• Data Mining at British Airways
• Simon Cumming (simon.n.cumming_at_britishairways.com)

• Principal Operational Research Consultant

Royal Statistical Society. Reading, Feb2005
2
Data mining at British Airways

• Introduction British Airways Operational
  Research
• History and some examples of data mining at BA
• Data mining and business complexity
• Successful data mining

3
Introduction British Airways

• UKs largest scheduled airline
• 159 destinations in 75 countries
• 114 from Heathrow
• Flights are split into three areas
• Domestic
• European
• Longhaul
• 4 cabins on long haul aircraft
• First Class
• Club World - Business Class
• World Traveller Plus
• World Traveller - Economy Class

4
The challenges BA has faced over the last 3 years

• Middle East (war in Iraq etc.)
• World Trade Centre aftermath / terror threats,
  security etc.
• Low Cost carriers
• SARS
• Economic instability
• Changing relations within the travel trade

5
Issues facing BA today

• Competing in ever tougher marketplace
• - Customer service and innovation.
• Improving punctuality and management of
  disruption.
• Ensuring continued financial performance
• - Return on investment for shareholders,
• and ability to invest for future.
• Making the most of new technologies, e.g. web,
  self-service.
• Getting ready for Terminal 5 at Heathrow.
• Reducing unnecessary complexity.
• Right use of alliances, codeshares, franchises.

6
Operational Research at British Airways

• OR at BA has been going for over 50 years.
• The Airline industry has some complex and
  interesting OR problems, e.g.
• Revenue management (yield management)
  optimising number of seats available in different
  selling classes (prices).
• End-to-end scheduling, I.e. scheduling,
  planning, rostering, etc.
• Engineering inventory, vehicle fleets, etc.
• Commercial customer data, frequent flyer
  programme, transaction data, market research,
  consultancy
• Operational Check-in, queuing, seat
  allocation, punctuality, baggage etc.

The academic body for airline OR is AGIFORS, the
Airline Group of the International Federation of
OR Societies (www.agifors.org)
7
Operational Research at BA

• Effective change through analytical excellence
• Problem Structuring
• Clarification and understanding of a complex
  problem
• Business Modelling
• Implications of future options, decisions and
  scenarios
• Quantitative and qualitative modelling of complex
  business areas or issues
• Complex Data Analysis
• Delivering insight into complicated issues and
  questions within the business, through uncovering
  trends, causes and relationships, to ensure
  decisions are made on basis of evidence that
  reflects the real world

There are also data mining people in the Sales
and Marketing departments.
8
Data mining quick overview

• Linear and logistic regression.
• Decision trees (Classification Regression Trees
  Breiman et al, 1984) recursive partitioning
  based on significance measure.
• Cluster analysis. Ward , k-means, etc.
• Self-organising map (Kohonen, 1982) can think
  of as a structured set of clusters.
• Neural network works out an approximation to
  the function relating the inputs to the outputs.
• Association rules based on conditional
  probabilities p(yx), e.g. If I buy bread, what
  is the probability I buy butter?

9
How a SOM works
Each dot represents a cluster centre, i.e. a
vector of data with the same columns (dimensions)
as your data set. For each row of the data set,
the algorithm finds the nearest cluster centre
and moves it, and its neighbours, towards the
current data row by a small amount This process
iterates through the data set a number of times.
10
Example of cluster output from SOM
11
Data mining commercial software example SAS
Enterprise Miner
http//www.sas.com/technologies/analytics/datamini
ng/miner
12
Data mining methodology example SAS Institutes
SEMMA concept

• Sample - by creating one or more data sets
• Explore - by searching for anticipated
  relationships, unanticipated trends, and
  anomalies in order to gain understanding and
  ideas
• Modify - by creating, selecting, and transforming
  the variables to focus the model selection
  process
• Model - by using the analytical tools
• Assess - by evaluating the usefulness and
  reliability of the findings
• You may not want to include all of these steps
• It may be necessary to repeat one or more of the
  steps several times
• Another examples of a data mining methodology is
  CRISP-DM (cross-industry platform for data
  mining)

13
Some examples of previous data mining work
research at BA

• 1989/90 - looking at neural nets for forecasting
  bookings and identifying special events.
• 1992 - Predicting no-shows (use of neural
  networks to predict, from the booking attributes,
  the number of people who have made a booking but
  do not check in for the flight)
• 1996/7 - Engine condition monitoring
  feedforward neural network and self-organising
  maps used for novelty detection to spot
  abnormal engine condition states and monitor
  trends (in addition to use of sophisticated
  conventional physical and data analysis
  techniques)
• 1996/7 - Neural network for estimation of work
  requirement for major engineering overhauls of
  aircraft.
• 1999 - Forecasting pilot training requirements
• Patterns in takeup of electronic ticketing and
  check-in.
• Effect of disruption and compensation on customer
  loyalty.

