RNA and RNA Transcription

1
RNA and RNA Transcription

• September 9, 2003

2
Flow of Genetic Information
DNA
RNA Transcription
DNA Replication
3
The Plan- RNA Transcription

• Today (9/9)
• Structure of RNA
• How is RNA made
• Types of different RNAs
• rRNA and tRNA
• A brief intermission
• Monday (9/15)
• Structure of mRNA
• Details of Transcription (mRNA)

4
Definition of RNA
RNA Ribonucleic Acid

• A polymer of ribonucleoside 5-monophosphates
  (i.e., ribonucleotides)

OH
5
Structure of RNA

• RNA is a polymer of ribonucleotides as opposed to
  the deoxyribonucleotides that make up DNA

5
1
4
5
1
4
2
3
2
3
Our old friend Deoxyribose
Ribose
6
Bases Found in RNA
Guanine
Adenine
Uracil
Cytosine
7
Information is encodedin the order of the Bases
U
1

• Bases attach to the 1 Carbon just as was seen in
  the DNA chain
• Remember that although the RNA chain looks very
  similar to the DNA chain there are
  differences!!!!!!!!!!!!!!!!!

C
1
1) RNA is chemically less stable than DNA 2) RNA
is single-stranded
U
1
RNA just doesnt need to hang around as long
8
Secondary Structure of RNA

• Unlike DNA, RNA is technically a single-stranded
  molecule
• The bases can pair with one another through
  intramolecular base pairing to give different
  structures
• Hairpins
• Double-stranded regions
• Helices (A type)
• Often bound to proteins

9
How does Information get Transferred from DNA to
RNA?

• DNA serves as a template for RNA polymerase
• As you might expect RNA polymerase is a DNA
  directed polymerizer of RNA
• Can anyone guess in which direction the RNA chain
  grows?

10
One strand of DNA serves as the template

• The RNA polymerase copies one of the strands of
  DNA in a process known as RNA transcription

C A T T A G T A C T A T A C T
3
5
DNA
G T A A T C A T G A T A T G A
3
5
5
3
RNA
C A U U A G U A C U A U A C U
Template Strand
11
RNA Polymerases

• Reaction catalyzed is chemically identical to
  that described for DNA polymerases
• Add a ribonucleotide to the 3-OH of an RNA chain
• RNA polymerases have 5-3 polymerase activity
  (No other activities)
• Unlike DNA polymerases they can simply initiate
  the chain on their own (i.e., they dont need any
  kind of priming)

12
Chemical Mechanism is Identical to that described
for DNA polymerase
5 RNA Chain
G
5
U
OH
3
OH
13
RNA Polymerization

• Requirements for RNA Synthesis
• DNA template
• RNA polymerase
• All four NTPs (N Nucleotide)
• ATP, CTP, GTP, UTP

(RNA)N NTP (RNA)N1 PPi
14
Recurring ThemeConservation of Mechanism

• The cell figures out a good way to do something
  and applies that mechanism to multiple processes
• An efficient way to synthesize nucleic acid
  chains is to add an activated (phosphorylated)
  ribonucleotide or deoxyribonucleotide to the
  3-OH group of an existing chain
• That mechanism is used for both
• DNA and RNA

15
How do RNA polymerases copy Chromatin?

• RNA polymerases require accessory factors to
  initiate synthesis
• After initiation they can move along without the
  aid of any other proteins
• Topisomerases probably still function to relax
  supercoils in front of the machine

16
RNA Polymerase Does Not Require Accessory Factors
Topisomerases
17
Different Classes of RNAs Cooperate to Direct
Protein Synthesis

• rRNA (80 of cellular RNA)
• Ribosomal RNA is a component of the ribosomes
  that mediate protein synthesis
• tRNA (15 of cellular RNA)
• Transfer RNA - acts as a cellular adapter
  between nucleic acids and proteins
• mRNA (5 of cellular RNA)
• Messenger RNA - takes the information encoded by
  the DNA to the protein translation machinery so
  that it can be read
• Others- snRNAs, scRNAs, mt rRNA

18
Synthesis of Different Classes of RNA Molecules

• Bacteria have a single RNA polymerase that
  synthesizes all the different types of RNAs
• Eukaryotic cells have polymerases specific for
  each type of RNA
• rRNA RNA polymerase I
• mRNA RNA polymerase II (topic for Monday)
• tRNA and others RNA polymerase III

19
Classes of RNA

• rRNA
• tRNA
• mRNA (covered Monday in gory detail)
• Other classes of RNA

20
Properties of rRNA

• rRNA is the most abundant form of RNA in the cell
  (80 of cellular RNA)
• Plays a structural role in building the ribosomes
  which are the machines that synthesize proteins
• Some catalytic roles
• Very stable RNAs due to
• Association with proteins
• Methylation of the 2-OH
• (antibiotic resistance)

OCH3
21
Ribosomal RNAs are Synthesized Simultaneously

• Different size ribosomal RNAs are needed to make
  the ribosomes
• 16S, 23S, 5S (sizes in prokaryotes)
• 18S, 28S, 5.8S, 5S (sizes in eukaryotes)
• Equal amounts of each of these RNAs are required
• The cell has devised a clever way to assure that
  equal amounts of these RNAs are made

22
In eukaryotes rRNA is synthesized in the Nucleolus

• In eukaryotes, the rRNA genes are repeats located
  in a special region of one chromosome
• rRNAs are transcribed in the Nucleolus

This makes sense because ribosomes are assembled
in the nucleolus
23
Some Common Antibiotics Interact with Ribosomal
RNAs

• These antibiotics work by inhibiting prokaryotic
  protein synthesis- dont affect the distinct
  eukaryotic ribosomes
• Streptomycin
• 16S RNA
• Chloramphenicol
• 23S RNA

24
Classes of RNA

• rRNA
• tRNA
• mRNA (to be covered Monday)
• Other classes of RNA

25
RNA-type Properties of tRNA

• tRNAs are relatively short RNA molecules 75-80
  nucleotides
• Bases are extensively modified (1of 10)
• Synthesized as longer pieces and then trimmed and
  spliced
• Highly structured molecules

26
Role of tRNA

• Transfer RNAs (15 of cellular RNA)
• tRNAs function as the decoders so that messenger
  RNA can serve as the template for making proteins
• tRNAs carry the amino acids that are going to be
  linked together in the process of protein
  synthesis
• One end reads the code in the messenger RNA and
  the other end carries the amino acid

27
tRNAs are Modified by Addition of an Amino Acid
to a 3-OH
Amino Acid
-OH

• The 3-OH is modified by addition of an amino
  acid
• The anticodon recognizes the codon in the
  messenger RNA
• tRNA serve to decode the genetic code

AAAA
Much much more to come on the function of tRNAs
28
Tertiary structure of tRNA
Amino acid
Messenger RNA
29
Classes of RNA

• rRNA
• tRNA
• mRNA (to be covered Monday)
• Other classes of RNA
• snRNAs
• snoRNAs
• RNPs
• ribozymes

30
Other Roles for RNA

• Many RNAs play a role in catalyzing other nucleic
  acid reactions- ribozymes
• Often these RNAs give sequence specificity to
  different reactions- such as helping to identify
  the region of another RNA molecule that needs to
  be modified

31
Take Home Message

• Structure of RNA (similarities to and differences
  from DNA)
• Transfer of information from DNA to RNA
• Classes of RNA
• rRNA
• tRNA
• mRNA (still to come- you can hardly wait )

More info on what I said about selectively
reading the DNA
