History of cosmic web of galaxies

1

History of cosmic web of galaxies

• Agnieszka Pollo
• Laboratoire d'Astrophysique de Marseille (LAM)
• Marseille, France

2
Short History of the Universe (one of)

• Planck Era 10(-43) s. 10(-33) cm regions
  homogeneous and isotropic. izotropowe,
  T10(32)K.
• Inflation. 10(-35) s after BB, T 10(27)
  10(28)K, fast expansion.
• Inflation ends. 10(-33 s), T 10(27)
  10(28)K. Homogeneous regions from Planck era
  have grown to 100 cm (gt 10(35) times). Tiny
  nearly gaussian density fluctuations.

3
Short History of the Universe

• Bariogenesis. 100,000,001 protons per 100,000,000
  antiprotons (and 100,000,000 photons).
• Till 100 s after BB Universe grows and cools
  down, T 109K. Protons anihillate with
  antiprotons, later e- and e. H i He are
  created.

4
Krótka historia Wszechswiata

• One month after BB processes which transform
  radiation field into black body radiation become
  slower than the velocity of expansion of the
  Universe from now on there is a chance of some
  informations being preserved in CMB 56 000 years
  after BB matter density radiation density. T
  9000 K. Inhomogeneities of (dark) matter start to
  grow

5
Short history of the Universe

• 380 000 after BB protons and electrons make
  neutral H. T3000K. The Universe becomes
  transparent - CMB may travel freely (last
  scattering surface). Normal (barionic) matter
  starts to accumulate on the dark matter
  overdensities
• 100-200 mln years after BB first stars shine and
  re-ionize the Universe. First supernovae explode.
  Galaxies and clusters form.
• 4,6 bln years ago Sun shines.
• Today 13.7 bln years after BB. T2.725 K.

6
After recombination (WMAP 3-years temperature map)
7
Large-scale structure in the local (zlt0.2)
Universe galaxies (Colless, Maddox, Peacock et
al.)
8
The Large Scale Structure of the Universe

• Gravitational instability theory
• Density fluctuations (of dark matter) after
  inflation, Gaussian (?) distribution
• Matter gathers around these
• Galaxies, clusters, LSS form
• The smaller scale the more non-linear evolution
• Tests of the model
• Statistics
• Simulations

9
From the observational side...

• The main source of our knowledge about the LSS of
  the Universe are catalogs of galaxies (2D
  positions only and 3D redshift surveys)

10
Redshift surveys may allow to investigate...

• The history of formation and evolution of
  galaxies
• Evolution of the LSS of the Universe and what
  physical processes may determine it in different
  epochs and timescales
• Formation and evolution of different classes of
  objects (e.g. AGNs)
• Formation and evolution of clusters

11
Most of great calalogs today only local
Universe

• Local Universe a few big surveys, like
• SDSS
• 2dF
• gt 1M galaktyk do z 0.3
• Distribution and properties relatively easy to
  examine
• BUT no evolution

12

13
Which means practical problems

• Few objects (until recently not more than a
  few1000 for 0.5ltzlt5)
• Small volumes (-gtbig cosmic variance)
• Different selection criteria for different
  measurements and related biases how to compare?
  How to make a joint analysis?

14
(No Transcript)
15
Structure evolution we want to see the whole
movie, not only the last slide!
16
Recent deep galaxy surveys

• Goalç to measure redshifts of gt 100 000 galaxies,
  to analyse history of LSS and galaxies themselves
• VVDS
• Deep-2
• ostatnio COSMOS

17
(No Transcript)
18
(No Transcript)
19
The origins build a redshift machine for the ESO
VLT targeted to deep, high-surface density galaxy
samples

• 1995 First ideas WFISNIRMOS
• 1996 Feasibility Study
• 1997 VIMOSNIRMOS contract
• VIisible Multi -Object Spectrograph
• Near InfraRed Multi -Object Spectrograph

20
Whos Who in the the
Consortium

• Six main nodes Marseille, Bologna,
  Haute-Provence, Milan, Naples, Toulouse
• PIs O. Le Fevre G.Vettolani
• co-Is D. Maccagni (Milano), J.P. Picat
  (Toulouse), D. Mancini (Naples)
• Science Advisory Committee
• 50 people involved in the Hardware/Software
  Team
• 90 people involved in the Science Team for the
  survey preparation and analysis
• See web page, www.oamp.fr/virmos

21

• Science drive the VIMOS-VLT Deep Survey (VVDS)
• 50 VIMOS guaranteed nights over 3 years on
  ESO-VLT UT3
• 100,000 redshifts to IABlt22 over an area of 16
  sq.deg., 0ltzlt1.3 in 5 fields
• 50,000 redshifts to 22ltIABlt24 over an area of
  1.5 sq.deg., 0ltzlt5
• 1000 redshifts to IAB26 over a 1x1 sq.arcmin
  area using a Integral Field Spectroscopy unit
  (6400 fibres)
• Preparatory IMAGING
• UBVRIJK photometric surveys at CFHT, ESO, CTIO
• RADIO (VLA_at_1.4GHz, 80 mJy) X-ray (XMM, 1014
  erg s-1 cm-2 for extended sources) coverage of
  the F02 field (deep 1 sq.deg. area at RA02h)
• X-ray (XMM) imaging to fx 10-15 erg s-1 cm-2
  over F02

