Geometric Crossover for Permutations with Repetitions: Application to Graph Partitioning

1
PPSN 2006
Geometric Crossover for Permutations with
RepetitionsApplication to Graph Partitioning
A. Moraglio, Y-H. Kim, Y. Yoon, B-R. Moon R.
Poli
2
Contents

• Geometric Crossover
• Geometric Crossover for Permutation with
  Repetitions
• Geometric Crossover for Graph Partitioning
• Combination with Labelling-Independent Crossover
• Experimental Results
• Conclusions

3
Geometric Crossover
4
Geometric Crossover

• Line segment
• A binary operator GX is a geometric crossover if
  all offspring are in a segment between its
  parents.
• Geometric crossover is dependent on the metric

5
Geometric Crossover

• The traditional n-point crossover is geometric
  under the Hamming distance.

H(A,X) H(X,B) H(A,B)
6
Many Recombinations are Geometric

• Traditional Crossover extended to multary strings
• Recombinations for real vectors
• PMX, Cycle Crossovers for permutations
• Homologous Crossover for GP trees
• Ask me for more examples over a coffee!

7
Being geometric crossover is important because.

• We know how the search space is searched by
  geometric crossover for any representation
  convex search
• We know a rule-of-thumb on what type of
  landscapes geometric crossover will perform well
  smooth landscape
• This is just a beginning of general theory, in
  the future we will know more!

8
Geometric Crossover for Permutations with
Repetitions
9
Geometric Crossover for Permutations

• PMX geometric under swap distance
• Cycle Crossover geometric under swap and Hamming
  distance (restricted to permutations)
• More crossovers for permutations are geometric
• We extend Cycle Crossover to permutations with
  repetitions and show its application to the graph
  partitioning problem
• The extended Cycle Crossover is still geometric
  under Hamming distance (restricted to
  permutations with repetitions) but not geometric
  under swap distance

10
Permutations with repetitions

• Simple permutation (21453)
• Permutation with repetitions
• (214151232)
• Repetition class (33111)
• We want to search the space of permutations
  belonging to the same repetition class

11
Generalized Cycle Crossover - Phase 1 find cycles

12
Generalized Cycle Crossover - Phase 2 mix cycles

13
Properties of the New Crossover

• it preserves repetition class
• it is a proper generalization of the cycle
  crossover (when applied to simple permutations,
  it behaves exactly like the cycle crossover)
• it searches only a fraction of the space searched
  by traditional crossover
• when applied to parent permutations with
  repetitions of different repetition class,
  offspring have intermediate repetition class

14
Geometric Crossover for Multiway Graph
Partitioning
15
2
6
1
4
7
3
5
Cut size 5
1 1 2 2 2 3 3
16
Cut size 6
1 3 1 2 2 3 2
17
Feasible Solutions

• Balanced Solution the difference in cardinality
  between the largest and the smallest subsets is
  at most one
• Balancedness is a hard constraint feasible
  solutions are balanced, infeasible solution are
  not balanced
• Our evolutionary algorithm does not use any
  repairing mechanism. It restricts the search to
  the space of the balanced solutions using search
  operators that preserve balancedness

18
Searching Balanced Solution Space

• Representation permutation with repetitions.
  Each Position in the permutation corresponds to a
  vertex in the graph. Each element of the
  permutation corresponds to a group
• Initial Population equally balanced solutions
  belonging to the same repetition class
• Crossover cycle crossover that preserves
  repetition class, hence balancedness
• Mutation swap mutation that preserves repetition
  class, hence balancedness

19
Combination withLabelling-Independent Crossover
20
Graph encoding and Hamming distance

• Redundant encoding
• Hamming distance is not natural.

1 1 2 2 2 3 3
21
Labeling-independent Distance Crossover

• LI distance Minimum Hamming distance between
  partitions over all possible relabelling
• LI Geometric Crossover Relabel the second parent
  such as it is at minimum Hamming distance from
  first parent (normalization). Do the normal
  n-point crossover using the first parent and the
  normalized second parent.

22
Combination of Cycle Crossover and
Labelling-Independent Crossover

• First normalization of second parent on first
  parent
• Then cycle crossover between first parent and
  normalised second parent
• Still geometric under LI-H distance restricted to
  balanced partitions

23
Experimental Results
24
Crossovers
25
Experimental Results
32-way partitioning (average results)
26
Experimental Results
32-way partitioning (average results)
27
Experimental Results
128-way partitioning (average results)
28
Experimental Results
128-way partitioning (average results)
29
Summary

• Geometric crossover offspring are in the segment
  between parents
• Cycle crossover for permutation geometric under
  Hamming distance
• Generalized cycle crossover extension of cycle
  crossover with permutation with repetition. It is
  geometric under hamming distance and it is
  class-preserving
• Geometric crossover for graph partitioning it
  searches only the space of feasible solutions
  (balanced partitions) that is a fraction of the
  search space searched by traditional crossover
• Combination with labelling-independent crossover
  it filters the redundancy of the labelling and it
  searches only balanced partitions. It is a
  geometric crossover
• Experimental results the combined geometric
  crossover has remarkable performance!

30
Thanks for your attentionquestions?