14
More recent data mining on Marketing data

• 1999 Decision trees used in customer value
  prediction (PCV).
• 1999 Self-organising maps used in Travel
  Service CRM.
• 2000/1 attrition models segmentation for
  Executive Club (frequent flyer) data.
• 2001 September 11th L
• 2002/3 Analysis of on-board customer survey
  data (global performance monitor)
• In-flight retail. Analysis of who buys what,
  on-board.
• 2004 Executive Club travel pattern segmentation

15
British Airways Executive Club

• Frequent flyer scheme (but also includes
  partner organisations e.g. car hire, hotels,
  credit cards, foreign exchange etc. )
• BA Miles can redeem these for free flights (and
  other things)
• Tier points count towards promotion from Blue
  to Silver and Gold Tiers.
• Silver and Gold members are eligible for
  benefits such as lounge access, preferential
  check-in etc.
• Data kept on flights booked and travelled and
  miles earnt with partner companies.

16
BA Data Mining Examples (1) some Executive
Club models

• UKUS attrition models (who is reducing their
  flying ?)
• Behavioural segmentation (patterns of travel,
  e.g. occasional longhaul premium, regular
  shorthaul commuter, etc. )
• Commercial partners usage segmentation (car
  hire, hotels, financial cards, etc. )
• Segment management (specific business
  propositions for top segment frequent premium
  stars)
• New joiners model (predict value from customer
  attributes and patterns)

• Techniques used .
• Cluster analysis
• Self-organising maps
• Logistic regression
• Classification Regression Trees
• Software used SAS, Enterprise Miner

17
BA Examples (2) Travel Service

• Leisure travel scheme whereby customer gave
  details of favourite destinations, activities,
  plus time of year and budget, and BA sent details
  of tailored offers.
• (now discontinued)
• Self-organising maps (SOMs) used to cluster
  database and select groups for matching. (1998/9)
• The diagram shows 16 customer segments (the green
  squares within each box) viewed on 20 different
  variables, to show booking, tavel and destination
  patterns. The area of the small squares shows
  magnitude.

Note this chart was not generated using
Enterprise Miner, though SAS was used in some of
the analysis
18
Travel Service some customer clusters
Cluster as of total
of cluster who have made a booking

• Sun seekers who want all components included
  (13.5,2.8)
• Blue tier exec club members with city breaks
  (1.2,4.3)
• Busy people who get away when can are not price
  sensitive (2.3,8.2)
• Adventure Trail Finders (2.6,3.2)
• Longhaul package type person (0.4,2.0)
• Type of person who just ticks all offers box
  (2.3,4.8)
• Retired Southerners looking for Australia?
  (9.7,2.3)
• Diners shoppers (or who like to think they do)
  (3.2,1.3)
• The bookers who have not provided us with all
  info (8.5,20.5)

19
BA Example (3) In-flight retail
This example shows a cluster with preferences
for jewellery / watches and experience packages.

20
BA Example (3) In-flight retail
A (small) cluster of shopaholics!
Variables listed in order of Difference of this
cluster from overall mean
Blue squares show average across all clusters
Purple squares show normalised mean For this
specific cluster
This example shows the use of a SOM in Enterprise
Miner to identify a small cluster of customers
with very high value purchase patterns
21
Data mining and Complexity
22
Commercial complexity and the airline business

• An airline is a very complex business
• In this presentation, we are just considering
  commercial complexity, that is in the selling
  process.
• Operational complexity is very important to us
  too, but is another subject!
• Some of this complexity is there for good
  reasons,
• e.g. good commercial sense, supply and demand
  economics,
• or for the convenience of the customer
• However, some is historic or dictated by third
  parties,
• or is not serving its purpose.
• One area in which British Airways is interested
  at the moment is,
• How should we measure commercial complexity?
• and how effective are the many different ways
  of selling tickets ?
• and does the complexity matter?

23
Using data mining methods to measure complexity

• How can we use data mining methods to try to
  measure complexity ?
• Data mining techniques are good at adjusting
  their parameters to represent the level of
  complexity in the data (number of dimensions, or
  interactions, or different things going on).
• Machine learning theory makes use of measures
  such as entropy (information), minimum
  description length, VC-dimension, etc.
• Take a decision tree, for example.
• It will continue to partition the data set
  recursively until it can no longer find
  significant splits.
• So, in the right circumstances, a decision tree
  can show which parts of the business are simple
  and which are complex. If we set the target
  variable to be a measure of revenue or
  profitability, we can also see how the complexity
  relates to yield, in a crude sort of way. (Note I
  have taken no account of cost here for the
  moment)

24
Decision tree tree-ring diagram
representationin Enterprise Miner

The outside of the diagram represents the lowest
levels of subdivision
The colours are used to represent the mean value
of the target variable within a group (darker
colour higher value)
tree ring diagram
The centre of the diagram represents the root
of the tree, i.e. the whole data set
An alternative way of viewing different levels
of structure in different parts of the tree
25
Using a decision tree to measure commercial
complexity

• In this example, a decision tree is used to show
  aspects of commercial complexity.
• The input data was for a London-Edinburgh flight
  on a single day.
• The input variables represent
• different ticket classes,
• channels (agents, call centres, website and so
  on),
• corporate deals,
• special fares,
• different currencies, etc.