22
VIMOS/NIRMOS layout
VLT Nasmith focus flattened separately into 4
channels, fed into 4 CCD cameras (7x8 arcmin
field of view each)
23
A redshift machine gt 500 spectra in one shot
FOV 4x56 sq arcmin multiplexing 800 spectral
resolution 200 -5000 IFU 1'x 1', 6400 fibres
24
(No Transcript)
25
VVDS and structure evolution

• 2-point correlation function in redshift slices
• Clustering per color, luminosity, spectral types
• Bias evolution
• Clustering of particular types of objects (EROS,
  starforming galaxies) as compared to general
  population
• Galaxy mergers how many close pairs in
  different epochs?
• redshift-space CF distortions -gt small-scale
  galaxy dynamics
• Clusters density Xray (XMM) and optical
  (multi-colour, I-K, matched filter, photo-z,)
• and many more...

26
(No Transcript)
27
First Epoch VVDS Data

• 11564 spectra from 17.5ltIABlt24, fields 0226-04
  and CDFS, area 0.61 sq.deg.
• 10518 galaxies with measured z, 8869 with
  confidence level gt80
• 836 stars
• 85 AGNs
• 125 unidentified objects
• Field coverage 25 - 30

28
First epoch VVDS-Deep survey VVDS-02 field
29
First VVDS data

• 0ltzlt5
• 1065 galaxies zgt1.4
• Successful measurements on the redshift desert ,
  i.e. 1.5ltzlt2.2
• Problems in 2.2ltzlt2.7 range (because of the
  filter coverage)

30
Distribution of secure redshifts (median 0.70)
31
(No Transcript)
32
(No Transcript)
33
(No Transcript)
34
2-point correlation function

• Definition probability above random that we
  find a pair of galaxies at a certain distance
  from each other (spatial, angular)
• In practice different estimators, e.g.
  Landy-Szalay
• Problems different densities of different parts
  of the fields because of different number of
  observation runs, bright stars, non-random choice
  of objects for spectroscopy

35
(No Transcript)
36
Measuring the correlation function
37
(No Transcript)
38
(No Transcript)
39
(No Transcript)
40
Biases removal for the redshift-space correlation
function
41
(No Transcript)
42
Biases removal for the 2D redshift space
correlation function
43
Biases removal for the projected (real space)
correlation function
44
Evolution of the 2-point correlation function
from the first-epoch VVDS data
45
Evolution of a comoving correlation length
46
Comparison with DEEP-2
(astro-h/0409135)
47
What theory says? Weinberg at al., 2004, LCDM
simulations clustering history of galaxies and
DM differs dramatically
48
Similar informations may be extracted directly
from PDF

49
(No Transcript)
50
Red (old) galaxies and blue (recently star
forming) galaxies

• Now it is well known that red/early type galaxies
  (elipticals, irregulars) are more clustered than
  blue/late type (spiral) ones
• How did it evolve? When did they segregate?
• When did galaxy types appear?
• Meneux et al., 2006, Cucciati et al. 2006

51
Correlation length for different galaxy types and
colors
52
(No Transcript)
53
CF properties vs absolute luminosities

• w_p(r_p) in different luminosity ranges for small
  and large z
• Correlation length r_0
• slope gamma
• Non power-law fit!
• Different relative bias at different scales

54
w_p in luminosity ranges

• VVDS-02, M_B
• 2 wide ranges corresponding to 3.5 bld years,
  medians z0.4 and z0.9
• 7 luminosity ranges in each

55
w_p(r_p) and the best (r_0, gamma)
56
w_p(r_p) power-law fit
57
r_0 VVDS vs SDSS and 2dF
58
gamma VVDS vs SDSS i 2dF
59
Relative bias at 1 Mpc scale
60
No power law Argument for Halo Occupation
Distribution Models...
61
...non-linear relative relative bias(with
rescpect to gal L)?
62
Summary structure evolution in VVDS

• General populationç correlation length almost
  constant between z0.5 and z2, in a survey
  where the only selection criterion is luminosity
  (IABlt24)
• This effects may be understood as a
  superposition of the evolution of structure
  itself,evolution of bias and different dependence
  of clustering on luminosity
• Generaal population in a good agreement with
  hydrodynamical simulations in a model with CMB
  and big cosmological constant
• Galaxies of early spectral types (eliptical and
  early spirals) are more clustered than late
  spirals and irregulars in all epochs
• Red galaxies more correlated than blue ones
• But a tendency to reverse this relation at
  z1.5?

