) Castor, dCache,
  DPM,
• Native Access protocols rfio, dcap, nfs,
• Transfer protocols gsiftp, ftp,
• Catalogs keep track where data are stored
• File Catalog
• Replica Catalog
• Metadata Catalog
• Data Movement schedules reliable file transfer
• File Transfer Service gLite FTS (manages
  physical transfers)

LCG File Catalog (LFC)
AMGA Metadata Catalogue
63
References

• gLite documentation homepage
• http//glite.web.cern.ch/glite/documentation/defau
  lt.asp
• DM subsystem documentation
• http//egee-jra1-dm.web.cern.ch/egee-jra1-dm/doc.h
  tm
• LFC and DPM documentation
• https//uimon.cern.ch/twiki/bin/view/LCG/DataManag
  ementDocumentation
• AMGA Project Homepage
• http//project-arda-dev.web.cern.ch/project-arda-d
  ev/metadata/
• FTS user guide
• https//edms.cern.ch/file/591792/1/EGEE-TECH-59179
  2-Transfer-CLI-v1.0.pdf

64
Questions