Highly fragmented areas such as here represent
many different rates and specific circumstances.
tree ring diagram
Large simple areas such as this one for
undiscounted club tickets represent low
complexity in this sense. There may be other
kinds of complexity e.g. due to ticket or booking
changes.
26
Data mining and complexity Output of process
Profitability
Complexity
27
Data mining and complexity Caveats

• Data representation. Need to allow enough detail
  not to average out the effect we are trying to
  measure, but need to limit it so we get a
  workable model.
• Choosing a target variable. There may be elements
  of complexity which we are interested in, but
  which do not cause a change in the target
  variable, and vice versa.
• Problem with decision tree if the output is a
  straightforward linear function of the input (it
  will try to model it as step-functions).
• This analysis does not tell us necessarily
  whether the complexity we are looking at is good
  or bad, but gives us places to start looking.
• Much of the time, of course, we are not bothered
  about the number of combinations, because the
  different variables are decoupled.
• There may of course be good reasons for retaining
  the complexity !

28
Using a self-organising map to look at patterns
in ticket sale data
revenue
Web bookings
BA ticketed
E-tickets
Each of the 8 diagrams shows the value of a
specific variable for each of the 100 (10x10)
clusters. Frequency (number of passengers in
each cluster ) is not shown but should be
examined alongside these charts.
Currency GB
Corporate dealt
Multi-leg flights
Fully flexible tickets
The input data were for a London-Edinburgh flight
on a single day. The input variables represent
different ticket classes, channels (agents,
call centres, website and so on), corporate
deals, special fares, different currencies, etc.
A subset of 8 variables is shown here.
Key red high value or proportion, yellow low
29
Using a self-organising map to measure complexity

• Here, there is no target variable
• We are using the SOM to find structure in the
  data
• We could find the size of SOM needed to model the
  envelope which covers the data, and use that
  size as a direct measure of complexity, in the
  same way as we could use the size of a decision
  tree to measure this dimension.
• We need to be careful how we represent the data,
  that we are not just measuring artefacts of the
  representation.
• In the SOM, we can also visually overlay the
  patterns of different variables as a way of
  visualising correlations and fine structure.
• In the example shown, some findings are
  immediately evident, e.g...
• Most non-e-tickets on these flights were
  multi-leg flights (i.e. transfers) ticketed by
  other airlines, in foreign currencies.
• Web bookings, though accounting for a relatively
  large number of transactions, show up as low
  complexity.

30
So what? how is this measuring complexity?
We gave the SOM the space to form 100 clusters.
It actually populated 90 of them. Part of the
objective is to find out how much of the
business falls into simple and complex
categories. 18 of the passengers fell into one
cluster, That is, web bookings sold by BA in
the UK, blue executive club tier,
non-flexible ticket classes. However over 25
of the clusters had less than 5 passengers in.
31
Successful data mining
32
Some possible difficulties with Data Mining

• Expectations either too high or too low.
• Myths of data mining.
• Loose use of the term data mining
• Asking the wrong questions.
• Wrong positioning in the company.
• Does not fit standard approach.
• Data driven and iterative, so cannot necessarily
  plan in advance.
• Can get swamped by results / options / model
  versions.
• Danger of stating the obvious or not being
  believed.
• Data quality, data definition and business
  understanding issues.

33
Successful Data Mining Spreading understanding

• It is often difficult initially to communicate
  the place, nature and benefits of data mining,
  even to experienced statisticians, operational
  researchers, or artificial intelligence people,
  but once people get it they are enthusiastic.
• Engineers, Revenue Management and Marketing
  analysts are often the closest to the ideas.
• Often difficult to convey complex results in
  meaningful business terms.
• There is sometimes a need to convince upstream
  processes of the value of collecting, cleaning
  and maintaining data for data mining.

34
Successful Data Mining asking the right
questions

• Much of the skill in data mining is in helping
  the client to articulate the question that they
  really want to answer and decide if it is really
  a data mining question.
• E.g.

35
Successful Data Mining the right mix of
knowledge

• With todays computing tools, it is easy to get
  results from a data mining exercise.
• The difficult part is interpreting these,
  sense-checking them, and articulating a simple
  message from what is often a complex picture.
• Mix of technical and business knowledge
  essential.
• Close involvement of clients and business domain
  experts.

36
Successful Data Mining the right tools and
infrastructure

• Algorithms
• Robustness and clarity often most important
• Build vs buy decisions
• What BA is looking for in a data mining tool
• Set of algorithms with good coverage of problem
  types.
• Scalability
• Ease of implementation of models / generated code
• Integration with data sources openness
• Compatibility with other software and company
  policy
• Justifiable value

37
Any questions ?
Simon Cumming British Airways PLC Waterside
(HDA3) PO box 365, Harmondsworth Middlesex UB7
0GB Tel / fax [phone] Email
simon.n.cumming_at_britishairways.com