63
Summary structure evolution in VVDS

• For different absolute luminosities
• r_0 and gamma rise for LgtL for large z
• non power law fit of CF z -gt argument in favor
  of HOD models?
• Scale-dependent bias?
• Conclusions
• In the z0.9 Universe bright galaxies more
  willingly were closer to other bright galaxies
  than today
• What happened to them? Did they merge? Did they
  get fainter?
• Bias not only evolving, but also non-linear?
• We have to develop models and theory

64
First epoch VVDS results (selected)

• Survey description (Le Fevre et al. 2005)
• Two-point correlation function in z slices (Le
  Fevre et al., 2005, Pollo et al., 2005, A A)
• Evolution of LF and B luminosity density (Ilbert
  et al. 2005, Tresse et al. 2005, Zucca et al.
  2005)
• Combined GALEX-VVDS evolution of UV LF and UV
  luminosity density (Arnouts et al. 2005,
  Schiminovich et al 2005)
• Clustering of color-selected classes (Meneux et
  al, 2006. AA, in press)
• Clustering as a function of luminosity (Pollo et
  al., 2006a, AA, in press, Pollo et al., 2006b,
  in prep.)
• Evolution of bias (Marinoni et al., 2005)
• Properties of K-selected galaxies in the
  VVDS-Deep survey (Iovino et al., AA, in press)

65

• Effective in isolating galaxies around z3
  (U-dropouts) and z4 (B-dropouts)
• Pioneered by Steidel Hamilton (1992)
• Spectroscopic confirmation only possible thanks
  to the new generation of 10m-telescope
  availability (Keck)
• Selects strongly star-forming galaxies with
  significant Lyman break

66
(No Transcript)
67
(No Transcript)
68

• Correlation length 3-5 h-1 Mpc, i.e. comparable
  to todays normal galaxies!

69
Lyman-break galaxies are strongly star-forming
objects, plausibly progenitors of todays
luminous cluster galaxies. Clearly, their
clustering is not representative of general
structure at z3. They are an illustrative
example of a highly biased population of LSS
tracers. Similar examples are provided by very
red galaxies selected using near-infrared bands
around z1 (R-K) and zgt2 (J-K) (e.g. works by
Cimatti et al. and Van Dokkum et al.). ? Need
for larger redshift surveys looking at the global
galaxy population. Two such projects underway
the DEEP2 survey at Keck (Davis et al) and the
VIMOS-VLT Deep Survey (VVDS)
70
(No Transcript)
71
Two-point correlation function from VVDS
first-epoch data per galaxy morphological types
example for one z slice
72
(No Transcript)
73
What we expect to find
74
2dFGRS Maximum likelihood fit of redshift-space
distortions
A more recent analysis of the 100,000 redshift
public release, with careful treatment of window
function aliases and error correlations finds
?0.16 (Tegmark, Hamilton Xu, 2002,
astro-ph/0111575)
75
(No Transcript)
76
(No Transcript)
77
The VIRMOS survey and the evolution of structure

• Two-point correlation function in z slices
• Clustering of color-selected classes
• Clustering of radio-loud vs. normal population
• Evolution of bias (i.e. the way light traces
  mass)
• Clustering of special classes (e.g. Extremely
  Red Objects, strongly star-forming galaxies) vs.
  general population
• Merging history how many close pairs at
  different redshifts?
• Small-scale dynamics from redshift-space
  distortions
• Evolution of number density of galaxy clusters
  X-ray selection (XMM survey over 2hrs field) vs.
  optical selection (multi-colour, I-K, matched
  filter, photo-z,)
• and much more

78
(No Transcript)
79
(No Transcript)
80
(No Transcript)
81
(No Transcript)
82
(No Transcript)
83
(No Transcript)
84
(No Transcript)
85
(No Transcript)
86
(No Transcript)
87
(No Transcript)
88
(No Transcript)
89
(No Transcript)
90
(No Transcript)
91
(No Transcript)
92
(No Transcript)
93
(No Transcript)
94

• Effective in isolating galaxies around z3
  (U-dropouts) and z4 (B-dropouts)
• Pioneered by Steidel Hamilton (1992)
• Spectroscopic confirmation only possible thanks
  to the new generation of 10m-telescope
  availability (Keck)
• Selects strongly star-forming galaxies with
  significant Lyman break

95

• Correlation length 3-5 h-1 Mpc, i.e. comparable
  to todays normal galaxies!

96
Lyman-break galaxies are strongly star-forming
objects, plausibly progenitors of todays
luminous cluster galaxies. Clearly, their
clustering is not representative of general
structure at z3. They are an illustrative
example of a highly biased population of LSS
tracers. Similar examples are provided by very
red galaxies selected using near-infrared bands
around z1 (R-K) and zgt2 (J-K) (e.g. works by
Cimatti et al. and Van Dokkum et al.). ? Need
for larger redshift surveys looking at the global
galaxy population. Two such projects underway
the DEEP2 survey at Keck (Davis et al) and the
VIMOS-VLT Deep Survey (VVDS)
97
(No Transcript)
98
(No Transcript)
99
(No Transcript)
